IPGARD SDVN-42-X User manual

12VDC3.0A
DVI OUT 1 DVI OUT 2 DVI OUT 3 DVI OUT 4 DVI IN 1 DVI IN 2 DVI IN 3 DVI IN 4
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio Audio
K/M
CAC
OUT-1 OUT-2 OUT-3 OUT-4IN-4IN-3IN-2IN-1
SELECT
SOURCE
USB
SELECTOR
CONSOLE 1
SELECT
SOURCE
USB
SELECTOR
CONSOLE 2
SELECT
SOURCE
USB
SELECTOR
CONSOLE 3
SELECT
SOURCE
USB
SELECTOR
CONSOLE 4
SDVN-44-X
Document ID: USM-0S0-3M1 Revision: 2.10
Made in U.S.A. www.iPGARD.com 1-800-284-2131
USER MANUAL
Advanced 4/8-Port DVI-D Matrix KVM
SDVN-42-X 4-Port Secure DVI-D Matrix KVM with Audio and CAC Support (2 Users)
SDVN-44-X 4-Port Secure DVI-D Matrix KVM with Audio and CAC Support (4 Users)
SDVN-82-X 8-Port Secure DVI-D Matrix KVM with Audio and CAC Support (2 Users)
SDVN-84-X 8-Port Secure DVI-D Matrix KVM with Audio and CAC Support (4 Users)
Release Date: July 3rd, 2018

TABLE OF CONTENTS
3
4
4
4
6
9
9
10
10
11
12
12
12
13
TECHNICAL SPECIFICATIONS___________________________________________________________
WHAT’S IN THE BOX?_________________________________________________________________
SECURITY FEATURES_________________________________________________________________
SDVN FRONT AND REAR______________________________________________________________
INSTALLATION_______________________________________________________________________
CAC INSTALLATION: COMMON ACCESS CARD, SMART CARD READER__________________________
CAC PORT CONFIGURATION____________________________________________________________
AUDITING: Dumping the Event Log via User Menu Options___________________________________
RESET: Restore Factory Default_________________________________________________________
LED’s BEHAVIOR_____________________________________________________________________
SYSTEM OPERATION__________________________________________________________________
TROUBLESHOOTING__________________________________________________________________
TECHNICAL SUPPORT_________________________________________________________________
LIMITED WARRANTY STATEMENT_______________________________________________________
Advanced 4/8 DVI-D Secure KVM Matrix Switch 2

TECHNICAL SPECIFICATIONS
Advanced 4/8 DVI-D Secure KVM Matrix Switch 3
VIDEO
Format DVI-I Dual Link
Host Interface SDVN-42-X/SDVN-44-X (4) DVI-I 29-pin (female)/DVI-D
SDVN-82-X/SDVN-84-X (8) DVI-I 29-pin (female)/DVI-D
User Console
Interface
SDVN-42-X/SDVN-82-X (2) DVI-I 29-pin (female)/DVI-D
SDVN-44-X/SDVN-84-X (4) DVI-I 29-pin (female)/DVI-D
Max Resolution 2560 x 1600 @ 60Hz; 3840x2160 @ 30Hz
DDC 5 volts p-p (TTL)
Input Equalization Automatic
Input Cable Length Up to 20 ft.
Output Cable Length Up to 20 ft.
USB
Signal Type USB 1.1 and 1.0 Keyboard and Mouse only. USB 2.0 for CAC connection.
Type A to B SDVN-42-X/SDVN-44-X (8)
SDVN-82-X/SDVN-84-X (16)
User Console Interface (2/4) USB Type-A for keyboard and mouse connection only
(2/4) USB Type-A for CAC connection (P models only)
AUDIO
Input (4/8) Connector Stereo 3.5mm Female
Output (2/4) Connector Stereo 3.5mm Female
POWER
Power Requirements 12V DC, 2A (minimum) power adapter with center-pin positive polarity. Quad head models require a 12V
DC 3A (minimum) power adapter with center-pin positive polarity.
ENVIRONMENT
Operating Temp 32° to 104° F (0° to 40° C)
Storage Temp -4° to 140° F (-20° to 60° C)
Humidity 0-80% RH, non-condensing
CERTIFICATIONS
Security Accreditation Common Criteria Validated To NIAP, Protection Prole PSS Ver. 3.0
OTHER
Emulation USB 1.1 and USB 2.0 Compatible
Control Front Panel Buttons

