Ivation IVFWCC121LB User manual

FREESTANDING
COMPRESSOR
WINE COOLERS
User Guide
IVFWCC121LB
Holds 12 bottles
IVFWCC241LB
Holds 24 bottles
IVFWCC331DLB
Holds 33 bottles
IVFWCC181LB
Holds 18 bottles
IVFWCC341LB
Holds 34 bottles
IVFWCC431DLB
Holds 43 bottles
IVFWCC125LB
Holds 12 bottles
IVFWCC281LB
Holds 28 bottles
IVFWCC511LB
Holds 51 bottles

2
INTRODUCTION
INTRODUCTION
Thank you for purchasing the Ivation® Freestanding
Compressor Wine Cooler. This User Guide is intended to
provide you with guidelines to ensure that operation of this
products safe and does not pose risk to the user. Any use
that does not conform to the guidelines described in this
User Guide may void the limited warranty.
Please read all directions before using the product and
retain this guide for reference. This product is intended for
household use only. It is not intended for commercial use.
This product is covered by a limited one-year warranty.
Coverage is subject to limits and exclusions. See warranty
for details.
This product is the next best thing to having a real wine
cooler in your home. It protects your favorite bottles and
stores them at the precise recommended temperatures for
red and/or white wines. The advanced compressor cooling
system delivers the optimal environment for those special
vintages, preserving their unique flavor and delicacy.
FEATURES
SAFETY PRECAUTIONS
PRODUCT OVERVIEW
USAGE / CARE
CARE / SPECS
SPECS / TROUBLESHOOTING
WARRANTY
GET IN TOUCH!
3
4
5
9
10
11
12
13
TABLE OF CONTENTS

3
FEATURES
FEATURES
YOUR WINE COOLER FEATURES:
• Keeps red and/or white wines at their proper temperature
• One-touch controls and LCD display
• Interior lighting with independent on/o control
• Celsius or Fahrenheit, adjustable by one-degree
increments
• Chrome shelves are easy to pull out
• Automatic panel lock
• Tempered smoked glass door protects wines from UV rays
• Black metal exterior
• CFC-free solid polyurethane foam insulation
• Lockable door for added security and peace of mind

4
SAFETY PRECAUTIONS
SAFETY PRECAUTIONS
1. WARNING: CHOKING HAZARD – Small parts. This
product contains small parts and is not suitable for children
under 3 years old.
2. Remove all packaging before using this device. Please keep
all packaging materials out of reach of children and pets.
3. Properly dispose of all packing materials immediately after
unpacking product, as the bags used for packaging could
present a suocation or choking hazard.
4. Read all instructions carefully before attempting to operate
this device. Improper usage could result in injury or a
reduction in ecacy.
5. Never allow children to operate, play with, or crawl inside
the appliance.
6. Keep all flammable liquids or materials away from this unit.
Failure to do so may result in a fire or explosion.
7. Keep out of direct sunlight and away from heat sources.
8. Do not attempt to repair or replace any parts or service this
unit unless specifically recommended in this User Guide.
9. Use only with a properly grounded, standard 115V 60Hz
electrical outlet to avoid the risk of electrical shock.
10. Do not use with an extension cord.
IMPORTANT SETUP NOTES
• Before plugging in your Wine Cooler, allow to stand upright
for 3 hours.
• Place only on a level surface that will support the full weight
once Wine Cooler has been fully loaded. You can ensure the
unit is level by placing a small ball on top and checking to
make sure it does not roll in any direction.
• Position in a dry, well-ventilated space with temperatures
between 41°F – 90°F (5°C – 32°C).
• Leave a space of at least 6" in the back of the unit and 10"
on both sides. Do not place any objects on top of the unit.
• Do not use without feet: the unit requires 2" of ground
clearance.
• If you are discarding an old unit, remove its door and leave
shelves in place to avoid an entrapment hazard.
Please note: it is normal for your Wine Cooler to make a whirring
sound that will cycle up when the compressor is working harder to
chill your wine, and cycle down as the temperature levels o.

