Ivation IVBWCC291DSS User manual

29 Bottle
Dual Zone Built-In Compressor
Wine Cooler
SKU: IVBWCC291DSS
User Guide

2
INTRODUCTION
INTRODUCTION
Thank you for purchasing the Ivation® Dual Zone Built-In
Compressor Wine Cooler. This User Guide is intended to
provide you with guidelines to ensure that operation of
this product is safe and does not pose risk to the user. Any
use that does not conform to the guidelines described in
this User Guide may void the limited warranty.
Please read all directions before using the product and
retain this guide for reference. This product is intended
for household use only. It is not intended for commercial
use.
This product is covered by a limited one-year warranty.
Coverage is subject to limits and exclusions. See warranty
for details.
FEATURES
SAFETY PRECAUTIONS
PACKAGE CONTENTS
PRODUCT OVERVIEW
INSTALLATION
WINE STORAGE TIPS
USAGE/CARE
CARE/SPECS
TROUBLESHOOTING
WARRANTY
GET IN TOUCH!
3
5
6
7
8
12
13
14
15
16
17
TABLE OF CONTENTS

3
FEATURES
FEATURES
A Better Way to Store Your Best Bottles
No wine cellar? No problem! This product will protect
your favorite bottles from the light and air that can
damage wine’s aromas, all while storing them at the
precise recommended temperature for your varietals. The
advanced compressor cooling system delivers the optimal
environment for those special vintages, preserving their
unique flavor and delicacy. You get serious performance
with a look that’s pure luxury — rounded edges and
seamless designer stainless steel trim on the doors and
shelving.
YOUR WINE COOLER FEATURES:
• Built-in model installs into your cabinetry for a custom-
designed look
• Internal fan helps maintain consistent temperature
throughout the unit
• Compressor provides consistent, energy-ecient cooling
with low energy costs
• Quiet operation and vibration suppression technology
• Keeps red and/or white wines at their proper temperature
• One-touch controls and LCD display
• Interior lighting with independent on/o control
• Celsius or Fahrenheit temperature control, adjustable by
one-degree increments
• Chrome shelves are stylishly accented with stainless steel
and are easy to pull out
• Tempered smoked glass door protects wines from UV rays
• Securely sealing door gasket and dual-pane glass help
maintain internal temperature
• Auto-defrost
• Holds 29 standard size 750mL bottles
• CFC-free solid polyurethane foam insulation

4
FEATURES
FEATURES
FOCUSED ON INNOVATION, COMMITTED TO QUALITY
The power of innovation plus quality drives all of our product
designs. We pay attention to the small details that add up to
an impactful experience. We believe it’s possible to be the
best while being unique, and we bring that value into each and
every one of our oerings.
Explore our full line of solutions for your home at
www.ivationproducts.com, and keep the conversation going
by calling us at 1-866-849-3049, or sending us an email at
[e-mail]
1-866-849-3049
[e-mail]
REGISTER YOUR WINE COOLER
Set up your warranty and stay current with information about
your unit by registering online. It only takes a moment, and
you’ll receive emails about product recalls, updates, and more.
Go to: register.ivationproducts.com.

5
SAFETY PRECAUTIONS
SAFETY PRECAUTIONS
1. WARNING: CHOKING HAZARD – Small parts. This
product contains small parts and is not suitable for children
under 3 years old.
2. Remove all packaging before using this device. Please keep
all packaging materials out of reach of children and pets.
3. Properly dispose of all packing materials immediately after
unpacking product, as the bags used for packaging could
present a suocation or choking hazard.
4. Read all instructions carefully before attempting to operate
this device. Improper usage could result in injury or a
reduction in ecacy.
5. Never allow children to operate, play with, or crawl inside
the appliance.
6. Keep all flammable liquids or materials away from this unit.
Failure to do so may result in a fire or explosion.
7. Keep out of direct sunlight and away from heat sources.
8. Do not attempt to repair or replace any parts or service this
unit unless specifically recommended in this User Guide.
9. Use only with a properly grounded, standard 115V 60Hz
electrical outlet to avoid the risk of electrical shock.
10. Do not use with an extension cord.
11. Do not lift the unit by the door handle.
12. Make sure the door is fully closed before and during
installation.
13. Do not obstruct airflow to the front of the unit or any of the
unit’s fans, as doing so can cause the unit to malfunction
and will void the warranty.