12VDC3.0A
DVI OUT 1 DVI OUT 2 DVI IN 1 DVI IN 2 DVI IN 3 DVI IN 4
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
K/M
CAC
Audio
K/M
CAC
Audio
OUT-1 OUT-2IN-4IN-3IN-2IN-1
SELECT
SOURCE
USB
SELECTOR
CONSOLE 1
SELECT
SOURCE
USB
SELECTOR
CONSOLE 2
SDVN-42-X
12VDC3.0A
DVI OUT 1 DVI OUT 2 DVI IN 1 DVI IN 2 DVI IN 3 DVI IN 4
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
K/M
CAC
Audio
K/M
CAC
Audio
OUT-1 OUT-2IN-4IN-3IN-2IN-1
SELECT
SOURCE
USB
SELECTOR
CONSOLE 1
SELECT
SOURCE
USB
SELECTOR
CONSOLE 2
SDVN-42-X
WHAT’S IN THE BOX?
SECURITY FEATURES
4
Anti-Tamper Switches
Each model is equipped with internal Anti-Tamper switches, which sense attempts to open the device
enclosure. Once the system identies such an attempt, all the front panel LED’s will ash rapidly and the
unit will become useless by shutting off connection with all attached PCs and peripherals disabling any
functionality.
Tamper-Evident Seal
The enclosure of the unit is protected with a tamper-evident seal to provide a visual evidence if the unit has
been opened.
Protected Firmware
The controller of the unit has a special protection feature that prevents reprogramming or reading the
rmware.
High Isolation on USB Channels
Opto-isolators are used in the unit to keep USB data paths electrically isolated from each other, providing
high isolation and preventing data leakage between ports.
Secure EDID Emulation
The unit prevents unwanted and unsecure data to be transmitted through the DDC lines by means of
secure EDID learning and emulation.
SDVN Unit 4/8-Port Single-Head Secure DVI-D Secure KVM Matrix Switch
PS12VDC2A or
PS12VDC3A
12V DC, 2A (minimum) power adapter with center-pin positive polarity. Quad head
models require a 12V DC 3A (minimum) power adapter with center-pin positive polarity.
User Manual
Figure 4-1: SDVN-42-X Front panel
Figure 4-2: SDVN-42-X Rear panel
Advanced 4/8 DVI-D Secure KVM Matrix Switch

