ITE IT9500 Series User manual

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 0Copyright 2012-2014, ITE Technologies, Inc
ccHDtv Return Channel User Guide
(USB UART kit)
Revision Log:
ITE Tech. Inc.
Easy HD Expressway
® ®
Revision
Date
Author
Remarks
1.0
2013/09/17
Ryan
Initial Release
1.1
2014/03/06
GUI version
1.1
2014/3/14
Chapter 3.2
1.2
2014/9/17
Tool update
2014/12/31
USB dongle kit
2014/01/27
USB UART kit
1.3
20150224
Jeff
Configure the video stream

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 1Copyright 2012-2015, ITE Technologies, Inc.
Table of Contents
1. Introduction............................................................................................................3
2. Installation..............................................................................................................4
2.1 Install USB UART Dongle .......................................................................4
2.2 Install Config Tool ReturnChannelGUI....................................................5
3. Configuration Tool (Return Channel GUI) Usage.................................................7
3.1 Launch the config tool kit.........................................................................7
3.2 Initialization..............................................................................................7
3.3 Basic Settings............................................................................................9
A. Imaging Settings .....................................................................................10
B. Bit Rate Settings .....................................................................................10
C. Channel Frequency and Bandwidth Settings..........................................10
3.4 Set Transmission Parameters ..................................................................12
3.5 Set Single Stream Output........................................................................16
3.6 Configure Encoded Video Stream Frame Size........................................16
3.7 Set Other Configurations ........................................................................17

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 2Copyright 2012-2015, ITE Technologies, Inc.
Table of Figure

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 3Copyright 2012-2015, ITE Technologies, Inc.
1.Introduction
This document describes how to use Return Channel test kit and USB UART dongle
to control ccHDtv DTV CAM in PC Windows environment.
USB UART dongle,
If you use receiver dongle/board with return channel feature to configure the camera,
please refer to the document “Config Tool with RC receiver kit (Return Channel GUI)
User Guide”,
USB receiver dongle or board with return channel feature,
The following picture shows the profile of the environment setup with USB UART
dongle.
USB UART
Dongle
DTV CAM
(DC-099BB)
PC Windows

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 4Copyright 2012-2015, ITE Technologies, Inc.
2.Installation
2.1 Install USB UART Dongle
You may connect the UAB UART to a Laptop PC.
On most Windows platforms, the driver will be installed with in-box driver
automatically.
However, if Windows prompts to install driver for the new device, please run
“PL2303_Prolific_DriverInstaller_v1.7.0.exe”, which can be found in the folder
“\PL2303_Prolific_DriverInstaller_v1.7.0”
If the device driver is installed well, there will be a new Com Port device, shown in
Windows Device Manager.
The com port assignment may vary depending on the PC configurations. In the
following example, COM5 is assigned.

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 5Copyright 2012-2015, ITE Technologies, Inc.
Note: the wirings between the USB dongle and camera UART port,
USB dongle RXD—Green—Camera UART TXD
USB dongle TXD—White—Camera UART RXD
USB dongle GND—Black—Camera UART GND
2.2 Install Config Tool ReturnChannelGUI
In the folder \ReturnChannelGUI, click on “Setup.exe”to run the installation.
After installation, you should find the kit in the folder ITE of the start menu.

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 6Copyright 2012-2015, ITE Technologies, Inc.

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 7Copyright 2012-2015, ITE Technologies, Inc.
3. Configuration Tool (Return
Channel GUI) Usage
3.1 Launch the config tool kit
When the camera boots completely (the video LED on the RF board PCB is on), click
on “ReturnChannel Tool Kit”in the start menu.
3.2 Initialization
It may prompt the following messages. Please ignore it and click on OK to continue.
Video LED

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 8Copyright 2012-2015, ITE Technologies, Inc.
Specify the com port of the USB UART dongle for both Rx and Tx, and then click on
“Open”.
(The com port assigned can be found in device manager, as described in 2.1)
Click on “Get All Device”and wait for a few seconds.
If the camera is connected, the camera ID will be showned and checked, as shown
below.

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 9Copyright 2012-2015, ITE Technologies, Inc.
Fig 3-1 Camera found and connected
3.3 Basic Settings
Basically, most of the configurations can be set in the basic setting menu.

