Jäger Z33-M060.51 K3 User manual

Manual
Z33-M060.51 K3
High Frequency Spindle
Manual tool change

Item no. 15201039-01, Revision 012 ( 36 )
Identification of HF spindle
Spindle type
Pmax *
Item no. .... Serial no.
Rated rotation speed
Serial no.
Item no.
Power data
Spindle type
Liquid-cooled spindle holder
S1-100% ... (*)
*
As we always ensure that our HF spindles are at the cutting edge of techno-
logical development, we reserve the right to make technical modifications
and variations from the exact design described in the manual.
The text in this manual has been compiled with the utmost care. However,
Nakanishi Jaeger GmbH cannot assume any legal responsibility or liability of
any kind for incorrect information and any consequences thereof.
Translations and reproductions – including of extracts – are prohibited with-
out the express written approval o Nakanishi Jaeger GmbH.

Item no. 15201039-01, Revision 01 3 ( 36 )
Contents:
Translation of the original manual
1 Preliminary information 4
1.1 Purpose of the manual ...................................................... 4
1.2 Explanation of symbols used .......................................... 4
2 Transport and packaging 5
2.1 Scope of supply of HF spindle ........................................ 5
2.1.1 Optional accessories............................................. 5
2.1.2 Documentation supplied.................................... 5
2.2 Packaging of HF spindle.................................................... 6
3 Designated use 6
3.1 Permissible types of machining ..................................... 6
3.2 Permissible materials ......................................................... 6
4 Safety instructions 7
4.1 Safe working.......................................................................... 8
4.2 Shutdown of HF spindle ................................................... 9
4.3 Installation and maintenance ......................................... 9
4.4 Modification and repair..................................................... 9
4.5 Improper operation............................................................ 9
5 Technical description 10
5.1 Connections of HF spindle.............................................10
5.2 Electrical connection........................................................10
5.3 Cooling..................................................................................11
5.3.1 Cooling via spindle holder................................11
5.4 Sealing air.............................................................................11
6 Technical Specifications 12
6.1 Dimensions..........................................................................13
6.2 Motor data ...........................................................................14
6.2.1 Performance Diagram........................................15
6.2.2 Equivalent circuit diagram data .....................15
Parameter.............................................................................16
6.3 Motor data ...........................................................................17
6.3.1 Performance Diagram........................................18
6.3.2 Equivalent circuit diagram data .....................18
Parameter.............................................................................19
6.4 Wiring diagram...................................................................20
6.5 Motor protection PTC 100°C..........................................21
6.6 Air-borne noise emissions..............................................21
7 Operating location 22
8 Installation 23
8.1 Installing the HF spindle .................................................23
8.2 Diameter of media supply line .....................................23
8.3 Compressed air...................................................................24
8.3.1 Air purity classes (ISO 8573-1).........................24
8.3.2 Setting the sealing air ........................................24
9 Commissioning 25
9.1 Running-in schedule ........................................................25
9.2 Daily start-up.......................................................................26
9.3 Shutdown signal................................................................26
9.4 Commissioning after storage........................................26
10 Tool change 27
10.1 Clockwise..............................................................................27
10.2 Manual tool change..........................................................28
10.2.1 Maximum tightening torques.........................28
11 Tools for high speed cutting 29
12 Maintenance 30
12.1 Ball bearings........................................................................30
12.2 Daily cleaning .....................................................................30
12.2.1 Before commencing work ................................30
12.2.2 With every tool change .....................................30
12.2.3 Every time the clamping device is changed
....................................................................................31
12.3 In the case of storage.......................................................31
12.4 Monthly maintenance .....................................................31
12.5 Long periods of storage..................................................31
12.6 Maximum storage time...................................................31
13 Dismantling 32
13.1 Disposal and environmental protection...................32
14 Service and repairs 32
14.1 Service partners .................................................................32
14.2 Malfunctions........................................................................33
15 Declaration of Incorporation 35

