Jøtul F 105 R User manual

Jøtul F 105 R
UK - Installation and operating instructions 4
FR - Manuel d’installation et d’utilisation 27
ES - Instrucciones para instalación 50
IT - Manuale di installazione ed uso 73
Jøtul F 105 R
Manual Version P05
The manuals which are enclosed with the product must be kept throughout the product’s entire service life.
Les manuels fournis avec le produit doivent être conservés pendant toute la durée de vie du produit. I manuali
inclusi con il prodotto vanno conservati per l’intera durata di vita del prodotto.
Jøtul F 105 B Jøtul F 105 LL Jøtul F 105 SL

2
Jøtul F 105 B
(Base) Jøtul F 105 R B (Base)
Jøtul F 105 LL
(Long legs) Jøtul F 105 R LL (Long legs)
Jøtul F 105 SL
(Short legs) Jøtul F 105 R SL (Short legs)

3
EU no. 215/1186 - 24/04/2015
Datasheet / Fiche Technique / Ficha técnica /
Scheda dati / Datasheet / Datenblatt
Requirements / Exigences / Requisitos / Requisiti /
Vereisten / Forderungen
Supplier /
Fabricante /
Fornitore /
Vereisten /
Lieferant:
Jøtul AS
Product models
Produits concernés
Modelos
Modelli
Product modellen
Varianten der Feuerstelle
Jøtul F 105 Series:
Jøtul F 105 B
Jøtul F 105 LL
Jøtul F 105 SL
Jøtul F 105 R B
Jøtul F 105 R LL
Jøtul F 15 R SL
Energy efficiency class / Classe énergétique / Clase de
eficiencia energética / Classe energetica / Energie
efficiëncy klasse / Energieeffizienz-Klasse A
Direct heat output / Puissance réelle de sortie / Potencia
calorifica emitida / Emissione di calore diretta / Directe
warmte afgifte / Nennwärmeleistung 5,2 kW
Energy efficiency index / Index de rendement énérgétique/
Índice de eficiencia energetica / Indice di efficienza
energetica / Energie efficiëncy index / Energieeffizienz-
Index
111,4
Efficiency at nominal heat output / Rendement à
puissance nominale / Eficiencia al rendimiento nominal /
Efficienza alla potenza nominale / Efficiency bij nominale
warmte afgifte / Wirkungsgrad bei Nennheizleistung
83 %
xAny specific precautions that shall be taken when the
local space heater is assembled installed or
maintained.
xToutes les précautions spécifiques doivent être prises
lors de l’assemblage, l’installation ou l’entretien de
l’appareil.
xCualquier precaución específica que deba tenerse en
cuenta durante el montaje, instalación o
mantenimiento del equipo de calefacción
xPrecauzioni specifiche da prendere quando il
riscaldatore viene assemblato, installato o mantenuto
in uno spazio.
xEventuele specifieke voorzorgsmaatregelen die
worden genomen wanneer de plaatselijke
ruimteverwarming wordt gemonteerd, geïnstalleerd of
onderhouden.
xBesondere Maßnahmen bei Montierung, Installation
und Wartung.
xFire safety precautions such as safety distances when
installing, national standards, local codes and
regulations. See the Instructions manual.
xLes précautions d'incendie telles que les distances de
sécurité lors de l'installation, le suivi des normes, les
codes locaux et les règlementations nationales. Veuillez
lire le manuel d’installation.
xPrecauciones frente a incendios como distancia de
seguridad en la instalación, estándares nacionales,
códigos locales y reglamentos. Lea el manual de
instalación.
xPrecauzioni per la sicurezza antincendio come le distanze
di sicurezza durante l'installazione, le normative nazionali
e locali. Leggere il manual.
xBrandveiligheidsmaatregelen, zoals veiligheids-
afstanden bij installatie, nationale normen, lokale
codes en voorschriften. Leesௗde installatiehandleiding.
xFür brenntechnische Verhältnisse, wie z.B.
Aufstellbedingungen und nationale Forderungen.
Siehe die Montage- und Bedienungsanleitung.