5
IVFWCC121LB
IVFWCC125LB
PRODUCT OVERVIEW
PRODUCT OVERVIEW
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
1Exterior
2Shelves
3Retainer bar
4Feet
5Upper door hinge with cover
6Control panel
7Glass door
8Door gasket
9Security lock
10
Bottom hinge
GET TO KNOW YOUR WINE COOLER

6
IVFWCC241LB
IVFWCC181LB
IVFWCC281LB
PRODUCT OVERVIEW
PRODUCT OVERVIEW
1
1
1
2
2
2
3
3
3
4
4
4
5
5
5
6
6
6
7
7
7
8
8
8
9
9
9
10
10
10

7
IVFWCC331DLB
IVFWCC341LB
IVFWCC511LB
PRODUCT OVERVIEW
PRODUCT OVERVIEW
1
1
1
2
2
2
3
3
4
4
4
5
5
5
6
6
6
7
7
7
8
8
8
9
9
9
10
10
10

8
IVFWCC431DLB
PRODUCT OVERVIEW
PRODUCT OVERVIEW
1
2
4
5
6
7
8
9
10
Model Storage Capacity Temperature Range
IVFWCC121LB 12 Standard Bottles 41-64°F (5-18°C)
IVFWCC125LB 12 Standard Bottles 41-64°F (5-18°C)
IVFWCC181LB 18 Standard Bottles 41-64°F (5-18°C)
IVFWCC241LB 24 Standard Bottles 41-64°F (5-18°C)
IVFWCC281LB 28 Standard Bottles 41-64°F (5-18°C)
IVFWCC341LB 34 Standard Bottles 41-64°F (5-18°C)
IVFWCC331DLB 33 Standard Bottles
Dual Zone Upper Zone:54-64°F (12-18°C)
Lower Zone:41-57°F
(5-14°C)
IVFWCC511LB 51 Standard Bottles 41-64°F (5-18°C)
IVFWCC431DLB 43 Standard Bottles
Dual Zone Upper Zone:54-64°F (12-18°C)
Lower Zone:41-54°F
(5-12°C)
RECOMMENDED TEMPERATURE
Fahrenheit Celsius
Red Wines 57° - 65° 14° - 18°
White Wines,
Champagnes and
Sparkling Wines,
and Dry Varietals
49° - 58° 9° - 14°
Rosé Wines 51° - 53° 10° - 11°

9
USAGE / CARE
USING YOUR CONTROL PANEL
Single zone models:
IVFWCC121LB/ IVFWCC125LB/ IVFWCC181LB/
IVFWCC241LB/ IVFWCC281LB/ IVFWCC341LB/
IVFWCC511LB
Dual zone models:
IVFWCC331DLB/ IVFWCC431DLB
1. Unlock the control panel by pressing the button
for 2 seconds. A beep will alert you that the panel has
been unlocked. (For Dual Zone model, press once more
to select either the upper or lower zone.)
2. Adjust the temperature in 1 degree increments
by pressing the ( and ) buttons until desired
temperature is reached.
3. To switch between Fahrenheit and Celsius, press the
for 2 seconds.
4. You can also turn the interior light on or o by pressing
the button. The light will turn o automatically after
10 minutes.
DE-ICING YOUR WINE COOLER
• The unit’s Auto Defrost feature should prevent ice
accumulation from occurring.
• However, should ice accumulation occur, you can do the
following:
- Unplug the Wine Cooler
- Wait for all ice to melt
- Once melting is complete, remove water from the unit
- Plug in and restart the unit
USAGE / CARE

