Itotec Robocut RC-100DX Operating instructions

TROUBLESHOOTING
PAPER GUILLOTINE
TYPE

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
CONTENTS
Power Supply..................................................................................1
・The power is not turned ON, and the power is turned OFF...1
T.D.C Lamp Lights Up.....................................................................1
Main Motor......................................................................................1
・The main motor cannot be started up. ...............................1
Display On Computer Display Unit..................................................2
1 The present position of backgauge is not displayed. .............2
2 "Err" is displayed............................................................... 2
Clamp..............................................................................................3
1 The clamp does not lower and the speed is low
when the clamp pedal is worked. ...........................................3
2 The clamp does not lower when the clamp pedal is worked,
and the speed is low.............................................................3
3 The clamp pressure during paper cutting is abnormal. ..........4
4 Pressure set value reference data ......................................4
Knife Drive........................................................................................5
1 Knife & clamp operation is not carried out............................5
2 The knife does not operate.................................................5
3 The knife stops halfway. ....................................................6
・ Knife circuit interruption due to power-OFF....................6
・ Insufficient holding time for cutting buttons ON-state.......7
・ Loose knife supporting bolt ..........................................7
・ Loose safety bolt ........................................................7
・ Safety beam guard operation ....................................... 8
・ Knife circuit error ........................................................8
Backgauge......................................................................................9
1 Abnormal noise during backgauge travelling........................9
2 The backgauge does not operate........................................ 9
Blower...........................................................................................10
1 The blower motor cannot be started up. ............................ 10
2 Insufficient air blow amount..............................................10
3 Air blow/stop control error................................................10
4 Abnormal noise .............................................................. 10

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
Paper Cutting Precision................................................................. 11
1Adjust the backgauge right & left,
upper & lower and exact size. ............................................ 11
2Residual cutting arises. .................................................... 11
Cut LineAdjustment ................................................................... 11
Working Lamp Adjustment.......................................................... 11
Clutch Key Switch Operation......................................................12
The knife is operated manually............................................................12
Soft Clamp..................................................................................13
Clamp Hold Circuit......................................................................13
Manual Backgauge Display........................................................13
Counter.......................................................................................13
Technical Information
(Maintenance engineering information used by reperesented engineer)
01 Fuse Detail Drawing & Clutch Key...................................14
02 Thermal Relay Reset .....................................................15
03 Safety Bolt Replacement ................................................16

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
1
Power Supply
(The power is not turned ON and turned OFF.)
Agreater part of power supply related trouble, such as "No power is turned ON." and
"The power is turned OFF.", is attributable to the input side. After taking safety
measures such that the unauthorized person is kept away from the machine, for
example, contact our repressentative.
【Technical Information 01 Fuse】
（Knife Circuit Interruption due to power-OFF on page 6）
Where there occurred power supply trouble during a series of operation cycle and
the machine stopped midway, eliminate the product inside the machine by backgauge
advance operation, then carry out operation after restoration.
Main Motor
The main motor cannot be started up.
Where the motor does not start up even when the main motor startup key switch is
operated, and "Err 01" is displayed on the operation panel, it is considered that the
thermal relay for the main motor inside the electric box 2 was actuated.
Turn the machine power switch "OFF" and take safety measures such that the
unauthorized person is kept away from the machine, then contact our representative.
If "Err" is not displayed on the operation panel, the fuse may possibly be faulty.
【Technical Information 01 Fuse】
【Technical Information 02 Thermal Relay】
When the clutch key operation is performed just before the main motor
fails to start up, ensure that the clutch key is turned counterclockwise.
T.D.C Lamp Lights Up
If this lamp lights up, it is indicated that the maintenance of clutch related to the
intermediate plate stopper function that is the safety mechanism for the knife drive unit
has become necessary.
Turn the machine power switch OFF, and after taking safety measures such that the
unauthorized person is kept away from the machine, contact our service section or our
representative.

