ITC elio Wander Configuration guide

3030 Corporate Grove Dr • Hudsonville • MI • 49426
Phone: [phone] • www.itc-us.com • [email protected] • DOC#: 710-00114 • Rev C: 08/20/20
For warranty information please visit www.itc-us.com/warranty
Wander Flexible Light Install Instructions
(Part #: HMTLVVKK-LLLWL-10)
Safety Instructions
• Disconnect power before installing, adding or changing any component.
• To avoid a hazard to children, account for all parts and destroy all packing materials.
• Do not install any luminaire assembly closer than 6” from any combustible materials.
5. Follow the wiring diagram below to wire the light to your system.
1. Determine installation location and
drill a hole in the mounting surface.
Installation Considerations For All Flexible Lighting Products
• Do not bend lighting more than necessary. Refer to page two for bend radius minimums.
• Only bend the LED ribbon in one natural direction, do not try to bend in an unnatural direction such as twisting.
**Installation Considerations For H Flexible Lighting
• Unroll the entire length of HMTL before installing.
• Start installation at the wire lead end.
• When installing the light on the mounting surface, make sure to push towards the wired end.
• Do not use any roller as that may cause damage to the LED circuit.
PARTS / TOOLS NEEDED:
Application Specic
Sealant
Flex Light & Mounting Clips Power Drill
(not provided)
#6 pan head screws
(not provided) (not provided) Butt Splices (not provided)
HMTL Flex Light
Black (+)
Red (R)
12V DC (+)
Black (-)
Incoming
12V DC
Power
Fuse
2. Secure clips to mounting surface
using #6 pan head screws
(not provided).
3. Feed the wires into the hole and apply
application specic sealant* around the
hole and wires.
*Sealant here
*Clip spacing is dependant on application, when
going around curves clip spacing should be closer.
4. Secure the light in the track by gently
pushing into clips
*Please review the considerations on page 2 to ensure a successful installation.
*HMTL exible lighting cannot be eld cut. Field cutting the light will void the warranty.
12V Wiring
Red (-)
White (-)*
Green (-)
Blue (-)
Red (+) Black (-)
Incoming
12V DC
Power
HMTL Flex Light
RGBW
Controller
sold separately
Black (+)
*Note the RGB lights will not have a white wire

3030 Corporate Grove Dr • Hudsonville • MI • 49426
Phone: [phone] • www.itc-us.com • [email protected] • DOC#: 710-00114 • Rev C: 08/20/20
For warranty information please visit www.itc-us.com/warranty
5.04
4.33
R20.0" MIN
DESIGN STATE:
INSTALLATION INSTRUCTION
Do not twist tapelight
ALWAYS INSTALL WIRE END FIRST!
CAUTION
MINIMUM BEND RADIUS
LATERAL BEND
R0.562" MIN
TOP TO BOTTOM BEND
5 Cont. Follow the wiring diagram below to wire the light to your system.
HMTL Flex Light
Red (+)
Black (-)
Green (G)
Neutral (N)
Load (L)
To 110V - 277V
Power
Positive (+)
Negative (-)
Constant Voltage
Class 2 Power Supply
13.6 V DC or 24V DC
Red (-)
White (-)*
Green (-)
Blue (-)
Red (+) Black (-)
Constant Voltage
Class 2 Power Supply
13.6V DC or 24V DC
HMTL Flex Light
RGBW
Controller
sold separately
Green (G)
Neutral (N)
Load (L)
Black (+)
*Note the RGB lights will not have a white wire