Preliminary information
Item no. 15201039-01, Revision 014 ( 36 )
1 Preliminary information
The high frequency spindle (HF spindle) is a high quality precision tool for
high speed machining.
1.1 Purpose of the manual
The manual is an important component of the HF spindle.
ÜStore the manual carefully.
ÜMake the manual available to all persons who work with the HF spindle.
ÜRead the documentation supplied in full.
ÜBefore carrying out any work, read the corresponding section of the man-
ual carefully again.
1.2 Explanation of symbols used
To enable quick classification of information, this manual uses visual aids in
the form of symbols and text markings.
Notes are marked with a signal word and a colored box:
DANGER
Dangerous situation!
Results in serious injury or death.
uMeasure to avert the danger.
WARNING
Dangerous situation!
May result in serious injury or death.
uMeasure to avert the danger.
CAUTION
Dangerous situation!
May result in minor to moderate injury.
uMeasure to avert the danger.
Note
May result in material damage. This warning symbol is not a warning for per-
sonal injury.
Tip
Tips indicate useful information for users.

Transport and packaging
Item no. 15201039-01, Revision 01 5 ( 36 )
2 Transport and packaging
Avoid strong vibrations or impacts during transportation, as these could dam-
age the ball bearings of the HF spindle.
ÜAny damage reduces the accuracy of the HF spindle.
ÜAny damage restricts the functionality of the HF spindle.
ÜAny damage shortens the service life of the HF spindle.
2.1 Scope of supply of HF spindle
The following parts are supplied with the HF spindle:
qHigh Frequency Spindle
qClamping nut
qJaw wrench
qHook wrench
qTransport packaging
ÜCheck the high frequency spindle for completeness upon delivery.
2.1.1 Optional accessories
Available on request:
qSpindle holder
qFrequency converter
qCollet
qFelt cleaning taper
qCollet grease
qFurther accessories on request.
Only approved accessories have been tested for operational safety and func-
tionality.
ÜDo not use any other accessories – this may invalidate any warranty claims
and compensation claims for damages.
ÜIf the spindle holder is to be produced in-house, it is essential to contact
Nakanishi Jaeger GmbH before starting production to request the toler-
ances and production plan for the spindle holder.
2.1.2 Documentation supplied
The documents listed below are supplied with the HF spindle:
qManual
qThe declaration of incorporation is part of the manual.
qInspection protocol
ÜCheck that the documentation supplied is complete when the spindle is
delivered. If necessary, request a new copy.

Designated use
Item no. 15201039-01, Revision 016 ( 36 )
2.2 Packaging of HF spindle
All transport packaging materials can be recycled in appropriate disposal facil-
ities.
3 Designated use
The HF spindle is an “incomplete machine” in accordance with the Machinery
Directive and cannot perform any function independently. The HF spindle can
only be operated in conjunction with a machine tool and a frequency con-
verter.
3.1 Permissible types of machining
The HF spindle has been developed only for the following types of machining.
qCutting
qDrilling
qEngraving
qGrinding
ÜContact Nakanishi Jaeger GmbH if other types of machining are required.
3.2 Permissible materials
The HF spindle has been developed only for the following materials.
qMetals (such as alloys, cast metals etc.)
qSintered materials
qPlastics
qWood
qGraphite
qStone (marble, etc.)
qPaper and cardboard
qCircuit boards
qGlass and ceramic
ÜContact Nakanishi Jaeger GmbH if other materials are to be machined.

