Ivation IVBWBCC403DSS User manual

20 Bottle & 66 Can
Dual Zone Built-In Compressor
Wine and Beverage Cooler
SKU: IVBWBCC403DSS
User Guide

2
INTRODUCTION
INTRODUCTION
Thank you for purchasing the Ivation® Dual Zone Built-In
Compressor Wine and Beverage Cooler. This User Guide
is intended to provide you with guidelines to ensure that
operation of this product is safe and does not pose risk to
the user. Any use that does not conform to the guidelines
described in this User Guide may void the limited
warranty.
Please read all directions before using the product and
retain this guide for reference. This product is intended
for household use only. It is not intended for commercial
use.
This product is covered by a limited one-year warranty.
Coverage is subject to limits and exclusions. See warranty
for details.
TABLE OF CONTENTS
FEATURES
SAFETY PRECAUTIONS
PACKAGE CONTENTS
PRODUCT OVERVIEW
INSTALLATION
WINE STORAGE TIPS
USAGE/CARE
CARE/SPECS
TROUBLESHOOTING
WARRANTY
GET IN TOUCH!
3
5
6
7
8
9
10
11
12
13
14

3
FEATURES
FEATURES
A Better Way to Store Your Best Bottles
No wine cellar? No problem! This product will protect your
favorite bottles from the light and air that can damage wine’s
aromas, all while storing them at the precise recommended
temperature for your varietals. The advanced compressor
cooling system delivers the optimal environment for those
special vintages, preserving their unique flavor and delicacy.
You get serious performance with a look that’s pure luxury —
rounded edges and seamless designer stainless steel trim on
the doors and shelving.
YOUR WINE COOLER FEATURES:
• Built-in model installs into your cabinetry for a custom-
designed look
• Internal fan helps maintain consistent temperature
throughout the unit
• Compressor provides consistent, energy-efficient cooling
with low energy costs
• Quiet operation and vibration suppression technology
• Keeps red and/or white wines at their proper temperature
• One-touch controls and LCD display
• Interior lighting with independent on/off control
• Celsius or Fahrenheit temperature control, adjustable by
one-degree increments
• Chrome shelves are stylishly accented with stainless steel
and are easy to pull out
• Tempered smoked glass door protects wines from UV rays
• Securely sealing door gasket and dual-pane glass help
maintain internal temperature
• Auto-defrost
• Holds 20 standard size 750mL bottles and 66 standard
size cans
• CFC-free solid polyurethane foam insulation

4
FEATURES
FEATURES
FOCUSED ON INNOVATION, COMMITTED TO QUALITY
The power of innovation plus quality drives all of our product
designs. We pay attention to the small details that add up to
an impactful experience. We believe it’s possible to be the best
while being unique, and we bring that value into each and every
one of our oerings.
Explore our full line of solutions for your home at
www.ivationproducts.com, and keep the conversation going by
calling us at 1-866-849-3049, or sending us an email at
[e-mail]
1-866-849-3049
[e-mail]
REGISTER YOUR WINE COOLER
Set up your warranty and stay current with information about
your unit by registering online. It only takes a moment, and
you’ll receive emails about product recalls, updates, and more.
Go to: register.ivationproducts.com.

5
SAFETY PRECAUTIONS
SAFETY PRECAUTIONS
1. WARNING: CHOKING HAZARD – Small parts. This
product contains small parts and is not suitable for children
under 3 years old.
2. Remove all packaging before using this device. Please keep
all packaging materials out of reach of children and pets.
3. Properly dispose of all packing materials immediately after
unpacking product, as the bags used for packaging could
present a suocation or choking hazard.
4. Read all instructions carefully before attempting to operate
this device. Improper usage could result in injury or a
reduction in ecacy.
5. Never allow children to operate, play with, or crawl inside
the appliance.
6. Keep all flammable liquids or materials away from this unit.
Failure to do so may result in a fire or explosion.
7. Keep out of direct sunlight and away from heat sources.
8. Do not attempt to repair or replace any parts or service this
unit unless specifically recommended in this User Guide.
9. Use only with a properly grounded, standard 115V 60Hz
electrical outlet to avoid the risk of electrical shock.
10. Do not use with an extension cord.
11. Do not lift the unit by the door handle.
12. Make sure the door is fully closed before and during
installation.
13. Do not obstruct airflow to the front of the unit or any of the
unit’s fans, as doing so can cause the unit to malfunction
and will void the warranty.

