IRT DVA-4004 User manual

4004-dva.ib.rev0.doc Page 1 of 9 15/10/2007
IRT Eurocard Type
DVA-4004
Serial Digital Distribution Amplifier
I R T Electronics Pty Ltd A.B.N. 35 000 832 575
26 Hotham Parade, ARTARMON N.S.W. 2064 AUSTRALIA
National: Phone: [phone] Fax: [phone]
International: [phone] [phone]
Email: [e-mail]
Web: www.irtelectronics.com
Designed and manufactured in Australia
IRT can be found on the Internet at:
http://www.irtelectronics.com

4004-dva.ib.rev0.doc Page 2 of 9 15/10/2007
DVA-4004
Serial Digital Distribution Amplifier
Instruction Manual
Table of Contents
Section Page
Operational Safety 2
General Description 3
Functional Block Diagram 3
Applications 3
Specifications 4
Cicuit Description 5
Installation 6
Front & rear panel diagrams 7
Maintenance & Storage 8
Warranty and Service 8
Equipment return 8
Drawing List Index 9
This instruction manual applies to units later than S/N 0509001
Operational Safety:
WARNING
Operation of electronic equipment involves the use of voltages and currents that
may be dangerous to human life. Note that under certain conditions dangerous
potentials may exist in some circuits when power controls are in the OFF position.
Maintenance personnel should observe all safety regulations.
Do not make any adjustments inside equipment with power ON unless proper
precautions are observed. All internal adjustments should only be made by suitably
qualified personnel. All operational adjustments are available externally without the
need for removing covers or use of extender cards.

4004-dva.ib.rev0.doc Page 3 of 9 15/10/2007
General Description
The IRT DVA-4004 is a one in six out reclocking distribution amplifiers for SMPTE/EBU and ASI serial digital
video signals with all output signals in phase with the input signal, an added feature is a bypass circuit which will
switch the input circuit to output connector number 1 when the power supply of the unit is not present.
The units feature an input circuit with automatic cable equalisation for Belden 8281 or PFS1/2 coaxial cable and
cable driver circuits for seven individually sourced outputs, six to the rear connector panel and one for monitoring
on the front panel.
In addition the DVA-4004 allows the signal to be inverted if required by operation of a front panel slide switch to
select an inverted signal in the signal path from the input equaliser circuit.
Alarm circuits are provided which will provide remote monitoring of loss of the signal or the power supply via a
grounding relay contact, and a indication of the operation of the signal inversion circuit by means of a grounding
open collector transistor circuit.
The DVA-4004 is built in 3U extended Eurocard 220 mm x 100 mm module designed to mount in the IRT FRU-
3000 and FRU-1030 family of Eurocard frames.
Functional Block Diagram:
Applications
The DVA-4004 is intended to be used where ASI or SDI serial digital signals may be present and multiple signal
outputs are required from equipment with only one output and to provide input cable equalisation for devices not
having this feature as most unequalised inputs will only support short input signal cable lengths.
In 270 Mb/s ASI signal circuits the DVA-4004 will provide the required in phase outputs needed to preserve the
ASI signal and provide the means of inverting the signal if other equipment in the line cause a inversion of the
signal. The input connector to output connector 1 bypass feature can preserve one main signal path in the event of
power failure. Alarm circuits are provided for external monitoring of the state of the signal inversion circuit and the
power fail/signal present circuit.
O/P 1
O/P 2
O/P 3
O/P 4
O/P 5
O/P 6
MON O/P
OUTPUTS
RL1−2
RELAY
RECLOCKING
EQUALISER DATA
RECOVERY
DATA FAIL
DETECTION
RL1−1
RELAY
INPUT
+V
INVERT
SIGNAL
Relay RL 1 = Power Fail Bypass
Relay RL 2 = Output Alarm
ALARM O/P
LINK
RL 2
BLOCK DIAGRAM DVA−4004 SIGNAL PATH

