UM027202-0816 Overview
S3F8S5A Development Kit
User Manual
1
Overview
Zilog’s S3F8S5A Development Kit, part number S3F8S5A0100ZCOG, allows you to
evaluate your S3F8S5A-based designs and applications. The Kit features a Development
Board consisting of the following components:
• Four LEDs
• Two pushbuttons
• Buzzer/Speaker
• LCD module
• UART
• 256 byte Serial EEPROM
• Header pins
This user manual provides instructions for setting up and configuring the S3F8S5A Devel-
opment Board. It includes schematic diagrams and a discussion of the Board features and
ZDS II.
The S3F8S5A Development Board features an S3F8S5A MCU in a 44-pin QFP package,
plus an S3 PGM connector to connect the Board to a host development PC using the S3
Flash In-System Programmer II (ISP). To learn more about the S3F8S5A MCU, refer to
the S3F8S5A Product Specification (PS0323) and/or the S3 Flash In-System Programmer
User Manual (UM0266).
This document guides you through the following tasks:
• Downloading and installing ZDSII software and documentation
• Connecting the S3 Flash ISP II and S3F8S5A Development Board to your PC
• Starting the S3F8S5A Ledblink sample program
Kit Contents
The S3F8S5A Development Kit contains the following items:
• S3F8S5A Development Board
• S3 Flash ISP II
• 10-circuit ribbon cable
• USB A (male) to Mini-B USB cable (2)
• S3F8S5A Development Kit hardcopy insert

UM027202-0816 Features
S3F8S5A Development Kit
User Manual
2
Figure 1 shows the contents of the S3F8S5A Development Kit.
Features
The S3F8S5A Development Kit includes the following key items.
• S3F8S5A Development Board, which contains the following features:
–S3F8S5A 44-pin QFP MCU operating at 12 MHz, with 48KB of internal Flash
memory and 1 KB of internal RAM memory
–USB interface to supply power to the board
–LCD module
–Buzzer/Speaker
–UART header at J8
–256 byte Serial EEPROM
–Test Points headers for all pins of MCU
–MCU current measurement Test Points J4 and J5
–Pin P03/AD3 level adjustable with potentiometer R4
• S3 Flash In-System Programmer II
• ZDSII software, samples, and documentation available free for download
–Sample programs
Figure 1. The S3F8S5A Development Kit

UM027202-0816 Supported Host Environments
S3F8S5A Development Kit
User Manual
3
Supported Host Environments
The S3F8S5A Development Board supports the following operating systems:
• Microsoft Windows 7 (32-bit/64-bit)
• Microsoft Windows 8 (32-bit/64-bit)
Install the ZDSII Software and Documentation
Observe the following steps to download and install your ZDSII software and documenta-
tion.
If you have already installed ZDSII – S3 <version> and have downloaded the software
and documentation by following the procedure on the paper insert in your kit (FL0170),
skip ahead to the next section.
1. Prior to connecting the S3F8S5A Development Board to your development PC, down-
load ZDS II for S3 v5.3.0 (or later) from the Downloadable Software category in the
Zilog Store.
2. When the download is complete, unzip the file to your hard drive, then double-click
the installation file named ZDS2_S3_<Version>.exe and follow the on-screen
instructions.
3. When the ZDS II installation is complete, double-click the installation file named
DOCS_S3<version>.exe and follow the on-screen instructions.
4. When these installations are complete, view the S3F8S5A Development Kit User
Manual (UM0272); this document will be located in the following path, by default:
C:\Zilog\ZDSII_ S3 _<version>\Documentation\Tools_Documentation
Establish a Connection with the PC
Observe the following procedure to connect the S3 Flash ISP II and S3F8S5A Develop-
ment Board to your PC.
Note:

UM027202-0816 Establish a Connection with the PC
S3F8S5A Development Kit
User Manual
4
Disconnect or turn off the power to the S3F8S5A Development Board before connecting
or disconnecting the S3 Flash ISP II.
1. Connect the Mini-B side of the USB A (male)-to-Mini-B cable to the S3 Flash ISP II.
Connect the other end of this cable to the PC, as shown in Figure 2.
2. Connect the 10p 5x2 ribbon cable to the S3 Flash ISP II, as shown in Figure 3.
3. Connect the other end of the ribbon cable to Debug Connector J1 on the Development
Board, shown in Figure 4.
Figure 2. Connecting the S3 Flash ISP II to the Development PC
Figure 3. Connecting the 10-pin Ribbon Cable to the S3 Flash ISP II
Caution:

UM027202-0816 Establish a Connection with the PC
S3F8S5A Development Kit
User Manual
5
4. After completing the procedure to connect the S3F8S5A Development Board to the
PC, the complete setup appears as shown in Figure 5.
Figure 4. Debug Connector J1
Figure 5. The Completed ISP II and Development Board Assembly

UM027202-0816 Start the S3F8S5A Ledblink Sample Program
S3F8S5A Development Kit
User Manual
6
Start the S3F8S5A Ledblink Sample Program
The S3F8S5A Development Kit includes a sample program that demonstrates an LED
blinking application. To start the S3F8S5A Ledblink sample program, observe the follow-
ing procedure.
1. Launch ZDSII by navigating from the Windows Start menu to Programs →Zilog
ZDSII –S3 <Version> →ZDSII –S3 <Version>.
2. From the File menu in ZDSII, select Open Project as indicated in Figure 6, and navi-
gate to the following filepath:
<ZDS Install>\samples\S3F8S5A\ledblink_asm
3. Select the ledblink.zdsproj project from within the ledblink_asm folder as
indicated in Figure 7 and click Open. A list of source files will appear in the Work-
space panel.
Figure 6. The Open Project Selection in the File Menu

UM027202-0816 Start the S3F8S5A Ledblink Sample Program
S3F8S5A Development Kit
User Manual
7
4. From the Build menu, select Set Active Configuration to open the Select Configura-
tion dialog box.
5. Select Debug, then click OK to close the Select Configuration dialog box.
6. From the Project menu in ZDSII, select Settings to open the Project Settings dialog
box. In the Project Settings dialog box, click the Debugger tab.
Figure 7. Select the ledblink.zdsproj Project

UM027202-0816 Start the S3F8S5A Ledblink Sample Program
S3F8S5A Development Kit
User Manual
8
7. On the Debugger page, select S3F8S5X_FlashIspII from the Target list, then select
S3FlashIspII from the Debug Tool drop-down menu, as indicated in Figure 8.
8. After selecting S3FlashIspII from the Debug Tool drop-down menu, click Setup to
select the serial number of the S3 Flash ISP II you are using, as indicated in Figure 9.
Click OK to close the Setup USB Communication dialog box.
Figure 8. Select the Target and Debug Tool

UM027202-0816 Start the S3F8S5A Ledblink Sample Program
S3F8S5A Development Kit
User Manual
9
The serial number you see on your screen will be different from the serial number shown
in Figure 9.
9. After selecting the serial number of the S3 Flash ISP II that you are using, select
Setup from the Target field to select the Target Voltage.
10. From the target Configuration dialog, enter “0” on ISP_DBRG_IDX and select the
3.3V by ISP button and Click OK. See Figure 10.
Figure 9. The Setup USB Communication Dialog
Note:

UM027202-0816 Start the S3F8S5A Ledblink Sample Program
S3F8S5A Development Kit
User Manual
10
11. Make sure that the Enhanced ISP Debug Library is selected on the debugger win-
dow..
12. Click OK to close the Project Settings dialog box.
13. If you are prompted to rebuild any affected files, click Yes. Otherwise, choose Build
from the menu bar, then click Rebuild All. The following example message is dis-
played:
OUTPUT CHECKSUM
ledblink.hex F834
ledblink.lod F834
0 warning(s
0 error(s)
Build succeeded.
Figure 10. The Target Configuration Dialog
Space Base Top Size Used Unused
Page0 P:00 P:05 COH 6H BAH
( 192 6 186 )
ROM C:0000 C:1BB7 C000H 1AB8H A548H
( 49152 6840 42312 )