12VDC3.0A
DVI OUT 1 DVI OUT 2 DVI OUT 3 DVI OUT 4 DVI IN 1 DVI IN 2 DVI IN 3 DVI IN 4
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio Audio
K/M
CAC
OUT-1 OUT-2 OUT-3 OUT-4IN-4IN-3IN-2IN-1
SELECT
SOURCE
USB
SELECTOR
CONSOLE 1
SELECT
SOURCE
USB
SELECTOR
CONSOLE 2
SELECT
SOURCE
USB
SELECTOR
CONSOLE 3
SELECT
SOURCE
USB
SELECTOR
CONSOLE 4
SDVN-44-X
12VDC3.0A
DVI OUT 1 DVI OUT 2 DVI OUT 3 DVI OUT 4 DVI IN 1 DVI IN 2 DVI IN 3 DVI IN 4
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio Audio
K/M
CAC
OUT-1 OUT-2 OUT-3 OUT-4IN-4IN-3IN-2IN-1
SELECT
SOURCE
USB
SELECTOR
CONSOLE 1
SELECT
SOURCE
USB
SELECTOR
CONSOLE 2
SELECT
SOURCE
USB
SELECTOR
CONSOLE 3
SELECT
SOURCE
USB
SELECTOR
CONSOLE 4
SDVN-44-X
5
Figure 5-1: SDVN-44-X Front panel
Figure 5-2: SDVN-44-X Rear panel
SELECT
SOURCE
USB
SELECTOR
CONSOLE 1
SELECT
SOURCE
USB
SELECTOR
CONSOLE 2
SDVN-82-X
12VDC3.0A
DVI-D OUT 1 DVI-D OUT 2
DVI-D IN 5 DVI-D IN 6 DVI-D IN 7 DVI-D IN 8
DVI-D IN 1 DVI-D IN 2 DVI-D IN 3 DVI-D IN 4
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
K/M
CAC
Audio
K/M
CAC
Audio
IN-8 OUT-1 OUT-2IN-7IN-6IN-5IN-4IN-3IN-2IN-1
K/M
CAC
Audio Audio
K/M
CAC
OUT-3 OUT-4
SELECT
SOURCE
USB
SELECTOR
CONSOLE 1
SELECT
SOURCE
USB
SELECTOR
CONSOLE 2
SDVN-82-X
12VDC3.0A
DVI-D OUT 1 DVI-D OUT 2
DVI-D IN 5 DVI-D IN 6 DVI-D IN 7 DVI-D IN 8
DVI-D IN 1 DVI-D IN 2 DVI-D IN 3 DVI-D IN 4
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
K/M
CAC
Audio
K/M
CAC
Audio
IN-8 OUT-1 OUT-2IN-7IN-6IN-5IN-4IN-3IN-2IN-1
K/M
CAC
Audio Audio
K/M
CAC
OUT-3 OUT-4
SELECT
SOURCE
USB
SELECTOR
CONSOLE 1
SELECT
SOURCE
USB
SELECTOR
CONSOLE 2
SELECT
SOURCE
USB
SELECTOR
CONSOLE 3
SELECT
SOURCE
USB
SELECTOR
CONSOLE 4
SDVN-84-X
12VDC3.0A
DVI-D OUT 1 DVI-D OUT 2
DVI-D IN 5 DVI-D IN 6 DVI-D IN 7 DVI-D IN 8
DVI-D IN 1 DVI-D IN 2 DVI-D IN 3 DVI-D IN 4
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
K/M
CAC
Audio
K/M
CAC
Audio
IN-8 OUT-1 OUT-2IN-7IN-6IN-5IN-4IN-3IN-2IN-1
DVI-D OUT 3 DVI-D OUT 4
K/M
CAC
Audio Audio
K/M
CAC
OUT-3 OUT-4
SELECT
SOURCE
USB
SELECTOR
CONSOLE 1
SELECT
SOURCE
USB
SELECTOR
CONSOLE 2
SELECT
SOURCE
USB
SELECTOR
CONSOLE 3
SELECT
SOURCE
USB
SELECTOR
CONSOLE 4
SDVN-84-X
12VDC3.0A
DVI-D OUT 1 DVI-D OUT 2
DVI-D IN 5 DVI-D IN 6 DVI-D IN 7 DVI-D IN 8
DVI-D IN 1 DVI-D IN 2 DVI-D IN 3 DVI-D IN 4
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
Audio
K/M
CAC
K/M
CAC
Audio
K/M
CAC
Audio
IN-8 OUT-1 OUT-2IN-7IN-6IN-5IN-4IN-3IN-2IN-1
DVI-D OUT 3 DVI-D OUT 4
K/M
CAC
Audio Audio
K/M
CAC
OUT-3 OUT-4
Figure 5-3: SDVN-82-X Front panel
Figure 5-5: SDVN-84-X Front panel
Figure 5-4: SDVN-82-X Rear panel
Figure 5-6: SDVN-84-X Rear panel
Advanced 4/8 DVI-D Secure KVM Matrix Switch

INSTALLATION
6
SYSTEM REQUIREMENTS
*TOE-P and -X models only Table 6-1
Console Port Authorized Devices
Keyboard
Wired keyboard and keypad without internal USB hub or composite device
functions, unless the connected device has at least one endpoint which is a
keyboard or mouse HID class, KVM/KM extender;
Audio out Analog amplied speakers, Analog headphones, Digital audio appliance.
Mouse/Pointing Device Any wired mouse or trackball without internal USB hub or composite device
functions, Touch-screen, Multi-touch or digitizer, KVM/KM extender.
User Authentication
Device Smart-card reader, PIV/CAC reader, Token or Biometric reader*
1. iPGARD Secure PSS is compatible with standard personal/portable computers, servers or thin-clients,
running operating systems such as Windows or Linux.
2. The peripheral devices that are supported by the KVM are listed in the following table:
Advanced 4/8 DVI-D Secure KVM Matrix Switch

