Compel™Horizontal Light Install Instructions
(Part #’s: 690UVX)
IMPORTANT SAFETY INSTRUCTIONS. READ CAREFULLY FOR YOUR PROTECTION AND SAVE ALL INSTRUCTIONS.
*Disconnect power before installing, adding or changing any component.
*To avoid a hazard to children, account for all parts and destroy all packing materials.
General Care and Cleaning
Long life and the exceptional performance of any equipment is dependent upon the care it receives. To ensure a long life, proper sanitation, and minimum maintenance costs, these
lights should be thoroughly cleaned, and wiped down weekly, at a minimum. Surfaces may be cleaned with a mild detergent and warm water to protect and maintain their appear-
ance.
•Do not use abrasive cleaners or scouring pads, as these will damage or scratch the light.
•Do not use solvent, oil or acidic-based cleaners on any interior surfaces.
•Do not use steam or high water pressure hoses to wash the lights. These will cause leaks and poor performance or potential failure.
Please visit www.itc-us.com for warranty info
1. Screw Mount Installation: For screw mount clips, draw a
center line on your mounting surface using a straight edge or
the side of the light. Mark the holes for each mounting clip.
Screw the mounting clip to the mounting surface using the
supplied screws. Do not over torque screws. Over torquing
screws will result in damage to the clips and/or stripped out
holes.
Snap light into clips by tilting light into clip.
2. Magnetic Mount Installation: Snap magnetic clips on to
lights, ensuring clip completely attaches to groove on light.
Install light in desired location.
Min: 8”
Max: 18”
PARTS/TOOLS NEEDED:
Compel Light Jumper Cables
(purchased separately)
Mounting Brackets
(purchased separately)
Pigtails
(purchased separately)
UL Approved
Power Supply
(purchased separately)
Power Drill
(not provided)
Make sure clip snaps
over groove
3. Adhesive Mount Installation: Make sure to clean the
mounting surface with a 50/50 mixture of alcohol and water prior to
installation. For proper adhesion, clips should be mounted between
60°F and 100°F. For more detailed instructions* please refer to the
3M™website. Snap clips onto back of light and remove the paper
backing. Press light in place.
*http://www.3m.com/3M/en_US/bonding-and-assembly-us/resources/full-story/?sto-
ryid=b3996cbd-9954-455f-8e72-88e452ca38c0

3030 Corporate Grove Dr • Hudsonville • MI • 49426
Phone: [phone] • www.itc-us.com • [email protected] • Revision 6: 05/29/19
6. See wiring diagram below for power supply wiring instructions.
AC Power
120V/277V
= Wire Nuts or Terminal Block
120V/277V -
24V Class 2
Power Supply
AC DC
Brown (L)
Black (L)
Blue (N)
White (N)
Black (-)
Red (+)
Red (+) Black (-)
Compel Light
Connector
Cord
4. Plug the 12” connector cord into the light making sure to be
careful not to damage the connector pins inside the light. Then,
place the light in desired location.
5. If wiring multiple lights use a jumper cable to connect two lights
together. If using only one light simply plug a pigtail (ordered
separately) into the 12” connector cord and then wire to the
power supply as shown in Figure 1.
Make sure cord
snaps over raised
portion
Wiring with the 2” Add-On
Wiring to Pigtail
Barrel connector cord option