6
PACKAGE CONTENTS
PARTS
AScrews (4 pieces)
Fastens the handle to
the door.
DWine cooler doors
Shuts out the elements to
help preserve your wines.
FBottle shelves
Allows you to store
bottles properly.
GCan shelves
Allows you to store
cans properly.
HUser guide
Installation, use, and
helpful tips.
BWashers (4 pieces)
Fastens the handle to
the door.
CWine cooler body
Keeps your wines at the
proper temperature.
EWine cooler handles
Easy to open.

7
PRODUCT OVERVIEW
PRODUCT OVERVIEW
118
19
20
21
22
24
25
26
27
28
2
3
4
5
623
7
8
99
10
11
12
13
14 14
15
16
17
1Left zone light switch
2Left zone temperature selector
3Left zone temperature display
4Left zone temperature selector
5Left upper hinge
6Left zone Celsius/Fahrenheit
selector
7Left zone fan
8Left zone light
9Exhaust outlet
10
Left handle
11 Left glass panel
12 Left door gasket
13 Temperature sensor
14
Shelf
15 Carbon filter
16
Kick plate
17 Stabilizing feet
18 Right zone Celsius/Fahrenheit
selector
19 Right zone temperature selector
20
Right zone temperature display
21 Right zone temperature selector
22
Right upper hinge
23
Right zone light switch
24 Right zone fan
25
Right zone light
26 Right handle
27
Right glass panel
28
Right door gasket
GET TO KNOW YOUR WINE COOLER

8
INSTALLING YOUR WINE COOLER
INSTALLATION
INSTALLATION
IMPORTANT INSTALLATION NOTES:
• Before installing your wine cooler, allow to stand upright for 3 hours.
• Once the unit is installed and turned on, allow 24 hours before use for
the temperature to stabilize.
• Clean the interior of the unit with warm water and a soft cloth, and
make sure it is dry.
• Place only on a level surface that will support the weight once
Wine Cooler is completely full. You can ensure the unit is level by
placing a small ball on top and checking to make sure it does not
roll in any direction.
• Position in a dry, well-ventilated space with temperatures between 41° –
90° F (5° - 32° C).
• Ensure that the ventilation panel on the bottom front of your wine
cooler remains unobstructed.
• Do not use without feet: the unit requires 2of ground clearance.
• If you are discarding an old unit, remove its door and leave shelves in
place to avoid an entrapment hazard.
INSTALLING THE DOOR HANDLE:
• The unit has been shipped with the door
handles Dsecurely stored inside, attached
to the shelves.
• Gently pull the door gasket back from the
screw holes where you will attach the handle.
• Use the two included screws Aand
washers Bin order to fasten the door
handle to the frame of the door.
POSITIONING THE UNIT:
• You will want to ensure that the unit will fit properly in your
desired location.
• Opening must be at least 34.3" H x 23.4" D x 25" L.

9
WINE STORAGE TIPS
WINE STORAGE TIPS
RECOMMENDED STORAGE TEMPERATURES
RECOMMENDED STORAGE TIMES
GENERAL TIPS
• Air and light are the factors that cause wines to age poorly. As
much as possible, avoid exposing your favorite bottles.
• Store corked bottles on their sides. This avoids having the
cork dry out, which would allow air into the bottle.
• UV light can aect wine’s color and flavor. Keep bottles
out of direct sunlight.
• Prevent sediment from being stirred up by avoiding
heavy vibrations.
• Avoid exposure to strong odors that might aect the
wine’s flavor.
Fahrenheit Celsius
Red Wines 57° - 65° 14° - 18°
White Wines,
Champagnes and
Sparkling Wines,
and Dry Varietals
49° - 58° 9° - 14°
Rosé Wines 51° - 53° 10° - 11°
Cabernet Sauvignon 7-10 years
Pinot Noir 5 years
Merlot 3-5 years
Zinfandel 2-5 years
Beaujolais Enjoy immediately
Chardonnay 2-3 years
Riesling 3-5 years
Sauvignon Blanc 18 months – 2 years
Pinot Gris 1-2 years
Champagne Enjoy immediately

