ISAFE MOBILE M360A01 User manual

IS360.2
OPERATING MANUAL
MODEL M360A01

Document No. 1057MM10REV00
Version: 2021-11-04
(c) 2021 i.safe MOBILE GmbH
i.safe MOBILE GmbH
i_Park Tauberfranken 10
97922 Lauda-Koenigshofen
Germany
Tel. [phone]
[email protected]
www.isafe-mobile.com Template: TEMPMM01REV10

CONTENTS
English.............................................................................. 4
Deutsch............................................................................ 18
Česky .............................................................................. 32
Dansk.............................................................................. 46
Español ............................................................................60
Suomi.............................................................................. 74
Français............................................................................88
Magyar ...........................................................................102
Italiano ...........................................................................116
Nederlands .......................................................................130
Norsk .............................................................................144
Polski .............................................................................158
Português (EU)....................................................................172
Português (BR)....................................................................186
Русский.......................................................................... 200
Svenska...........................................................................214
Hrvatski...........................................................................228
Slovenská.........................................................................242
Српски ...........................................................................256
Japanese..........................................................................270
Arabic ........................................................................... 284
This Operating Manual complies with these standards:
IEC 60079, IEC 82079, ANSI Z535.6
Diese Bedienungsanleitung erfüllt die Anforderungen der folgenden Normen:
IEC 60079, IEC 82079, ANSI Z535.6

4
ENGLISH
READ AND UNDERSTAND THE INSTRUCTIONS
PROTECT YOUR LIFE AND READ THE OPERATING MANUAL
This Operating Manual is part of the device IS360.2 (model M360A01). This Operating
Manual provides important information for safe use of the device.
Before using the device, read this Operating Manual carefully and pay particular attention
to the “Safety” section and the warnings highlighted with the warning symbol.
Also read the Safety Instructions before using the device.
You can nd these at www.isafe-mobile.com/en/support/downloads.
Make sure you have access to this Operating Manual when you need it. You can nd the
current Operating Manual at www.isafe-mobile.com/en/support/downloads.
Follow all instructions given on the device and on the packaging.
Follow local safety regulations.
INTENDED USE
The IS360.2 is an Internet-capable communication device for industrial use in explosion
hazardous areas of Zone 2/22, in accordance with Directives 2014/34/EU, 1999/92/EC and the
IECEx system, among others.
Only use the device as described in this Operating Manual. Any other use is considered impro-
per and can lead to death, severe injuries and damage to the device.
The manufacturer i.safe MOBILE GmbH does not assume any liability for damage caused by
improper use. The warranty expires in the event of improper use.

EN 5
WARRANTY
You can nd the warranty conditions at
www.isafe-mobile.com/en/support/service.
For any damage caused by computer viruses that you download while using the Internet
functions responsibility is at your hand.
There is no right of recourse against i.safe MOBILE GmbH.
EU DECLARATION OF CONFORMITY
You will nd the EU declaration of conformity at
www.isafe-mobile.com/en/support/downloads.
FCC/IC STATEMENT
The FCC/IC declaration can be found at www.isafe-mobile.com/en/support/downloads.
EX MARKINGS
ATEX:
II 3G Ex ic IIC T4 Gc
II 3D Ex ic IIIC T135°C Dc
EU Type Examination Certicate:
EPS 21 ATEX 1 126 X
CE-designation:
IECEx:
Ex ic IIC T4 Gc
Ex ic IIIC T135°C Dc
IECEx Certicate: IECEx EPS 21.0043X
Temperature range:
-10°C … +50°C (EN/IEC 60079-0)
-10°C … +50°C (EN/IEC 62368-1)
Manufactured by:
i.safe MOBILE GmbH
i_Park Tauberfranken 10
97922 Lauda-Koenigshofen
Germany

6
DEVICE OVERVIEW/FUNCTIONS
1 2
4
5
6
3
10
7
8
9
11
16
12 13
15
14
17

EN 7
1 EARPHONE JACK
2 FUNCTION KEY: Optional function (can be assigned via apps used).
3 STATUS LED: Display for notications and charging status.
4 POWER KEY: A long press switches the device on/o. A short press switches the stand-
by mode on/o.
5 FUNCTION KEY: Optional function (can be assigned via apps used).
6 LOUDNESS CONTROL: Volume up/Volume down.
7 CURRENT APPLICATION: Shows all open applications.
8 HOME KEY: Switch to the main screen.
9 BACK KEY: Go to the previous screen.
10 MICROPHONE
11 LOUDSPEAKER
12 BACK CAMERA
13 MICROPHONE: Noise cancelling microphone/hands-free microphone.
14 LED FLASH
15 CHARGING CONTACTS
16 USB INTERFACE: Connection for the TypeC USB Cable or for connection to other
devices. Also see sections “Charging” and “Connecting approved accessories”.
17 BELT CLIP