Safety instructions
Item no. 15201039-01, Revision 01 7 ( 36 )
4 Safety instructions
The high frequency spindle is a state of the art product and is safe to operate.
However, the HF spindle may pose a risk in the following cases:
qIf it is installed by untrained personnel.
qIf it is used incorrectly.
qIf it is not used in accordance with its intended use.
The high frequency spindle may only be installed, commissioned, and main-
tained by specialist personnel.
Definition: Specialist personnel are persons who are familiar with the assem-
bly, installation, commissioning, and operation of the product and have the
relevant qualifications for their area of activity. The operator must closely con-
trol the responsibility, training, and monitoring of these personnel.
DANGER: Due to explosion.
HF spindles are not approved for use in areas at risk of explosion. Use in such
areas may result in explosions.
uDo not use the HF spindle in potentially explosive atmospheres.
DANGER: Due to flying parts.
The HF spindle operates at high speeds and may therefore be flung away by
these.
uOperate the HF spindle only if it is installed in the machine or system in a
fixed manner.
Note: Adhere to the limit values.
uObserve the limit values specified in the technical data.
Note: Take account of the machine.
uObserve the manual of the machine in which the HF spindle is installed.
uObserve all safety instructions specified by the machine manufacturer.
uEnsure that the machine does not cause any hazards (e.g. uncontrolled
movements). Do not install the HF spindle in the machine until this has
been done.
Note. Do not damage the HF spindle.
uAny damage reduces the accuracy of the HF spindle.
uAny damage restricts the functionality of the HF spindle.
uAny damage shortens the service life of the HF spindle.

Safety instructions
Item no. 15201039-01, Revision 018 ( 36 )
4.1 Safe working
Observe all safety instructions set out in the manual, the applicable national
accident prevention regulations, and the valid company work, operation, and
safety guidelines.
DANGER: Due to flying parts.
Tools that are not clamped correctly will be flung away by the centrifugal
forces that occur during machining.
uUse the full clamping depth of the collet.
uClamp the tool securely.
DANGER: Due to flying parts.
If the wrong rotational direction is used, the clamping system releases and
the tool is flung away.
uIt is essential to adhere to the rotational direction of the HF spindle.
WARNING: Risk of injury due to flying parts.
The HF spindle operates at high speeds which may cause chips to fly out
with great force.
uNever remove the protective devices of the machine or system.
uAlways wear protective goggles during work.
Exampleofdesign: Inserting the
shank
Note: Ensure functionality.
uNever operate the HF spindle without a clamped tool shank.
If no tool shank is clamped:
qThe clamping system is damaged by the centrifugal forces.
qThe clamping system is shifted.
qThe balance of the HF spindle is affected.
qThe bearing is damaged.
ÜTake the relevant measures to protect against splashes and spray accord-
ing to the type of machining, the type of material being machined, and the
type of tool selected.
ÄObserve the manual of the machine in which the HF spindle is installed.
ÜObtain the maximum circumferential speeds of the tools used from the
tool supplier.
Single-point tools are not suitable for high speed cutting.
If they are required for production reasons:
ÜOnly use a balanced tool.
ÄDIN ISO 1940
ÄBalance grade 2,5

Safety instructions
Item no. 15201039-01, Revision 01 9 ( 36 )
The tool cutting diameter (X) must not be greater than the maximum
clamping range (Y).
ÜAlways clamp the tool so that it is as short as possible.
ÜKeep the dimension (Z) small.
Ä(Y) See section: Technical Specifications [}12].
4.2 Shutdown of HF spindle
The procedure for shutting down the high frequency spindle for installation
and maintenance work is as follows:
ÜCompletely disconnect the power supply.
ÜCompletely disconnect the media supply (air and liquid).
ÜMake sure that the shaft of the HF spindle has come to an absolute stand-
still.
If the HF spindle is being shut down to be cleaned:
ÜReconnect only the sealing air.
Tip: Forward the data to the controller.
uUse the option on the frequency converter of detecting the shutdown
signal from the shaft and forwarding this to the machine controller for
evaluation.
4.3 Installation and maintenance
ÜCarry out installation, cleaning, and maintenance work only after shutting
down the HF spindle and after the shaft has come to a standstill.
ÜInstall all safety and protective devices of the machine immediately after
completing work.
4.4 Modification and repair
Modifications or alterations to the HF spindle are only permitted after prior
consultation with Nakanishi Jaeger GmbH.
Only the service partners listed in the “Service and repair [}32]” section are
authorized to open and repair the HF spindle.
Only approved accessories have been tested for operational safety and func-
tionality.
4.5 Improper operation
The high frequency spindle is only safe to operate for its designated use.
ÜObserve the safety instructions in all sections of the manual to prevent
hazards to persons, the environment, the machine, or the HF spindle itself.
Failure to observe the safety instructions may invalidate any warranty claims
and compensation claims for damages.