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
2
Display in Computer Unit
1 The backgauge present position is not displayed.
Where the present position is not displayed even when the START key is
depressed with power ON, display the backgauge manually. (Manual Backgauge
Display on page 13)
At this time, if the backgauge drive motor does not work, investigate the
backgauge drive. (See "The backgauge doesnot operate." on page 9)
2 "Err" is displayed.
Subsequent to "Err", 2-digit numerals are displayed.
This value indicates the error details.
Err No display Backgauge drive circuit error
（"The backgauge does not operate." on page 9）
Err 01 Main motor thermal relay actuated
【Technical Information 02 Thermal】
Err 03 Blower motor thermal relay actuated
【Technical Information 02 Thermal】
Err 04 Knife lifter motor thermal relay actuated
（Knife lifter option attaching machine）
Err 05 Loose knife supporting bolt, not mounted yet
（Excluding the knife lifter option attaching machine）
Loose safety bolt, rupture
【Technical Information 03 Safety Bolt Replacement】

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
3
Clamp
1 The clamp does not return, and the clamp returning speedis low.
・Check to see if the knife replacement lever is on the cutting side.
(Excluding the knife lifter option attaching machine)
・The clamp return timing becomes slow by the designated time on the page in
which the clamp timer (clamp up timing delay) was set.
・If the knife comes to a halt in the course of lowering and the clamp hold circuit
is actuated, the clamp will hold the position at that time. By pressing the knife
cutting buttons panel reset button or the main motor stop button, the error will
be reset.
・In other cases, the clamp mechanism unit fails. Apply oil to the clamp
mechanism.
The clamp is always being pulled upwards by the pull up spring.
Never approach the clamp work-space envelope in case of
sudden motion.
Where the faulty place is not known and no restoration is possible, turn the
machine power switch OFF, and after taking safety measures such that the
unauthorized person is kept away from the machine, contact our service section or
local service center.
2 The clamp does not lower when the clamp pedal is worked,and the speed is
low.
･Check to see if the main motor is started up.
･Check to see if the hydraulic oil level is proper.
･Check to see if the knife replacement lever is on the cutting side.（excluding
the knife lifter option attaching machine）
･Only when the numerical value indicating the present backgauge position is
displayed on the backgauge display unit of display panel, the clamp can be
operated. Press the START button.
･Check to see if the set value for soft clamp adjustment（Soft Clamp on page
13）is not too low.
･Ensure that the hydraulic controller power inside Box 1 is "ON".
･Apply oil to the clamp mechanism unit.
Apply oil to the clamp mechanism unit. Where the faulty place is not known and
no restoration is possible, turn the machine power switch OFF, and after taking
safety measures such that the unauthorized person is kept away from the machine,
contact our service section or localservice center.

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
4
3 The clamp pressure during cutting operation is abnormal.
・Adjust the clamp pressure adjust knob and clamp pressure level selector
switch. Where the set value on the operation panel is not obtained in the
specific course, check the pressure set value by "clamp pressure setting"
operation in the corresponding course. This pressure set value takes
precedence over that set by the pressure adjust knob.
＜Refer to "Clamp Pressure Setting" in the instruction manual＞
・Check the hydraulic oil amount and contamination. Changing hydraulic oil
once per year is recommendable. Shortly after the hydraulic oil was changed,
clamp operation may become unstable due to air mixed in the hydraulic circuit
when oil is extracted. In this case, with the main motor started approx. 10
minutes, store it, then carry out test cutting and ensure that the clamp is in
normal operation before starting operation.
Where the faulty place is not known and no restoration is possible, turn the
machine power switch OFF, and after taking safety measures such that the
unauthorized person is kept away from the machine, contact our service section
or local service center.
4 Pressure Setting Reference Data
Pressure sensitive paper 400kg Max.
Intermediate quality paper 2000kg
Wood free paper 2000kg
Coat paper 2000kg
Art paper 2000kg
Cellophane 3000kg
Glassine paper 3000kg
Board paper 3000kg
To control the changes in product precision after cutting due to the amount (height) of
a product cut once or the area of a product coming into contact with the clamp as much
as possible, there is a need to be always conscious of the optimum pressure.
When pressure sensitive paper is cut, it is possible to reduce coloring if a magnet
rubber (optionally available) is attached to the clamp rear surface. Also, there is a
method of cutting intermediate quality paper by placing wood free paper thereon.

