Jäger Z100-M618.03 S5R User manual

Manual
Z100-M618.03 S5R
High Frequency Spindle
Manual taper change

Item no. 10206007, Revision 002 ( 44 )
Identification of HF spindle
Spindle type
Pmax S6-60% S1-100%
Item no. .... Serial no.
Rated rotation speed
Serial no.
Item no.
Performance data
Spindle type
As we always ensure that our HF spindles are at the cutting edge of techno-
logical development, we reserve the right to make technical modifications
and variations from the exact design described in the manual.
The text in this manual has been compiled with the utmost care. However,
Nakanishi Jaeger GmbH cannot assume any legal responsibility or liability of
any kind for incorrect information and any consequences thereof.
Translations and reproductions – including of extracts – are prohibited with-
out the express written approval o Nakanishi Jaeger GmbH.

Item no. 10206007, Revision 00 3 ( 44 )
Contents:
Translation of the original manual
1 Preliminary information 5
1.1 Purpose of the manual ...................................................... 5
1.2 Explanation of symbols used .......................................... 5
2 Transport and packaging 6
2.1 Scope of supply of HF spindle ........................................ 6
2.1.1 Optional accessories............................................. 6
2.1.2 Documentation supplied.................................... 6
2.2 Packaging of HF spindle.................................................... 7
3 Designated use 7
3.1 Permissible types of machining ..................................... 7
3.2 Permissible materials ......................................................... 7
4 Safety instructions 8
4.1 Safe working.......................................................................... 9
4.2 Shutdown of HF spindle .................................................10
4.3 Installation and maintenance .......................................10
4.4 Modification and repair...................................................10
4.5 Improper operation..........................................................10
5 Technical description 11
5.1 Connections of HF spindle.............................................11
5.2 Electrical connection........................................................12
5.3 Cooling..................................................................................12
5.4 Sealing air.............................................................................12
5.5 Internal coolant supply ...................................................13
5.5.1 Cooling lubricant .................................................13
5.5.2 Filtering the cooling lubricant ........................14
5.5.3 Avoiding pressure peaks...................................14
5.6 Leakage.................................................................................14
5.6.1 Internal coolant supply, vertical installation
....................................................................................15
5.6.2 Internal coolant supply, horizontal installa-
tion............................................................................15
6 Technical Specifications 16
6.1 Dimensions..........................................................................17
6.2 Motor data ...........................................................................18
6.2.1 Performance Diagram........................................19
6.2.2 Equivalent circuit diagram data .....................19
6.3 Wiring diagram...................................................................22
6.4 Motor protection Pt1000................................................23
6.5 Motor protection PTC 150°C..........................................24
6.6 Speed sensor (digital differential magneto resistor)
..................................................................................................25
6.7 Air-borne noise emissions..............................................26
7 Operating location 27
8 Installation 28
8.1 Installing the HF spindle .................................................28
8.2 Diameter of media supply line .....................................29
8.3 Cooling water......................................................................29
8.3.1 Quality of cooling water....................................29
8.3.2 Setting the cooling..............................................29
8.4 Compressed air...................................................................30
8.4.1 Air purity classes (ISO 8573-1).........................30
8.4.2 Setting the sealing air ........................................30
8.5 Setting the internal coolant supply ............................31
9 Commissioning 32
9.1 Running-in schedule ........................................................32
9.2 Daily start-up.......................................................................32
9.3 Shutdown signal................................................................32
9.4 Commissioning after storage........................................33
10 Tool change 34
10.1 Clockwise and counter-clockwise ...............................34
10.2 Manual hollow shank taper ...........................................34
11 Tools for high speed cutting 36
12 Maintenance 37
12.1 Ball bearings........................................................................37
12.2 Daily cleaning .....................................................................37
12.2.1 Before commencing work ................................37
12.2.2 With every tool change .....................................37
12.2.3 Every time the clamping device is changed
....................................................................................38
12.3 In the case of storage.......................................................38
12.4 Monthly maintenance .....................................................38
12.5 Long periods of storage..................................................38
12.6 Maximum storage time...................................................38
13 Dismantling 39
13.1 Disposal and environmental protection...................39
14 Service and repairs 40
14.1 Service partners .................................................................40