Technical description
Item no. 15201039-01, Revision 0110 ( 36 )
5 Technical description
5.1 Connections of HF spindle
1
3
1Electrical connection
3Sealing air M5
5.2 Electrical connection
The HF spindle may only be operated with a frequency converter (FC).
ÜCheck whether the current, voltage, and frequency data of the HF spindle
match the raw data for the frequency converter.
ÜUse a motor supply line that is as short as possible.
ÜAdjust the speed of the HF spindle using the FC.
ÜRefer to the frequency converter manual for further information.
The FC detects the following operating states of the HF spindle, depending on
the version:
qHF spindle rotating.
qHF spindle too hot.
qHF spindle at a standstill, etc.
The FC forwards the operating states of the HF spindle to the machine con-
troller.

Technical description
Item no. 15201039-01, Revision 01 11 ( 36 )
5.3 Cooling
The HF spindle does not feature built-in cooling. However, this means that it
has a lower power than an HF spindle with cooling.
Note: Extension of the service life through heat dissipation.
Heat is produced during operation of the HF spindle. The temperature of the
HF spindle should not exceed + 45° C as this shortens the service life of the
bearing.
uCheck the temperature of the HF spindle on the housing.
uDissipate the heat using the spindle holder.
5.3.1 Cooling via spindle holder
Exampleofdesign:
Air-cooled spindle holder
Exampleofdesign:
Liquid-cooled spindle holder
To increase the power of the HF spindle, the heat generated must be dissi-
pated via the spindle holder (optional accessory).
If the spindle holder is to be produced in-house:
ÜContact Nakanishi Jaeger GmbH.
ÜRequest the tolerances and production plan for the spindle holder.
ÜProduce the spindle holder from a thermally-conductive material (e.g. alu-
minum).
ÜObserve the dimensions of the clamping range in the Technical Specifica-
tions [}12] section. Make sure that the HF spindle is enclosed by the spin-
dle holder to the specified length.
ÜAdd cooling fins or holes (greater heat dissipation) to the external surface
of the spindle holder.
5.4 Sealing air
For guidelines on air quality,
see "Air purity classes (ISO
8573-1) [}24]" section.
The sealing air prevents foreign bodies such as chips and liquids (e.g. emul-
sions) from entering the HF spindle.
ÜCheck that air escapes at the front between the housing and the rotating
parts of the HF spindle.

Technical Specifications
Item no. 15201039-01, Revision 0112 ( 36 )
6 Technical Specifications
Bearings Hybrid ball bearing (pcs) 2 (front)
Steel ball bearing (pcs) 1 (rear)
Lifetime lubricated maintenance free
Power values
Spindle holder cooled
Pmax./5s S6-60% S1-100%
Rated power 0,55 0,5 0,43 [kW]
Torque 0,1014 0,0931 0,0817 [Nm]
Voltage 57 57 57 [V]
Current 10 9,4 8,6 [A]
Power values
Uncooled
Pmax./5s S6-60% S1-100%
Rated power 0,4 0,34 0,25 [kW]
Torque 0,08 0,075 0,06 [Nm]
Voltage 47 47 44 [V]
Current 8,2 7,8 8,1 [A]
Motor data Motor technology 3-phase asynchronous drive
(no brushes or sensors)
Frequency 1.000 Hz
Motor poles (pairs) 1
Rated rotation speed 60.000 rpm
Acceleration/braking value
Per second
10 000 rpm
(other values by consultation)
Characteristics Motor protection PTC 100°C
Housing Aluminium
Housing diameter 33 mm
Cooling Uncooled
Heat dissipation Via the spindle holder
Housing temperature < + 45° C
Ambient temperature + 10°C … + 45°C
Sealing air
Protection category
(sealing air turned on) IP54
Tool change Manual tool change
Collet type ER 8
Optional accessories