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
5
Knife Drive
1 The knife and clamp do not work.
Knife operation is started up by pressing the Knife button. It is assumed that the
preparations for fetching the Knife button pressing signal are not made or the Knife
button pressing signal was fetched but the system failed in subsequent processing.
･If the numerical value indicating the present backgauge position is not
displayed on the backgauge display unit of the display panel, both clamp and
knife do not operate. Press the START button for backgauge display.
･When "Err 05" is displayed on the display panel, both clamp and knife do not
operate.
･Check to see if the knife supporting bolt (excluding the knife lifter option
attaching machine) is not loose.
･Visually check the safety bolt.
【Technical Information 03 Safety Bolt Replacement】
Do not insert your hand into the machine interior.
Where looseness or damage is found, adjustments or replacement by our
representative is required.
･Where the page and data now on the display in the semi-automatic and full-
automatic modes are in the proper protrusion/arrangement mode, the clamp and
knife do not operate.
･Ensure that the green LED of the unit (receiver and projection unit) on the
safety beam guard right side lights up. If it goes out, clean the right-side unit
(receiver) and left-side unit(projector).
Where the faulty place is not known and no restoration is possible, turn the
machine power switch OFF, and after taking safety measures such that the
unauthorized person is kept away from the machine, contact our representative.
2 The knife does not operate.
Where the clamp operates when the Cutting buttons was depressed without
working the clamp pedal but the knife does not operate, it follows that the knife
circuit fails, such as a defective fuse inside the clutch power unit. Check to see if
the operation mode at that time is semi-automatic or full-automatic, and the air
bleeding function is not set on the displayed page. In this air blow function, the
knife does not operate.
Stop machine operation, turn the machine power switch "OFF", and taking safety
measures such that the unauthorized person is kept away from the machine,
contactourrepresentative. 【Technical Information 01 Fuse】

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
6
3 The knife stops halfway.
The knife drive circuit started up by the Cutting buttons is held until one cycle is
completed, but this was interrupted for some cause. Except the causes
attributable to power supply, the safety circuit (Clamp Hold Circuit on page 13) for
holding the clamp in the as-is position is actuated.
Where the knife is present in the product when the knife stopped halfway for any
cause, move the knife up to the uppermost part once ("The knife is operated
manually." on page 12), and after checking the process, start operation after
restoration.
There is a possibility that the knife is stopping in the
position where the knife edge is lower than the clamp
lower surface due to sudden power cutoff. Give utmost
care to the knife edge.
Cause of halfway stop of knife
・Knife circuit cutoff due to power-OFF
Where the machine power is turned OFF when the knife started up by
pressing the Cutting buttons stopped halfway or where momentary power
interruption is considered to have occurred,it is necessary to examine the
power supply and other related parts. ("Power Supply" on page 1)
〈Procedure for operation re-start when the trouble was removed and the
power supply was restored〉
Where a product is present in the machine
（1）Press the STOP key on the operation panel.
（2）Return the knife up to the uppermost part with a spanner.
("The knife is operated manually" on page 12)
（3）Eliminate the product in the machine.
（4）After manual display of the backgauge ("Manual Backgauge
Display" on page 13), check the process to re-start operation.
Where no product is present in the machine
（1）Press the STOP key on the operation panel.
（2）Start the main motor and depress the clamp pedal.
（3）When the clamp has come into contact with the surface plate,
press the Cutting buttons to reset the knife to the uppermost part.
（4）After manual display of the backgauge ("Manual Backgauge Display"
on page 13), re-start operation work.
＜ ＞