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 10 Copyright 2012-2015, ITE Technologies, Inc.
A. Imaging Settings
B. Bit Rate Settings
This option sets the stream encoding bit rate.
Higher bit rate means better video quality but consumes more channel cpacity.
C. Channel Frequency and Bandwidth Settings
This option is used to set RF channel frequency and bandwidth for the rotary switch 0.
Note: the setting is applied to rotary switch 0 only.
It mean no matter what the rotary switch is setting now, the new frequency/bandwidth
set only affects rotary switch 0.

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 11 Copyright 2012-2015, ITE Technologies, Inc.
If current rotary switch is not set in “0”, the new RF channel setting will not take
effect until you set switch to “0”and reboot the camera.
In case you forgot the channel frequency/bandwidth setting of switch 0, you may set
the rotary switch to any other than 0 because all other switch settings map to a fixed
frequency/bandwidth table.
DC-099 TV band Bandwidth 7/8MHz Channel Table
0*
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
Frequenc
y
(in MHz)
142.5
*
156.
5
177.
5
191.
5
205.
5
291.
5
47
4
49
0
50
6
52
2
53
8
55
4
57
0
58
6
60
2
61
8
Bandwidt
h
(in MHz)
7*
7
7
7
7
7
8
8
8
8
8
8
8
8
8
8
DC-099 900MHz band Bandwidth 6 MHz Channel Table
0*
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
Frequency
905*
911
917
923
935
947
797
803
815
827
839
851
863
875
887
899
Rotary Switch for RF
Channel setting

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 12 Copyright 2012-2015, ITE Technologies, Inc.
(in MHz)
Bandwidth
(in MHz)
6*
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
DC-099 TV band bandwidth 6MHz Channel Table
0*
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
Frequency
(in MHz)
177
189
203
213
473
485
497
509
521
539
551
581
593
617
629
647
Bandwidth
(in MHz)
6*
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
*Note: switch 0 is user configurable; the table shows its default factory setting.
3.4 Set Transmission Parameters
More advanced transmission parameters can be set by clicking on the tab “ccHDtv”to
get or set the RF transmission parameters.

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 13 Copyright 2012-2015, ITE Technologies, Inc.
Click on the tab “Set”to set the RF transmission parameters.
Note: The frequency and bandwidth settings are only applied to the channel 0 of
the rotary switch.
All other settings are applied to all the channels of the rotary switch.
Rotary Switch for RF
Channel setting

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 14 Copyright 2012-2015, ITE Technologies, Inc.
When you change the settings for the transmission parameters, the modulation data
rate (channel capacity, data transmitted per second) may change.
Please check if the current encoding option is set properly to fit the channel capacity.
The channel capacity is recommended to be larger than the sum of the video stream
bit rates by at least 10% or more.
In the following example, there are two video service (stream) output simultaneously,
one is 1920x1088x24P(7M bps) and the other is 720x480x24P(2M bps). The total
video data rate is 9 Mbps.
Rotary Switch for RF
Channel setting

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 15 Copyright 2012-2015, ITE Technologies, Inc.
To set the encoding parameters of the streams,
1. Select one video stream service to configure
2. Set custom parameters
3. Click on “set”button to go

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 16 Copyright 2012-2015, ITE Technologies, Inc.
3.5 Set Single Stream Output
By default, there are two video streams output, 1 x HD and 1x SD.
You may disable the second stream (default SD), while the first stream must be there.
1. Click on “Media”
2. Click on “videoEncConfig”
3. Select the second profile
4. Change the use count to 0
5. Click on “Set”button to save the settigns.
3.6 Configure Encoded Video Stream Frame Size
You may change the configuration of the encoded video frame size, frame rate and
data rate.
1. Click on “Media”
2. Click on “videoEncConfig”
3. Select the profile (stream) to be configured.
4. Change the video configurations, frame size, frame rate and data rate.
5. Click on “Set”button to save the settigns.

ccHDtv Configuration Tool (USB UART kit) IT9500 Series
2/24/2015 17 Copyright 2012-2015, ITE Technologies, Inc.
3.7 Set Other Configurations
For other configuration settings, please refer to the document
“ccHDtv_Return_Channel_Spec”.