10
CARE / SPECS
CARE / SPECS
HOW TO CLEAN YOUR WINE COOLER
TO CLEAN THE EXTERIOR:
• Unplug before cleaning.
• Do not use abrasive cleaning products.
• Wash the cabinet exterior only with mild soap and water and
rinse thoroughly.
• Clean the glass door with glass cleaner or mild soap and
water and a soft cloth.
• Wipe the control panel with a damp cloth and dry thoroughly.
To avoid damaging the panel, do not use cleaning sprays or
over-saturated.
TO CLEAN THE INTERIOR:
• Unplug before cleaning.
• Do not use abrasive cleaning products.
• Cleaning the door gasket:
- Use mild soap or baking soda solution
- Rinse well
- Apply a thin layer of petroleum jelly to the gasket at the hinge
side to prevent sticking
• Use a warm water and baking soda solution inside the unit (about
one tablespoon of baking soda to one quart of water) to clean
and neutralize odors.
IVFWCC121LB:
Power Supply: 115V 60Hz
Rated Power: 95W
Unit Dimensions (W x D x H):
9.9 x 17.7 x 31.2 in.
(252 x 450 x 792 mm)
Net Weight: 37.5 lbs. (17 kg)
IVFWCC181LB:
Power Supply: 115V 60Hz
Rated Power: 95W
Unit Dimensions (W x D x H):
13.6 x 17.7 x 30.3 in.
(345 x 450 x 770 mm)
Net Weight: 43 lbs. (19.51 kg)
TECHNICAL SPECIFICATIONS
IVFWCC125LB:
Power Supply: 115V 60Hz
Rated Power: 95W
Unit Dimensions (W x D x H):
17.3 x 18.5 x 20.9 in.
(440 x 470 x 530 mm)
Net Weight: 39.7 lbs. (18 kg)
IVFWCC241LB:
Power Supply: 115V 60Hz
Rated Power: 95W
Unit Dimensions (W x D x H):
16.9 x 17.7 x 29.1 in.
(430 x 450 x 740 mm)
Net Weight: 47 lbs. (21.3 kg)

11
IVFWCC281LB:
Power Supply: 115V 60Hz
Rated Power: 95W
Unit Dimensions (W x D x H):
16.9 x 17.7 x 33.1 in.
(430 x 450 x 840 mm)
Net Weight: 49.6 lbs. (22.5 kg)
IVFWCC331DLB:
Power Supply: 115V 60Hz
Rated Power: 65W
Unit Dimensions (W x D x H):
19.5 x 16.9 x 33.4 in.
(495 x 430 x 848 mm)
Net Weight: 59.5 lbs. (27 kg)
IVFWCC431DLB:
Power Supply: 115V 60Hz
Rated Power: 90W
Unit Dimensions (W x D x H):
19.5 x 22.3 x 33.4 in.
(495 x 565 x 848 mm)
Net Weight: 75 lbs. (34 kg)
IVFWCC341LB:
Power Supply: 115V 60Hz
Rated Power: 90W
Unit Dimensions (W x D x H):
18.7 x 17.3 x 33.1 in.
(474 x 440 x 840 mm)
Net Weight: 50.7 lbs. (23 kg)
IVFWCC511LB:
Power Supply: 115V 60Hz
Rated Power: 90W
Unit Dimensions (W x D x H):
19.5 x 22.3 x 33.4 in.
(495 x 565 x 848 mm)
Net Weight: 75 lbs. (34 kg)
SPECS / TROUBLESHOOTING
SPECS / TROUBLESHOOTING
TROUBLESHOOTING
If the unit doesn’t work:
Check to make sure the power supply has the correct voltage. Also
check to make sure there isn't a circuit breaker that has been tripped or a
blown fuse.
If the unit isn’t getting cold enough:
Make sure the temperature settings are adjusted correctly. If so, the room
in which the unit is operating might be too hot. Also check whether the
door has been opened too frequently or has not been completely closed.
Check the deal on the door to make sure it is intact. Make sure the unit
has sucient clearance on all sides.
If the unit vibrates or makes excessive noise:
Make sure the unit has been placed on a level, stable surface. Also check
to make sure the fan is working properly.
If the LED display is not working or shows an error message:
Check to see if the unit is plugged in properly. If so, there may be a
problem with the main circuit board that requires professional servicing.
If the buttons don’t work:
The Control Panel may be damaged.