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
7
・Insufficient holding time for cutting buttons ON-state (This is no failure.)
Maintain the ON-state for the cutting buttons until the machine finishes
cutting the product. If the cutting buttons is released halfway, the knife will
come to a halt.
At this time, the clamp hold circuit ("Clamp Hold Circuit" on page 12) is
actuated, and the clamp holds its position.
After resetting the knife to the uppermost part with the manual handle
("The knife is operated manually." on page 12), re-arrange the products
properly and re-start operation.
・Loose knife supporting bolt
By removing the knife supporting bolt, "Err 05" is displayed on the display
panel, and the knife circuit is interrupted.
However, for micro looseness, "Err" is not displayed. If the knife is started
up in this condition, "Err" may be detected momentarily during operation due
to machine vibration, etc., thereby stopping knife operation. (At this time,
the clamp hold circuit ("Clamp Hold Circuit" on page 13) is actuated.)
Check the knife supporting bolt and re-tighten it.
Where no product is present in the machine, reset the knife up to the
uppermost part with the Cutting buttons with the clamp pedal depressed.
Also, where a product is present in the machine, reset the knife to the
uppermost part with the manual handle ("The knife is operated manually." on
page 12) to re-arrange the products properly.
Check the process to re-start operation.
・Loose safety bolt
If looseness is present in the safety bolt, the limit switch will detect its
looseness, interrupting the knife circuit. At this time, "Err 05" is displayed
on the display panel, and the clamp hold circuit ("Clamp Hold Circuit" on
page 13) is actuated.
Open the knife height adjusting window to check the safety bolt visually.
If the safety bolt is broken, this replacement is required. After taking safety
measures such that the unauthorized person is kept away from the machine,
contact our representative.
【Technical Information 03 Safety Bolt Replacement】

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
8
・Safety beam guard operation
When the red LED of the unit (receiver & projector) on the safety beam
guard right side goes out, itfollows that the left side (projector) or right side
(receiver) is stained or fails.
Where the LED does not light up even when the unit is cleaned, turn the
machine power switch OFF, and after taking safety measures such that the
unauthorized person is kept away from the machine, contact our
representative.
However, even where the forward part of the cut product from the knife
interrupted the optical axis of safety beam guard, the knife comes to an
urgent halt. This is not a trouble.
Reset the knife to the uppermost part with a spanner ("The knife is operated
manually." on page 12), and after checking the process of product re-
arrangement, re-start operation.
・Knife circuit error
This abnormality results from knife cycle holding circuit malfunctions. It is
necessary for our representative to diagnose the knife circuit, such as the
knife button switch, relay and shear cable, etc.
Turn the machine power switch "OFF" and after taking safety measures
such that the unauthorized person is kept away from the machine, contact
our representative.
Before re-starting operation, reset the knife to the uppermost part with a
spanner ("The knife is operated manually." on page 12), re-arrange the
products properly, then check the process.

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
9
Backgauge
1 Abnormal noise during backgauge travelling
・Surface plate and comb contact sound
1 Clean the surface plate and comb tip.
2 Adjust the gap between the comb and surface plate.
3 By applying silicone spray onto the surface plate, a favorable effect is
obtained.
・Poor rotation of slot closing tape guide roller
Slot closing tape guide roller and roller shaft fouling impedes free rotation of
the roller, thereby leading to abnormal noise generation. Clean these parts
periodically.
・Vibration sound produced by backgauge drive motor itself
This abnormal noise is caused by mismatching of the motor drive amplifier
adjustment value and mechanical system load.
Adjustment is required. Contact our service section or our local service
center.
2 The backgauge does not operate.
・When the power is turned ON, display the numerical value indicating the
backgauge position on the backgauge display unit of the display panel by
pressing the START key. The backgauge advance & retract operation is invalid
until it is displayed.
・Where an abnormality was detected in the motor and motor driver receiving the
backgauge operation instructions regardless of the automatic and manual modes,
"Err" is displayed on the display panel. This error is reset due to 5 minutes or
more power-OFF. The error information is logged and accumulated. After
taking safety measures such that the unauthorized person is kept away from the
machine, contact our service section or our local service center.
As a matter of course, an abnormal load in the mechanism unit is handled as an
error. Apply oil periodically.

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
10
Blower
The blower motor is extremely heated. Even after stop as well as during
operation, never touch the blower motor until this temperature lowers.
1 The blower motor cannot be started up. ("Err 03" is displayed on the display panel.)
The thermal relay for blower motor protection is actuated.
Contact our service section or our local service center.
【Technical Information 02 Thermal Relay】
2 Insufficient air blow amount
Check the air intake port filter for clogging or the air piping for damage.
3 Air blow/stop control error
Air blow and stop of the surface plate air nozzle are controlled with the valve
attached between the blower motor blowoff port and surface plate air nozzle.
Where abnormal phenomena are present in operation based on <Instruction
Manual - "Operation Method" "How To Use Air Table">, including no air jetting and
no air stop, it follows that the packing is deteriorated or the valve control circuit is
abnormal.
Contact our service section or our local service center.
4 Abnormal noise
Abnormal noise is attributable to blower motor internal bearing deterioration or
fan damage and intrusion of foreign matter. The blower unit must be replaced.
Turn the power switch "OFF", and contact our representative.

