Itm Inforce color le/mp User manual

Offensively, the INFORCE Color Law Enforcement / Military Police Strobing Illumination System supports long distance visibility with a 200-lumen

high powered white light while having the advantages of medium and low intensities. Defensively, it lets you be seen with strobing red and blue

output. It also features a disorienting red/blue/white strobe with random pattern and frequency cycles. Using a proprietary venting system, the

INFORCE Color LE/MP is built to stay cool for maximum performance.

LIGHT OUTPUT, PRIMARY LED:

High Setting: 200 lumens

Medium Setting: 60 lumens

Low Setting: 8 lumens

RUN TIMES:

High Setting: 2h 45min

Medium Setting: 6h+

Low Setting: 40h+

Red/Blue Strobe: 12h

Red/Blue/White Strobe: 5h 45min

Bezel Diameter: 1.25 in. / 3.175 cm.

Length: 6.175 in. / 15.68 cm.

Weight: 4.5 oz. / 127.5 g.

(2) Lithium 123A Batteries Included

Primary White Light

2-Color ID/Marker Beacon

3-Color Disorienting Strobe

INFORCE®

INFORCE COLOR LE/MP

STROBING ILLUMINATION SYSTEM

135 Circuit Drive, North Kingstown, RI 02852; Tel: 401-294-2030; Fax: 401-294-2050; www.inforce-mil.com

INFORCE and EMISSIVE ENERGY are registered trademarks of Emissive Energy Corp. The distinctive shapes, styles, packaging conﬁgurations and overall appearances of

INFORCE lighting systems are trademarks of Emissive Energy Corp. Designed and manufactured under one or more of the following U.S. and International patents: U.S.:

6,966,677; 7,121,680; 7,153,004; 7,226,183; 7,517,108; 7,652,303; 7,784,963; D526,730; D565,220; D579,201; D596,329; D619,283. European: 467295-0001; 467295-0002.

Other U.S. and International patents are pending.

Designed and assembled in the U.S.A. of domestic and foreign components. INFORCE products qualify as “American Made” under the Buy America Act.

PM1049/111807

CAUTION: Do not use counterfeit or inferior-quality batteries, as they do

not meet safety and performance standards and have been the cause

of personal and property damage. To ensure safety and performance,

the purchase of established brands, such as Duracell®, Energizer®or

Panasonic®is recommended.

ITEM NUMBER BODY COLOR LED

INF-B-PBR Black Primary: White; Secondary: Red, Blue

FIBER COMPOSITE BODY is ultralight and durable.

SINGLE-HAND OPERATION

Simple, reliable, intuitive tailcap switch operates programs and modes.

BELT CLIP W/BUILT-IN LANYARD HOLE accepts 550 cord.

SCALLOPED HEAD is designed to let the light “spill out” to indicate

that the light is on while in an upright position.

PATENTED HEAT RELEASING VENTS maximize LED performance

and keep the light cool to hold.

Features and Beneﬁts:

HIGH EFFICIENCY EMITTERS provide longer run times and are

virtually immune to failure.

PRECISION OPTICS provide focused hot spot and balanced peripheral light.

HIGH-IMPACT GLASS WINDOW

WATERPROOF to 66 feet.

MIL-STD-810F Certiﬁed.

Limited Lifetime Warranty

www. .com information@itm.com1.800.561.8187

PM1041/111807

INFORCE®

INFORCE COLOR LE/MP STROBING ILLUMINATION SYSTEM

USER MANUAL AND WARRANTY

Turn tailcap switch and

TIGHTEN SECURELY.

These two ribs must align

to make proper contact.

GETTING STARTED

Your INFORCE light is equipped with two (2) high-efficiency 123A Lithium batteries.

To insert the batteries, turn the multi-function tailcap counterclockwise to remove it from

the flashlight body. Insert the batteries into the open handle, positive (+) end first.

Re-thread the multi-function tailcap clockwise onto the flashlight handle. When the

tailcap can be turned no further, it is ready for operation. Rotate to the desired function

position for activation.

If the flashlight malfunctions, the tailcap switch hasn’t been sufficiently tightened;

ribs must align to make proper contact. Remove the cap and repeat the process.

CAUTION: Lithium batteries can explode or cause burns if recharged, shorted, disassembled

or exposed to water, high temperatures or fire. Please follow manufacturer’s guidelines for

safe storage, use and disposal. If the light has been submerged, dry the exterior of the light

prior to replacing the batteries. Fresh and salt water will damage internal electronics and

batteries. Do not use counterfeit or inferior-quality batteries, as they do not meet safety

standards and have been the cause of personal and property damage. To ensure safety

and performance, the purchase of established brands, such as Duracell®, Energizer®or

Panasonic®is recommended.

Notes:

• Whenreplacingbatteries,nevermixbatterytypeoroldandnewbatteries.

• Batteriescanleakandmaycausedamagetotheinsideofthelight.Removethe

batteries if the flashlight will be stored for more than 2 weeks.

• Flashlightheadsarenon-removable;anyattempttoremovetheheadwilldamage

the light and void the warranty.

• Thelightoutputoftheflashlightwilldimovertimeasyourbatteriesstarttodrain.

At some point, batteries that have been depleted substantially will not have

enough energy to sustain a full high power output. At that time, there will be

little to no distinction when attempting to cycle between high and medium modes.

