iPuray BRT-112 User manual

Product Description of BRT-112 Page 1of 4
Shenzhen Asia Bright Industry co., Ltd., Building 10, Asia Industrial Park, Gangtou, Bantian, Shenzhen, China.
www.a-brt.com. [email protected].
© 2015 All rights reserved. Subject to change without notices.
Glass Touch Screen Timer Switch
(No Neutral Required)
Model #：BRT-112
Features:
BRT-112 is a glass touch screen timer switch which is controlled by a micro controller unit and
has timing capability for one load. It is designed for easy installation and retrofit, directly fit into
standard wall box with no need for the neutral.
High quality glass as faceplate, luxury and elegant;
Delay-off time of 30 seconds or instant on/off;
Easy to use. A gentle touch will turn on or turn off the load;
Good for all kind of loads (an additional adaptor is needed for capacitive loads);
Can be used as night light. All the buttons are always lit by blue backlights, so they are easy
to find even in the dark;
Costume color and pattern available;
ABS-V0 flame resistance material; and
Classical 86 series design and high quality build.
Front View and Back View:
Fig. 1 and Fig. 2 show the front view and the back view of the BRT-112 glass touch screen timer
switches respectively.
Fig. 1 Front View Fig. 2 Back View

Product Description of BRT-112 Page 2of 4
Shenzhen Asia Bright Industry co., Ltd., Building 10, Asia Industrial Park, Gangtou, Bantian, Shenzhen, China.
www.a-brt.com. [email protected].
© 2015 All rights reserved. Subject to change without notices.
There is one on/off button on the front, and there are wiring terminal blocks on the back. The
button is backlit with blue light.
Specification Parameters:
Input Voltage
180～250V(50Hz/60Hz)
Operating
Temperature
-20℃～55℃
Wattage
2000W
Relative
Humidity
No-condensation 20-90% RH
Mounting Hole
Spacing
60mm
Matching
Box
75mm x 75mm x 50mm
Dimension
86mm x 86mm x 38mm
Weight
140g
Wiring Diagram and Installation Guide:
BRT-112 glass touch screen timer switch only requires hot wire for installation:
Hot wire (ACL): Coming from the power line with 220V;
Load wires: Going to the load.
Fig. 3 BRT-112 Wiring Diagram
Warning: Please make sure power is turned off before starting installation!
Fig. 3 shows the wiring diagram and Fig. 4 shows the step-by-step installation instructions. There
are three easy steps:
Step one: Use a screwdriver to pry off the front plate in position A;
Step two: Wiring according to the diagram and the labelled ports of the switch; and
Step three: Install the switch to the wall box using screws and put back the front plate.

Product Description of BRT-112 Page 3of 4
Shenzhen Asia Bright Industry co., Ltd., Building 10, Asia Industrial Park, Gangtou, Bantian, Shenzhen, China.
www.a-brt.com. [email protected].
© 2015 All rights reserved. Subject to change without notices.
Fig. 4 BRT-112 Installation Guide
BRT-112 Operation Guide:
Switch on/off the load: After BRT-112 is powered on, touching the on/off buttons will turn
on or turn off the load respectively, when the delay-off function is not setup. When a load is
turned on, the button will become brighter in blue.
Fig. 5 Dip Switches for Activating Delay-off Time

Product Description of BRT-112 Page 4of 4
Shenzhen Asia Bright Industry co., Ltd., Building 10, Asia Industrial Park, Gangtou, Bantian, Shenzhen, China.
www.a-brt.com. [email protected].
© 2015 All rights reserved. Subject to change without notices.
Set up delay-off function: Use a screwdriver to pry off the front plate to access the dip
switches as shown in Fig.5. Switching the first dip switch to on will set up the on/off button
for delay-off operation.
The delay-off time is set at 30 seconds at factory. Please talk to our sales representative if
other customized settings are required.
Activate delay-off function: Once the delay-off function is set up, touching the on/off
button once will turn on the load, and touching the on/off button the second time will trigger
delay-off for the load. The blue LED indicator will blink until the load is automatically
turned off after 30 seconds.
During the delay-off time countdown, touching the On/Off button will turn off the load
immediately.
Applications:
BRT-112 glass touch screen timer switch can be used for automatically turning on and/or turning
off various loads such as fans, lights, appliances, or other kinds of electrical equipment. They are
perfect for saving energy and bringing convenience and safety to our daily life and work.
They have wide applications at various locations such as homes, hotels, schools, laboratories,
hospitals, offices, etc.
