J.Burrows ASHTON JBASH2DCAB User manual

ASSEMBLY INSTRUCTIONS
1/7
JBASH2DCAB
ASHTON 2 DRAWER LATERAL FILING CABINET
This design and instruction booklet is subject to copyright.
www.officeworks.com.au 1CTN

Officeworks Superstores Pty Ltd. I 236-262 East Boundary Road I East Bentleigh I 3165 I AUSTRALIA
2/7
Tools Required For Assembly
Recommend 2 Adults to Assemble
Assemble Item On a Clean Flat Surface
Please check you have all hardware before assembling.
If you think you are missing any hardware please contact the store of purchase.
Please ensure you have the name of the item and hardware part required and quantity.
Please retain your receipt for proof of purchase to validate warranty. Enjoy your new purchase.
At least every 4 months, check all bolts, screws and knobs to be sure they are tight.
If parts are missing, broken, damaged or worn, stop use of the product until repairs are made,
using factory authorized parts.
Failure to follow these warnings could result in serious injury.
WARNING
.
.
.
.
Do not tighten the screws before all screws are in right place.
.Do not use this cabinet unless all bolts, screws and knobs are firmly secured.
.
.
.
.

HARDWARE LIST
3/7
ABC
376mm
x4Pcs
x4Pcs
Dx8Pcs
x2Pcs
PARTS LIST
x1Pc

4/7
BCD
C
D
B
B
A
A
Step 2
Step 1

Step 3
5/7
If you need to remove the drawer,
please pull the drawer all the way out, then
simultaneously push the plastic release
lever of the ball bearing slides up on one
side and down on the other side, and then
pull the drawer completely out. As shown.
#B
Detail #B
Detail #B

Step 4
6/7
To place the drawer back, simply push
the ball bearing cart all the way to the end
of the slides (in both sides), and align the
slide runners on the drawer with the slide
tracks on the unit. Push it carefully inside
until it stops. If the drawer does not go in
smoothly, please take it out and repeat the
step.

Step 5
7/7