4
Table of contents
1.0 Technical data .........................................4
2.0 Relationship to the authorities..................4
3.0 Safety.......................................................5
4.0 Installation .............................................13
5.0 Daily Use................................................22
6.0 Maintenance...........................................23
7.0 Servicing ................................................23
8.0 Optional Extras.......................................26
9.0 Recycling................................................26
10.0 Warranty ................................................26
On all our products there is a label
indicating the serial number and
year. Write this number in the
place indicated in the installation
instructions.
Always quote this serial number
when contacting your retailer or
Jøtul.
les combustibles recommandés.
Respectez les consignes d'utilisation. Utilisez uniquement
Verwenden Sie nur empfohlenen Brennstoffen.
Montage- und Bedienungsanleitung beachten.
Follow user`s instructions. Use only recommended fuels.
standard
Certificate/
The appliance can be used in a shared flue.
Minimum distance to adjacent combustible materials:
Emission of CO in combustion products
Serial no: Y-xxxx,Year: 200x
Manufacturer:
N-1602 Fredrikstad
Norway
Jøtul AS
POB 1441
Sweden
EUR Intermittent
Nominal heat output
Norway
Country
Operational type
Fuel type
Operation range
Efficiency
Klasse II
Classification
Standard
Flue gas temperature
Room heater fired by solid fuel
Product:
Jøtul
SP Sveriges Provnings- och
221546
Forskningsinstitut AB
SP Swedish National
Testing and Research
Institute
:
Approved by
:
:
:
:
:
:
:
Minimum distance to adjacent combustible materials:
OGC SP
EN
Serial no.
1.0 Relationship to the
authorities
• Installation of a fireplace must be carried out in compliance
with national laws and regulations. All local ordinances,
including those that refer to national and European
standards, must be complied with when products are
installed.
• The installation can only be put into use after it has been
checked by a qualified inspector.
• Contact your local building authorities before installing a
new fireplace.
2.0 Technical data
Material: Cast iron
Finish: Paint / enamel
Fuel: Wood
Log length, max: 33 cm
Smoke outlet: Top, rear
Flue pipe dimension: Ø 125 mm
Outside air connection: Ø 80 mm
Product weight:
Burnchamber with short legs: 94 kg
Burnchamber with long legs: 97 kg
Burnchamber with base: 107 kg
Soapstone top: 14,5 kg
Optional extras Ash lip, kit for outside air
connection, soapstone top,
ash lip for Jøtul F 105 with
legs, handle for ash pan,
convection plate
Product dimensions, distances: See Fig. 1
Technical data in acc. with EN 13240
Nominal heat output: 4,5 kW
Flue gas volume: 4,2 g/s
Chimney draught, EN 13240: 12 Pa
Recommended negative pressure
in smoke outlet: 14-16 Pa
Efficiency: 83%@5,2 kW
CO emissions (13% O2): 0,09%
CO emissions (13% O2): 1101 mg / Nm3
NOx at 13% O2: 99 mg / Nm3
OGC @ 13 % O2: 76 mg/Nm3
Particle emission NS 3059: 2,7 g / kg
Air consumption: 3,4 litre/sec or 12,2 m3/h
Chimney temperature, EN 13240: 231 oC
Temperature in smoke outlet: 277 oC
Dust: <7 mg/Nm3@13%O2
Type of fuel: Wood
Max. log length: 33 cm
Fuel consumption: 1,51 kg/h
Max. kindling amount: 2,0 kg
Nominal kindling amount: 1,1 kg
Operation: Intermittent
Intermittent combustion here means normal use of a fireplace,
i.e. add more fuel as soon as the fire has burned down to
embers.
Register your fireplace at jotul.com for a 25-
year warranty
ENGLISH

