Isimple Pxdp User manual

Add iPod Capability to

Your Factory Radio

iSimple Solutions®,

A division of AAMP of America™

13160 56th Court Clearwater, Florida 33760

Ph. 866-788-4237

[email protected]

Owner’s

Manual

PXDP

SoundByte

01-27-11

Table of Contents

Pages

CHAPTER 1-Getting Started

1.1 Introduction 4

1.2 Precautions 4

1.3 Conguration & Harnesses 5

1.4 Programming the PXDP 6

CHAPTER 2-General Installation

2.1 Installation Location 7

2.2 Pre-Installation Checklist 8

2.3 Wiring Connections 8

2.4 Installation at Changer Location 10

2.5 Installation at Radio 11

CHAPTER 3 -Operation

3.1 Operation 13

3.2 Troubleshooting 15

3.3 Warranty 16

3.4 Warning 16

3.5 FCC Statement 17

Dipswitch Settings & Harness Guide 18

PXDP Connections

Factory Radio

(not included)

Vehicle Specic Harness

( actual harness may vary)

iPod Input

PXDP Interface

Chapter 1- Getting Started

1.1 Introduction

Thank you for purchasing the PXDP iPod Interface, by

iSimple®. The PXDP is designed to provide endless hours

of listening pleasure through most vehicles’ factory radios.

To ensure that your iPod performs correctly in your car or

truck, we recommend that you read this entire manual before

attempting installation of the PXDP interface.

The PXDP interface will allow you to connect your iPod to

a factory radio that has the ability to control a CD changer.

The PXDP is designed to be used with most iPod Models

featuring the 30 pin docking port.

1.2 Precautions (Important, Please Read)

UPDATING iPod FIRMWARE

For proper operation of the PXDP, your iPod must be

updated with the most recent version of Firmware from

Apple. This is done on your computer. To Update the

software on the iPod go to http://www.apple.com/ipod/

download/. Follow the directions on the website to complete

the download. There is no charge for this update.

PREVENTING DAMAGE TO YOUR VEHICLE OR iPod.

The manufacturer recommends unplugging the iPod when

not in use.To eliminate the risk of an electrical short, we

recommend disconnecting the car battery in most vehicles,

prior to installation except in the following situations:

• Vehicles equipped with on-board navigation should not

have the car’s battery disconnected. Doing so may cause

loss of memory settings. These settings would then have

to be reprogrammed by an authorized car dealer for a fee

to be paid by the vehicle’s owner. For these vehicles, we

recommend extreme caution when handling exposed 12V

power or ground wires/connectors.

•Vehicles that incorporate a security-code protecting the

radio. If the car’s battery or the radio’s power plugs are

disconnected, the radio will not operate without re-entering

the security-code. If you have access to the security-code,

feel comfortable disconnecting the battery and the radio’s

power connectors. Otherwise, do not disconnect the battery

and exercise extreme caution while handling exposed 12V

power or ground wires/connectors.

PROPER MOUNTING LOCATION

Securely install the interface in a location free from; heat,

humidity, moving parts or direct sunlight. Beware of hot-

air ow from your vehicle’s climate control system. We

recommend securing the interface to a suitable location, free

of sharp metal edges, using; double sided tape, Velcro or

wire ties.

1.3 Conguration and Harness Selection

This section will instruct you on how to properly identify and/

or conrm the proper interface dip-switch conguration and

vehicle specic harness selection.

Use the guide located in the back of this manual on page 18

to locate your vehicle, inform you of the proper dip-switch

conguration for the interface, and the vehicle specic

harness that you will need for your particular vehicle.

Depending on the type of PXDP kit you purchased, it might

include a bundle of different vehicle harnesses or none at all.

If the kit contains many harnesses, only one will be needed

for your specic vehicle. If the kit came without any vehicle

harness, your authorized iSimple® dealer will have the

harness for you to purchase separately.

PXDP interface Docking cable

PXDP Interface Docking Cable Vehicle Specic Harness

As you consult the application guide, please take a moment

to review our IMPORTANT COMPATIBILITY NOTES listed

with each of the vehicle manfactuers. These notes will

inform you of any issues or circumstances that can affect the

compatibility of our product with your factory audio system

and accessories. Some situations result in the loss of use

of some factory audio players. Please read and understand

these notes before proceeding with the installation.

