Jøtul C450 Kennebec
Fireplace Insert
Keep these instructions for future reference.
Installation and Operating Instructions
for the United States & Canada
Jøtul C450 Kennebec
Fireplace Insert

2
Welcome to Jøtul...
Congratulations on the purchase of your new
Jøtul C 450 Kennebec Fireplace Insert.
We at Jøtul are glad you’ve made the decision to
warm your hearth with a Jøtul product.
Your new fireplace insert exemplifies our
experience gained over 150 years as the world’s
largest manufacturer of solid fuel burning
appliances.We’ve been making fine quality cast
iron wood and coal stoves and fireplaces
continuously since 1853.
The C 450 Kennebec Fireplace Insert combines
advanced wood combustion technology with the
warm, traditional elements of cast iron.
With proper care and use, your Jøtul fireplace will
provide you with many years of safe, dependable
and satisfying service.
The C 450 Kennebec Fireplace Insert is designed
and approved for installation into an existing,
conventional masonry fireplace. Please take a
few minutes to familiarize yourself with this
manual and the features of your new Jøtul
fireplace.

3
Table of Contents
Standards and Safety Notices
Standards / Codes ........................................................ 4
Safety Notices ............................................................... 5
Preparation ..................................................................... 5
Specifications
C450 Kennebec Fireplace Insert ................................ 6
C450 Kennebec Surround Assembly ......................... 6
Installation
Masonry Fireplace Requirements ............................. 7
Factory-built Fireplace Requirements ...................... 7
Chimney Height ............................................................. 7
Clearance to Combustibles ........................................ 8
Hearth Protection ......................................................... 9
Chimney Connection ................................................. 10
Surround Assembly .................................................... 11
Mantel Heat Shield Assembly ................................. 12
Blower ........................................................................... 13
Operation
Wood Fuel ..................................................................... 16
Air Control .................................................................... 16
Starting / Maintaining the Fire ............................... 17
Formation of Creosote ............................................. 17
Maintenance
Ash Removal ................................................................ 18
Glass Care .................................................................... 18
General Maintenance ............................................... 19
Gaskets ......................................................................... 19
Illustrated Parts Breakdown
Parts List .............................................................. 20-21
Appendix A
Alternate Floor Protection ....................................... 22

4
Standards
The Jøtul C450 Kennebec Fireplace Insert has been
tested and listed to: U.S: ANSI/UL 1482
Canada: CAN/ULC-S628-93
Tests performed by:
ITS, Intertek Testing Services, Middleton, WI
Manufactured and distributed by:
Jøtul North America
55 Hutcherson Dr.
Gorham, ME 04038
MEA No. 368-04-E
This heater meets the U.S. Environment Protection
Agency’s Emissions limits for wood heaters
manufactured and sold after July 1, 1990.
Under specific test conditions, this heater has
shown heat output at rates ranging from 10,000
to 35,000 BTU’s per hour.
THE JØTUL C450 KENNEBEC FIREPLACE INSERT IS
ONLY LISTED TO BURN WOOD. DO NOT BURN ANY
OTHER FUELS.
READ THIS ENTIRE MANUAL BEFORE YOU INSTALL
AND USE YOUR NEW FIREPLACE INSERT.
SAVE THESE INSTRUCTIONS AND MAKE THEM
AVAILABLE TO ANYONE USING OR SERVICING THE
FIREPLACE.
Check Building Codes
When installing, operating and maintaining your
Jøtul C450 Kennebec Fireplace Insert, follow the
guidelines presented in these instructions, and
make them available to anyone using or servicing
the stove.
Your city, town, county or province may require a
building permit to install a solid fuel burning
appliance.
In the U.S., the National Fire Protection
Association’s Code, NFPA 211, Standards for
Chimneys, Fireplaces, Vents and Solid Fuel Burning
Appliances, or similar regulations, may apply to the
installation of a solid fuel burning appliance in
your area.
In Canada, the guideline is established by the CSA
Standard, CAN/CSA-B365-M93, Installation Code
for Solid-Fuel-Burning Appliances and Equipment.
Always consult your local building inspector or
authority having jurisdiction to determine what
regulations apply in your area.
Installation and Operation Instructions for USA/Canada
Installation et fonctionnement pour Canada
SAFETY NOTICE: IF THIS SOLID FUEL ROOM HEATER IS NOT PROPERLY INSTALLED, A
HOUSE FIRE MAY RESULT. FOR YOUR SAFETY, FOLLOW THE INSTALLATION
DIRECTIONS. CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS
AND INSTALLATION INSPECTION REQUIREMENTS IN YOUR AREA. SAVE THESE
INSTRUCTIONS FOR FUTURE REFERENCE.
Avis de sécurité: Une installation non appropriée de ce poêle de chauffage risque
de provoquer un incendie. Assurez votre sécurité en respectant les directives
d’installation suivantes. Consultez les autorités locales du bâtiment ou de la
prévention des incendies au sujet des restrictions et exigences relatives aux
inspections d’installations dans votre région.
Tested and listed by ITS, Intertek Testing Services, Middleton, Wisconsin.
Tested to U.S. Standards: ANSI/UL 1482, Canadian Standards: CAN/ULC-S627-M93