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
11
Paper Cutting Precision
1 Adjust the backgauge right & left, upper & lower and exact size.
Paper cutting precision is affected by not only paper cutter performance but paper
quality, paper storage condition, flow pattern, knife edge angle, knife edge
sharpness, clamp pressure, product hardness and knife hardness, etc.
Follow the instruction manual <Adjustment Method - Backgauge Adjustment> and
<Operation Method - Correction of Errors Between Exact Size and Indicated
Size>.
2 Residual cutting arises.
Check the knife for cutting quality, nicked edge and the cutting stick, and adjust
the knife balance and knife height.
Cut Line Adjustment
Where the cut line is not displayed even when the working lamp switch is
operated, the cut line bulb (24 V 45 W), fuse F4 (5A) and enamel resistor (1 ohm
40 W) are assumed to be faulty.
To replace the cut line bulb, turn the machine power OFF, remove the cover in the
main body upper part, and turn the bulb 90 degrees counterclockwise while
pushing it in: the bulb can be detached from the bulb holder.
This spare bulb is provided in the electric box 2.
Working Lamp Adjustment
A commercially available fluorescent lamp apparatus is used.
Replace the glow or lamp according to the symptom of malfunctions with the
machine power "OFF".

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
12
Clutch Key Switch Operation
1. Open the door of electric box 1 softly to check the clutch key switch position.
【Technical Information 01】
2.
Turn the power "ON".
3. Select the manual mode.
4. The clutch key switch is in the normal condition in the position in which it is turned
counterclockwise, and it in the ON-state by turning it clockwise.
5. In the clutch key ON-state, the main motor startup switch becomes invalid.
6. 120 seconds after power-ON, no operation is carried out.
7. 120 seconds after main motor stop button operation during main motor operation, no
operation is carried out.
8. By operating the clutch key switch during main motor operation, the main motor
starts stop operation, and in 120 seconds, the clutch is actuated.
9. When the STOP key LED on the operation panel goes out, no operation is carried
out. Press the STOP key.
The knife is operated manually
1 Remove the shaft guard cover on the main body right side face and check the
spanner attaching position.
2 Turn the clutch "ON" with the clutch key switch.
3 When the clutch operating sound was heard, attach a spanner and rotate the shaft.
4 Where the knife is stopping before reaching
the cutting stick, turn the clutch key switch
clockwise.
Where the knife is stopping after having
reached the cutting stick, turn it
counterclockwise.
5 When the knife went up to the uppermost
part,
turn the clutch key switch counterclockwise.
6 Remove the spanner and attach the shaft guard cover.
Shaft

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
13
Soft Clamp
The clamp pressure when the clamp pedal was depressed can be adjusted.
1 Select the MN mode.
2Press the CLMP key.
3The present pressure set value is displayed on the data display unit of
operation panel.
0(Low)to9(High)
4 Adjust the clamp pressure with the keys "+", "-" to define it with the STOR key.
Clamp Hold Circuit
This circuit is the safety circuit for holding the clamp in the present position as it is
where the knife came to an urgent halt in the course of lowering for some reason.
This abnormal condition is reset by main motor stop or pressing the RESET button on
the cutting buttons panel of the main body.
Manual Backgauge Display
Normally, by using the START button with power ON, the backgauge display is made,
but the backgauge can also be displayed even according to the following procedure.
1 Press the STOP key to turn the STOP key LED "ON".
2 Where the present position of the backgauge is at least 40 cm apart from the
knife, pass it through the position 30 cm apart from the knife with the backgauge
FRONT H key.
3 Where the present position of the backgauge is 40 cm Max. apart from the
knife, pass it through the position 30 cm apart from the knife with the backgauge
FRONT H key after moving it to the position at least 40 cm apart from the knife
with the backgauge BACK H.
Counter
The counter counts and stores the frequency of knife operations in memory.
While the key "=" is being depressed, the counts are displayed on the data display unit.