Item no. 10206007, Revision 004 ( 44 )
Contents:
Translation of the original manual
14.2 Malfunctions........................................................................41
15 Declaration of Incorporation 43

Preliminary information
Item no. 10206007, Revision 00 5 ( 44 )
1 Preliminary information
The high frequency spindle (HF spindle) is a high quality precision tool for
high speed machining.
1.1 Purpose of the manual
The manual is an important component of the HF spindle.
ÜStore the manual carefully.
ÜMake the manual available to all persons who work with the HF spindle.
ÜRead the documentation supplied in full.
ÜBefore carrying out any work, read the corresponding section of the man-
ual carefully again.
1.2 Explanation of symbols used
To enable quick classification of information, this manual uses visual aids in
the form of symbols and text markings.
Notes are marked with a signal word and a colored box:
DANGER
Dangerous situation!
Results in serious injury or death.
uMeasure to avert the danger.
WARNING
Dangerous situation!
May result in serious injury or death.
uMeasure to avert the danger.
CAUTION
Dangerous situation!
May result in minor to moderate injury.
uMeasure to avert the danger.
Note
May result in material damage. This warning symbol is not a warning for per-
sonal injury.
Tip
Tips indicate useful information for users.

Transport and packaging
Item no. 10206007, Revision 006 ( 44 )
2 Transport and packaging
Avoid strong vibrations or impacts during transportation, as these could dam-
age the ball bearings of the HF spindle.
ÜAny damage reduces the accuracy of the HF spindle.
ÜAny damage restricts the functionality of the HF spindle.
ÜAny damage shortens the service life of the HF spindle.
2.1 Scope of supply of HF spindle
The following parts are supplied with the HF spindle:
qHigh Frequency Spindle
qFelt cleaning taper
qHexagon screwdriver
qTransport packaging
ÜCheck the high frequency spindle for completeness upon delivery.
2.1.1 Optional accessories
Available on request:
qSpindle holder
qFrequency converter
qChiller
qCollet grease
qFurther accessories on request.
Only approved accessories have been tested for operational safety and func-
tionality.
ÜDo not use any other accessories – this may invalidate any warranty claims
and compensation claims for damages.
ÜIf the spindle holder is to be produced in-house, it is essential to contact
Nakanishi Jaeger GmbH before starting production to request the toler-
ances and production plan for the spindle holder.
2.1.2 Documentation supplied
The documents listed below are supplied with the HF spindle:
qManual
qThe declaration of incorporation is part of the manual.
qInspection protocol
ÜCheck that the documentation supplied is complete when the spindle is
delivered. If necessary, request a new copy.

Designated use
Item no. 10206007, Revision 00 7 ( 44 )
2.2 Packaging of HF spindle
All transport packaging materials can be recycled in appropriate disposal facil-
ities.
3 Designated use
The HF spindle is an “incomplete machine” in accordance with the Machinery
Directive and cannot perform any function independently. The HF spindle can
only be operated in conjunction with a machine tool and a frequency con-
verter.
3.1 Permissible types of machining
The HF spindle has been developed only for the following types of machining.
qCutting
qDrilling
qEngraving
qGrinding
ÜContact Nakanishi Jaeger GmbH if other types of machining are required.
3.2 Permissible materials
The HF spindle has been developed only for the following materials.
qMetals (such as alloys, cast metals etc.)
qSintered materials
qPlastics
qWood
qGraphite
qStone (marble, etc.)
qPaper and cardboard
qCircuit boards
qGlass and ceramic
ÜContact Nakanishi Jaeger GmbH if other materials are to be machined.