8
SAFETY
Read the “Safety” section of this Operating Manual carefully before using the device. If you
do not follow these instructions or do not understand them, this could lead to death, severe
injuries and damage to the device.
USER
Only trained users who are qualied in the use of Ex devices in explosion hazardous areas and
who have read and understood this Operating Manual may use this device.
USE IN EXPLOSION HAZARDOUS AREAS
DANGER
Improper use can result in death or severe injuries!
Only use the device in explosion hazardous areas of zones2/22 or outside of
explosion hazardous areas.
Before entering a explosion hazardous area with the device,
•make sure that only approved accessories are connected to the device, see section
“Connecting approved accessories”,
•make sure that no gap can be seen between the two halves of the device,
•make sure the device is not damaged,
•make sure that all the labels on the device are readable,
•make sure the battery compartment is screwed tight.
If you use the device in a explosion hazardous area,
read and follow the instructions in the “Possible User Errors” section.
Switch o the device immediately and leave the explosion hazardous area without delay if
•malfunctions occur on the device,
•you have damaged the housing of the device,
•you have exposed the device to excessive loads,
•the labels on the device are no longer readable.
USE OUTSIDE OF EXPLOSION HAZARDOUS AREAS
DANGER
Improper use can result in death or severe injuries!
Do not use the device in places where its use is prohibited.
Turn o the device in clinics or other medical facilities.
Always keep a safety distance of at least 15cm between the device and a pacemaker or
hearing aid. The device can aect the functioning of medical devices such as pacemakers and
hearing aids.
When using the device while driving a motor vehicle, be sure to comply with applicable
national laws.
Make sure you prevent the user errors described in the section entitled “Possible User Errors”.
Only charge the device as described in the “Charging” section.

EN 9
CAUTION
When using earphones or headsets at the maximum volume setting, you can dama-
ge your hearing.
First set the volume control on the device to 50 % of the maximum volume.
Gradually adjust the volume.
NOTICE
Incorrect use can damage the device.
Only use accessories approved by i.safe MOBILE, as described in the section on
“Connecting approved accessories”.
Protect the device and the Power Adapter from strong electrical magnetic elds as for examp-
le those emitted by induction cookers or microwave ovens, for example.
Protect the device from high mechanical hazards, strong UV radiation and highly electrically
charging processes.
Do not touch the display with sharp objects.
POSSIBLE USER ERRORS
DANGER
Improper use can result in death or severe injuries! Follow the instructions below:
Do not modify the device structurally.
Do not expose the device to high temperatures.
Do not expose the device to strong UV radiation.
Do not expose the device to processes with high electrical charges.
Do not expose the device to aggressive acids or bases.
When working in explosion hazardous areas, please note:
Do not loosen the screws on the device.
Do not connect any accessories to the device.
Do not open any interface cover.
Do not charge the device.
Do not open the device.
Do not damage the device.
SCOPE OF DELIVERY
Your device packaging contains the following:
1 x IS360.2
1 x Battery
1 x Quick Start Manual
1 x Safety Instructions
1 x Display Protection Foil

10
1 x Type C USB Cable
1 x Power Adapter universal (power supply unit and various country-specic adapters)
1 x Screwdriver
1 x Display cleaning cloth
CELL BROADCAST
The device supports cell broadcast. Cell broadcast is a cellular service for sending messages to
all recipients within a cell.
INSTALLING THE BATTERY
DANGER
Installing the wrong battery in the device, poses a risk of explosion, which could result in
death or serious injuries! Only t the battery supplied or an approved replacement battery in
the device outside of explosion hazardous areas. The approved replacement battery can be
found on the website www.isafe-mobile.com/en/products.
Loosen the screws on the battery compartment using the Screwdriver provided.
Remove the battery compartment cover.
Place the battery in the battery compartment as shown.
Check that the battery is seated correctly and securely.
Reinstall the battery compartment cover and hand-tighten the screws using the Screwdriver
provided.

EN 11
INSERT/REMOVE SIM CARD
DANGER
An incorrect procedure in explosion hazardous areas poses a risk of death or severe injuries!
Only open the device outside of explosion hazardous areas to insert or remove the SIM card.
NOTICE
Proceeding incorrectly when inserting/removing the SIM card can damage the device and
the SIM card. Switch o the device before inserting or removing a SIM card. Do not charge the
device while inserting or removing a SIM card.
Loosen the screws on the battery compartment using the Screwdriver provided.
Remove the battery compartment cover.
Remove the battery from the battery compartment.
Insert the SIM card into the slot. The device has two slots for one SIM card each. The slots are
marked „SIM 1“ and „SIM 2“.
If you have inserted two SIM cards, select a favorite card. Information on operating the device
can be found at www.isafe-mobile.com/en/support/service under the menu item „FAQ“.
Reinstall the battery. See section “Installing the battery”.