1.6 Programming the PXDP

Now that you have identied the correct harness and dip-

switch conguration using the application guide, it is now

time to program the interface. To program the interface, set

the dip-switches located on the side of the interface (see

Fig.1 below) to the congguration listed for your vehicle in

the application guide. Switches are in their default setting of

“off” in the up position and are turned “on” when switched

down. This programs the PXDP to work with the vehicle

in which it will be installed. The dip-switches MUST be set

before the interface is plugged into the vehicle. Otherwise

the PXDP will not work correctly.

Please Refer to Page 18 for Conguration Settings

PLEASE NOTE: If after installation you experience low

volume from the interface, Dipswitch 6 can be turned on

for a 6Db gain.

12345678

DIPON

Fig.1 Side view of Interface with dip switches

Chapter 2- General Installation

2.1 Installation Location

Most installations will require you to remove the factory

radio in order to plug in the vehicle specic harness. Some

vehicles may require you to connect the interface to a factory

pre-run CD changer cable. The location of these CD changer

cables will vary by vehicle. Some common locations of these

cables are in the trunk, behind the glove box, and in or under

a center console. ( see Fig.2 below)

Common Connection Locations

SEEK

SCAN

RDS

VOL

PWR

TUNE

DSP

BAND

TAPE

DISC

INFOTRAF

SEEK

TYPE

AUTO

VOI

3 4

125 6

Fig. 2

iPod

PXDP

interface

(Sold Separately)

Refer to Application Guide

correct harness

iPod Docking Cable

2.2 Pre-Installation Checklist

At this time and before beginning the installation

please ensure that:

• You have read and understand the precautions

outlined in section 1.2

• Your iPod’s Firmware is up to date. (section

1.2)

• You have your radio’s security code.(when

applicable, see section 1.2)

• The dip-switches on the interface have been

set with the proper conguration. (see section

1.3)

• You have in your possession the correct

harness for your vehicle. (see sec. 1.3)

• You have determined your installation location.

(see section 2.1)

If any of these steps has not been taken,

STOP. Only when ALL of these steps have been

taken should you proceed with the rest of the

installation.

2.3 Wiring Connections

Some vehicle specic harnesses require wiring connections

that involve splicing of wires. If you are not condent in

making these connections to your radio’s wiring harness, we

recommend you seek professional installation. You can visit

www.isimplesolutions.com and click on the dealer link at the

top of the page to nd an authorized professional installer.

Make these connections only after verifying the proper circuit

on your radio harness with a voltmeter. With the key OFF

and the negative test lead of the voltmeter rmly touching a

bare metal chassis part of your car, begin probing the wires

in the main radio harness with the positive test lead. The

constant 12V+ circuit should read a continuous 12 volts or

higher.

Once you’ve identied the constant 12V+ circuit, strip

back about 1/8” of the insulation. Now take the positive

test lead and insert it into the wire stranding so that you

can now probe for a suitable ground location in the dash

cavity using the negative test lead. Bare chassis metal is

the recommended ground spot. The voltmeter will read a

constant 12 volts or higher when you have found a good

ground point. Attach the BLACK ground wire to this spot

with either an existing bolt or screw or use a metal piercing

screw. You also have the option of splicing into the ground

wire in the main radio harness. Probe the remaining wires

with the negative test lead until you again nd a circuit that

reads a constant 12 volts on the voltmeter. When you’ve

found a circuit that reads constant 12 volts, turn the dash

light dimmer control to make sure you have not probed the

illumination dimmer circuit. If the circuit continues to read

a constant 12 volts or higher regardless of the dimmer

position, you have found the ground wire. If not, continue

testing until you do. Some vehicles do not have a ground

wire in their main radio harness and instead ground through

their mounting brackets to the dash. In these cases, you

will have to ground the black wire to the bare metal chassis

inside the dash . Once the ground wire is connected, please

nish your wiring connections by splicing in the external

YELLOW wire from the vehicle specic harness.

