Isimet LA Series Installation manual

Application:
The LA Series Single Source and Companion Style Controllers operate as dual output controllers. This Unit is ideally
suited for the instructor’s desk within the classroom where a single switch can operate all connected utilities.
The Unit can be companioned to other Controllers to permit inter-action between units for Panic Response.
ISIMET LA Kitchen Controller
Utility Controller -Limited Application
Dual Output Circuits Ver 4.41 pcb
Single Source and Companion Styles
(having 120-vac, 24-vac; and 12-vac or 12-vdc output circuit)
Installation, Operations, Start-up and
Maintenance Instructions
Table of Contents:
Page
Warranty………………………………………………….. 2
Enclosure Specifications and Dimensions………………… 3
Styles……………………………………………………… 3
Model Number……………………………………………. 3
Mounting Instructions (Flush)….…………………………. 4
Mounting Instructions (Casework)..………………………. 4
Mounting Instructions (Surface Mount)..…………………. 4
Mounting the Wall Panel..………………………………… 4
Circuit Output Configurations………………………….…. 5
Monitoring Configurations………………………….…….. 5
Installing the Electrical Conduit…………………………... 6
Wiring the Unit……………………………………………. 6
Wiring Configurations.. …………………………………… 6
Operation of Unit………………………………………….. 7
Equipment Maintenance…………………………………… 7
October 2015 DOC# 18011-A

2
ISIMET LA Series Utility Controller
Installation, Maintenance, Operations, and Startup Instructions
Copyright © 2015 ISIMET/MAPA, LLC
ISIMET is a trademark of ISIMET/MAPA, LLC, an affiliate of WCM Industries, Inc.
All rights reserved.
Patent 6,757,589 B1, 6,990,393 B2
This document is copyrighted. This document may not, in whole or part, be copied, duplicated, reproduced, translated,
electronically stored, or reduced to machine readable form without prior written consent from ISIMET.
Although the material contained herein has been carefully reviewed, ISIMET does not warrant it to be free of errors or
omissions. ISIMET reserves the right to make corrections, updates, revisions, or changes to the information contained herein.
Warranty:
ISIMET will repair or replace any defective parts or workmanship of this product for a period of one year from date of
installation. The Primary Operating P.C. Board has a two year limited warranty. Damage caused by incorrect
installation or improper usage is not warranted. Failure to follow recommended installation, operation, and/or
maintenance procedures listed in this manual may void product warranty. Recovery rights shall be limited to the total
sum of the amounts paid for the product by the purchaser.
Limits of Liability:
ISIMET's liability shall be limited to costs of repair or replacement parts. The Laboratory Service Panel and Utility
Controller are not intended for usage other than those expressly described in this manual. ISIMET shall not be liable for
damage or injury caused by the improper use of the product.
ISIMET does not warrant against or assume liability for failure of operation or lack of notification to secondary
integrated monitoring systems. The system should be thoroughly tested and adjustments made at time of initial
operation. Periodic testing should be conducted by the user to assure that all components function and operate according
to specifications.
Care should be taken in the installation of this product. ISIMET shall not be liable for damage or injury caused from the
improper installation of the product.
Warranty is Subject to Compliance with Specific Installation Requirements.
EXTENDED WARRANTY:
ISIMET will extend the warranty period of the products when installation complies with all start up procedures and that
a factory authorized agent either performs or is in attendance during start-up of the system(s). Controllers, Companion
and Accessory Panels will be extended to a period of five years from date of installation. Except for ISIMET FLA, DLA,
RLA and other Units where automation systems are not common, Control System(s) must be interfaced with a building
automation system or other ISIMET approved time sequencing control for “non-use” system shutdown. All operating
components of the system must be ISIMET provided. Prescribed routine maintenance procedures must be performed per
ISIMET recommendations.
All Start-up and Routine Maintenance Documentation shall be per Factory Recommendation.
Further, required start-up and maintenance procedures must be performed as directed upon all affected systems. This
warranty shall only become enforceable upon issuance of application specific Extended Warranty Document. A copy of
this document should be maintained at all times at the location of the warranted systems.
DISCLAIMER OF IMPLIED WARRANTY:
THERE ARE NO WARRANTIES THAT EXTEND BEYOND THE DESCRIPTION HEREIN. SELLER DISCLAIMS
ANY IMPLIED WARRANTY OF MERCHANTABILITY OF THE GOODS OR OF THE FITNESS OF THE GOODS
FOR ANY PURPOSE, AND BUYER AGREES THAT THE GOODS ARE SOLD “AS IS.”
NOTE: Only qualified craftsmen licensed within the governing jurisdiction to perform the work associated with this
installation should install and/or service this equipment.
Printed in the United States