5
Safety Notices
• BURN SOLID WOOD FUEL ONLY
•DO NOT USE CHEMICALS OR FLUIDS TO START
THE FIRE. DO NOT BURN GARBAGE OR
FLAMMABLE FLUIDS.
•IF THIS ROOM HEATER IS NOT PROPERLY
INSTALLED, A HOUSE FIRE MAY RESULT. TO
REDUCE THE RISK OF FIRE, FOLLOW THE
INSTALLATION INSTRUCTIONS. FAILURE TO
FOLLOW THESE INSTRUCTIONS MAY RESULT
IN PROPERTY DAMAGE, BODILY INJURY, OR
LOSS OF LIFE.
• CONTACT THE LOCAL BUILDING OR FIRE
OFFICIALS ABOUT RESTRICTIONS AND
INSTALLATION INSPECTION REQUIREMENTS
IN YOUR AREA. WHEN NOT ADDRESSED IN
THIS MANUAL, OR BY LOCAL CODE AUTHORI-
TIES, INSTALLATION SPECIFICATIONS AND
REQUIREMENTS DEFER TO NFPA 211.
•DO NOT CONNECT THIS FIREPLACE TO ANY
AIR DISTRIBUTION DUCT OR SYSTEM .
•EXTREMELY HOT WHILE IN OPERATION! KEEP
CHILDREN, CLOTHING AND FURNITURE AWAY.
CONTACT WILL CAUSE SKIN BURNS.
• NEVER OPERATE THE FIREPLACE WITH A
CRACKED OR BROKEN GLASS PANEL.
• Install smoke detectors in the living areas
and bedrooms of your home. Test them
regularly and install new batteries twice
annually. When installed in the same room
as the stove, a smoke detector should be
located as far from the stove as possible to
prevent it from sounding when adding fuel
to the fire.
• Avoid creating a low pressure condition in the
room where the stove is operating. Be aware
that operation of an exhaust fan or clothes
dryer can create a low pressure area and
consequently promote flow reversal through
the stove and chimney system. The chimney
and building, however, always work together
as a system - provision of outside air, directly
or indirectly to an atmospherically vented
appliance will not guarantee proper chimney
performance. Consult your local Jøtul autho-
rized dealer regarding specific installation/
performance issues.
Installation
Preparation
We strongly urge you to have your authorized Jøtul
dealer install your new Jøtul C450 Kennebec
Fireplace Insert. If you install the unit yourself, ask
your dealer to review your installation plans.
• Check with local building officials to determine
what permits may be required before installa-
tion.
• Notify your insurance company before installing
this fireplace.
Approved Installations
The Jøtul C450 Kennebec Fireplace Insert may be
installed into an existing masonry fireplace with a
fully-lined masonry chimney.
Unpacking the Fireplace
All components of the Jøtul C450 Kennebec Fire-
place Insert are contained within the carton on a
single pallet. Carefully unpack the contents and
inspect each item for damage. Notify your dealer of
any damage such as dents, cracked glass, or broken
bricks.
Contents:
• Steel Firebox - including Firebricks, 18 installed
• Surround Panels - Matte Black / Blue Black
Left Breastplate Right Breastplate
Left Leg Panel Right Leg Panel
Trim Rod
• Ashlip Assembly / Base Extension
• Hardware Bag
• Fireplace Conversion Notice Plate
• M6 x 12 Hex Head Flange Bolts, 4
• M6 x 10 Hex Head Flange Bolts, 2
• M6 Fender Washers, 4
• Stove Tool
Tools & Materials Required:
• work gloves
• safety glasses
• tape measure
• phillips screwdriver
• tin snips
• power drill
• High Temperature Sealant
• 1” (25 mm) masonry anchors or nails, two
• #10 x 1/2” sheet metal screws, three
• 10 mm open end wrench or socket