Vehicle Specic Harnesses that require wiring

connections:

PXHFD1 – connect the Yellow wire to constant 12V+ &

connect the Black wire to ground.

PXHFD2 – connect the Yellow wire to constant 12V+ &

connect the Black wire to ground.

PXHFD3 – connect the Yellow wire to constant 12V+ &

connect the Black wire to ground.

PXHGM3 – connect the Yellow wire to constant 12V+ &

connect the Black wire to ground.

PXHVW2 – connect both the Black and Black/White wires to

ground.

2.4 Installation at the CD Changer Location

In this section you will learn how to install the PXDP in the

factory CD changer location. If your vehicle is equipped with

a factory CD changer you will need to disconnect it from

the factory pre-run harness in order to connect the PXDP

interface. If your vehicle is not equipped with a factory CD

changer, you will need to locate the factory pre-run harness.

This may involve the removal of the; center console, glove

box, or carpeted side panels in the trunk. Please consult

your vehicle’s dealership or a local car audio professional

for instruction or assistance with locating the factory CD

changer connection if necessary.

1. Connect your vehicle specic Harness to the factory pre-

run CD changer harness in the vehicle.

2. Make any necessary wiring connections on your vehicle

specic harness. Please see section 2.3 for details on

making these wiring connections.

3. Now that the interface is connected to the radio, you

will need to test the operation of the interface before

permanently running the black iPod docking cable or re-

assembling the dash.

First, connect the black iPod cable to the iPod. The iPod

should indicate that it is being charged. Turn on the factory

radio and press the button that would activate the factory CD

changer to select the iPod. It may take up to three minutes

for the interface to initialize to the radio (this only happens

the very rst time you select the iPod). Once the iPod has

been selected, press Play on the iPod. You should be able

to hear the music on your iPod through your factory radio.

Now press the “Next Track” button on the radio. The iPod

should change to the next song on the iPod. By pressing

the “Previous Track” button on the radio the iPod should

change to the previous song. With the operation of the

interface conrmed, you may continue with the installation.

If you experience difculties in operation, please see our

troubleshooting chart in section 3.2.

4. Decide on a convenient location to mount your iPod.

5. Run the docking cable from the interface to the desired

mounting location. Use caution to not cut, pinch, or crimp

the cable during this step. Avoid moving parts, vehicle wiring

harnesses and areas of excessive heat when routing the

cable.

6. Secure the interface in the vehicle using; double sided

tape, Velcro or wire ties. Make sure to check for proper

clearance and avoid moving parts. Take into account the size

of the interface and the wire harness and do not force the

interface and harness into a space that is too tight, damage

to the harness may result.

7. Now that the interface is secured and the docking cable

has been run, you are ready to enjoy your iPod in your

vehicle!

2.5 Installation at the Radio

In this section you will learn how to install the PXDP behind

the radio. If your vehicle is equipped with a factory CD

changer or other external audio source, you will need to

disconnect it from the back of the radio in order to connect

the PXDP interface.

1. Carefully remove the radio from the vehicle. If your radio

uses a Security Code, make sure that you have the code

before unplugging the radio. Some vehicles require the use

of special tools to remove the radio. Please consult your

vehicle’s dealership or a local car audio professional for

instruction or assistance with radio removal if necessary.

2. Make any necessary wiring connections on your vehicle

specic harness. Please see section 2.3 for details on

making these wiring connections.

3. Connect the Vehicle Specic Harness to the CD changer

port on the back of the radio. Be sure to make a rm

connection but do not force it. If there is difculty making the

connection, please consult the application guide to conrm

your vehicle specic harness selection.

4. Now that the interface is connected to the radio, you

will need to test the operation of the interface before

permanently running the black iPod docking cable or re-

assembling the dash.

First, connect the black iPod cable to the iPod. The iPod

should indicate that it is being charged. Turn on the factory

radio and press the button that would activate the factory CD

changer to select the iPod. It may take up to three minutes

for the interface to initialize to the radio (this only happens

the very rst time you select the iPod). Once the iPod has

been selected, press Play on the iPod. You should be able

to hear the music on your iPod through your factory radio.