3
Specifications:
Control Panel - Stainless Steel 16 gauge
9.875 X 16
9.875 X 18 * where 12 vdc output is provided
Wall Box – 16 gauge powder coated sheet metal
6.0 X 12.25 X 4.0
6.0 X 14.25 X 4.0 * where 12 vdc output is provided
* all dimensions are in inches
Output Reset Switch: (Where Provided)
Reset Switches are specifically rated to
accommodate output load requirements.
Styles:
Single Source – Unit provides a single workstation with control over 120-vac convenience outlets as well as up to three
24 or 120-vac solenoid valves to operate domestic water and/or natural gas at the station. A single
switch controls all output circuits.
Companion –The Single Source Unit is configured so as to serve as a companion output source for our
Utility Controller where the application requires a single workstation such as an instructor’s
demo station to be controlled by a single remote output circuit.
•All Standard Styles are provided with Panic Button Assembly.
•Transformer ratings are determined by actual application requirements.
Styles
# Output
Circuits
Trans-
former
Panel
Fuse
pcb
Fuse 1
Output Rating
(Standard)
Relay Rating
LA –2 &
LA - 3
2 @ 120 vac
1 amp
20 amp
1 amp
15 amp @ 120 vac
Max.
1 @ 15 amp @ 120 vac
1 @ 2 amp @ 120 vac
LA –2 &
LA - 3
2 @ 24 vac
3 amp
5 amp
3 amp
2 @ 2 amp @ 24 vac
3 amp MAX
2 @ 2 amp @ 24 vac
LA –2 &
LA - 3
1 @ 120 vac
1 @ 24 vac
3 amp
20 amp
3 amp
1 @ 15 amp @ 120 vac
1 @ 2 amp @ 24 vac
1 @ 15 amp @ 120 vac
1 @ 2 amp @ 24 vac
Output fuse on PCB, FUSE 1 is Slow Blow. PCB circuit fuse, FUSE 3 is 500 mA Fast Acting
Inclusion of 12-vdc output does not change the ratings as shown in the table.

4
Wall Panel Terminal Mounting Brackets (2)
Mounting
Screws
(4)
Mounting Instructions: Flush Wall Mount
Two mounting flanges with screws are provided with the
unit. Attach flanges as shown. Flanges can be affixed to
any two corners of the unit. Then, fasten unit between
two (2) wall studs. The face of the box should be even
with the face of finished wall surface. After mounting
unit, protect interior of box from construction debris.
CAUTION: Provided mounting hardware must be used.
Mounting Instructions: Casework Mount
Two mounting flanges with screws are provided with unit.
Holes are slotted to permit adjustments for variations in
cabinet material thickness. Attach flanges as shown in
figure above. Make cutout in desired location in casework
to permit wall unit to pass easily into opening. From within
the cabinet fit into opening and fasten unit to back of
casework. Face of wall box should be even with face of
cabinet. After mounting unit, protect interior of box from
construction debris.
CAUTION: Provided mounting hardware must be used.
Mounting Instructions: Surface Mount
In order to surface mount the unit, it is necessary to attach
the provided brackets to the rear of the housing. Care should
be taken to verify that the mounting means securely fastens
the unit to the wall surface. A stainless skirt is provided in
order to conceal the wall box from view.
CAUTION: Provided mounting hardware must be used.
Output
Terminal
Wall
Casework
Mounting the Wall Panel:
•Verify that Unit is wired with Junction box cover in
place.
•With the Door open, position the Wall Panel over the
Wall Box as shown.
•Holding panel in front of box, insert the cable connector
into the socket on the pcb and tighten the screws.
•Then affix panel to box using four (4) 8-32 stainless
screws
•Close the panel and lock.
CAUTION! Do not install the panel until all wall finishes
are complete.