12
INSERT/REMOVE MICROSD CARD
DANGER
An incorrect procedure in explosion hazardous areas poses a risk of death or severe injuries!
Only open the device outside of explosion hazardous areas to insert or remove the microSD
card.
NOTICE
Proceeding incorrectly when inserting/removing the microSD card can damage the device
and the microSD card. Switch o the device before inserting or removing a microSD card. Do
not charge the device while inserting or removing a microSD card.
Loosen the screws on the battery compartment using the Screwdriver provided.
Remove the battery compartment cover.
Remove the battery from the battery compartment.
Insert the microSD card into the slot provided. The device has a slot for a microSD card up to
128GB. The slot is marked “microSD”.
Reinstall the battery. See section “Installing the battery”.
CHARGING
DANGER
An incorrect procedure in explosion hazardous areas poses risk of death or severe injuries!
Only charge the device outside of explosion hazardous areas. Do not charge the device in the
vicinity of ammable substances.
NOTICE
Incorrect charging can cause damage to the device. Please note the following when charging:
Only charge the device using the Type C USB Cable supplied.
Only charge the device at ambient temperatures between +5°C to +35°C (+41°F to +95°F).
Charge the device under dry indoor conditions only.
Do not charge the device in environments dusty or humid.

EN 13
Your device package contains a power supply unit, various country-specic adapters, an
TypeC USB Cable.
Connect the adapter suitable for your country to the power supply unit.
Connect the TypeC USB Cable to the power supply unit.
Connect the TypeC USB Cable to the USB interface of the device.
SWITCHING ON/OFF
Press and hold the on/o key for about 3 seconds.
Enter the device or SIM PIN when the input dialog for the device or SIM PIN appears after
switching on.
Select the <Switch o> menu item if the power o menu appears when switching o.
USING THE DEVICE
When turning on the device for the rst time, follow the instructions on the screen.
Further information on operating the device can be found at
www.isafe-mobile.com/en/support/service under the menu item “FAQ”.
CONNECTING APPROVED ACCESSORIES
Only connect accessories approved by i.safe MOBILE to the device. Accessories approved by
i.safe MOBILE can be found at www.isafe-mobile.com/en/products.
Approved accessories can be connected to the USB interface.
USB INTERFACE
DANGER
Improper use can result in death or severe injuries! Only use USB interface outside of explosi-
on hazardous areas. Under no circumstances should you open the cover of the USB interface
in explosion hazardous areas.
The USB interface is used for charging and data transfer.
Connect approved accessories or other devices to the USB interface only by using the
Type C USB Cable.

14
CHANGING THE BATTERY
WARNING
If you replace the battery with the wrong battery in the device, there is a risk of explosion,
which could result in death or serious injuries! Only replace the battery with an approved
replacement battery outside of explosion hazardous areas. An approved replacement battery
can be found on the website www.isafe-mobile.com/en/products.
Loosen the screws on the battery compartment using the Screwdriver provided.
Remove the battery compartment cover.
Remove the battery from the battery compartment.
Place the approved replacement battery in the battery compartment.
Check that the battery is seated correctly and securely.
Reinstall the battery compartment cover and hand-tighten the screws using the Screwdriver
provided.

EN 15
POSSIBLE DEVICE PROBLEMS
You can nd information on possible device problems and how to rectify them at
www.isafe-mobile.com/en/support/service under the menu item “FAQ”.
If you have any further questions, please contact the i.safe MOBILE repair service at
www.isafe-mobile.com/en/support/service.
MAINTENANCE/REPAIR
The device itself has no serviceable parts.
WARNING
Incorrect repairs present a risk of explosion or re, which can result in death or severe injuries!
Do not open the device or carry out any repairs yourself.
Contact the i.safe MOBILE repair service at www.isafe-mobile.com/en/support/service if
the device is not working normally, if the device needs to be repaired or if a replacement part
is required.
RETURN SHIPMENT
Contact the i.safe MOBILE repair service at www.isafe-mobile.com/en/support/service.
DISTRIBUTION PARTNER
You can nd the specialist distribution partner responsible for your country at
www.isafe-mobile.com/en/contact.
CLEANING
NOTICE
Incorrect cleaning can cause damage to the device. Please note the following when cleaning:
Turn o the device before cleaning.
Do not charge the device while cleaning.
Do not use chemical agents for cleaning.
Clean the device and the Power Adapter with a soft, moistened antistatic cloth.
Clean the display screen regularly with a soft, antistatic cloth.
STORAGE
NOTICE
Incorrect storage can cause damage to the device. Store the device at ambient temperatures
between +5°C to +35°C (41°F to +95°F) and a humidity between 10 % to 60 %.