Now press the “Next Track” button on the radio. The iPod

should change to the next song on the iPod. By pressing

the “Previous Track” button on the radio the iPod should

change to the previous song. With the operation of the

interface conrmed, you may continue with the installation.

If you experience difculties in operation, please see our

troubleshooting chart in section 3.2.

5. Decide on a convenient location to mount your iPod.

6. Run the docking cable from the interface to the desired

mounting location. Use caution to not cut, pinch, or crimp

the cable during this step. Avoid moving parts, vehicle wiring

harnesses and areas of excessive heat when routing the

cable.

7. Secure the interface in the dash cavity behind the radio

using; double sided tape, Velcro or wire ties. Make sure to

check for proper clearance and avoid moving parts. Take into

account the size of the interface and the wire harness and

do not force the interface and harness into a space that is

too tight, damage to the harness may result.

8. Now that the interface is secured and the docking cable

has been run, you may reinstall the radio and replace any

panels that may have been removed to access the radio.

You are ready to enjoy your iPod in your vehicle!

Chapter 3- Operation

3.1 Operation

SELECTING THE IPOD

To select the iPod from the radio, press the button that would

normally activate the factory CD changer. This button varies

by vehicle manufacturers. In some applications the PXDP is

accessed like an XM reciever, In these cases you will press

the appropriate activation button. Some radio models require

pressing the “Seek >” button once, after pressing the CD

button. Yet, it may also be necessary to press Play on the

iPod itself to begin playback. In some cases, if it is the rst

time selecting the iPod from the radio it may take up to three

minutes for the PXDP to initialize.

CONTROLLING THE IPOD FROM THE RADIO

With the PXDP interface, the radio will control the iPod as

if it were a factory CD changer. Therefore, operation will be

done by using the same buttons you would use to control

a factory CD changer. For more details on your particular

radio, consult your vehicle’s owner’s manual.

The PXDP interface allows you to skip songs forward and

backwards and also to fast forward and rewind through a

particular song. In general, most radios will utilize “seek” or

“track” buttons to control these functions.

CONTROLLING THE IPOD FROM THE IPOD

The PXDP interface allows you to keep full control of the

iPod from the click wheel. You can browse les and change

playlist on the iPod. You can also skip songs forward and

backwards from the iPod. The PXDP interface does not

disable any functionality of the iPod!

RADIO DISPLAY DURING IPOD OPERTION

Some factory radio’s may show DISC and TRACK numbers

on the display of the radio. The PXDP interface does not

send any information from the iPod to the radio. This means

that the DISC and TRACK numbers shown on the display

will not and can not reect the song number on the iPod

due to the complex nature of the music library. Some factory

radio’s may ash zero’s on the display of the radio, or toggle

back and forth between 1:00 and 2:00. All these are normal

behaviors and do not represent a malfunction.

CONTROLING THE IPOD FROM THE STEERING WHEEL

CONTROLS

If your vehicle’s steering wheel controls have the ability to

select track and control the forward and rewind functions of

your factory CD changer, then they will also control these

same functions on the iPod.

3.2 Troubleshooting

SymptomCause Remedy

No Power Blown fuse in vehicle fuse

block. Replace fuse with same

amp rating. If the fuse

blows again, call tech

support.

No Power Bad connectionCheck cable and wiring

connection.

Alternator noise is heard

(Changes with Engine RPM) Improper wiring creates a

ground loop Install a Ground loop isola-

tor or seek professional

service from a local car

audio shop.

You can hear music from

the iPod but you cant con-

trol it from the radio.

The Firmware on the iPod

may not be updated. Update the Firmware on

the iPod. See section 1.2

of this manual.