6
5 1/4
158 mm
12 1/2 
311 mm
12 3/4
349 mm
6 1/2
165 mm
16 3/4
425 mm
25 1/2
635 mm
1 1/2
38 mm
29
737 mm
9 1/4
235 mm
8 1/2
216 mm
25 1/4
641 mm
2 1/2
64 mm
12 3/4 - 16 3/4
324 mm - 425 mm
Cabinet Depth Adjustment
5
127 mm
22
559 mm
5 1/4
158 mm
to
9 1/4
235 mm
Jøtul C450 Kennebec
Specifications
Performance
Fuel: 20” Logs
Heat Output1: 50,000 BTU/hr. (4.1 kg/hr.)
Heating Capacity2: 1,100 - 1,600 sq. ft.
Overall Efficiency3: 71%
Emissions: 4.4 grams/hr.
Burn Time: 4-9 hours
Optional Blower: 125 cfm.
Shipping Weight: 445 lbs. (202 kg.)
1 Maximum Heat Output based on total
kilograms of dry wood burned in a
one hour period.
2 Heating Capacity and Maximum Burn
Time will vary depending on design of
home, climate, wood type and
operation.
3 Overall Efficiency is based on a burn
rate of .99 kg wood per hour.
The Jøtul C450 Kennebec Fireplace Insert
meets U.S. EPA emission limits for wood
heaters sold after July 1990, and are
tested and listed to ANSI/UL 1482, and
CAN/ULC S628.93. It is intended for
installation in accordance with NFPA
211 or CAN/CSA B365.
MEA No. 113-00-E
to Glass Panel
Surround
Panel
Figure 4. Flue Collar Centerline from Front Face
Figure 3. Overall Surround Dimensions
Figure 2. Minimum Sleeve Adjustment
Figure 1. Maximum Sleeve Adjustment
Firebox
Sleeve
Firebox
Sleeve
Firebox
Firebox
to Glass
Panel
27
40
1016 mm
30 1/4
768 mm

7
Installation
Masonry Fireplace Requirements
• The entire fireplace and chimney must be cleaned
and inspected before installation. The system must
meet local building code requirements.
• The structure and components must be free of any
defects such as cracks or broken bricks or flue tiles.
Any damage must be repaired before installation.
Any opening that may exist between the masonry
of the fireplace and the facing masonry must be
permanently sealed.
• The chimney must have a clay tile liner or a
stainless steel liner utilizing a positive connection.
•DO NOT REMOVE BRICKS OR MORTAR FROM THE
FIREPLACE OR CHIMNEY STRUCTURE. However,
masonry or steel may be removed from the
smoke shelf and adjacent damper frame area to
accommodate installation of a chimney liner,
provided that their removal will not weaken the
structure of the fireplace or chimney, and will
not reduce protection for combustible materials.
•CHIMNEY HEIGHT:
Minimum - 15 ft. ( 4.57 meters)
Maximum - 33 ft. (10.5 meters)
Factory-Built Fireplace Requirements
The Jøtul C450 may be installed into a factory-built
fireplace with the following conditions:
• The factory-built fireplace must be listed per UL
127 or ULC S610.
• Installation must include a full height listed
chimney liner meeting type HT requirements
(2100F) per UL 1777 (U.S.) or ULC S635 (CAN). The
liner must be securely attached to the insert flue
collar and the chimney top.
• The damper or fireplace front must be sealed to
prevent passage of room air into the the chimney
cavity.
• Circulating air chambers (i.e. in a steel fireplace
liner or metal heat circulator) may not be blocked.
• Air flow within and around the fireplace shall not
be altered by installation of the insert. The C450
Surround Panels comply with this requirement.
• Alteration of the fireplace is limited to
a) removal of the damper for liner installation
b) removal of external, non-functional trim which
must be stored within the fireplace for replace-
ment.
• Fireplace Conversion Notice PN 220508 must be
permanently attached to the back of the fireplace.
• Final approval is contingent on the authority
having local jurisdiction.
Minimum Fireplace Dimensions
A: FRONT WIDTH * ...................... 27 1/2” (698 mm)
B: HEIGHT ............................................. 23” (584 mm)
C: REAR WIDTH............................ 25 1/2” (648 mm)
D: REAR HEIGHT .......................... 21 1/2” (546 mm)
E: DEPTH............................................... 14” (355 mm)
EC
D
A
B
Figure 5. Minimum Fireplace Dimensions
*NOTE: Width dimension accommodates clearance for
Surround attachment to the front of the firebox.