10
USING YOUR WINE COOLER
USAGE/CARE
USAGE / CARE
USING YOUR CONTROL PANEL:
1Adjust the temperature on the left zone and right zone
control panels by in 1 degree increments by pressing the
and buttons until desired temperature is reached.
2To switch between Fahrenheit and Celsius, press the
button for 2 seconds.
3The light turns on automatically when you open the door.
You can also turn the interior light on by pressing the
button.
DE-ICING YOUR WINE COOLER
• The unit’s Auto Defrost feature should prevent ice accumulation
from occurring.
• However, should ice accumulation occur, you can do the following:
- Unplug the Wine Cooler
- Wait for all ice to melt
- Once melting is complete, remove water from the unit
- Plug in and restart the unit
HOW TO CLEAN YOUR WINE COOLER
TO CLEAN THE EXTERIOR:
• Unplug before cleaning.
• Do not use abrasive cleaning products.
• Wash the cabinet exterior only with mild soap and water and
rinse thoroughly.
• Clean the glass door with glass cleaner or mild soap and water
and a soft cloth.
• Wipe the control panel with a damp cloth and dry
thoroughly. To avoid damaging the panel, do not use
cleaning sprays or oversaturate.
TO CLEAN THE INTERIOR:
• Unplug before cleaning.
• Do not use abrasive cleaning products.
Please note: it is normal for your Wine Cooler to make a whirring sound that will
cycle up when the compressor is working harder to chill your wine, and cycle down
as the temperature levels o.

11
CARE/SPECS
CARE / SPECS
• Cleaning the door gasket:
- Use mild soap or baking soda solution
- Rinse well
- Apply a thin layer of petroleum jelly to the gasket at the hinge
side to prevent sticking
• Use a warm water and baking soda solution inside the unit (about
one tablespoon of baking soda to one quart of water) to clean
and neutralize odors.
IF YOU NEED TO MOVE YOUR WINE COOLER
• Remove all bottles.
• Secure and tape down any shelves or loose items inside the unit.
• Secure the door closed with tape.
• Make sure the unit is kept in an upright position while moving.
TECHNICAL SPECIFICATIONS
Voltage: 110-120V
Rated Current: 1.5A
Frequency: 60Hz
Input Power: 90W
Power Consumption: 0.68KW.h/24h
Temperature Range Left Zone: 38˚F-66˚F
Temperature Range Right Zone: 38˚F-66˚F
Net Weight: 107.5 lbs
Gross Weight: 122.3 lbs
Unit Size: 33.8" H x 22.4" D x 24" L
Package Size: 39" H x 29.3" D x 28.1" L
Electrical Circuit Diagram

12
TROUBLESHOOTING
TROUBLESHOOTING
If the unit doesn’t work:
Check to make sure the power supply has the correct
voltage. Also check to make sure there isn’t a circuit
breaker that has been tripped or a blown fuse.
If the unit isn’t getting cold enough:
Make sure the temperature settings are adjusted correctly.
If so, the room in which the unit is operating might be too
hot. Also check whether the door has been opened too
frequently or has not been completely closed. Check the
deal on the door to make sure it is intact. Make sure the unit
has sucient clearance on all sides.
If the unit vibrates or makes excessive noise:
Make sure the unit has been placed on a level, stable
surface. Also check to make sure the fan is working
properly.
If the light doesn’t work, or if the LED display is not
working or shows an error message:
Check to see if the unit is plugged in properly. If so, there
may be a problem with the main circuit board that requires
professional servicing.
If the buttons don’t work:
The Control Panel may be damaged.