4004-dva.ib.rev0.doc Page 4 of 9 15/10/2007
Technical specifications
DVA-4004
Input:
Number 1.
Impedance 75 Ohm.
Return loss >15 dB 5 MHz to 360 MHz.
Outputs:
Number 7.
Signal level 800 mV ± 10%
Impedance 75 Ohm.
Return loss >15 dB 5 MHz to 360 MHz.
DC offset Nil.
Performance:
Cable compensation Automatic, better than 300 metres at 270 Mb/s
for Belden 8281 or equivalent cable.
Output rise time <1 ns, (700ps typically).
Connectors: BNC.
Indicators:
Power LED (green) DC.
Signal Present LED (green) SIG
270 Mb/s lock selected LED (green) 270
360 Mb/s lock selected LED (yellow) 360
Inverted signal LED (yellow) INV
Power requirement:
Voltage 28 Vac CT (14-0-14 Vac) or ±16 Vdc.
Consumption 2.5 VA (<80 mA).
General:
Temperature range 0 - 50° C ambient
Mechanical Suitable for mounting in IRT 19" 1RU and 3RU
rack chassis with input, output and power
connections to the rear.
Size 6 HP x 3U Extended Eurocard (220 mm x 100 mm).
Weight With rear assembly 330g.
Finish:
Front panel Grey background, silk screened black lettering &
red IRT logo.
Rear assembly Detachable silk screened PCB with direct mount
connectors to Eurocard and external signals.
Standard accessories: Rear connector assembly (supplied with module).

4004-dva.ib.rev0.doc Page 5 of 9 15/10/2007
Circuit Description
The input circuit again consists of U1 a CLC014 adaptive cable equaliser IC, which automatically adapts to equalise
any cable length from zero metres to lengths that attenuate the signal by 40dB at 200MHz. This corresponds to 300
metres of Belden 8281 cable. A carrier detect and output mute circuit in the CLC014 is used to mute the output
when no signal is present. The CLC014 is insensitive to the pathological patterns that can be present in the serial
digital video signal.
The output of the CLC014 input stage is coupled to U2 a ECL multiplexer which can be switched to select a normal
or inverted signal stream to U3 a CLC016 data re-timing PLL with automatic rate selection. The CLC016 is set up
for manual rate selection of the serial data rates of 270 and 360 Mb/s using link LK3. As with (the CLC014 input
stage) the carrier detect and mute circuit of U2 is used to mute the output when no signal is present. U3 the CLC016
has a low residual output jitter of less than 170 ps p-p at 270 Mb/s and is insensitive to the pathological patterns that
can be present in the serial digital video signal.
The output of the CLC016 re-timing stage is coupled to CLC007 cable driver circuits U4, U5, U6 and U7 to provide
the seven isolated outputs from the DVA-4004. A relay RL1 wired in a change-over configuration is wired in the
input signal path and the signal path to output 1 on the rear panel, with this relay energised by the +5 volts supply
the input and output circuits are completed to provide normal operation of the DVA-4004. When +5 volts supply is
not present the relay will switch the input signal to output 1 on the rear panel to provide a fail-safe circuit for the
signal.
Note the cable driver outputs are wired so that all outputs are in phase with the input signal of the DVA-4004 when
the front panel slide switch is in the NORMAL position.
IC U8 provides the necessary LED drivers and logic to decode the rate detection indications from U3. LED LD5 is
used to indicate the state of the carrier detect circuit, indicating the presence of signal to the re-timing IC U3, and
LED’s LD3 and LD2 are used to indicate PLL rate of 270 Mb/s or 360 Mb/s signal by U3.
Monitoring circuits are provided to indicate loss of signal or power to the unit and the state of the signal inversion
circuit of the DVA-4004. Monitoring of loss of signal or power this is done by a relay RL2 which is energised when
signal is detected by the reclocking IC U3, the relay contact is set by LK2 to provide a contact closure to ground on
failure. The state of the front panel switch is monitored by U9 a opto-isolator circuit whose output is a npn transistor
with the emitter grounded, this transistor will be switched to ground when the signal inversion switch is switched to
INVERT.
The dual AC inputs are rectified by D1 to D4, and then regulated in a LM2575-5 switch mode regulator circuit U10
to provide the +5V operating voltage for the unit.