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
14
Technical Information
《This technical data contains maintenance engineering information used by
our representative 》【Technical Information 01】
Fuse Detail Drawing and Clutch Key
1F1 5A For main power
F2 5A For 100 VAC circuit
F4 5A For cut line
F8 3A For computer unit 10 V power supply
F9 2A For computer unit 18 V power supply
2F2 5A For hydraulic solenoid circuit
3F1 5A For clutch power supply
4 5A For 24 V power circuit
For fuse checking, there are various methods; for example, visually check for
continuity, check it with a tester, and attempt to replace the fuse with a spare one.
The spare fuse is provided inside Electric Box 2. Prior to use, ensure that the fuse is
of the same size, and the indication of amperage stamped on the fuse edge agrees to
the spare fuse.
The causes of fuse non-conductive state are as follows.
①Deterioration of fuse itself.
②Atrouble occurred in the load-side circuit, and extremely large current flowed.
③There occurred a larger load than usual due to wear or poor lubrication in the
mechanical unit.
④The load possessed by the product to be machined exceeded the machine
capacity.
In the abnormal condition (1) above, if the fuse is replaced, the operation can be
performed. In the case of (2) to (4) above, however, the operation in such an
abnormal state is dangerous. When the fuse has become defective, investigate the
cause, including item (1) as well, and take necessary action therefor.
Main body right-side rear
panel BOX1
Main body left-side rear
panel BOX2
1 2 3
4
Clutch key

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
15
【Technical Information 02】
Thermal Relay Reset
Cause of thermal relay operation
・When an abnormal load was detected
The thermal relay is actuated due to heat. After the temperature
decreases, reset the thermal relay.
Locate the cause for loading and take adequate measures therefor.
・When the thermal relay itself failed
Parts replacement is required.
Blower motor thermal relay
reset button
Main motor thermal relay reset
BOX 2

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
16
【Technical Information 03】
Safety Bolt Replacement
If excessive load is applied to the knife, looseness or breakage will be caused to the
safety bolt, and the knife comes to a halt urgently. At this time, "Err 05" is displayed
on the display panel in the RC-100DX to RC-137DX paper cutters (excluding computer
non-loaded SD).
Explanation is given below of the safety bolt replacement procedure.
Where the rod is not supporting the knife, safety bolt looseness may fail to be
checked visually. It is also necessary to make an attempt to tighten the safety bolt
once.
1 Stop main motor operation. (The power switch remains ON.)
2 Open the knife height adjusting window (right and left doors as viewed from the
front).
Observe the condition of rod 1 and rod 2. (When observing the interior, give
utmost care to the knife edge or the like.)
3 Ensure that the joint surface of rods 1, 2 separated due to broken safety bolt is in
the parallel state: it is necessary to judge whether the rods can be jointed without
any gap by machine reversing operation.
4 Rod 2 separated from rod 1 may face laterally or downward, depending on the
condition when the safety bolt was damaged.
The repair work in this case is extremely difficult, and in most cases, parts
replacement becomes necessary. Where the joint surface of rods 1, 2 is parallel
and these rods seem to be able to be jointed without any gap by machine reversing,
advance to the following step.
5 Turn the clutch ON with the clutch key switch and rotate the shaft with a spanner.
("Clutch Key Switch Operation" on page 12) (The knife is operated manually." on
page 12)
Rod 1 and rod 2 are approaching gradually to join each other.
6 At this time, attempt to align the rod 1 and rod 2 safety bolt mounting holes with
each other.
While ensuring that the both have been joined perfectly, move the knife up to the
uppermost part.
7 Turn the clutch key "OFF".

TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
17
8 Remove the spanner and attach the cover.
With the spanner attached, never start up the knife.
Remove the unrequired spanner immediately.
9 Insert the safety bolt from bottom (rod 2), and attach 2
washers and nuts from top.
［CAUTION］
2 safety bolts are provided in one rod.
Even when either one was broken, replace
the both in set. When no spare is available,
place an order with our company.
10 Ensure that "Err 05" display disappeared.
This completes the safety bolt replacement work.
Before re-starting operation, it is necessary to locate the cause for which the safety
bolt was broken and take adequate measures therefor.
Rod 1 Rod 2
