ASSEMBLY INSTRUCTIONS
COBALT 5 SHELF METAL SHELVING UNIT
JB5TMTLSWE
This design and instruction booklet is subject to copyright.
www.officeworks.com.au 1CTN

Furniture Assembly Instructions Style Guide
2/ 9
Tools required for assembly
Recommend 2 adults to assemble
Assemble item on a clean flat surface
Officeworks Ltd | 236-262 East Boundary Road | East Bentleigh | 3165 | AUSTRALIA
NOTE
Please check you have all hardware before assembling.
If you are missing any hardware, please contact the store of purchase.
Please ensure you have the name of the item, required hardware part and quantity.
Please retain your receipt as proof of purchase to validate your warranty.
CAUTION
Do not tighten screws before all screws are in the right place.
Do not use this product unless all bolts, screws and knobs are firmly secured.
Check that all bolts, screws and knobs are securely tightened at least every 3 months.
WARNING
If parts are missing, broken, damaged or worn stop using the product until all repairs
are made using manufacturer authorised parts.
Failure to follow these warnings could result in serious injury.
DANGER
CHILDREN MUST BE SUPERVISED.

Furniture Assembly Instructions Style Guide
3/ 9
PARTS LIST
HARDWARE LIST
1
2
3
4
5
6
Post x8
Short beam x10
Long beam x10
Shelf x5
Coupler x8
Post cap x8
A
ST3.5*38 Screw x4
B
Expansion rubber
head plugs x4
C
Nylon cable ties x2
D
Nylon part x2

Furniture Assembly Instructions Style Guide
4/ 9
Step 2
Step 1
Step 3
Step 4
x1
6
1
6 x1
①
2
3
x1
4

Furniture Assembly Instructions Style Guide
5/ 9
Step 6
Step 5
3
2
4
x1
Step 7
Step 8
x1
5
1
3
2
5 x8
①
x1

Furniture Assembly Instructions Style Guide
6/ 9
Step 9
4
Step 10
x1
3
2
Step 11
4
Step 12
x1
3
2

Furniture Assembly Instructions Style Guide
7/ 9
Step 14
Step 13
4
6
Step 15
WALL
WARNING: Serious or fatal crushing injuries can occur from furniture tip-over.
To prevent this item from tipping over it must be permanently fixed to the wall.
Plaster wall fixings are included with this item. Other wall materials require different wall
fixing devices. Use fixings suitable for the walls in your home. For advice on suitable
fixing systems, contact the store of purchase.
B
C
A
D
①
6 x4
①
4pcs
A
2pcs
D
2pcs
C
4pcs
B

Furniture Assembly Instructions Style Guide
8/ 9
Also can be assembled as workbench

Furniture Assembly Instructions Style Guide
9/ 9
MAXIMUM WEIGHT CAPACITY
The shelving is designed to carry up to 90kgs per layer.
DANGER –To prevent furniture from toppling, attach, mount, bolt or otherwise secure to
walls and floors. Do not put heavy items on top shelves. Do not place unstable furniture
near where children play.
Suitable anchor kits are available at your nearest hardware store.
Place equipment evenly and ensure it does not overlap.
The product is intended to hold the maximum weight indicated.
Exceeding the maximum weight will result in instability and may cause injury.
Thank you for your purchase!
Please retain your receipt to validate warranty. If you’d like to know more about
Officeworks’ furniture products, please visit our website. www.officeworks.com.au
CAUTION
CAUTION
Note: 90kgs per shelf