However, there will still be enough energy in the batteries to produce useful light for

a period of time. This is not an indication that the batteries have to be changed.

MAINTENANCE/CLEANING INSTRUCTIONS

Your INFORCE flashlight has been designed to provide maximum performance with

minimum maintenance. Should the flashlight become dirty from dust, sand or caked-on

mud, rinse fully assembled light with water and dry with a soft cloth.

IMPORTANT

Red Gasket Seal Contacts

Threads

NEVER USE LUBRICANT, GREASE, OIL OR OIL-

IMPREGNATED CLOTH ON ANY SEALS, THREADS OR

CONTACTS WITHIN THE LIGHT.

Lubricants will adversely affect the compression seals

and performance of the switching mechanism of the

multi-function tailcap switch. Should the seals get lubricant

or grease on them, simply clean the threaded surfaces

and gasket seals with alcohol.

CONSTANT WHITE: Turn the tailcap switch two clicks to the left of the center position

and rapidly press the tailcap button to select High, Medium or Low level light.

MOMENTARY WHITE: The tailcap position for momentary white light is one click to the

left of center. The light intensity level will be determined by the light level selected in the

constant white mode. If the tailcap switch is rotated from the momentary white position

back to the constant white position, the light will turn on at the same light level that was

originally selected.

INFORCE COLOR LE/MP OPERATION

Engineered for single-hand operation and ease of use, the INFORCE COLOR LE/MP flashlight

as been designed to deliver precise lighting performance. It includes three programmed levels

CONSTANT WHITE MOMENTARY WHITE CENTER

OFF/LOCKOUT

RED/BLUE/WHITE

DISORIENTING STROBE

RED/BLUE MARKER

STROBE

RED/BLUE/WHITE DISORIENTING STROBE: Turn the tailcap switch one click to the right

of the center position.

RED/BLUE MARKER STROBE: Turn the tailcap switch two clicks to the right of the center

position.

of lighting intensity in the white constant and momentary settings plus red/blue marker

strobe, red/blue/white disorienting strobe and lockout modes.

NOTE: High, medium or low light settings selected in CONSTANT WHITE position will be programmed/saved if rotated to the momentary position. When the light is turned

off by clicking the activation button or by rotating the tailcap switch to the center position, the light will reset to the default/high intensity.

PRODUCT WARRANTY

Emissive Energy Corp. (EEC) warrants our products and accessories to be free of defect in workmanship and materials for the lifetime of the original owner. We will repair or replace the product, at our

discretion, if it is determined by us to be defective. In countries or jurisdictions in which specific restrictions exist on lifetime warranties, EEC provides a 10-year limited warranty. Damage to the

productfrommisuse,abuse,neglect,useofotherthanINFORCEbrandaccessories,disassembly,defectivebatteriesoralteringtheproductfromitsoriginalstatevoidsthewarranty.Batterypower

depletion and battery expiration is not covered. This warranty is in addition to and does not affect your statutory rights with respect to faulty goods.

THISCONSTITUTESEEC’SENTIREWARRANTY;WEMAKENOOTHERWARRANTIES,WHETHEREXPRESSORIMPLIED,WITHRESPECTTOTHEPRODUCTS,INCLUDINGANDWITHOUTLIMITATIONTO

WARRANTIESOFMERCHANTABILITYANDFITNESSFORAPARTICULARPURPOSE.EXCEPTFORTHEEXPRESSWARRANTYTOREPAIRORREPLACETHEPRODUCTASSETFORTHABOVE,EECISNOT

RESPONSIBLEFORANYDIRECT,SPECIAL,INCIDENTAL,CONSEQUENTIAL,EXEMPLARYORINDIRECTCOSTSORDAMAGES,REGARDLESSOFTHEFORMOFACTION,WHETHERINCONTRACT,TORT

(INCLUDINGNEGLIGENCE),STRICTLIABILITYOROTHERWISE,EVENIFEECHASBEENADVISEDOFTHEPOSSIBILITYTHEREOF,NORISEECLIABLEFORANYSUCHCOSTSORDAMAGESCAUSEDBY

MISUSE,NEGLIGENCE,MALFUNCTION,ALTERATIONORMODIFICATIONOFANYINFORCEPRODUCTS.BECAUSESOMESTATESDONOTALLOWTHEEXCLUSIONORLIMITATIONOFLIABILITYFOR

CONSEQUENTIALORINCIDENTALDAMAGES,INSUCHSTATESEEC’SLIABILITYISLIMITEDTOTHEFULLEXTENTPERMITTEDBYLAW.

INFORCEandEMISSIVEENERGYareregisteredtrademarksofEMISSIVEENERGYCORP.Thedistinctiveshapes,styles,packagingconfigurationsandoverallappearanceofallINFORCEflashlights

andlightingproductsaretrademarksofEMISSIVEENERGYCORP.DesignedandmanufacturedunderoneormoreofthefollowingU.S.andInternationalpatents:U.S.:6,966,677;7,121,680;

7,153,004;7,226,183;7,517,108;7,652,303;7,784,963;D526,730;D565,220;D579,201;D596,329;D619,283.European:467295-0001;467295-0002.Other U.S. and International patents

are pending.
