IRONEDGE Pro 2 User manual

Instruction Manual

Introduction to products
1
Product name: Massage Gun Pro 2
Brand：IRONEDGE
Weight:0.98kg
Dimension:245*78*255mm
Input voltage:110-240V，50/60Hz
Plug type: DC,16.8/1A
Massage mode: Warm compress，constant
speed，undulating and climbing mode
Speed:5 speed settings
Power：≤60W
Rotate Speed:1600-3200RPM/Min
Main material: PC+ABS
Power supply:16.8V/2600mAh Rechargeable
Lithium-ion battery

Product structure
5 Interchangeable massage head
Detachable
battery Button
Power/Display
charging
Control panel
Battery main switch
Charge Port
2
Flat head “U”Shape head
Round head
Taper head
Warm massage head

3
Battery and massage head installation method
Battery installation
method
Make the reading of
main body align to the
fluting of battery case
Battery
Removal Method
Press the battery
remove button，
Pull the battery out
Heating head
installation method
Make the reading of
the heating head
align to the fluting of
the machine case
‘U’shape head
installation method
Make the reading
of the ‘U’ shape
head align to the
fluting of the
machine case
Remark:1.Other massage heads is not installed limit,direct vertical press into place.
2.Disassembly method of massage head:Pull them out vertically

Product instructions
Speed display light
Warm compress
mode display
Increase/Decrease
Button
Mode Adjustment
display
Warm compress button
Decrease button
Constant speed
massage
Undulating massage
Climbing
massage
1、Turn on the main power switch at the bottom of the
handle,Power indicator displays the current power
indicator.(More than 40% of the power is displayed blue
light;Less than 30% of the power is displayed yellow light;
less than 10% of the power is displayed red light)
4
2、When the machine is in standby,press to start
massage,Then adjust the massage mode and speed
according to your preference.
3、If you need to use ‘Warm compress Mode’. Turn off the
main power switch first,Pull out the existing massage
head,Then take out the hot compress massage head and
aim at the limit position.Turn on the main power switch,
Press to start Warm compress static massage mode,you
can press button to adjust the warm compress mode
with the other three massage mode and speed according
to your preference.
4、When the machine is working, Press to pause the
machine,When the machine is paused,Press to start
‘Warm compress static massage mode or press to Return
to previous working mode
5、The machine will turn off the mode display and speed
display automatically when the machine is stop in 5
minutes. Press button to start massage.
6、The machine is equipped with intelligent protection
mode, The machine will automatically enter the sleep
state When the motor works continuously for 20 minutes.
It will take 1 minutes to restart.(Press button to start
massage)

Massage heads and Feature
Flat head
Used for relaxing and
shaping each muscle
part
“U”Shape head
Used for neck, spinal and
achilles massage
Round head
Used for hand, back,
buttock, leg massage
Taper head
Used for deep tissue, such as
joints, palm and plantar
Temperature ranges from 42-48 ° C, you
can feel warm and comfortable, it benefits
the blood circulation ,it helps relax sore
and stiff muscles and relieves the pain.
Warm massage head
5
Speed up the preheating
effect before exercise
Keep your muscles active
during exercise
Lactic acid is rapidly
decomposed after
exercise
Shaking relaxes the
myofascial membrane
Stretch the lines of
the muscles
Improves muscle
balance
Deep release fatigue
Relieve muscle tension
Rapid release of lactic acid
Activate the
muscles
Persistent state
Remove Fatigue
Relieve Muscle
Fatigue
Fitness plasticity
Auxiliary training
Effective muscle
relaxation
Relieve pain and
stiffness
Accelerate
muscle recovery

Instruction Manual
6
Main machine Battery Charger
Flat head “U”Shape head
Round head
Taper head
Warm massage head
Instr uctio n Man ual

8
Maintain
If the following abnormal conditions occur during the use of this
product, please refer to the solution：
Abnormal condition Abnormal cause Exception handling
Cannot start function
Automatic stop in use
The hot compress head
temperature is not enough
The temperature of the hot
compress massage head
is too high
The instrument is suspended for 5
minutes, and all the display lights
on the main control board are off
The battery may be low
1. The battery may be low
2.The motor has been working
for 20 minutes
Preheat the massage
head for 1-2 minutes
Hot compress massage mode is
turned on without contact with the
body to balance the temperature
Enter smart power saving mode
Please charge
Please charge
Restart in one minutes
Normal
Turn off the warm compress
mode for 3 minutes before
resuming normal use
Press the start button to
return to the previous
working mode
Remark: If there are any other abnormal conditions that cannot be solved, please contact the
customer service in time

Matters needing attention
Disclaimer
1、Do not use this machine while charging
2、Do not insert or touch the gap between the massage head and the shell with your fingers or other objects
during use, so as not to pinch.
3、 Do not allow children to use alone.
4、This machine can not be self-disassembled or modified.
5、Due to the high power of this machine,it’s recommended to use it for 15-20 minutesat a time to avoid
physical discomfort.
6、If you find any abnormal phenomena or faults during use,lease stop using them immediately and contact
our company or dealer in time.
7、Be sure to use the original power adapter to charge the machine.
8、When the massage head is changed, it must be switched off and replaced.
9、Turn off the main power switch after each use of the instrument.
10、Do not rinse or soak with water or other liquids while cleaning. The best way is to use a wrung dry wet
towel or medical alcohol cloth to wipe, to prevent water into the body.
Not suitable to use this device
Osteoporosis patients,people with heart problems and wearing electronic medical devices and
pacemakers pregnant women or menstrual women,people with physical trauma or feel unwell
by doctors,and are banned from this machine when the body is wet.
8