4004-dva.ib.rev0.doc Page 6 of 9 15/10/2007
Installation
Pre-installation:
Handling:
This equipment may contain or be connected to static sensitive devices and proper static free handling precautions
should be observed.
Where individual circuit cards are stored, they should be placed in antistatic bags. Proper antistatic procedures
should be followed when inserting or removing cards from these bags.
Power:
AC mains supply: Ensure that operating voltage of unit and local supply voltage match and that
correct rating fuse is installed for local supply.
DC supply: Ensure that the correct polarity is observed and that DC supply voltage is maintained
within the operating range specified.
Earthing:
The earth path is dependent on the type of frame selected. In every case particular care should be taken to ensure
that the frame is connected to earth for safety reasons. See frame manual for details.
Signal earth: For safety reasons a connection is made between signal earth and chassis earth. No attempt should be
made to break this connection.
Installation in frame or chassis:
See details in separate manual for selected frame type.
Ensure that the front panel slide switch is in the NORMAL position for correct operation with ASI signals.
LK3 and LK4 set the PLL lock frequency of U3. LK3 is used to switch between 270 Mb/s (link closed) and 360
Mb/s (link open). LK4 is not fitted, it may be fitted if operation at 143 Mb/s or 177 Mb/s if desired.
LK3 RATE SELECTED
Closed 270 Mb/s
Open 360 Mb/s
Link LK2 sets the operation of RL2 contact set, the position closest to the board edge is the normally closed
position which will give a contact closure to ground on a signal or power failure, this is the preferred position for
common alarm circuits from a number of units.
The presence of the internal +5 Vdc supply is indicated by the front panel LED (green).

4004-dva.ib.rev0.doc Page 7 of 9 15/10/2007
Front & rear panel diagrams
The following front panel and rear assembly drawings are not to scale and are intended to show relative positions of
connectors, indicators and controls only.
DC
360 INV
270 SIG
DVA-4004
N140
OUTPUT MON
INVERT
NORMAL
J1
SK8
BYPASS ON POWER FAIL
O/P5
O/P3
O/P1
O/P6
OUTPUTS
OUTPUTS
1
1=GND
2=SIGNAL/POWER LOSS
3=SIGNAL INVERSION
O/P2
DVA-4004
INPUT
O/P4
P3
P2

4004-dva.ib.rev0.doc Page 8 of 9 15/10/2007
Maintenance & Storage
Maintenance:
No regular maintenance is required.
Care however should be taken to ensure that all connectors are kept clean and free from contamination of any kind.
This is especially important in fibre optic equipment where cleanliness of optical connections is critical to
performance.
Storage:
If the equipment is not to be used for an extended period, it is recommended the whole unit be placed in a sealed
plastic bag to prevent dust contamination. In areas of high humidity a suitably sized bag of silica gel should be
included to deter corrosion.
Where individual circuit cards are stored, they should be placed in antistatic bags. Proper antistatic procedures
should be followed when inserting or removing cards from these bags.
Warranty & Service
Equipment is covered by a limited warranty period of three years from date of first delivery unless contrary
conditions apply under a particular contract of supply. For situations when “No Fault Found” for repairs, a
minimum charge of 1 hour’s labour, at IRT’s current labour charge rate, will apply, whether the equipment is within
the warranty period or not.
Equipment warranty is limited to faults attributable to defects in original design or manufacture. Warranty on
components shall be extended by IRT only to the extent obtainable from the component supplier.
Equipment return:
Before arranging service, ensure that the fault is in the unit to be serviced and not in associated equipment. If
possible, confirm this by substitution.
Before returning equipment contact should be made with IRT or your local agent to determine whether the
equipment can be serviced in the field or should be returned for repair.
The equipment should be properly packed for return observing antistatic procedures.
The following information should accompany the unit to be returned:
1. A fault report should be included indicating the nature of the fault
2. The operating conditions under which the fault initially occurred.
3. Any additional information, which may be of assistance in fault location and remedy.
4. A contact name and telephone and fax numbers.
5. Details of payment method for items not covered by warranty.
6. Full return address.
7. For situations when “No Fault Found” for repairs, a minimum charge of 1 hour’s labour will apply,
whether the equipment is within the warranty period or not. Contact IRT for current hourly rate.
Please note that all freight charges are the responsibility of the customer.
The equipment should be returned to the agent who originally supplied the equipment or, where this is not
possible, to IRT direct as follows.
Equipment Service
IRT Electronics Pty Ltd
26 Hotham Parade
ARTARMON
N.S.W. 2064
AUSTRALIA
Phone: [phone] Fax: [phone]
Email: [email protected]

4004-dva.ib.rev0.doc Page 9 of 9 15/10/2007
Drawing List Index
Drawing # Sheet # Description
805074 1 DVA-4004 serial digital VDA schematic diagram.