AUDIO IN
CAC IN
DVI-D IN
USB IN
Input Connectivity
Output Connectivity
AUDIO OUT
CAC OUT
DVI-D OUT
USB OUT
SDVN-44-X
SELECT
SOURCE
USB
SELECTOR
CONSOLE 1
SELECT
SOURCE
USB
SELECTOR
CONSOLE 2
SELECT
SOURCE
USB
SELECTOR
CONSOLE 3
SELECT
SOURCE
USB
SELECTOR
CONSOLE 4
SDVN-44-X
INSTALLATION (Continued)
Single-Head Units:
1. Ensure that power is turned off or disconnected from the unit and the computers.
2. Use a DVI cable to connect the DVI output port from each computer to the corresponding DVI-D
IN ports of the unit.
3. Use a USB cable (Type-A to Type-B) to connect a USB port on each computer to the respective
USB ports of the unit.
4. Optionally connect a stereo audio cable (3.5mm to 3.5mm) to connect the audio output of the
computers to the AUDIO IN ports of the unit.
5. Connect monitors to the DVI-D OUT console port of the unit using a DVI cables.
6. Connect a USB keyboard and mouse in the two USB console ports.
7. Optionally connect stereo speakers to the AUDIO OUT port of the unit.
8. Optionally connect CAC (COMMON ACCESS CARD, SMART CARD READER) to the CAC port in
the user console interface.
9. Finally, power on the Secure KVM Switch by connecting a 12VDC power supply to the power
connector, and then turn on all the computers.
Figure 7-1: SDVN-44-X
Note: The computer connected to port 1 will always be selected by default after power up.
Note: You can connect up to 8 computers to the 8 port KVM and up to 4 computers to the 4 port KVM.
7
IMPORTANT WARNINGS - For security reasons:
• This product does not support wireless devices. Do not attempt to use a wireless keyboard or a
wireless mouse with this product.
• This product does not support keyboards with integrated USB hubs or USB ports. Only use
standard (HID) USB keyboards with this device.
• This product does not support microphone audio input or line input. Do not connect any
microphones or headsets with microphones to this device.
• Connection of authentication devices (CAC) with external power sources is prohibited.
Advanced 4/8 DVI-D Secure KVM Matrix Switch

8
Advanced 4/8 DVI-D Secure KVM Matrix Switch
INSTALLATION (Continued)
EDID Learn:
The Secure KVM Switch is designed to learn the connected monitor’s EDID upon power up. In the event of
connecting a new monitor to the Secure KVM Switch, a power recycle is required.
The Secure KVM Switch will indicate to the user the EDID learn process by ashing the front panel’s server
signal.
The monitor must be connected to the video output connector “1” located in the console space at the back
of the Secure KVM Switch during the EDID learn process.
If the read EDID from the connected monitor is identical to the current stored EDID in the Secure KVM
Switch then the EDID learn function will be skipped.

Advanced 4/8 DVI-D Secure KVM Matrix Switch
CAC (COMMON ACCESS CARD, SMART CARD READER) INSTALLATION
CAC PORT CONFIGURATION
The following steps are intended for the system administrator or IT manager only.
If you have the optional CAC ports there will be 2 ports on a 2 host ports KVM and 4 ports on a 4 host
ports KVM.
CAC connection to the computer requires a USB cable connection separate from the keyboard and mouse.
This allows the CAC to be connected independently from the keyboard and mouse. It also allows the user to
select whether CAC for a certain computer is supported or not.
1. Ensure that power is turned off or disconnected from the unit and the computer.
2. Use a USB cable (Type-A to Type-B) to connect a USB port on a computer to its respective CAC USB
ports on the KVM. Do not connect the USB cable if CAC functionality is not needed for that computer.
3. Connect a CAC (smart card reader) to the CAC port in the user console interface.
4. Power on the KVM by connecting a 12VDC power supply to the power connector, and then turn on all
the computers.
5. To disable CAC for any channel (all CAC ports are enabled as default), use the front panel buttons to
switch the KVM to the channel whose CAC mode you wish to change. Once the channel is selected, the
button LED for this specic channel should be on (CAC port enabled). Press and hold the button for 3
seconds until the button LED turns off. The CAC port is now disabled for this channel.
6. To enable CAC for any channel, use the front panel buttons to switch the KVM to the channel whose
CAC mode you wish to change. Once the channel is selected, the button LED for this specic channel
should be off (CAC port disabled). Press and hold the button for 3 seconds until the button LED turns
on. The CAC port is now enabled for this channel.
The following steps are intended for the system administrator and operators (users).
Note: Only one computer connected to port 1 is required for this operation
CAC port Conguration is an optional feature, allowing registration of any USB peripheral to operate with
the KVM. Only one peripheral can be registered and only the registered peripheral will operate with the
KVM. By default, when no peripheral is registered, the KVM will operate with any Smart Card Reader.
Congure the CAC Port via User Menu Options
1. Open the Administration and Security Management Program.
2. Using the keyboard, press the Alt key twice and type “cnfg”.
3. At this stage the mouse connected to the KVM/KM
will stop functioning.
4. Enter the default username “user” and press Enter.
5. Enter the default password “12345” and press
Enter.
6. Select option 2 from the menu on your screen and
press Enter.
7. Connect the peripheral device to be registered to
the CAC USB port in the console side of the
KVM/KM and wait until the KVM/KM is reading the
new peripheral information.
8. The KVM/KM will list the information of the
connected peripheral on the screen and buzz
3 times when registration is completed.
Figure 9-1: User Menu
9