8
Minimum Clearances
Clearances are measured from the hearth surface,
glass, or centerline as noted below.
A: Hearth Protection, width from centerline ..........
.............................................................. 20” (508 mm)
B: Hearth Protection, forward from glass ................
.............................................................. 18” (457 mm)
C: Side Trim, 1” max. thickness, from centerline ....
.......................................................... 20 3/4” (527 mm)
D: Side Room Wall ..................... 44 1/4” (1124 mm)
E: Mantel- with no Heat Shield:
3 1/2” (90 mm) ...................... 49 1/2” (1257 mm)
F: Mantel- with no Heat Shield:
12” (304 mm) max. depth - 55 1/2” (1410 mm)
Figure 6. Clearance Diagram - No Heat Shielding
Figure 7. Mantel Clearances - measured from the
hearth surface to the lowest mantel surface.
Clearance to Combustible Materials
• There may be no combustible materials located
anywhere within 36” (914 mm) of the front of the
fireplace insert. This precaution includes items
such as drapes or doors that could swing into the
area within 36” of the insert.
• Clearance (open space) must be maintained
between the fireplace insert and combustible
materials located above and to the side.
See figures 6 - 8 for minimum dimensions.
Mantel Clearance with
Optional Heat Shield 155346
Clearance may be reduced as shown in fig. 8.
Maximum approved Mantel Depth is 12”.
Clearance is measured from the hearth to the
bottom of the mantel as illustrated.
39
99 cm
37 1/2
95 cm
40 1/2
103 cm
42
107 cm
43 1/2
111 cm
12
305 mm
9 7/8
250 mm
7 3/4
197 mm
5 5/8
143 mm
3 1/2
89 mm
MANTEL
AREA
Figure 8. Mantel Clearances, with Mantel Heat Shield
155346 - measured from the hearth to the mantel.
51
130 cm
49 1/2
126 cm
52 1/2
134 cm
54
138 cm
55 1/2
142 cm
12
305 mm
9 7/8
250 mm
7 3/4
197 mm
5 5/8
143 mm
3.5
89 mm
MANTEL
AREA
C
B
D
E
A
F

9
Hearth Protection Requirements
The floor area in front of fireplace insert must be
protected from live sparks and radiant heat.
• Materials: Hearth protection must be noncom-
bustible insulating board, having an R value of
2.92 (0.343 K-value) such as Kaowool® 2600 #15
or the equivalent mortared masonry material. See
Appendix A on page 18 for information how to
calculate the R-value of alternative materials.
Alternate protection must composed of materials
as specified by NFPA 211.
• Protected Area: 18” Deep x 40” Wide
A) Front - The protection must extend at least 18
inches (457 mm) forward from the glass panel in
the fireplace insert doors.
B) Sides - Protection must extend 20 inches
(508 mm) to both sides of the centerline of the
insert.
• Note that the firebox may extend out forward of
the fireplace face depending on where the
cabinet sleeve has been set to accommodate flue
connection. Always measure hearth protection
from the final, installed position of the firebox
and glass doors. See figures 9 and 10.
6 1/2
(165 mm)
24 1/2
(622 mm)
from face
18
(457 mm)
from glass
Firebox
Sleeve
Figure 10. Provide hearth protection to accommodate
maximum firebox extension forward of fireplace face.
Figure 9. Sleeve adjustment results in minimum
firebox extension forward of fireplace face.
2 1/2
(64 mm)
18
(457 mm)
from glass
20 1/2
(521 mm)
from face
Firebox
Sleeve

10
Locking
Bracket
Damper
Frame
djustable
Sealing Plate
Flex
Connector
Apply sealant
around damper
opening
Flex Connector
Pipe extends into
the flue tile
Figure 11. Positive Chimney Connection - U.S.
Attach Fireplace
Conversion
Notice Plate to
Rear Wall of
Fireplace
Chimney Connection
A positive connection must be made between the
fireplace insert and the chimney by one of the two
following approved methods.
In the U.S: See fig. 11. The insert is connected to a
listed stainless steel flexible connector that
extends beyond the chimney flue tile liner.
Alternatively, 22 ga. blue steel or greater may be
used. A sealed block-off plate must be installed
at the damper area of the existing fireplace.
In Canada: See fig. 11a. This fireplace insert must be
installed with a continuous chimney liner of 6”
(152 mm) diameter extending from the fireplace
insert to the top of the chimney. The chimney
liner must conform to the Class 3 requirements
of CAN/ULC-S635, Standard for Lining Systems
for Existing Masonry or Factory-Built Chimneys
and Vents, or CAN/ULC-S640, Standard for Lining
Systems for New Masonry Chimneys.
Do not use aluminum or galvanized steel pipe for
chimney connection components - these materials
are not suitable for use with solid fuel.
Installation
1. Remove the existing damper and linkage compo-
nents from the fireplace. Alternatively, you can
wire the damper plate to lock it in the open
position. Thoroughly clean the firebox and
smokeshelf area with a wire brush.
2. If the fireplace has been modified to accommo-
date installation, use anchors or masonry nails to
attach the metal Fireplace Conversion Notice
Plate (PN 220508) to the back wall of the ma-
sonry fireplace firebox where it will be readily
seen should the insert be removed.
3. Install the Flex Connection plate according to the
manufacturer’s instructions. The sealing plate
may require trimming to accommodate your
specific fireplace damper.
