Islander MR3 Series Technical specifications

Islander MR3 Series
MAINTENANCE INSTRUCTIONS
Thank you for purchasing an Islander MR3 model mooching reel.
In this manual you will find tips and instructions on how to keep your
new reel functioning like new for years to come. Concise illustrations
will help you clean and lubricate each important component.
FEATURES
Large arbor, ultra-light spool with ventilated arbor. The large
arbor allows for two to three times the retrieval rate of a standard
arbor.
A huge 2
7/16"
drag surface using Islander's proven Graphite
impregnated cork material. This, coupled with a dual phosphor
bronze pawl, translates incredible stopping power.
Converts from right to left-hand retrieve in seconds
Large,contoured palming rim and handles.
Buttery smooth sealed stainless steel bearings.
Large sculptured drag knob
REQUIRED TOOLS
REQUIRED TOOLS
Lar
g
e flat bladed screwdrive
r
(a North American dime can be substituted)
Synthetic light oil and grease
(we recommend Synco Superlube™ Oil and Grease with Teflon®)
Powdered Graphite
(Often used to lubricate door locks.)
Lint-free cloth or paper towel.
Isopropyl Alcohol
(70% concentration at least)
A small, soft, scrubbing brush.
(Soft toothbrushes work well.)
Q-Tips®






Spool
Diameter
(inches)
Spool
Width
(inches)
Spool
Volume
(inches³)
Weight
(ounces) Capacity
4.6 0.9 6.7 12.8 350 yards of
30 lbs mono
SPECIFICATIONS
FFor parts and service
call toll free: 1-888-404-1119
www.mikesreelrepair.comww.mikesreelrepair.com

4
1
5
2
6
3
1
0
7
11
8
12
9
1
3
14
1
6
1
7
1
8
2
0
1
9
2
5
2
3
1
5
Frame Assembly - MAINTENANCE - Rinse and dry after use.
Foot/Reel Seat - MAINTENANCE -Rinse and dry after use.
Pawl Assembly(ies) - MAINTENANCE - See References 16,17,18.
Spindle - MAINTENANCE - Remove all the old lubricant and any grit from the
spindle and apply a small amount of grease to the base of the spindle.
Clutch Surface - MAINTENANCE - Wipe surface to remove excess oil and graphite.
Apply a small amount of oil and powered graphite to the cork surface and work it
in with your finger. - See References 19 and 20 for further instruction.
Spindle O-Ring - MAINTENANCE. Remove old grease and any grit prior to clutch
(ref. 6) installation.
1
2
3,4
5
6
7
24
21
22
A. CARE AND MAINTENANCE
A. CARE AND MAINTENANC
tof
While
t
hi
s
reel i
sco
n
st
r
uct
e
dou
insecorrosion resistant materials, it is best to r
use
,
y
our reel off with warm water after each
a
ter
.
particularl
y
after exposure to salt w
a
Spool Assembly - MAINTENANCE - Rinse and dry after use.
Handle Assemby(ies) - MAINTENANCE -See ref. 24.
Front Spool Bearing - MAINTENANCE - Remove old grease and grit with a dry
cloth or one with a small amount of isopropyl alcohol (at least 70% USP). Apply a
small amount of grease to the exposed bearing shield.
Dragspring - MAINTENANCE - Remove old grease and any grit. Soapy water and a
tooth brush work the best. Rinse with fresh water. There is no need to regrease
the dragspring as lubricant from the Front Spool Bearing (ref. 11) will migrate into
the dragspring.
Dragknob Washer - MAINTENANCE - Remove old grease and any grit. There is no
need to regrease the washer, as grease from the dragknob (ref. 13) will migrate.
8
9,10
11
12
13
For parts and service
call toll free: 1-888-404-1119
www.mikesreelrepair.com