5
ENGLISH
3.0 Safety
NB! To guarantee optimal performance and safety, Jøtul
recommends that its stoves are fitted by a qualified
installer (see www.jotul.com for a complete list of dealers).
Any modifications to the product by the distributor, installer or
consumer may result in the product and safety features not
functioning as intended. The same applies to the installation of
accessories or optional extras not supplied by Jøtul. This may
alsobethecaseif partsthatareessential tothefunctioning and
safety of the fireplace have been disassembled or removed.
In all these cases, the manufacturer is not responsible or liable
for the product and the right to make a complaint becomes null
and void.
NB: Parts of the stove, in particular, the external surfaces, get
hot during combustion! Exercise caution!
Caution! Do not store wood underneath the product with
legs.
The Clean Air Act
“The Clean Air Act 1993 and Smoke Control Areas”
Under the Clean Air Act local authorities may declare the
whole or part of the district of the authority to be a smoke
control area. It is an offence to emit smoke from a chimney of
a building, from a furnace or from any fixed boiler if located in a
designated smoke control area. It is also an offence to acquire
an “unauthorised fuel” for use within a smoke control area
unless it is used in an “exempt” appliance (“exempted” from
the controls which generally apply in the smoke control area).
In England appliances are exempted by publication on a list
by the Secretary of State in accordance with changes made to
sections 20 and 21 of the Clean Air Act 1993 by section 15 of
theDeregulationAct2015. Similarly in Scotland appliancesare
exempted by publication on a list by Scottish Ministers under
section 50 of the Regulatory Reform (Scotland) Act 2014.
In Northern Ireland appliances are exempted by publication
on a list by the Department of Agriculture, Environment and
Rural Affairs under Section 16 of the Environmental Better
regulation Act (Northern Ireland) 2016.
In Wales appliances are exempted by regulations made by
Welsh Ministers.
Further information on the requirements of the Clean Air Act
can be found here: https://www.gov.uk/smoke-control-area-
rules
Your local authority is responsible for implementing the Clean
Air Act 1993 including designation and supervision of smoke
control areas and you can contact them for details of CleanAir
Act requirements.
The Jøtul F 105 B,, Jøtul F 105 LL, Jøtul F 105 SL, Jøtul
F 105 R B, Jøtul F 105 R LL and Jøtul F 105 R SL have been
recommended as suitable for use in smoke control areas
when burning wood logs.
3.1 Fire Prevention Measures
There is a certain element of danger every time you use
your fireplace. The following instructions must therefore be
followed:
• The minimum safety distances when installing and using
the fireplace are given in fig. 1. The specified distance to
flammable materials, applies to this stove.
• The stove must be installed with a CE approved flue. The
distance of the flue pipe to combustible materials must
also be observed.
• Ensure that furniture and other flammable materials are
not too close to the fireplace. Flammable materials should
not be placed within 900 mm of the fireplace.
• Allow the fire to burn out. Never extinguish the flames with
water.
• The fireplace becomes hot when lit and may cause burns
if touched.
• Only remove ash when the fireplace is cold. Ash can
contain hot embers and should therefore be placed in a
non-flammable container.
• Ash should be placed outdoors or be emptied in a place
where it will not present a potential fire hazard.
In case of chimney fire:
• Close all hatches and vents.
• Keep the firebox door closed.
• Check the loft and cellar for smoke.
• Call the fire service.
• Before use after a fire an expert must check the fireplace
and the chimney in order to ensure that it is fully functional.
Steel chimney
If a top-mounted steel chimney is used, fit an uninsulated
pipe from the burn chamber to approx. 10 mm over the top
grate. Make sure that the gasket is properly seated between
the flue pipe and the smoke outlet. Then fit the steel chimney
in accordance with the chimney supplier’s installation
instructions.
3.2 Floor
Foundation
You needtomakesure thefoundationissuitable forafireplace.
See “2.0 Technical Data” for specified weight.
We recommend the removal of any flooring that is not attached
to the foundation (“floating floors”) beneath the installation.
Jøtul F 105 SL (with short legs)
Jøtul F 105 SL can only be installed on a constructional
hearth which must have an extension of minimum 500
mm in front of the stove. This applies also if the product
rests on a floor plate. For further information please see
Approved Document J2010 Section 2.22.