16
RECYCLING
NOTICE
Incorrect disposal of electronic products, batteries and packaging material puts the environ-
ment at risk. Please note the following when disposing of items:
DO NOT throw away batteries with household waste.
Always dispose electronic products, batteries and packaging material at the
appropriate collection points. This way, you prevent uncontrolled waste disposal and
promote the recycling of material resources.
You can obtain further information from regional waste disposal companies, state authorities or
the i.safe MOBILE service centre responsible for your country or region at
www.isafe-mobile.com/en/support/service.
TRADEMARKS
i.safe MOBILE and the i.safe MOBILE logo are registered trademarks of the
i.safe MOBILE GmbH.
All other trademarks and copyrights are the properties of their respective owners.

EN 17

18
DEUTSCH
ANWEISUNGEN LESEN UND VERSTEHEN
SCHÜTZEN SIE IHR LEBEN UND LESEN SIE DIE BEDIENUNGSANLEITUNG
Diese Bedienungsanleitung ist Teil des Geräts IS360.2 (Modell M360A01). Die Bedienungsan-
leitung liefert wichtige Informationen für eine sichere Verwendung des Geräts.
Lesen Sie vor der Verwendung des Geräts diese Bedienungsanleitung sorgfältig durch und
beachten Sie insbesondere den Abschnitt „Sicherheit“ und die mit dem Warnsymbol hervor-
gehobenen Warnhinweise.
Lesen Sie vor der Verwendung des Geräts auch die Sicherheitsvorschriften. Diese nden Sie
unter www.isafe-mobile.com/de/support/downloads.
Sorgen Sie dafür, dass Sie bei Bedarf Zugri auf diese Bedienungsanleitung haben.
Die aktuelle Bedienungsanleitung nden Sie unter www.isafe-mobile.com/de/support/
downloads.
Beachten Sie alle Anweisungen auf dem Gerät und auf der Verpackung.
Befolgen Sie die örtlichen Sicherheitsvorschriften.
BESTIMMUNGSGEMÄSSE VERWENDUNG
Das IS360.2 ist ein internetfähiges Kommunikationsgerät für den industriellen Einsatz in
explosionsgefährdeten Bereichen
der Zone 2/22 unter anderem nach den Richtlinien
2014/34/EU, 1999/92/EG und dem IECEx-System.
Verwenden Sie das Gerät nur, wie in dieser Bedienungsanleitung beschrieben. Jede andere
Verwendung gilt als nicht bestimmungsgemäß und kann zu Tod, schweren Verletzungen und
Schäden am Gerät führen.
Der Hersteller i.safe MOBILE GmbH übernimmt keine Haftung für Schäden, die durch nicht
bestimmungsgemäße Verwendung entstanden sind. Die Garantie erlischt bei nicht bestim-
mungsgemäßer Verwendung.

DE 19
GARANTIE
Die Garantiebestimmungen nden Sie unter
www.isafe-mobile.com/ de/ support/service .
Für Schäden durch Computerviren, die Sie beim Verwenden der Internetfunktionen
herunterladen, sind Sie selbst verantwortlich. Ein Regressanspruch gegenüber der
i.safe MOBILE GmbH besteht nicht.
EUKONFORMITÄTSERKLÄRUNG
Die EU-Konformitätserklärung nden Sie unter
www.isafe-mobile.com/ de/support/downloads.
FCC/IC ERKLÄRUNG
Die FCC/IC Erklärung nden Sie unter
www.isafe-mobile.com/ de/support/downloads.
EXKENNZEICHNUNGEN
ATEX:
II 3G Ex ic IIC T4 Gc
II 3D Ex ic IIIC T135°C Dc
EU-Baumusterprüfbescheinigung:
EPS 21 ATEX 1 126 X
CE-Kennzeichnung:
IECEx:
Ex ic IIC T4 Gc
Ex ic IIIC T135°C Dc
IECEx-Zertikat: IECEx EPS 21.0043X
Temperaturbereich:
-10°C … +50°C (EN/IEC 60079-0)
-10°C … +50°C (EN/IEC 62368-1)
Hersteller:
i.safe MOBILE GmbH
i_Park Tauberfranken 10
97922 Lauda-Koenigshofen
Germany

20
GERÄTEÜBERSICHT/FUNKTIONEN
1 2
4
5
6
3
10
7
8
9
11
16
12 13
15
14
17