Title
SCALE
SIZE
Sheet
DRAWN CHECKED ENG. APP. Revision:
DO NOT COPY NOR
DISCLOSE TO ANY
THIRD PARTY
WITHOUT WRITTEN
CONSENT
of1
IRT Electronics Pty. Ltd.
Drawing No.
COPYRIGHT
ARTARMON NSW AUSTRALIA 2064
A3
N.T.S. 5
DVA-4004
805074
Date: 1
15-Oct-2007
RECLOCKING SERIAL D.A.
K.N.
1 26-04-2005
+5V
PCB 805075
SDO SDO
Input INV SIGNAL 270 360
Input and Reclocking circuit 805074s2.sch
J2/RA optional power in
(used when fitted to FRU-1030 frame)
1
2
3
4
5
6
7
8
9
10 13
14
15
16
17
18
19
20
21
22
RL1
G5Y-254P 5V
3 2 1
SW1
INVERT SIGNAL
21
R50 4K7
+5V
21
LD4 yell
21 R46
560R
12
65
7
U9
IL207
1 2
L6
1 2
C47
10nF
12C50
10nF
2 1
R51
560R
INVERT
L1R-L7R = 22nH R1R-R7R = 75R
1A 1B 2A 2B 3A 3B 4A 4B 5A 6A 6B 7A 7B 8A 8B
10A 10B
5B
11A 11B 12A 12B 13A 13B 14A 15A 15B 17A 17B 18A 18B
9A 9B
20A 20B 14B 21A 21B 22A 22B 23A 24B 24A 25B 26A 27A 27B 28A 23B 19A 19B 30A 30B 26B 31A 31B 32A 32B 25A 16A 16B 28B 29A 29B
P1
AC1 AC2 AC3 AC4
Power Supply circuit
805074s4.sch
MON. O/P
+5V
SIGNAL
+5V
PRESENT
21 R45
560R
31
2
LK2
1 2
C10
4u7
21
LD5
grn
12 L5
1 2
C46 10nF
38
RL2A
V23026
10 1
5RL2B
+5V
270 Mb/s 360 Mb/s
21 R48
560R
21 R47
560R
21
LD3
grn
21
LD2 yell
21
3Q4
BAV70
(A4)
OUT 5 OUT 6MON OUT 4 OUT 3 OUT 2 OUT 1
SDI SDI
Output circuit 805074s3.sch
'DC'
grn
21
R49
560R
21
LD1
+5V
2 1
R44 N/C
1
2
SK9
1 3
2
D7
BAV70
1 3
2
D8
BAV70
1 3
2D9
BAV70
SIGNAL PRESENT SIGNAL INV ALARM
RX
TX270 MHz
Control Interface 805074s5.sch
+5V
+5V
32
1
Q5
BSS123
1 3
2D11
BAV70
(OUTPUTS)
INPUT
1 2
L1R
1 2
L2R
1 2 3
J2
21 R2R
75R
1 2
L3R
21 R3R
75R
1 2
L5R
21 R5R
75R
1 2
L4R
21 R4R
75R
1 2
L7R
21 R7R
75R
1 2
L6R
21 R6R
75R
21
R1R
1A 1B 2A 2B 3A 3B 4A 4B 5A 6A 6B 7A 7B 8A 8B 10A 10B 5B 11A 11B 12A 12B 13A 13B 14A 15A 15B 17A 17B 18A 18B 9A 9B 20A 20B 14B 21A 21B 22A 22B 23A 24B 24A 25B 26A 27A 27B 28A 23B 19A 19B 30A 30B 26B 31A 31B 32A 32B 25A 16A 16B 28B 29A 29B
J1
DIN64
O/P5 O/P6 O/P3 O/P4 O/P2 O/P1
3 2 1
SK8
1 3 5 7 9
P2
1 2 3 4 5 6
P3
Tx Rx