5
Monitoring Circuit- JP3
Output Configuration Jumpers
@ Panic Output
1 jumper across center two posts
= dry-contact @ CON 5-a.
2 jumpers across each pair of posts
= 24-vac output @ CON 5-a.
CON 5-b is always dry-contact.
Output Circuits
Where Reset Switches are provided @ Output Terminal, DO NOT Bypass.
12-vac Output is intended for use W/ ISIMET Fuel Gas Sensoe and CO Sensors where required by manufacturer.
Care should be taken to insure that polarity is correct in order for 12-vdc solenoids to function as intended.
WARNING!! Other pcb Jumper placements
Jumpers at JP 1, JP 4 and JP 5 are factory placed in order to configure the circuit board to specific functions for the
Controller. Removal and/or re-placement may cause the unit to malfunction.
Output Terminal:
120-vac Solenoid(s) connected to1 & 2 @ Output Terminal
OR 1& 2; 1 & 3 where 2 120-vac Solenoids are provided.
24-vac Solenoid connected to 3 & 4 @ Output Terminal.
NOTE: Only make conections of solenoids @ Terminal
Posts specifically marked as Solenoid Output.

6
Installing the Electrical Conduit:
Knockout holes for connecting the electrical conduits are located at the top left and right of the Wall Box.
•Connect rigid conduit for the required 120-vac electrical service.
•Connect conduit for the operating power to the upper left top of the enclosure at the junction box.
•Connect conduit for the operating power for the output to the upper right top of the enclosure.
Wiring the Unit:
Important!
Verify that the electrical supply is disconnected prior to connecting wiring to the Utility Controller.
To wire the Controller:
1. Remove the junction box cover.
2. Make final connections to the 120-vac electrical service to wiring within the junction box. Verify that line
wiring (Black), neutral (White), and ground wire (Green) are correctly connected.
Minimum recommended wire size is 14 AWG.
3. Replace the junction box cover before activating or testing the unit.
Output Wiring Configurations:
The Unit is factory configured as either 24-vac or 120-vac outputs. Two to Four output terminals are provided
based on specifications for the Unit. The unit is equipped with a dedicated 120-vac rated at 15 amps for connection
of a single convenience outlet circuit. See page 5 for typical wiring schematics. Do not attempt to modify the unit
to accept other than voltage outputs as specified for the unit. To replace a PC Board not configured correctly for a
specific application, contact the factory or a local representative.
Optional Input Control circuit:
“EMS” Input: 24-vdc /vac active OFF will disable the operation of the unit.
Alarm Input: 24-vac/vdc active OFF. Refer to jumper configuration chart above. Make connection of this optional
wiring at CON 4.
Optional Remote Panic Input Connection:
An optional input from an ISIMET Remote Panic Assembly can be connected to the PCB at CON 4-a.
Optional Panic Output Terminal:
A configurable Panic output is activated at CON 5. See configuration chart and location of this connector
on page 5.
Connection of the Wall Panel Plug:
The Unit is equipped with a 9 pin d-sub connector
•Turn counter-clockwise the two retaining clips at the top of the Panel, and open.
•Insert plug onto circuit header on PCB.
•Turn Power ON.
•Close the panel and lock.
CAUTION! Do not install the panel until all wall finishes are complete. Verify that the plug is configured
correctly. Incorrect insertion will prevent operation of unit.
Important!
All local codes must be followed when installing the unit and connecting the conduit to the service panel and
making wiring connections. Do not install wiring or cable for integrated systems, remote panic assemblies or
other interface wiring within conduit for either 24-vac control or 120-vac line voltage. Each wiring system
including outputs should be housed in independent conduit and not bundled with wiring for other systems.