6
PACKAGE CONTENTS
PACKAGE CONTENTS
PARTS
AUpper hinge
Allows you to switch the
door opening from right
to left.
CScrews (2 pieces)
Fastens the handle to
the door.
ERound rubber stoppers
(5 pieces)
Covers the opening at the
left front corners of the unit.
GExtra screws for bottom
hinge (3 pieces)
Fastens the hinges to
the wine cooler body.
IWine cooler door
Shuts out the elements to
help preserve your wines.
KWine cooler shelves
Allows you to store
bottles properly.
LUser guide
Installation, use, and
helpful tips.
BBottom hinge (2 pieces)
Allows you to switch the
door opening from right
to left.
DWashers (2 pieces)
Fastens the handle to
the door.
FExtra screws for top and
bottom hinges (4 pieces)
Fastens the hinges to the
wine cooler body.
HWine cooler body
Keeps your wines at the
proper temperature.
JWine cooler handle
Easy to open.

7
PRODUCT OVERVIEW
PRODUCT OVERVIEW
9
8
1
17
18
19
20
2
3
4
5
6
7
11
12
13
14
15
16
10
1Right upper hinge
2Upper zone light
3Upper zone fan
4Upper zone temperature sensor
5Exhaust outlet
6Lower zone temperature control
7Upper zone temperature control
8Upper/lower zone selector switch
9Light switch
10
Carbon filter
11 Lower zone fan
12 Lower zone light
13 Shelf
14
Lower zone temperature sensor
15 Exhaust outlet
16
Stabilizing feet
17 Door gasket
18 Glass panel
19
Handle
20
Lower hinge
GET TO KNOW YOUR WINE COOLER

8
INSTALLING YOUR WINE COOLER
INSTALLATION
INSTALLATION
IMPORTANT INSTALLATION NOTES:
• Before installing your wine cooler, allow to stand
upright for 3 hours.
• Once the unit is installed and turned on, allow 24 hours
before use for the temperature to stabilize.
• Clean the interior of the unit with warm water and a
soft cloth, and make sure it is dry.
• Place only on a level surface that will support the
full weight once Wine Cooler is completely full. You
can ensure the unit is level by placing a small ball on
top and checking to make sure it does not roll in any
direction.
• Position in a dry, well-ventilated space with
temperatures between 41° - 90° F (5° - 32° C).
• Ensure that the ventilation panel on the bottom front of
your wine cooler remains unobstructed.
• Do not use without feet: the unit requires 2" of ground
clearance.
• If you are discarding an old unit, remove its door and
leave shelves in place to avoid an entrapment hazard.
INSTALLING THE DOOR HANDLE:
• The unit has been shipped with the door handle J
securely stored inside, attached to the shelves.
• The default door-opening option of your wine cooler
will have it swinging open from left to right. If you
need to reverse this door swing, please
follow the separately listed instructions
on the next page.
• Gently pull the door gasket back from
the screw holes where you will attach
the handle.
• Use the two included screws Cand
washers Din order to fasten the door
handle to the frame of the door.

9
INSTALLATION
INSTALLATION
TO REVERSE THE DOOR-OPENING:
CAUTION: Do not attempt to complete this step by yourself.
This task requires two people, as otherwise the door could fall,
resulting in possible damage to the product or your person.
• Follow the previous steps for installing the door handle.
• Fully open the door.
• Pull out the rubber stoppers Efrom the screwholes on the left
upper and lower corners.
• Install the L-shaped piece Bof the lower left hinge, using the
3 screws Gprovided.
Upper left corner Lower left corner

10
INSTALLATION
INSTALLATION
• With your helper holding the door, unscrew and remove the
upper door hinge.
• Working together, carefully lift the door o of its bottom hinge.
Carefully set the door down in secure
position.
• In order to avoid scratching the door
upon re-installation in its new position,
unscrew and remove the bottom right
hinge.
• Flip it around. The handle will now be
on the right side of the door.
• Seat the door (in its new position)
on the bottom hinge.
• Install the other piece of the lower left hinge B, using two of
the other screws Fprovided.

11
POSITIONING THE UNIT:
• You will want to ensure that the unit will fit properly in
your desired location.
• Opening must be at least 34.3" H x 23.4" D x 15.8" L.
INSTALLATION
INSTALLATION
• With the door fully opened, attach the top hinge Ausing the
2 screws Fprovided. The top hinge will now be on the upper
left side of the door.
• Install the rubber stoppers Ein the screwholes on the
right side.