6
ENGLISH
Jøtul F 105 R
900200-P00
Fig. 1 a
690
290
590
125
325
410
325
410
125
*40
690
290
590
*80
550
150
450
325
125
410
740
590
325
125
740
290
325
125
*40 590
*80
600
150
450
325
125
410 410
Y
**900
x
Jøtul F 105 R with long legs Jøtul F 105 R with base Jøtul F 105 R with short legs
Jøtul F 105 R long legs and soapstone top Jøtul F 105 R with base
and soapstone top Jøtul F 105 R with short legs
and soapstone top
Floorplate
Radiation
zone
Min. measurements floorplate X / Y= According to national laws and regulations ** Min. distance to furniture / combustible material
NB: The short legged version (F 105 R SL) can only be installed on a constructional hearth which must have an extension of minimum 500 mm in front of the stove. This applies also if the product rests on a floor plate. For further information please see Approved Document J2010 Section 2.22.
* Outside air connection

7
ENGLISH
900200-P00
Fig. 1 b Jøtul F 105 R Min. distance to combustible wall
605
400
*40
430 385
510
*40
* 216
631
*603
Flue pipe center
Outside air connection center
Flue pipe center
Outside air connection center
* 76 (short legs)
* Outside air connection *** Distance to combustible wall with semi-insulated / shielded flue pipe
(min.30 mm insulation)
Combustible wall

8
Fig. 1 c Jøtul F 105 R
Min. distance to combustible wall protected by firewall
900200-P00
720
350
*40
225
175
376 *348
656
867
350
790
430
225
225
317
*40
100
1072
350
*40
225
856
175
376 *348
*40
225
350
1050
500
966
430
225
External Integrated
* Outside air connection
Combustible wall
Firewall
ENGLISH

9
ENGLISH
Jøtul F 105
900181-P01
Fig. 1 d
Y
**900
x
690
350
290
590
150
325
410
350
325
410
150
*40
690
290
590
*80
550
150
450
350
325
150
410
740
590
325
350
150
740
290
350
325
150
*40 590
*80
600
150
450
350
325
150
410 410
Jøtul F 105 with long legs Jøtul F 105 with base Jøtul F 105 with short legs
Jøtul F 105 long legs and soapstone top Jøtul F 105 with base
and soapstone top Jøtul F 105 with short legs
and soapstone top
Floorplate
Radiation
zone
Min. measurements floorplate X / Y= According to national laws and regulations ** Min. distance to furniture / combustible material
NB: The short legged version (F 105 SL) can only be installed on a constructional hearth which must have an extension of minimum 500 mm in front of the stove. This applies also if the product rests on a floor plate. For further information please see Approved Document J2010 Section 2.22.
* Outside air connection

10
605
400
* 40 ***100
200
***250
350
900181-P01
Fig. 1 e
*40
Med standard konveksjonsplate
Jøtul F 105 Min. distance to combustible wall
* 216
527
*499
300
Flue pipe center
Outside air connection center
Flue pipe center
Outside air connection center
* 76 (short legs)
* Outside air connection *** Distance to combustible wall with semi-insulated / shielded flue pipe
(min.30 mm insulation)
Combustible wall
ENGLISH

11
ENGLISH
Fig. 1 f Jøtul F 105
Min. distance to combustible wall protected by firewall
900181-P01
100
774
225
*40
75
656
100
327
*299
688
225
742
355
150
264
*40
75
951
355
895
150
470
*40
75
225
856
100
327
*299
1192
225
*40
75
External Integrated
* Outside air connection
Combustible wall
Firewall