7
Failure to comply with these wiring specifics may create transient voltage at the pc board and cause system
malfunction and/or failure.
Operation of the Unit:
CAUTION: Having outlets such as Gas Turrets Open when Services are activated can result in injury or death.
Verify that these outlets are closed prior to activating the unit.
With the panel service switch(s) ON, engage the Key-switch. The circuit(s) will activate and the panel Green LED
will illuminate to indicate that the services are active. After turning a switch OFF, it will be necessary to re-engage
the Key-switch in order to reactivate the services.
After turning the switch OFF, it will be necessary to re-engage the key switch in order to reactivate the service. The
Red LED will illuminate when the services are OFF.
Pressing the panic button will deactivate the services. All Panel lights should illuminate with Panic.
Receipt of an Alarm Signal will deactivate the services. All Panel LEDs will illuminate and all output circuits will
turn OFF.
Once in Panic or Alarm Modes the Key-switch must be engaged in order to reactivate service. The Alarm Signal
must be withdrawn prior to reactivation.
Power to the solenoids should be turned OFF when utilities are not in service.
Equipment Maintenance:
The LA Series Controller should have semi-annual inspections.
ISIMET recommends that you periodically conduct a brief test of the system to verify that the output circuit
performs as intended.
If examination of the unit indicates tampering, ISIMET recommends that you first review the installation and
wiring portions of this manual prior to placing the unit in service.
ISIMET recommends that when solenoids are operated by the unit, the piping systems be thoroughly flushed
and cleaned and tested for leaks prior to placing the system into use. Periodic testing of these solenoids will
assure that the piping system continues to function properly.
If you have any questions regarding the operation and maintenance of the Utility Controller, please contact an
ISIMET Service Representative.
The enclosure has a NEMA 1 rating. It is not intended for use in wet areas. Exercise caution to prevent exposure of
the interior compartment of the enclosure to moisture. If moisture is present within the enclosure, ISIMET
recommends that the control switch be turned OFF, power be disconnected from the unit until the source of the
moisture is determined, and all moisture is removed from the compartment.
The electronic controller (PCB) is sensitive to dust and other air-borne particles. Do not expose the interior
compartment of the enclosure to dust. During the semi-annual inspection, if dust or other material is present,
ISIMET recommends that you remove all foreign matter before operating the unit.
If the Unit fails to operate, ISIMET recommends that you check the power supply to the unit. With the control
switch in the ON position, LED Fuse 1 should illuminate. If not, check the service breaker.
If the fuse is not damaged and the unit still does not function, contact ISIMET or your local Service Representative.
CAUTION:
ISIMET DOES NOT recommend that service to emergency and/or safety devices, such as emergency
showers and eyewashes, be controlled by the Utility Controller System or Solenoids. Such devices are
intended to operate independent of restrictive authority operation, as is the case with the design of this unit.
ISIMET makes available components for the monitoring of such safety devices. Please contact ISIMET
regarding any questions regarding this type of application.

8
ISIMET/MAPA, LLC
PO Box 129 (Mailing)
103 W. CJ Wise Pkwy
Naples, Texas 75568-0129
Phone [phone]
Fax [phone]
www.ISIMET.com
Innovative Systems
Integrating
Mechanical and Electrical
Technology
ISIMET believes that sole and local authority means that the primary operator or the
instructors should have the sole authority to start and stop the utility services within the
immediate area of use during normal usage. This should distinguish this type of operating
environment from that where a single emergency shut-down device is located remotely from
the areas of use. As an example, the ISIMET system is not specifically intended for use in
applications where a master shut-down and re-instate device is located away from areas of
normal use. ISIMET’s opinion is that in such cases there is risk that the operator of the system
during re-start may inadvertently activate utilities in an unoccupied area that is remote from
the present occupancy, thus creating the risk of injury and/or fire where the utility is fuel gas.