13
WARRANTY
WARRANTY
WARRANTY INFORMATION
LIMITED WARRANTY ON IVATION® 20 BOTTLE & 66 CAN DUAL
ZONE BUILT-IN COMPRESSOR WINE AND BEVERAGE COOLER
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS
AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM
STATE TO STATE.
WE WARRANT THAT DURING THE WARRANTY PERIOD, THE
PRODUCT WILL BE FREE FROM DEFECTS IN MATERIALS AND
WORKMANSHIP.
LIMITATION OF LIABILITY
TO THE EXTENT NOT PROHIBITED BY LAW, THIS WARRANTY
IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES,
ORAL, WRITTEN, STATUTORY, EXPRESS OR IMPLIED. EXCEPT
FOR THE EXPRESS WARRANTIES CONTAINED IN THIS LIMITED
WARRANTY STATEMENT AND TO THE EXTENT NOT PROHIBITED
BY LAW, WE DISCLAIM ALL OTHER WARRANTIES, EXPRESSED
OR IMPLIED, STATUTORY OR OTHERWISE, INCLUDING WITHOUT
LIMITATION, THE WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. SOME STATES DO
NOT ALLOW DISCLAIMERS OF IMPLIED WARRANTIES, SO THIS
DISCLAIMER MAY NOT APPLY TO YOU. TO THE EXTENT SUCH
WARRANTIES CANNOT BE DISCLAIMED UNDER THE LAWS OF
YOUR JURISDICTION, WE LIMIT THE DURATION AND REMEDIES
OF SUCH WARRANTIES TO THE DURATION OF THIS EXPRESS
LIMITED WARRANTY.
OUR RESPONSIBILITY FOR DEFECTIVE GOODS IS LIMITED TO
REPAIR, REPLACEMENT OR REFUND AS DESCRIBED BELOW IN
THIS WARRANTY STATEMENT.
WHO MAY USE THIS WARRANTY? C&A Marketing, Inc. located at
114 Tived Lane East, Edison, NJ (“we”) extend this limited warranty
only to the consumer who originally purchased the product (“you”).
It does not extend to any subsequent owner or other transferee of
the product.
WHAT DOES THIS WARRANTY COVER? This limited warranty
covers defects in materials and workmanship of the Ivation® 20
Bottle & 66 Can Dual Zone Built-In Compressor Wine and Beverage
Cooler (the “product”) for the Warranty Period as defined below.
WHAT DOES THIS WARRANTY NOT COVER? This limited warranty
does not cover any damage due to: (a) transportation; (b) storage;
(c) improper use; (d) failure to follow the product instructions or

14
GET IN TOUCH!
GET IN TOUCH!
to perform any preventive maintenance; (e) modifications; (f)
unauthorized repair; (g) normal wear and tear; or (h) external causes
such as accidents, abuse, or other actions or events beyond our
reasonable control.
WHAT IS THE PERIOD OF COVERAGE? This limited warranty starts
on the date of your purchase and lasts for one year (the “Warranty
Period”). The Warranty Period is not extended if we repair or replace
the product. We may change the availability of this limited warranty
at our discretion, but any changes will not be retroactive.
WHAT ARE YOUR REMEDIES UNDER THIS WARRANTY? With
respect to any defective product during the Warranty Period, we
will, at our sole discretion, either: (a) repair or replace such product
(or the defective part) free of charge or (b) refund the purchase
price of such product if an exchange unit cannot be provided.
HOW DO YOU OBTAIN WARRANTY SERVICE? To obtain warranty
service, you must contact us at 1-866-849-3049 or by email at info@
myivation.com during the Warranty Period to obtain a Defective
Merchandise Authorization (“DMA”) number. No warranty service
will be provided without a DMA number and return shipping costs to
our facilities shall be assumed by you, the purchaser. Shipping costs
of the replacement unit to you shall be assumed by us.
GET IN TOUCH!
[e-mail]
1-866-849-3049
IVATION is a trademark of C&A IP Holdings, LLC, in the U.S, Canada, and the E.U.
All other products, brand names, company names, and logos are trademarks of their respec-
tive owners, used merely to identify their respective products, and are not meant to connote
any sponsorship, endorsement or approval.
Distributed by C&A Marketing, Inc., 114 Tived Lane East, Edison, NJ 08837.
MADE IN CHINA
© 2019. C&A IP Holdings, LLC. All Rights Reserved.