Technical Specifications
Item no. 15201039-01, Revision 01 13 ( 36 )
Clamping range up to 5 mm (13/64" )
Clockwise
Connection Cable
length 3 m
Weight ~ 0,62 kg
Inner taper run out < 1 µ
6.1 Dimensions
(*) = Clamping range

Technical Specifications
Item no. 15201039-01, Revision 0114 ( 36 )
6.2 Motor data
The power values (S1, S6, S2)
are valid for sinusoidal cur-
rents and voltages.
The power values of the HF
spindle are dependent on the
frequency converter used and
may vary from the indicated
values.
Spindle characteristic curve 1016
Motor technology AC Motor
Motor type ACM 26/15/45-2E
Rated power 0,43 kW
Rated rotation speed 60.000 rpm
Cooling Spindle holder cooled
(liquid-cooled spindle holder)
Heat dissipation via the mount
Motor protection PTC 100°C
Winding resistance (phase-phase) 0,476 Ω
Power dissipation 174 W – max. (S1)
S1-100% Rated rotation speed 5 000 10 000 30 000 60 000 rpm
Speed 2 905 7 888 27 887 57 985 rpm
Frequency 83 167 500 1 000 Hz
Rated power 0,025 0,066 0,223 0,431 kW
Torque 0,0817 0,0802 0,0765 0,0709 Nm
Voltage 7 12 29 57 V
Current 8,2 8,2 8,2 8,6 A
cos φ 0,93 0,87 0,8 0,73
S6-60% Rated rotation speed 5 000 10 000 30 000 60 000 rpm
Speed 2 720 7 755 27 744 57 588 rpm
Frequency 83 167 500 1 000 Hz
Rated power 0,027 0,074 0,249 0,5 kW
Torque 0,0931 0,091 0,0857 0,083 Nm
Voltage 8 12 30 57 V
Current 9 9 9 9,4 A
cos φ 0,94 0,88 0,81 0,76
S2-Pmax./5 s Rated rotation speed 5 000 10 000 30 000 60 000 rpm
Speed 2 769 7 814 27 870 57 935 rpm
Frequency 83 167 500 1 000 Hz
Rated power 0,03 0,083 0,283 0,558 kW
Torque 0,104 0,1014 0,0969 0,092 Nm
Voltage 8 13 30 57 V
Current 10 10 10 10 A
cos φ 0,94 0,88 0,8 0,77

Technical Specifications
Item no. 15201039-01, Revision 01 15 ( 36 )
Note on operation with static frequency converters:
For operation with a frequency converter, the effective fundamental voltage
must correspond to the specified motor voltage.
The measured currents may be greater than the specified values due to the
harmonic content.
6.2.1 Performance Diagram
6.2.2 Equivalent circuit diagram data
Note: Damage due to incorrect performance data.
The values of the parameters relate exclusively to the motor.
uHF spindle values: See tables S1-100%, S6-60% and S2-Pmax.