B
.
H
O
W T
O
DI
S
A
SS
EMBLE Y
OU
R REE
L
FI
G
.
1
Step 1
Remove the Spindle
Screw by turning it
counter-clockwise with
a flat bladed screw
driver.
Step 2
Remove the Dragknob
by turning it by hand
counter-clockwise until
you can remove it.
The dragspring and
dragknob washer may
follow the dragknob
out of the reel.
Dragknob - MAINTENANCE - Remove old grease and any grit. Clean center
threads using a Q-Tip or a small cloth. Apply a small amount of grease to the
back of the dragknob. Apply a small amount of grease to the internal
threads.
Spindle Screw - MAINTENANCE -Remove old grease and any grit. Apply a
very small amount of grease around the threads.
Pawl Assembly(ies) - MAINTENANCE - Remove old oil and any grit. Soapy
water and a tooth brush work the best. Rinse with fresh water. Apply a drop
of oil around the pawl(s) (ref. 16) and around the pawl springs (ref.17 and 18).
Clutch Assembly - MAINTENANCE - Remove old grease and any grit from the
bearing (ref. 19), inside and out. Apply a small amount of grease to the
bearing. Remove old grease from between the teeth of the clutch (ref. 20).
Apply a small amount of grease between the teeth.
14
15
16
17
18
19
20
Handle Assembly(ies) - MAINTENANCE - The handle assemblies need very little
maintenance. You may notice a black powder develop after long and extreme use.
This is normal. If your handles start to stick, you can remove the handle from the
base (ref. 21) by undoing the handle screw (ref. 23) and remove any grit. No
lubrication is required.
Clicker Assembly - MAINTENANCE -Remove old oil and any grit. Soapy water and
a tooth brush work the best. Rinse with fresh water. Apply a drop of oil through
each hole on the clicker and around the screw head (ref. 23) and a small amount of
oil around the clicker spring (ref. 24).
Rear Spool Bearing - MAINTENANCE - Remove old grease and any grit with a dry
cloth or one with a small amount of isopropyl alcohol (at least 70% USP). Apply a
small amount of grease to the exposed bearing shield.
21
22
23
24
25
Ste
p
3
Grasp the frame with
one hand and the
spool with your other
hand and separate
them.
FI
G
.
2
C. HOW TO REASSEMBLE YOUR REEL
Reassembly is the opposite of disassembly. Make sure when
you are reinstalling the drag knob, make sure the stainless steel
washer is under the dragknob and not the dragspring.
FIG
.
3
FIG 3
For parts and service
call toll free: 1-888-404-1119
www.mikesreelrepair.com

LEFT HAN
DR
ET
R
IEVE
.
FIG. 4 - Dra
g
set for ri
g
ht hand retrieve
.
gg
FIG 5. - Drag set for left hand retrieve.
g
Ste
p
1
D
isassem
b
le
y
our reel
as
p
er instructions on
the previous page
.
Ste
p
2
Remove the S
p
indle
O-Rin
g
(
see Exploded
Vi
e
w
o
f th
e
r
ee
l
o
n th
e
previous pa
g
e
)
.
Ste
p
3
Remove the
C
lutch
Assembl
y
(
see
Ex
p
loded View of the
reel on the
p
revious
pa
g
e
).
Ste
p
4
Arran
g
e the pawl
direction as
p
er FIG. 3
or FI
G
. 4 on the left o
f
this pa
g
e.
Ste
p
5
Re
p
lace Clutch
Assembl
y
and Spindle
O-Ring. Reassemble
r
ee
l
.
E. PRODUCT INFORMATION
Recommended Lubricants
Islander recommends the use of Super Lube® brand oil and grease with
Teflon® for all lubricating application. Superlube® is manufactured b
y
:
Synco Chemical Cop., N.Y. Teflon® is a registered trademark of E.I.
duPont DeNemours & co.
Oil: Super Lube® Multi-Purpose Synthetic-Based Oil with PTFE®.
Grease: Super Lube® Multi-Purpose Lubricant with Teflon®.
If you need to return your reel to Islander for service, please contact:
Islander Reels
6771 Kirkpatrick Crescent
Saanichton B.C. V8M1Z8 Canada
Phone [phone]
Fax [phone]
Email [e-mail]
www.islander.com
Islander recommends that you remove the line from your reel before
shipping it to Islander for service. To fix some problems, all the line has to
be removed and Islander cannot guarantee that the line will be replaceable.