Radio is not recognizing

PXDP interface Bad cables or cables are

not connected properly

between converter box and

car radio

Check connection and

Radio is not recognizing

PXDP interface interface -

ration for your car. (See

section 1.3)

Radio is not recognizing

PXDP interface Yellow and black wires are

not connected to Constant

12V+ and Ground. (When

applicable)

Please read wiring instruc-

tions in chapter 2 of this

manual and see if your car

requires to connect the

yellow and black cable to

power and ground

iPod Audio is Low or

Distorted PXDP interface is con-

nected with an external CD

changer or other external

factory audio source

Disconnect the factory

external audio source.

iPod is not charging Yellow and black wires are

not connected to Constant

12V+ and Ground. (When

applicable)

Please read your vehicles

section in this manual and

see if your car requires to

connect the yellow and

black cable to power and

ground

3.3 Warranty

One Year Limited Warranty

The quality controls used in the manufacture of this product

This warranty covers any supplied or manufactured parts

of this product that, upon inspection by iSimple authorized

personnel, is found to have failed in normal use due to

defects in material or workmanship. This warranty does not

apply to installation expenses.

Attempting to service or modify this unit, operating this unit

under conditions other than the recommended voltage will

render this WARRANTY VOID.

Unless otherwise prescribed by law, iSimple shall not be

liable for any personal injury, property damage and or any

incidental or consequential damages of any kind (including

water damage) resulting from malfunctions, defects, misuse,

improper installation or alteration of this product.

All parts of this iSimple product are guaranteed for a period

of 1 year as follows:

Within the rst 12 months from date of purchase, subject

to the conditions above, iSimple will repair or replace the

product at their discretion, if it is defective in material or

workmanship providing it is returned to an Authorized

iSimple’s Dealer, with PROOF OF PURCHASE from an

authorized iSimple dealer.

3.4 Warning

This equipment may be reset by unintentional electrostatic

discharge during operation. Exposure to direct sunlight or

extreme heat may cause damage or malfunction.

3.5 FCC Class B Radio Frequency Interference

Statement

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part

15 of FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause

harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more

of the following measures:

1. Reorientate or relocate the receiving antenna.

2. Increase the separation between the equipment and

receiver.

3. Connect the equipment into an outlet on a circuit different

from that of which the receiver is connected.

4. Consult the dealer or an experienced radio / television

technical for help

Notice : The changes or modications not expressly

approved by the party responsible for compliance

could void the user authority to operate the equipment.

Make Model Year Part # Harness Dip Switch Settings** Vehicle Specific Notes

Acura CL 1998-2000 PXDP PXHHD1 1,4,8 ON

CL 1996-1997 PXDP PXHCH2 1,4,8 ON

Integra 1998-2001 PXDP PXHHD1 1,4,8 ON

Integra 1992-1997 PXDP PXHCH2 1,4,8 ON

Legend 1992-1995 PXDP PXHCH2 1,4,8 ON

RL 1998-2002 PXDP PXHHD1 1,4,8 ON

RL 1996-1997 PXDP PXHCH2 1,4,8 ON

RSX 2002 PXDP PXHHD1 1,4,8 ON

TL 1999-2002 PXDP PXHHD1 1,4,8 ON

TL 1996-1997 PXDP PXHCH2 1,4,8 ON

Vigor 1992-1994 PXDP PXHCH2 1,4,8 ON

All Models 2003-2007 Not Compatible

MDX All Years Not Compatible

SLX All Years Not Compatible

NSX All Years Not Compatible

Make Model Year Part # Harness Dip Switch Settings* Vehicle Specific Notes

Audi All Models (Except Below) 1998-2004 PXDP PXHAD1 1,8 ON Connect at pre-wired 13-pin cable in the left rear trunk.

All Models (Except Below) 1998-2004 PXDP PXHAD2 + PXHVW2* 1,8 ON

Make Model Year Part # Harness Dip Switch Settings* Vehicle Specific Notes

BMW 3 Series 1996-2005 ISBM72 Included 3,4,8, ON Not Compatible with DSP radios, Trunk Mounting Location

5 Series 1996-2005 ISBM72 Included 3,4,8, ON Not Compatible with DSP radios, Trunk Mounting Location

7 Series 1999-2001 ISBM72 Included 3,4,8, ON Not Compatible with DSP radios, Trunk Mounting Location

Mini 2001-2006 ISBM72 Included 3,4,8, ON Not Compatible with DSP radios, Trunk Mounting Location

X5 1999-2005 ISBM72 Included 3,4,8, ON Not Compatible with DSP radios, Trunk Mounting Location

Z3/Z5 1998-2003 ISBM72 Included 3,4,8, ON Not Compatible with DSP radios, Trunk Mounting Location

Z4 2003-2005 ISBM72 Included 3,4,8, ON Not Compatible with DSP radios, Trunk Mounting Location

IMPORTANT BMW APPLICATION INFORMATION

ISBM71: Not Compatible with Factory Head Units with DSP. "DSP" will be indicated on a radio button. Not compatible with vehicles equipped with iDrive.