Safety instructions
Item no. 10206007, Revision 008 ( 44 )
4 Safety instructions
The high frequency spindle is a state of the art product and is safe to operate.
However, the HF spindle may pose a risk in the following cases:
qIf it is installed by untrained personnel.
qIf it is used incorrectly.
qIf it is not used in accordance with its intended use.
The high frequency spindle may only be installed, commissioned, and main-
tained by specialist personnel.
Definition: Specialist personnel are persons who are familiar with the assem-
bly, installation, commissioning, and operation of the product and have the
relevant qualifications for their area of activity. The operator must closely con-
trol the responsibility, training, and monitoring of these personnel.
DANGER: Due to explosion.
HF spindles are not approved for use in areas at risk of explosion. Use in such
areas may result in explosions.
uDo not use the HF spindle in potentially explosive atmospheres.
DANGER: Due to flying parts.
The HF spindle operates at high speeds and may therefore be flung away by
these.
uOperate the HF spindle only if it is installed in the machine or system in a
fixed manner.
Note: Adhere to the limit values.
uObserve the limit values specified in the technical data.
Note: Take account of the machine.
uObserve the manual of the machine in which the HF spindle is installed.
uObserve all safety instructions specified by the machine manufacturer.
uEnsure that the machine does not cause any hazards (e.g. uncontrolled
movements). Do not install the HF spindle in the machine until this has
been done.
Note. Do not damage the HF spindle.
uAny damage reduces the accuracy of the HF spindle.
uAny damage restricts the functionality of the HF spindle.
uAny damage shortens the service life of the HF spindle.

Safety instructions
Item no. 10206007, Revision 00 9 ( 44 )
4.1 Safe working
Observe all safety instructions set out in the manual, the applicable national
accident prevention regulations, and the valid company work, operation, and
safety guidelines.
DANGER: Due to flying parts.
Tools that are not clamped correctly will be flung away by the centrifugal
forces that occur during machining.
uUse the full clamping depth of the clamping system.
uClamp the tool securely.
DANGER: Due to flying parts.
If the wrong rotational direction is used, the clamping system releases and
the tool is flung away.
uIt is essential to adhere to the rotational direction of the HF spindle.
WARNING: Risk of injury due to flying parts.
The HF spindle operates at high speeds which may cause chips to fly out
with great force.
uNever remove the protective devices of the machine or system.
uAlways wear protective goggles during work.
Exampleofdesign: Inserting the
shank
Note: Ensure functionality.
uNever operate the HF spindle without a clamped tool shank.
If no tool shank is clamped:
qThe clamping system is damaged by the centrifugal forces.
qThe clamping system is shifted.
qThe balance of the HF spindle is affected.
qThe bearing is damaged.
ÜTake the relevant measures to protect against splashes and spray accord-
ing to the type of machining, the type of material being machined, and the
type of tool selected.
ÄObserve the manual of the machine in which the HF spindle is installed.
ÜObtain the maximum circumferential speeds of the tools used from the
tool supplier.
Single-point tools are not suitable for high speed cutting.
If they are required for production reasons:
ÜOnly use a balanced tool.
ÄDIN ISO 1940
ÄBalance grade 2,5

Safety instructions
Item no. 10206007, Revision 0010 ( 44 )
The tool cutting diameter (X) must not be greater than the maximum
clamping range (Y).
ÜAlways clamp the tool so that it is as short as possible.
ÜKeep the dimension (Z) small.
Ä(Y) See section: Technical Specifications [}16].
4.2 Shutdown of HF spindle
The procedure for shutting down the high frequency spindle for installation
and maintenance work is as follows:
ÜCompletely disconnect the power supply.
ÜCompletely disconnect the media supply (air and liquid).
ÜMake sure that the shaft of the HF spindle has come to an absolute stand-
still.
If the HF spindle is being shut down to be cleaned:
ÜReconnect only the sealing air.
Tip: Forward the data to the controller.
uUse the option on the frequency converter of detecting the shutdown
signal from the shaft and forwarding this to the machine controller for
evaluation.
4.3 Installation and maintenance
ÜCarry out installation, cleaning, and maintenance work only after shutting
down the HF spindle and after the shaft has come to a standstill.
ÜInstall all safety and protective devices of the machine immediately after
completing work.
4.4 Modification and repair
Modifications or alterations to the HF spindle are only permitted after prior
consultation with Nakanishi Jaeger GmbH.
Only the service partners listed in the “Service and repair [}40]” section are
authorized to open and repair the HF spindle.
Only approved accessories have been tested for operational safety and func-
tionality.
4.5 Improper operation
The high frequency spindle is only safe to operate for its designated use.
ÜObserve the safety instructions in all sections of the manual to prevent
hazards to persons, the environment, the machine, or the HF spindle itself.
Failure to observe the safety instructions may invalidate any warranty claims
and compensation claims for damages.