Technical Specifications
Item no. 15201039-01, Revision 0116 ( 36 )
Parameter*Meaning Value Unit
p0304 Rated voltage (phase-phase) 57 Vrms
p0305 Rated current 8,6 Arms
p0307 Rated power 0,431 kW
p0308 Rated power factor 0,73 cos φ
p0310 Rated frequency 1.000 Hz
p0311 Rated speed 57.958 rpm
--- Rated power loss 174 W
--- Rated rotation speed 60.000 rpm
p0312 Rated torque 0,071 Nm
p0314 Motor poles (pairs) 1 ---
p0320 Rated magnetization current 5,17 Arms
p0322 Maximum speed 60.000 rpm
p0326 Stalling torque correction factor 100 %
p0335 Cooling type Spindle holder cooled
p0341 Moment of inertia 0,0000053 kgm²
p0348 Field weakening operating speed VDC=600V 253.070 rpm
p0350 Stator resistance, cold (strand) 0,238 Ω
p0353 Series inductance (strand) 0 mH
p0354 Rotor resistance, cold 0,136 Ω
p0356 Stator stray inductance 0,058 mH
p0358 Rotor stray inductance 0,083 mH
p0360 Main inductance 0,89 mH
p0604 Motor temperature warning threshold 80 °C
p0605 Motor temperature fault threshold 100 °C
p0640 Current limit 10 Arms
p1800 Pulse frequency 16 kHz
--- DC link voltage 80 VDC
--- Series capacitance µF
--- Maximum voltage V
--- Idle reduction %
--- Stator stray reactance X1 0,367 Ω
--- Rotor stray reactance X2 0,519 Ω
--- Main field reactance Xh 5,59 Ω
(*) Parameters for Siemens SINAMICS 120

Technical Specifications
Item no. 15201039-01, Revision 01 17 ( 36 )
6.3 Motor data
The power values (S1, S6, S2)
are valid for sinusoidal cur-
rents and voltages.
The power values of the HF
spindle are dependent on the
frequency converter used and
may vary from the indicated
values.
Spindle characteristic curve 1012
Motor technology AC Motor
Motor type ACM 26/15/45-2E
Rated power 0,25 kW
Rated rotation speed 60.000 rpm
Cooling Uncooled
Heat dissipation via the mount
Motor protection PTC 100°C
Winding resistance (phase-phase) 0,476 Ω
Power dissipation 69 W – max. (S1)
Measured values: S1-100%
Rated rotation speed 5 000 10 000 20 000 30 000 40 000 50 000 60 000 rpm
Speed 3 953 8 458 18 000 27 953 37 806 47 954 58 182 rpm
Frequency 83 167 333 500 667 833 1 000 Hz
Rated power 0,022 0,053 0,112 0,169 0,207 0,232 0,245 kW
Torque 0,0536 0,0603 0,0595 0,0577 0,0522 0,0462 0,0403 Nm
Voltage 8 11 18 25 31 37 44 V
Current 8,1 6,7 6,8 6,8 6,5 6,1 5,6 A
cos φ 0,85 0,84 0,83 0,81 0,81 0,79 0,77
Measured values: S6-60%
Rated rotation speed 5 000 10 000 20 000 30 000 40 000 50 000 60 000 rpm
Speed 3 512 7 925 17 928 27 956 37 866 47 504 57 580 rpm
Frequency 83 167 333 500 667 833 1 000 Hz
Rated power 0,023 0,062 0,135 0,201 0,257 0,303 0,343 kW
Torque 0,0629 0,0751 0,0718 0,0686 0,0649 0,061 0,057 Nm
Voltage 7 11 19 28 35 40 47 V
Current 6,8 7,8 7,7 7,5 7,4 7,3 7 A
cos φ 0,91 0,87 0,82 0,8 0,79 0,81 0,8

Technical Specifications
Item no. 15201039-01, Revision 0118 ( 36 )
Measured values: S2-Pmax./5 s
Rated rotation speed 5 000 10 000 20 000 30 000 40 000 50 000 60 000 rpm
Speed 3 462 8 127 18 020 28 161 38 025 47 687 57 722 rpm
Frequency 83 167 333 500 667 833 1 000 Hz
Rated power 0,026 0,068 0,147 0,222 0,287 0,349 0,406 kW
Torque 0,073 0,0799 0,0778 0,0754 0,072 0,0699 0,067 Nm
Voltage 7 12 19 28 35 40 47 V
Current 7,7 8,2 8,2 8,1 8 8,1 8 A
cos φ 0,91 0,87 0,83 0,8 0,8 0,82 0,81
Note on operation with static frequency converters:
For operation with a frequency converter, the effective fundamental voltage
must correspond to the specified motor voltage.
The measured currents may be greater than the specified values due to the
harmonic content.
6.3.1 Performance Diagram
6.3.2 Equivalent circuit diagram data