UM027202-0816 Troubleshooting Tips
S3F8S5A Development Kit
User Manual
11
This Output Checksum message is an example and may not match the actual checksum of
the project for a particular release of the ZDS installation software.
14. To run the application, select Reset+Go from the Debug menu, as indicated in
Figure 11. As a result, LEDs D2, D3, and D4 will blink in sequence.
Troubleshooting Tips
The following troubleshooting tips are useful when starting the S3F8S5A Ledblink sample
program.
• Ensure that the LED1 PWR indicator on the S3 Flash ISP II lights up upon connecting
to the USB port of your PC.
• Navigate to Project →Settings →Debugger →Debug Tool →Setup. Upon click-
ing Setup on the Setup USB Communication dialog box, verify that the S3FlashIspII
serial number is displayed.
Figure 11. Select Reset+ Go from the Debug Menu
Note:

UM027202-0816 S3F8S5A Development Board
S3F8S5A Development Kit
User Manual
12
• Remove and reconnect the ISP II on the USB port of your PC.
• Refer to Figure 14 on page 13 to learn more about the operations and power options of
the S3F8S5A Development Board.
S3F8S5A Development Board
The purpose of the S3F8S5A Development Kit is to provide a set of hardware and soft-
ware tools for the development of hardware and firmware for applications based on the
S3F8S5A microcontroller. An image of the S3F8S5A Development Board is shown in
Figure 12; a block diagram is shown in Figure 13.
Figure 12. The S3F8S5A Development Board

UM027202-0816 Operations and Power Options
S3F8S5A Development Kit
User Manual
13
Operations and Power Options
The operations and power options of the S3F8S5A Development Board are listed in Fig-
ure 14.
Figure 13. S3F8S5A Development Board Block Diagram
Figure 14. Operations and Power Options of the S3F8S5A Development Board

 




 


 

UM027202-0816 S3F8S5A MCU
S3F8S5A Development Kit
User Manual
14
S3F8S5A MCU
Key features of the S3F8S5A MCU include:
• SAM88RC CPU core
• 48K x 8 bits program memory
• 1024 × 8 bits data memory
• Endurance: 10,000 Erase/Program cycles
• 78 instructions
• 36 normal I/O pins in the 44-pin QFP package
• Eight bit-programmable pins for external interrupts
• One 8-bit basic timer for oscillation stabilization and watchdog functions (system reset)
• Three 8-bit timer/counters and two 16-bit timer/counters with selectable operating
modes
• Watch timer for real time
• LCD controller/driver
• A/D converter with 8 selectable input pins
• Synchronous SIO modules
• Two asynchronous UART modules
• Pattern generation module
To learn more about the S3F8S5A MCU, refer to the S3F8S5A Product Specification
(PS0323).
Magnetic Buzzer
The CEM1206S magnetic buzzer (U5) manufactured by CUI Inc. is rated at a frequency
of 2400Hz and an operating voltage of 3.0–8.0V zero-to-peak (V0–P). An image of the
CEM1206S device is shown in Figure 15.

UM027202-0816 Reset Circuit
S3F8S5A Development Kit
User Manual
15
To learn more about the CEM1206S device, visit http://www.cui.com/product/resource/
cem-1206s.pdf.
Reset Circuit
The reset circuit features a 100KΩpull-up resistor R3 and SW1. This circuit resets the
S3F8S5A MCU when SW1 is pressed. See Figure 16 for a representation of the reset cir-
cuit.
ISP II Connector
The ISP II connector (J1) provides an interface between the S3 Flash ISP II tool and the
S3F8S5A device. See Figure 17 for an illustration of the ISP II connector.
Figure 15. Magnetic Buzzer
Figure 16. The Reset Circuit

UM027202-0816 LCD
S3F8S5A Development Kit
User Manual
16
LCD
The VIM-404-DP-RC-S-HV LCD manufactured by Varitronix Ltd. is a 20-pin module.
Figure 18 shows an image of this LCD.
This four-digit LCD is activated by selecting the segment of each digit that must light up.
Figure 19 shows the LCD pin configuration and assignments.
Figure 17. The ISP II Connector
Figure 18. LCD

UM027202-0816 Serial EEPROM
S3F8S5A Development Kit
User Manual
17
Serial EEPROM
The 93C56B is enabled through the Chip Select pin (CS) and accessed via a 3-wire serial
interface consisting of Data Input (DI), Data Output (DO), and Shift Clock (SK). Upon
receiving a Read instruction at DI, the address is decoded, and the data is clocked out seri-
ally on the DO pin. Figure 20 shows the Serial EEPROM schematics.
Figure 19. LCD Pin Configuration and Assignments
Figure 20. Serial EEPROM