12
Requirements for protection of wooden
flooring beneath the fireplace
The function of a floor plate is to protect the floor and
flammable materials against embers.
Jøtul F 105 with legs must have a floorplate below and in
front according to national standards and regulations.
Important! The space under the burnchamber of Jøtul F 105
with legs cannot be used for storage.
Jøtul recommends that any flooring made of combustible
material, such as linoleum, carpets, etc. should be removed
from under the floor plate.
Requirements for protection of
inflammable floors in front of the
fireplace
Thefront plate must comply with national laws and regulations.
Contact your local building authorities regarding restrictions
and installation requirements.
3.3 Walls
Distance to walls made of combustible material - see fig. 1
Distance to combustible wall protected by firewall: See
fig. 1.
The fireplace may be used with an uninsulated flue pipe
provided the distances between the fireplace and walls made
of combustible materials are as shown in fig. 1. Alternative
distances with shielded or insulated flue pipe are also
displayed in fig. 1.
NB: Place the product in such a way that it is possible to clean
the stove, the flue pipe and the chimney passage.
Note! Ensure that furniture and other flammable materials
are not too close to the fireplace. Flammable materials
should not be placed within 900 mm of the fireplace.
NB: Make sure that furniture and other household items are
not so close as to get dried up by the stove.
Fresh air supply
The air used for combustion in any well-insulated house needs
to be replaced. This is particularly important in houses with
mechanical ventilation. Such replacement air can be procured
in several ways. The most important thing is to supply the air
to the room where the stove is placed. Place the outside wall
valve as close to the stove as possible and make sure that it
can be closed when the stove is not in use.
For the fresh air supply connection, follow the national and
local building regulations.
Closed combustion system
Usethe stove’sclosedcombustionsystemifyou liveinrecently
built, airtight dwellings. Connect the external combustion air
through a ventilation pipe through the wall or the floor.
Air supply
TheamountofcombustionairforJøtul’sproductsisapproximately
20-40 m3/h. The outside air connection may be fitted directly to
the Jøtul F 105 through:
• the bottom
• through a flexible supply hose from the outside/chimney
(only if the chimney has its own duct for external air) and to
the product’s outside air connector.
Fig. 2A, through an outside wall
Fig. 2B, through the floor and ground plate
ENGLISH

13
ENGLISH
Fig. 2C, through the floor and basement
Fig. 2D, indirectly through an outside wall
4.0 Installation
NB: Check that the fireplace is undamaged before installation
begins.
NB: The product is heavy! Ensure you have help when
positioning and installing it. Make sure the product does
not topple over.
NB: Do not place anything on the top plate of the stove as this
could cause permanent damage to the paint.
NB: Read the Installation and Operating instructions carefully
before installing the fireplace!
Requirement for UK
Fig. 3
1
2
A
C
B
1. Push the air vent (A) to the right.
2. Unscrew the screw (B).
3. Fasten the 40 mm screw (C) from the bag of screws.

14
4.1 Prior to installation - Jøtul F 105
with long legs
Fig. 4
AA
B
4. Remove the two transport screws (A) that fasten the stove
to the wooden pallet.
5. Leave the stove standing on the transport pallet.
6. Take out the glove, bag of screws, external air connector
and adapter lying in the burn chamber.
7. Check that the control lever (B) moves easily.
Fig. 5
AA
8. Lift the stove from the pallet.
9. Set up the stove and adjust using a cap wrench to a
horizontal position with the 4 height adjustment screws.
Mark on the wall if there has to be a rear outlet for flue pipe
and external air supply. NB: Take into account the height
of the floor plate.
Approval label
Fig. 6
A
B
1. Take the approval label (A) out of the burn chamber and
fasten it with the screw (B), as displayed. Tighten the screw
with a cap wrench. NB: Do not cut off the wire used for
fastening the label.
ENGLISH