Technical description
Item no. 10206007, Revision 00 11 ( 44 )
5 Technical description
5.1 Connections of HF spindle
11 12a 3a 3b 12b 12
1Electrical connection
2Cooling water G 1/4"
3a Sealing air (front) G 1/8"
3b Sealing air (rear) G 1/8"
11 Internal coolant supply G 1/8"
12a Leakage M7
12b Leakage M7

Technical description
Item no. 10206007, Revision 0012 ( 44 )
5.2 Electrical connection
The HF spindle may only be operated with a frequency converter (FC).
ÜCheck whether the current, voltage, and frequency data of the HF spindle
match the raw data for the frequency converter.
ÜUse a motor supply line that is as short as possible.
ÜAdjust the speed of the HF spindle using the FC.
ÜRefer to the frequency converter manual for further information.
The FC detects the following operating states of the HF spindle, depending on
the version:
qHF spindle rotating.
qHF spindle too hot.
qHF spindle at a standstill, etc.
The FC forwards the operating states of the HF spindle to the machine con-
troller.
Note: Connect the SpeedTEC quick locking connector.
uFor the combination SpeedTEC connector plug/SpeedTEC cable plug:
uRemove the O ring on the SpeedTEC connector plug.
5.3 Cooling
Liquid cooling keeps the HF spindle at a constant temperature during opera-
tion.
Note: Extension of the service life through heat dissipation.
Heat is produced during operation of the HF spindle. The temperature of the
HF spindle should not exceed + 45° C as this shortens the service life of the
bearing.
uCheck the temperature of the HF spindle on the housing.
5.4 Sealing air
For guidelines on air quality,
see "Air purity classes (ISO
8573-1) [}30]" section.
The sealing air prevents foreign bodies such as chips and liquids (e.g. emul-
sions) from entering the HF spindle.
ÜCheck that air escapes at the front between the housing and the rotating
parts of the HF spindle.

Technical description
Item no. 10206007, Revision 00 13 ( 44 )
5.5 Internal coolant supply
The internal coolant supply cools the tool and the HF spindle.
The tool coolant is routed internally through the HF spindle and tool, and
emerges at the interface of the clamped tool. The coolant lubricates the tool
at the same time.
Note: Unsuitable tool.
Tools without an internal hole are not suitable for internal coolant supply.
uIt is essential to switch off the internal coolant supply if tools without an
internal hole are being used for production reasons.
If this is not done, the HF spindle will be damaged or destroyed.
ÜOnly use tools and tool holders that are suitable for internal coolant sup-
ply.
ÜMake sure that the cooling lubricant used conforms to the current specifi-
cations in legislation and from the trade associations.
5.5.1 Cooling lubricant
ÜDo not use pure or distilled water.
ÄSuch water causes immediate corrosion on bare parts, which is often un-
noticeable at first, but later leads to serious corrosion damage.
ÜOnly use cooling lubricants that comply with the following guidelines:
Corrosion protection in accordance with DIN 51360 Part 2:
No corrosion after 2 hours.
Compatibility with elastomers:
No change to Shore hardness values or elongation
Compatibility with non-ferrous metals:
No damage to copper, brass, or aluminum parts
Adhesive residue behavior after slow evaporation at 50°C:
Not adhesive.
No “adhesive tape effect”
Easily resoluble or re-emulsifiable.