IMPORTANT AUDI APPLICATION INFORMATION

PXDP: Not compatible with any factory external audio source such as: XM tuner, CD changer, or Cassette player. These devices must be disconnected during the installation and will no longer function. Vehicles with Symphony sound systems must use

special adapter harness PXHAD2 as well as PXHVW2 and connect at radio.

*Dip Switch Settings: Please See Product Instructions for Dip Switch Configuration Settings

Dipswitch Settings & Harness Applications

IMPORTANT ACURA APPLICATION INFORMATION

dash 6 disk cd changer. Not compatible with navigation radios.

Make Model Year Part # Harness Dip Switch Settings* Vehicle Specific Notes

Buick Century 1997-2003 PXDP PXHGM1 & GMH32T 3,8 ON Must use GMH32T "T"-harness then plug *PXHGM1 behind radio.

Le Sabre 1999-2002 PXDP PXHGM3 1,3,8 ON

Park Ave 1995-2005 PXDP PXHGM1 & GMH32T 3,8 ON Must use GMH32T "T"-harness then plug *PXHGM1 behind radio.

Rainier 2005 PXDP PXHGM3 1,3,8 ON

Regal 1995-2003 PXDP PXHGM1 & GMH32T 3,8 ON Must use GMH32T "T"-harness then plug *PXHGM1 behind radio.

Rendezvous 2003-2005 PXDP PXHGM3 1,3,8 ON

Riviera 1996-1999 PXDP PXHGM1 & GMH32T 3,8 ON Must use GMH32T "T"-harness then plug *PXHGM1 behind radio.

Roadmaster 1995-1996 PXDP PXHGM1 & GMH32T 3,8 ON Must use GMH32T "T"-harness then plug *PXHGM1 behind radio.

Allure 2005 Not Compatible

LaCrosse 2005 Not Compatible

Make Model Year Part # Harness Dip Switch Settings* Vehicle Specific Notes

Cadillac Catera 2001 PXDP PXHGM2 3,8 ON Behind radio or Trunk Mounting Location

Deville 1995-2003 PXDP PXHGM2 3,8 ON or 1,3,8 ON Behind radio or Trunk Mounting Location

El Dorado 1995-2002 PXDP PXHGM2 3,8 ON Trunk Mounting Location

Escalade 1999-2002 PXDP PXHGM1 3,8 ON

Escalade 2003-2006 PXDP PXHGM3 1,3,8 ON or 2,3,8 ON

Seville 1995-2005 PXDP PXHGM2 3,8 ON

Make Model Year Part # Harness Dip Switch Settings* Vehicle Specific Notes

Chevrolet Astro Van 1996-2005 PXDP PXHGM1 3,8 ON

Avalanche 2002 PXDP PXHGM1 3,8 ON

Avalanche 2003-2006 PXDP PXHGM3 1,3,8 ON

Blazer 1998-2002 PXDP PXHGM1 3,8 ON

Camaro 1997-2002 PXDP PXHGM1 3,8 ON

Cavalier 1996-1999 PXDP PXHGM1 3,8 ON

Cavalier 2003-2005 PXDP PXHGM3 1,3,8 ON or 2,3,8 ON

Colorado 2005 PXDP PXHGM3 1,3,8 ON

Corvette 1997-2004 PXDP PXHGM2 3,8 ON Trunk Mounting Location

Corvette 1997-2004 PXDP PXHGM4 3,8 ON As a substitute, Can also use PXHGM1 and GMH20T Harnesses

Impala 1995-1999 PXDP PXHGM1 3,8 ON

Impala 2000-2005 PXDP PXHGM3 1,3,8 ON

Lumina 1996-1999 PXDP PXHGM1 3,8 ON

Malibu 1997-2000 PXDP PXHGM1 3,8 ON

Monte Carlo 1995-1999 PXDP PXHGM1 3,8 ON

slave may not be able to support an external device. Therefore the PXDP may not be compatible. If you are an experienced installer, you can retain XM. Please follow this link to the Tech Brief to retain XM:

http://peripheralelectronics.com/web/tech_dept.asp. 1995-1999 Radios with built in CD player (Except Corvette) are NOT compatible because they do not have CD changer control functions.