12
WINE STORAGE TIPS
WINE STORAGE TIPS
RECOMMENDED STORAGE TEMPERATURES
RECOMMENDED STORAGE TIMES
GENERAL TIPS
• Air and light are the factors that cause wines to age poorly.
As much as possible, avoid exposing your favorite bottles.
• Store corked bottles on their sides. This avoids having the
cork dry out, which would allow air into the bottle.
• UV light can aect wine’s color and flavor. Keep bottles
out of direct sunlight.
• Prevent sediment from being stirred up by avoiding
heavy vibrations.
• Avoid exposure to strong odors that might aect the
wine’s flavor.
Fahrenheit Celsius
Red Wines 57° - 65° 14° - 18°
White Wines,
Champagnes and
Sparkling Wines,
and Dry Varietals
49° - 58° 9° - 14°
Rosé Wines 51° - 53° 10° - 11°
Cabernet Sauvignon 7-10 years
Pinot Noir 5 years
Merlot 3-5 years
Zinfandel 2-5 years
Beaujolais Enjoy immediately
Chardonnay 2-3 years
Riesling 3-5 years
Sauvignon Blanc 18 months – 2 years
Pinot Gris 1-2 years
Champagne Enjoy immediately

13
USING YOUR WINE COOLER
USAGE/CARE
USAGE / CARE
USING YOUR CONTROL PANEL:
1Adjust the temperature on the upper zone and lower zone
control panels by 1 degree increments by pressing the
and buttons until desired temperature is reached.
2To switch between Fahrenheit and Celsius, press the
button for 2 seconds.
3The light turns on automatically when you open the door.
You can also turn the interior light on by pressing the
button.
DE-ICING YOUR WINE COOLER
• The unit’s Auto Defrost feature should prevent ice accumulation
from occurring.
• However, should ice accumulation occur, you can do the following:
- Unplug the Wine Cooler
- Wait for all ice to melt
- Once melting is complete, remove water from the unit
- Plug in and restart the unit
HOW TO CLEAN YOUR WINE COOLER
TO CLEAN THE EXTERIOR:
• Unplug before cleaning.
• Do not use abrasive cleaning products.
• Wash the cabinet exterior only with mild soap and water and
rinse thoroughly.
• Clean the glass door with glass cleaner or mild soap and water
and a soft cloth.
• Wipe the control panel with a damp cloth and dry thoroughly.
To avoid damaging the panel, do not use cleaning sprays or
oversaturate.
Please note: it is normal for your Wine Cooler to make a whirring sound that will
cycle up when the compressor is working harder to chill your wine, and cycle down
as the temperature levels o.

14
CARE/SPECS
CARE / SPECS
TO CLEAN THE INTERIOR:
• Unplug before cleaning.
• Do not use abrasive cleaning products.
• Cleaning the door gasket:
- Use mild soap or baking soda solution
- Rinse well
- Apply a thin layer of petroleum jelly to the gasket at the hinge
side to prevent sticking
• Use a warm water and baking soda solution inside the unit (about one
tablespoon of baking soda to one quart of water) to clean and neutralize
odors.
IF YOU NEED TO MOVE YOUR WINE COOLER
• Remove all bottles.
• Secure and tape down any shelves or loose items inside the unit.
• Secure the door closed with tape.
• Make sure the unit is kept in an upright position while moving.
TECHNICAL SPECIFICATIONS
Voltage: 110-120V
Rated Current: 1.2A
Frequency: 60Hz
Input Power: 90W
Power Consumption: 0.41KW.h/24h
Temperature Range: 40˚F-50˚F (upper zone), 50˚F-66˚F (lower zone)
Net Weight: 71.6 lbs
Gross Weight: 84.2 lbs
Unit Size: 33.8" H x 22.4" D x 14.8" L
Package Size: 37.9" H x 26.6" D x 19" L
Electrical Circuit Diagram

15
TROUBLESHOOTING
TROUBLESHOOTING
If the unit doesn’t work:
Check to make sure the power supply has the correct voltage.
Also check to make sure there isn’t a circuit breaker that has
been tripped or a blown fuse.
If the unit isn’t getting cold enough:
Make sure the temperature settings are adjusted correctly. If so,
the room in which the unit is operating might be too hot. Also
check whether the door has been opened too frequently or
has not been completely closed. Check the deal on the door to
make sure it is intact. Make sure the unit has sucient clearance
on all sides.
If the unit vibrates or makes excessive noise:
Make sure the unit has been placed on a level, stable surface.
Also check to make sure the fan is working properly.
If the light doesn’t work, or if the LED display is not
working or shows an error message:
Check to see if the unit is plugged in properly. If so, there
may be a problem with the main circuit board that requires
professional servicing.
If the buttons don’t work:
The Control Panel may be damaged.