12
WARRANTY
WARRANTY
WARRANTY INFORMATION
LIMITED WARRANTY ON
IVATION® FREESTANDING WINE COOLER
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS
AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM
STATE TO STATE.
WE WARRANT THAT DURING THE WARRANTY PERIOD, THE
PRODUCT WILL BE FREE FROM DEFECTS IN MATERIALS AND
WORKMANSHIP.
LIMITATION OF LIABILITY
TO THE EXTENT NOT PROHIBITED BY LAW, THIS WARRANTY
IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES,
ORAL, WRITTEN, STATUTORY, EXPRESS OR IMPLIED. EXCEPT
FOR THE EXPRESS WARRANTIES CONTAINED IN THIS LIMITED
WARRANTY STATEMENT AND TO THE EXTENT NOT PROHIBITED
BY LAW, WE DISCLAIM ALL OTHER WARRANTIES, EXPRESSED
OR IMPLIED, STATUTORY OR OTHERWISE, INCLUDING WITHOUT
LIMITATION, THE WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. SOME STATES DO
NOT ALLOW DISCLAIMERS OF IMPLIED WARRANTIES, SO THIS
DISCLAIMER MAY NOT APPLY TO YOU. TO THE EXTENT SUCH
WARRANTIES CANNOT BE DISCLAIMED UNDER THE LAWS OF
YOUR JURISDICTION, WE LIMIT THE DURATION AND REMEDIES
OF SUCH WARRANTIES TO THE DURATION OF THIS EXPRESS
LIMITED WARRANTY.
OUR RESPONSIBILITY FOR DEFECTIVE GOODS IS LIMITED TO
REPAIR, REPLACEMENT OR REFUND AS DESCRIBED BELOW IN
THIS WARRANTY STATEMENT.
WHO MAY USE THIS WARRANTY? C&A Marketing, Inc. located at
114 Tived Lane East, Edison, NJ (“we”) extend this limited warranty
only to the consumer who originally purchased the product (“you”).
It does not extend to any subsequent owner or other transferee of
the product.
WHAT DOES THIS WARRANTY COVER? This limited warranty covers
defects in materials and workmanship of the Ivation® Freestanding
Wine Cooler (the “product”) for the Warranty Period as defined
below.
WHAT DOES THIS WARRANTY NOT COVER? This limited warranty
does not cover any damage due to: (a) transportation; (b) storage;
(c) improper use; (d) failure to follow the product instructions or

13
GET IN TOUCH!
GET IN TOUCH!
to perform any preventive maintenance; (e) modifications; (f)
unauthorized repair; (g) normal wear and tear; or (h) external causes
such as accidents, abuse, or other actions or events beyond our
reasonable control.
WHAT IS THE PERIOD OF COVERAGE? This limited warranty starts
on the date of your purchase and lasts for one year (the “Warranty
Period”). The Warranty Period is not extended if we repair or replace
the product. We may change the availability of this limited warranty
at our discretion, but any changes will not be retroactive.
WHAT ARE YOUR REMEDIES UNDER THIS WARRANTY? With
respect to any defective product during the Warranty Period, we
will, at our sole discretion, either: (a) repair or replace such product
(or the defective part) free of charge or (b) refund the purchase
price of such product if an exchange unit cannot be provided.
HOW DO YOU OBTAIN WARRANTY SERVICE? To obtain warranty
service, you must contact us at 1-866-849-3049 or by email at info@
myivation.com during the Warranty Period to obtain a Defective
Merchandise Authorization (“DMA”) number. No warranty service
will be provided without a DMA number and return shipping costs to
our facilities shall be assumed by you, the purchaser. Shipping costs
of the replacement unit to you shall be assumed by us.
GET IN TOUCH!
[e-mail]
1-866-849-3049
IVATION is a trademark of C&A IP Holdings, LLC, in the U.S, Canada, and the E.U.
All other products, brand names, company names, and logos are trademarks of their respec-
tive owners, used merely to identify their respective products, and are not meant to connote
any sponsorship, endorsement or approval.
Distributed by C&A Marketing, Inc., 114 Tived Lane East, Edison, NJ 08837.
MADE IN CHINA
© 2019. C&A IP Holdings, LLC. All Rights Reserved.