Technical Specifications
Item no. 15201039-01, Revision 01 19 ( 36 )
Note: Damage due to incorrect performance data.
The values of the parameters relate exclusively to the motor.
uHF spindle values: See tables S1-100%, S6-60% and S2-Pmax.
Parameter*Meaning Value Unit
p0304 Rated voltage (phase-phase) 44,4 Vrms
p0305 Rated current 5,6 Arms
p0307 Rated power 0,245 kW
p0308 Rated power factor 0,77 cos φ
p0310 Rated frequency 1.000 Hz
p0311 Rated speed 58.182 rpm
--- Rated power loss 69 W
--- Rated rotation speed 60.000 rpm
p0312 Rated torque 0,04 Nm
p0314 Motor poles (pairs) 1 ---
p0320 Rated magnetization current 2,71 Arms
p0322 Maximum speed 60.000 rpm
p0326 Stalling torque correction factor 100 %
p0335 Cooling type Uncooled
p0341 Moment of inertia 0,0000053 kgm²
p0348 Field weakening operating speed
VDC=600V 324.887 rpm
p0350 Stator resistance, cold (strand) 0,238 Ω
p0353 Series inductance (strand) 0 mH
p0354 Rotor resistance, cold 0,136 Ω
p0356 Stator stray inductance 0,087 mH
p0358 Rotor stray inductance 0,121 mH
p0360 Main inductance 1,323 mH
p0604 Motor temperature warning threshold 60 °C
p0605 Motor temperature fault threshold 70 °C
p0640 Current limit 8 Arms
p1800 Pulse frequency 16 kHz
--- DC link voltage 65 VDC
--- Series capacitance µF
--- Maximum voltage V
--- Idle reduction %
--- Stator stray reactance X1 0,546 Ω
--- Rotor stray reactance X2 0,758 Ω
--- Main field reactance Xh 8,31 Ω
(*) Parameters for Siemens SINAMICS 120

Technical Specifications
Item no. 15201039-01, Revision 0120 ( 36 )
6.4 Wiring diagram
Note: Do not change the ex-works configuration.
Any change may cause overvoltage on the electrical components (e.g. PTC,
differential magneto resistor).
Spindelstecker S7C (S15)
spindle plug S7C (S15)
.
.
.
.
.
.
U
V
W
GNYE
BN 0,2mm²
BU 0,2mm²
BK 0,2mm²
WH (KTY) / BU (PTC) 0,14mm²
BN (KTY) / RD (PTC) 0,14mm²
Stator
KTY / PTC
Spindel
1
3
5
PE
6
2
BN 0,5 mm²
GN 0,5 mm²
WH 0,5 mm²
GNYE 0,5 mm²
GY 0,5 mm²
PK 0,5 mm²
Motorkabel 7x0,5mm²
motor cable 7x0,5mm²
1
Perschewski
14.09.16
1
29043670
g
f
e
d
c
b
a
456
13 2
a
b
c
d
e
f
g
Bl.
Übersetzungen, Vervielfältigungen und die Weitergabe an Dritte, auch nur auszugsweise,
ist ohne schriftliche Gehnehmigung der Fa. Alfred Jäger GmbH untersagt
Datum
Gepr.
Bearb.
Norm
Projekt Nr.:
Version Nr.:Zeichn.Nr.:
von
Blatt
DIN 81346Kabelanschlussplan S7 (S15)
1.0
4