AUDITING: Dumping the Event Log via User Menu Options
RESET: Restore Factory Defaults
The following steps are intended for the system administrator.
Note: Only one computer connected to port 1 is required for this operation
The Event Log is a detailed report of critical activities stored in the KVM or KVM memory. A comprehensive
feature list and guidance for Administration and Security Management Tools can be found in the
Administrator’s Guide available for download from: http://ipgard.com/documentation/
To view or dump the Event Log:
1. Open the Administration and Security
Management Program
2. Using the keyboard, press the Alt key twice and
type “cnfg”.
3. Enter the default admin name “admin” and press
Enter.
4. Enter the default password “12345” and press
Enter.
5. Request a Log Dump by selecting option 5 in the
menu. (Shown in Figure 10-1)
* See Administration and Security Management Tool Guidance
for detailed information.
* See Administration and Security Management Tool Guidance for detailed information.
The following steps are intended for the system administrator.
Note: Only one computer connected to port 1 is required for this operation
Restore Factory Defaults will reset all settings on the KVM to their original state
To Restore Factory Defaults via User Menu Options:
KVM mode
CAC port registration will be removed
KVM settings will be reset to factory defaults
1. Open the Administration and Security Management Program
2. Using the keyboard, press the Alt key twice and type “cnfg”
3. Enter the default admin name “admin” and press Enter.
4. Enter the default password “12345” and press Enter.
5. Select option 7 from the menu on your screen and press enter. (Menu shown in Figure 10-1)
Figure 10-1
10
Advanced 4/8 DVI-D Secure KVM Matrix Switch

11
LED’s BEHAVIOR
User Console Interface – Display LED:
User Console Interface – CAC LED:
Front Panel – Port Selection LED’s:
Front Panel – CAC Selection LED’s:
Front Panel - Port and CAC Selection LED’s:
IMPORTANT!
# Status Description
1 Off Monitor is not connected
2 On Monitor is connected
3 Flashing EDID problem – Learn EDID to x the problem
# Status Description
1 Off CAC is not connected
2 On Authorized and functional CAC is connected
3 Flashing Non-CAC peripheral is connected
# Status Description
1 Off Non-selected port
2 On Selected port
3 Flashing EDID learn in process
# Status Description
1 Off CAC port is disabled or non-selected port
2 On CAC port is enabled
3 Flashing EDID learn in process
# Status Description
1 All Flashing Connected peripheral to keyboard or mouse
console ports is rejected
If all the Front Panel LED’s
are ashing and the buzzer is
beeping, the KVM has been
TAMPERED with and all
functions are permanently
disabled. Please contact
iPGARD technical support at
suppor[email protected].
If all Front Panel LED’s are on
and not ashing, the POWER
UP SELF TEST has failed and
all functions are disabled.
Check if any of the front
panel port selection buttons
are jammed. In this case,
release the jammed button
and recycle the power. If
power up self test is still
failing, please contact iPGARD
technical support at
suppor[email protected].
EDID Learn - Front Panel LED’s:
All LED’s are turned on for 1 second. Then:
• Port 1 LED’s will ash until the end of the process.
• Port 2 LED’s will ash until the end of the process if a second video board exists (Dual-head KVM)
• Port 3 LED’s will ash until the end of the process if a third video board exists (Quad-head KVM)
• Port 4 LED’s will ash until the end of the process if a fourth video board exists (Quad-head KVM)
Advanced 4/8 DVI-D Secure KVM Matrix Switch