16
WARRANTY
WARRANTY
WARRANTY INFORMATION
LIMITED WARRANTY ON IVATION® 29 BOTTLE DUAL ZONE
BUILT-IN COMPRESSOR WINE COOLER
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS
AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM
STATE TO STATE.
WE WARRANT THAT DURING THE WARRANTY PERIOD, THE
PRODUCT WILL BE FREE FROM DEFECTS IN MATERIALS AND
WORKMANSHIP.
LIMITATION OF LIABILITY
TO THE EXTENT NOT PROHIBITED BY LAW, THIS WARRANTY
IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES,
ORAL, WRITTEN, STATUTORY, EXPRESS OR IMPLIED. EXCEPT
FOR THE EXPRESS WARRANTIES CONTAINED IN THIS LIMITED
WARRANTY STATEMENT AND TO THE EXTENT NOT PROHIBITED
BY LAW, WE DISCLAIM ALL OTHER WARRANTIES, EXPRESSED
OR IMPLIED, STATUTORY OR OTHERWISE, INCLUDING WITHOUT
LIMITATION, THE WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. SOME STATES DO
NOT ALLOW DISCLAIMERS OF IMPLIED WARRANTIES, SO THIS
DISCLAIMER MAY NOT APPLY TO YOU. TO THE EXTENT SUCH
WARRANTIES CANNOT BE DISCLAIMED UNDER THE LAWS OF
YOUR JURISDICTION, WE LIMIT THE DURATION AND REMEDIES
OF SUCH WARRANTIES TO THE DURATION OF THIS EXPRESS
LIMITED WARRANTY.
OUR RESPONSIBILITY FOR DEFECTIVE GOODS IS LIMITED TO
REPAIR, REPLACEMENT OR REFUND AS DESCRIBED BELOW IN
THIS WARRANTY STATEMENT.
WHO MAY USE THIS WARRANTY? C&A Marketing, Inc. located at
114 Tived Lane East, Edison, NJ (“we”) extend this limited warranty
only to the consumer who originally purchased the product (“you”).
It does not extend to any subsequent owner or other transferee of
the product.
WHAT DOES THIS WARRANTY COVER? This limited warranty
covers defects in materials and workmanship of the Ivation® 29
Bottle Dual Zone Built-In Compressor Wine Cooler (the “product”)
for the Warranty Period as defined below.
WHAT DOES THIS WARRANTY NOT COVER? This limited warranty
does not cover any damage due to: (a) transportation; (b) storage;
(c) improper use; (d) failure to follow the product instructions or
to perform any preventive maintenance; (e) modifications; (f)

17
GET IN TOUCH!
GET IN TOUCH!
unauthorized repair; (g) normal wear and tear; or (h) external causes
such as accidents, abuse, or other actions or events beyond our
reasonable control.
WHAT IS THE PERIOD OF COVERAGE? This limited warranty starts
on the date of your purchase and lasts for one year (the “Warranty
Period”). The Warranty Period is not extended if we repair or replace
the product. We may change the availability of this limited warranty
at our discretion, but any changes will not be retroactive.
WHAT ARE YOUR REMEDIES UNDER THIS WARRANTY? With
respect to any defective product during the Warranty Period, we
will, at our sole discretion, either: (a) repair or replace such product
(or the defective part) free of charge or (b) refund the purchase
price of such product if an exchange unit cannot be provided.
HOW DO YOU OBTAIN WARRANTY SERVICE? To obtain warranty
service, you must contact us at 1-866-849-3049 or by email at info@
myivation.com during the Warranty Period to obtain a Defective
Merchandise Authorization (“DMA”) number. No warranty service
will be provided without a DMA number and return shipping costs to
our facilities shall be assumed by you, the purchaser. Shipping costs
of the replacement unit to you shall be assumed by us.
GET IN TOUCH!
[e-mail]
1-866-849-3049
IVATION is a trademark of C&A IP Holdings, LLC, in the U.S, Canada, and the E.U.
All other products, brand names, company names, and logos are trademarks of their respec-
tive owners, used merely to identify their respective products, and are not meant to connote
any sponsorship, endorsement or approval.
Distributed by C&A Marketing, Inc., 114 Tived Lane East, Edison, NJ 08837.
MADE IN CHINA
© 2019. C&A IP Holdings, LLC. All Rights Reserved.