Technical description
Item no. 10206007, Revision 0014 ( 44 )
5.5.2 Filtering the cooling lubricant
Unfiltered flow media with a particle size in excess of 50 µm lead to increased
wear.
ÜUse a filter upstream of the internal coolant supply that filters out particles
that are bigger than 50 μm from the medium.
The greater the number of particles in the flow medium, the greater the wear
on the internal coolant supply.
5.5.3 Avoiding pressure peaks
Pressure peaks mainly occur when an incompressible medium (e.g. cooling lu-
bricant) collides at high speed with a closed or almost closed hole. This impact
may cause the pressure to increase to many times the permitted pressure.
ÜSelect the duty cycle of the valve so that the peaks in pressure that occur
not exceed the normally permitted operating pressure.
Closing valves may also cause excessive pressure (fluid hammer).
Excessive pressures may also occur when pressure is additionally applied to an
incompressible medium (e.g. cooling lubricant) in a closed space due to a
stroke motion.
ÜRemedy: ventilation.
5.6 Leakage
Note: Damage to the HF spindle due to leakage.
Cooling lubricant may enter the HF spindle through the bearing of the inter-
nal coolant supply and destroy it:
qIf the internal coolant supply is operated in the lower pressure range.
qIf the pressure of the cooling medium builds up slowly.
uUse leakage monitoring to protect the HF spindle from damage.

Technical description
Item no. 10206007, Revision 00 15 ( 44 )
5.6.1 Internal coolant supply, vertical installation
Exampleofdesign: Leakage
Leakage Screw-in depth
1High Frequency Spindle max. 6 mm
2Internal coolant supply max. 6 mm
ÜRemove the sealing plugs that protect the connections against damage
and contamination during transportation.
ÜInstead of these sealing plugs, install the appropriate hose fittings.
ÜInstall the corresponding hoses in the hose fittings
ÜRoute the leakage hose with a falling gradient so that the leakage can be
discharged.
ÄAngle: at least 15°.
ÜRoute away the leak to avoid backing up.
5.6.2 Internal coolant supply, horizontal installation
Exampleofdesign: Leakage
Leakage Screw-in depth
1High Frequency Spindle max. 6 mm
2Internal coolant supply max. 6 mm
ÜPosition the HF spindle so that all leakage lines can always be connected to
the relief holes in the 6 o’clock position (at the lowest point).
ÜRemove the sealing plugs that protect the connections against damage
and contamination during transportation.
ÜInstead of these sealing plugs, install the appropriate hose fittings.
ÜInstall the corresponding hoses in the hose fittings
ÜRoute the leakage hose with a falling gradient so that the leakage can be
discharged.
ÄAngle: at least 15°.
ÜRoute away the leak to avoid backing up.

Technical Specifications
Item no. 10206007, Revision 0016 ( 44 )
6 Technical Specifications
Bearings Hybrid ball bearing (pcs) 4
Lifetime lubricated maintenance free
Power values
Liquid cooled
Pmax./5s S6-60% S1-100%
Rated power 11,7 8,7 7,7 [kW]
Torque 6,85 5,19 4,7 [Nm]
Voltage 282 282 282 [V]
Current 38 28,5 25,7 [A]
Motor data Motor technology 3-phase asynchronous drive
(no brushes or sensors)
Frequency 600 Hz
Motor poles (pairs) 2
Rated rotation speed 18.000 rpm
Acceleration/braking value
Per second
10 000 rpm
(other values by consultation)
Characteristics Speed sensor Differential magneto resistor (TTL)
Number of signals = 6
Motor protection PTC 150°C
Pt1000
Housing Stainless steel
Housing diameter 100 mm
Cooling Liquid cooled
Ambient temperature + 10°C … + 45°C
Sealing air
Protection category
(sealing air turned on) IP54
Internal coolant supply
Internal coolant supply < 80 bar
< 10 l/min
Tool change Manual taper change
Tool Holder HSK-C 40 + HSK-D 50
Clamping range up to 16 mm
Clockwise and anticlockwise
Coupler plug 9-pin (SpeedTEC)
Weight ~ 12,5 kg

Technical Specifications
Item no. 10206007, Revision 00 17 ( 44 )
Inner taper run out < 1 µ
Axial run-out < 1 µ
6.1 Dimensions
(*) = Clamping range