IMPORTANT BUICK APPLICATION INFORMATION

IMPORTANT CADILLAC APPLICATION INFORMATION

http://peripheralelectronics.com/web/tech_dept.asp. 1995-1999 Radios with built in CD player (Except Corvette) are NOT compatible because they do not have CD changer control functions.

Make Model Year Part # Harness Dip Switch Settings* Vehicle Specific Notes

Chevrolet Monte Carlo 2000-2005 PXDP PXHGM3 3,8 ON

Silverado 1996-2002 PXDP PXHGM1 3,8 ON

Silverado 2003-2006 PXDP PXHGM3 1,3,8 ON

Suburban 1995-2002 PXDP PXHGM1 3,8 ON

Suburban 2003-2006 PXDP PXHGM3 1,3,8 ON

Tahoe 1995-2002 PXDP PXHGM1 3,8 ON

Tahoe 2003-2006 PXDP PXHGM3 1,3,8 ON

Trailblazer 2002-2007 PXDP PXHGM3 1,3,8 ON or 2,3,8 ON

Venture 1997-1999 PXDP PXHGM1 3,8 ON

Venture 2004-2005 PXDP PXHGM3 1,3,8 ON or 2,3,8 ON

Make Model Year Part # Harness Dip Switch Settings* Vehicle Specific Notes

Chrysler All Models 2002-2005 PXDP PXHCH3 4,8 ON Must be non-CANBUS, if radio is an REF,REC,RAQ, RAK series, vehicles are not compatibl

All Models 1999--2001 PXDP PXHCH2 4,8 ON *1999 Radios with rounded corners use PXHCH2

All Models 1995-1999* PXDP PXHCH1 1,4,8 ON *1999 Radios with square corners use PXHCH1

Pacifica 2006 PXDP PXHCH3 4,8 ON

Sebring 2006 PXDP PXHCH3 4,8 ON

Make Model Year Part # Harness Dip Switch Settings* Vehicle Specific Notes

Dodge All Models 2002-2005 PXDP PXHCH3 4,8 ON

Must be non-CANBUS, if radio is an REF,REC,RAQ, RAK series, vehicles are not compatible

All Models 1999*-2001 PXDP PXHCH2 4,8 ON *1999 Radios with rounded corners use PXHCH2

All Models 1995-1999* PXDP PXHCH1 1,4,8 ON *1999 Radios with square corners use PXHCH1

Make Model Year Part # Harness Dip Switch Settings* Vehicle Specific Notes

Eagle All Models 1995-1998 PXDP PXHCH1 1,4,8 ON All models must have “Disc ^ ” printed on Preset Button # 1.

factory radio must have "Disk ^" on preset 1. Vehicle must be non-CANBUS, if radio is an REF,REC,RAQ, RAK series, vehicles are not compatible. The series is indicated on the front of the radio. 1999 Chrysler vehicles have one of two different style radios.

These two radios use different harnesses. The shape of the radio face will determine which harness you will use. If your radio face is SQUARE, you will use the harness part# PXHCH1. If your radio face is OVAL (rounded corners), you will use the harness

part# PXHCH2.

IMPORTANT CHEVROLET APPLICATION INFORMATION

IMPORTANT DODGE APPLICATION INFORMATION

you must disconnect it in order to be able to install the interface. You will lose the use of the factory CD changer to gain use of your iPod.

IMPORTANT CHRYSLER APPLICATION INFORMATION

IMPORTANT EAGLE APPLICATION INFORMATION

part# PXHCH2.

http://peripheralelectronics.com/web/tech_dept.asp. 1995-1999 Radios with built in CD player (Except Corvette) are NOT compatible because they do not have CD changer control functions.

This manual suits for next models

Table of contents