12
SYSTEM OPERATION
TROUBLESHOOTING
TECHNICAL SUPPORT
• Make sure that the power adapter is securely connected to the power connector of the unit.
• Check the output voltage of the power supply and make sure that the voltage value is around
12VDC.
• Replace the power supply.
• Check if all the video cables are connected properly.
• Connect the computer directly to the monitor to verify that your monitor and computer are
functioning properly.
• Restart the computers.
• Check if the keyboard is properly connected to the unit.
• Check if the USB cables connecting the unit and the computers are properly connected.
• Try connecting the USB on the computer to a different port.
• Make sure that the keyboard works when directly connected to the computer.
• Replace the keyboard.
• Check if the mouse is properly connected to the unit.
• Try connecting the USB on the computer to a different port.
• Make sure that the mouse works when directly connected to the computer.
• Replace the mouse.
• Check if all the audio cables are connected properly.
• Connect the speakers directly to the computer to verify that the speakers and the computer
audio are functioning properly.
• Check the audio settings of the computer and verify that the audio output is through the
speakers.
• Check if the USB cables connecting the unit and the computers are properly connected.
• Make sure the CAC port is enabled.
For product inquiries, warranty questions, or technical questions, please contact [email protected].
Note: The NUM, CAPS, and SCROLL Lock LED indicators on the keyboard are not supposed to light up if
connected to the KVM.
Front Panel Control
To switch to an input port, simply push the desired input button on the front-panel of the KVM. If an input
port is selected, the LED of that port will turn on.
No Power
No Video
Keyboard is not working
Mouse is not working
No Audio
No CAC (COMMON ACCESS CARD, SMART CARD READER)
Advanced 1/2/4/8/16 DVI-I Secure KVM Switch

13
LIMITED WARRANTY STATEMENT
A. Extent of limited warranty
iPGARD, Inc. warrants to the end-user customers that the iPGARD product specied above will be free from
defects in materials and workmanship for the duraon of 1 year, which duraon begins on the date of
purchase by the customer. Customer is responsible for maintaining proof of date of purchase.
iPGARD limited warranty covers only those defects which arise as a result of normal use of the product, and
do not apply to any:
a. Improper or inadequate maintenance or modicaons
b. Operaons outside product specicaons
c. Mechanical abuse and exposure to severe condions
If iPGARD receives, during applicable warranty period, a noce of defect, iPGARD will at its discreon replace
or repair defecve product. If iPGARD is unable to replace or repair defecve product covered by the iPGARD
warranty within reasonable period of me, iPGARD shall refund the cost of the product.
iPGARD shall have no obligaon to repair, replace or refund unit unl customer returns defecve product to
iPGARD.
Any replacement product could be new or like new, provided that it has funconality at least equal to that of
the product being replaced.
iPGARD limited warranty is valid in any country where the covered product is distributed by iPGARD.
B. Limitaonsofwarranty
To the extent allowed by local law, neither iPGARD nor its third party suppliers make any other warranty or
condion of any kind whether expressed or implied with respect to the iPGARD product, and specically
disclaim implied warranes or condions of merchantability, sasfactory quality, and tness for a parcular
purpose.
C. Limitaonsofliability
To the extent allowed by local law the remedies provided in this warranty statement are the customers sole
and exclusive remedies.
To the extent allowed by local law, except for the obligaons specically set forth in this warranty statement,
in no event will iPGARD or its third party suppliers be liable for direct, indirect, special, incidental, or
consequenal damages whether based on contract, tort or any other legal theory and whether advised of the
possibility of such damages.
D. Local law
To the extent that this warranty statement is inconsistent with local law, this warranty statement shall be
considered modied to be consistent with such law.
Advanced 1/2/4/8/16 DVI-I Secure KVM Switch

DESIGNED
AND MADE
IN THE USA
14
NOTICE
The information contained in this document is subject to change without notice. iPGARD makes no
warranty of any kind with regard to this material, including but not limited to, implied warranties of
merchantability and tness for particular purpose. iPGARD will not be liable for errors contained
herein or for incidental or consequential damages in connection with the furnishing, performance
or use of this material. No part of this document may be photocopied, reproduced, or translated
into another language without prior written consent from iPGARD, Inc.
20180109
Toll Free: [phone]
Phone: [phone]
Fax: [phone]
3291 N. Jones Blvd.,
Las Vegas, NV 89108
iPGARD.COM
Advanced 1/2/4/8/16 DVI-I Secure KVM Switch