Technical Specifications
Item no. 10206007, Revision 0018 ( 44 )
6.2 Motor data
The power values (S1, S6, S2)
are valid for sinusoidal cur-
rents and voltages.
The power values of the HF
spindle are dependent on the
frequency converter used and
may vary from the indicated
values.
Spindle characteristic curve 8523
Motor technology AC Motor
Motor type ACM 82/50/80-4E
Rated power 7,7 kW
Rated rotation speed 18.000 rpm
Cooling Liquid cooled
Motorschutz PTC 150° C
Pt1000
Winding resistance (phase-phase) 0,45 Ω
Power dissipation 1.667 W – max. (S1)
Measured values: S1-100% Rated rotation speed 5 000 10 000 15 000 18 000 rpm
Speed 4 185 9 242 14 271 17 288 rpm
Frequency 167 333 500 600 Hz
Rated power 1,898 4,546 6,6 7,74 kW
Torque 4,332 4,698 4,442 4,28 Nm
Voltage 89 170 240 282 V
Current 24,8 25,7 24,8 24,3 A
cos φ 0,84 0,8 0,79 0,78
Measured values: S6-60% Rated rotation speed 5 000 10 000 15 000 18 000 rpm
Speed 4 313 9 269 14 277 17 282 rpm
Frequency 167 333 500 600 Hz
Rated power 2,122 5,037 7,4 8,72 kW
Torque 4,699 5,189 5 4,82 Nm
Voltage 89 170 240 282 V
Current 27,4 28,5 27,8 27,3 A
cos φ 0,85 0,81 0,8 0,8

Technical Specifications
Item no. 10206007, Revision 00 19 ( 44 )
Measured values: S2-Pmax./
5 s
Rated rotation speed 5 000 10 000 15 000 18 000 rpm
Speed 3 796 8 945 13 933 16 926 rpm
Frequency 167 333 500 600 Hz
Rated power 2,433 6,412 9,8 11,72 kW
Torque 6,12 6,846 6,712 6,61 Nm
Voltage 89 170 240 282 V
Current 38 38 38 38 A
cos φ 0,9 0,84 0,82 0,81
Note on operation with static frequency converters:
For operation with a frequency converter, the effective fundamental voltage
must correspond to the specified motor voltage.
The measured currents may be greater than the specified values due to the
harmonic content.
6.2.1 Performance Diagram
6.2.2 Equivalent circuit diagram data

Technical Specifications
Item no. 10206007, Revision 0020 ( 44 )
Note: Damage due to incorrect performance data.
The values of the parameters relate exclusively to the motor.
uHF spindle values: See tables S1-100%, S6-60% and S2-Pmax.
Parameter*Meaning Value Unit
p0304 Rated voltage (phase-phase) 380 Vrms
p0305 Rated current 22,5 Arms
p0307 Rated power 9,8 kW
p0308 Rated power factor 0,8 cos φ
p0310 Rated frequency 833 Hz
p0311 Rated speed 24.113 rpm
--- Rated power loss 1.667 W
--- Rated rotation speed 18.000 rpm
p0312 Rated torque 3,884 Nm
p0314 Motor poles (pairs) 2 ---
p0320 Rated magnetization current 8,9 Arms
p0322 Maximum speed 42.000 rpm
p0326 Stalling torque correction factor 100 %
p0335 Cooling type Liquid cooled
p0341 Moment of inertia 0,001266 kgm²
p0348 Field weakening operating speed VDC=600V 60.178 rpm
p0350 Stator resistance, cold (strand) 0,225 Ω
p0353 Series inductance (strand) 0 mH
p0354 Rotor resistance, cold 0,243 Ω
p0356 Stator stray inductance 0,365 mH
p0358 Rotor stray inductance 0,352 mH
p0360 Main inductance 4,035 mH
p0604 Motor temperature warning threshold 110 °C
p0605 Motor temperature fault threshold 130 °C
p0640 Current limit 380 Arms
p1800 Pulse frequency 16 kHz
--- DC link voltage 565 VDC
--- Series capacitance 0 µF
--- Maximum voltage V
--- Idle reduction %
--- Stator stray reactance X1 1,91 Ω
--- Rotor stray reactance X2 1,841 Ω
--- Main field reactance Xh 21,128 Ω
(*) Parameters for Siemens SINAMICS 120
