iSentry Buon Handle
Model: DL-BTN-HDL
Installaon and User Manual
i S m a r t L o c k s

1. INTRODUCTION
Item No.
Dimension
Material
Weight
iSentry Buon Latch
DL-BTN-HDL
154*68*78mm
Zinc Alloy
2.3Kgs
1-1 . Standard Single latch :
Latch length can be adjusted as 60mm or 70mm

Communicaon mode
1-2. Item Dimension:
Unlocking way
Support System
Unlock me
Power supply
Stac current
Working current
Bluetooth 4.0ble
Bluetooth, Code, Mechanical key
Android 4.3 / IOS 7.0 above
≈ 1.5 sec
4pcs AA baeries
≤30uA
≤200mA

2. INSTALLATION GUIDE
2-1. Installaon condion
● Door frame 110mm
● Door thickness: 38-50mm
2-2. Installaon instrucons step by step

3. FEATURES
(PS: A mobile phone can manage more than one smart lock; select the lock you would
like to manage)
Admin Bluetooth key: Press eKey icon to unlock via Bluetooth
Admin Password: Mobile Click sengs and set the admin passcode, only Admin can set
admin passcode
Bluetooth key remote authorizaon: The Admin can instantly send Bluetooth keys to oth-
er people’s mobile phone APP and can also limit the use of the Bluetooth key, by freeze,
authorize, set validity me
Password remote authorizaon: The app can generate permanent, cyclic, one-me, limit-
ed me and customized passcodes even in the absence of wi and internet
Password protecon: The smart lock will be automacally locked for 5 minutes when
the wrong password is entered 5 mes; You can enter any number of digits before the
correct password, make sure the last few digits are
the correct password can be unlocked.
Automac locking: Auto lock me can be set in “Sengs” between 5 to 120 seconds
aer unlocking
General lock: Press and hold ”#” for 5seconds
Lower Baery Consumpon: 4pcs AA baeries can provide 5000 openings (approx. 6
months)
Lower Baery Indicator: When baery power is low, the Bluetooth lock will emit low bat-
tery warning sound. The baery level is indicated on the app. If baery power runs out,
use 9V backup baery or mechanical key.
Real me monitoring: When users use app or password to unlock the Admin can nd
unlock records on APP.
Real-me reminder: Mobile phone and door lock connected click “ “on the upper right
corner of the interface you can query the record of received Bluetooth key and more
user informaon.

4. PROGRAMMING
4-1. Paring lock to the phone
1) Android Play Store, Search for the applicaon “TTLOCK”
2) App Store, Search for the applicaon “TTLOCK”
3) Register a new account (phone number or email) or login with an exisng account.
4-2. Unlock
1. Bluetooth: Press eKey icon in the app
2. Passcode : press the numbers and then press “#”
3. Mechanical Key : Insert Keys on the handle knob
4-3. Lock
1. Press and hold “#” for 5 seconds
2. Set auto lock : Check instrucon in Features given in secon 3
3. Mechanical key : Use Mechanical key
4-4. Modify the Admin password
Change admin passcode from sengs, remember admin passcode can only be congured when lock is con-
nected to app via Bluetooth. Recommended to change admin key when you are near your lock
4-5.Modify the Admin
A door lock can only have one Admin，you need to delete the original Admin. Go to sengs of the lock and
press “Delete” which is right at the end of the sengs secon of the app. You can only perform this opera-
on when next to lock and the lock is connected via Bluetooth to the app
4-7. The Admin’ s phone has the right to freeze, delete, authorize, and rename for the electronic key that
has been sent
Select the lock, press eKeys, it will then show eKeys, select the eKey that needs to be managed and set the
validity sengs or just press delete if it is no longer required
4-8. Password remote authorizaon，Admin’ s phone can remotely send password to other users to un-
lock， Press “send passcode” and generate permanent, one-me, cyclic, med and custom passcodes. Once
generated, advise the person via phone, e-mail or SMS
4-9. The Admin’ s phone has the right to rename, delete the password that has been sent
Press “passcodes” and select the passcode that needs to be changed and change the validity

Permanent password: The password will be valid in long-term with unlimited mes to open the door.
(PS:User need to open the door with already set password within 24 hours, otherwise, it will be invalid.)
Timed password: User can open the door randomly with set password in a limited me. Like a week, an
hour, a day, 30 minutes...etc.(PS:User need to open the door with already set password within 24 hours,
otherwise, it will be invalid.)
Cyclic password: set specic me on each week period. For example, you can set up a period 10:00-
11:00am on every Saturday for housekeeper to enter your house, then they can only open the door during
10:00-11:00am on Saturday. Any other me, the password is invalid.
One-Time password: User can only used the password to unlock the door for one me, the password will
be eecve within 6 hours aer set-up
5. Changing baeries
To open the baery compartment, unscrew the back panel and put 4pcs AA baeries.(It is recommended
to use a beer baery, 4 baeries using the same brand).
Find installaon videos on the website under support tab.