15
ENGLISH
4.2 Preparations for Jøtul F 105 with
short legs
Jøtul F 105 SL (with short legs) can only be installed on
floors whose surface and structure are both made of non-
flammable materials. This applies also if the product rests
on a floor plate.
NB: The non-flammable area must extend to at least 500
mm in front of the stove.
NB: We advise against installing underfloor heating
(whether water or electric) in this area.
For further information please seeApproved Document J2010
Section 2.22.
Fig. 7
AA B
1. Remove the two transport screws (A) that fasten the stove
to the wooden pallet.
2. Leave the stove standing on the transport pallet.
3. Take out the gloves, baffle, bag of screws, external air
connector and adapter lying in the burn chamber.
4. Check that the control lever (B) moves easily.
Fig. 8
A
A
A
A
5. Lift the stove from the pallet.
6. Set up the stove and adjust using a cap wrench to a
horizontal position with the 4 height adjustment screws.
Mark on the wall if there has to be a rear outlet for flue pipe
and external air supply. NB: Take into account the height
of the floor plate.
Approval label
Fig. 9
A
7. Take the approval label (A) out of the burn chamber and
fasten it with the screw (B), as displayed. Tighten the screw
with a cap wrench. NB: Do not cut off the wire used for
fastening the label.

16
4.3 Preparations for Jøtul F 105 with
base
Fig. 10
1
2
3
A
B
C
D
8. Take out the gloves, baffle, bag of screws, external air
connector and adapter lying in the burn chamber.
9. 1. Unscrew the screw placed in the middle of the rear side
of the side plate.
2. Remove the side plate (C).
3. Remove the transport screw (D) that fastens the stove
to the wooden pallet.
10.Check that the control lever (A) moves easily.
11. Lift the stove from the pallet and set it up (see fig. 1).
Fig. 11
A
A
A
12.Lift the stove from the pallet.
13.Set up the stove and adjust to a horizontal position with the
4 height adjustment screws. Use the hex key placed in the
bag of screws. Mark on the wall if there has to be a rear
outlet for flue pipe and external air supply. NB: Take into
account the height of the floor plate.
Approval label
Fig. 12
A
B
14.Take the approval label (A) out of the burn chamber and
fasten it with the screw (B), as displayed. Tighten the screw
with a cap wrench. NB: Do not cut off the wire used for
fastening the label.
ENGLISH

17
ENGLISH
External air supply through the floor
Fig. 13
ABB
1. Fasten the adapter (A) to the bottom side of the burn
chamber using the accompanying screws (B) (pre-
mounted on Jøtul F 105 B).
Fig. 14
B
B
CC
A
2. Fasten the external air connector (A) to the adapter by
inserting the two screws (B) into the track and tightening
with the nuts (C).
External air supply through a rear
outlet
Fig. 15
ABB
1. Fasten the adapter (A) to the burn chamber using the two
accompanying screws (B) (pre-mounted on Jøtul F 105 B).
Fig. 16
A
CC
B
B
2. Fasten the external air connector (A) to the adapter by
inserting the two screws (B) into the track and tightening
with the nuts (C).

18
Outside air connection through the base
Through a rear outlet
Fig. 17
100
3. Forfastening Ø 80 fresh air intake tube (optionalequipment
– item no. 51047509), see the manual (item no. 10047508)
accompanying the external air set. See the installation
instructions that follow with the external air set. Attach the
hose to the external air connector with a hose clip to avoid
using joints. The external air hose insulation ends approx.
100 mm below the burn chamber.
Through the floor
Fig. 18
100
4. Forfastening Ø 80 fresh air intake tube (optionalequipment
– item no. 51047509), see the manual (item no. 10047508)
accompanying the external air set. See the installation
instructions that follow with the external air set. Attach the
hose to the external air connector with a hose clip to avoid
using joints. The external air hose insulation ends approx.
100 mm below the burn chamber.
4.4 Chimney and flue pipe
• The fireplace must only be connected to a chimney and
flue pipe approved for solid fuel fireplaces with flue gas
temperatures as specified in «2.0 Technical Data».
• The cross-section of the chimney must be designed to fit the
fireplace. Use «2.0 Technical Data» to calculate the correct
chimney cross-section.
• The chimney must be connected in accordance with the
installation instructions of the chimney supplier.
• Before a hole is made in the chimney, the product should
be test-mounted in order to correctly mark the position of
the fireplace and the hole in the chimney. See fig. 1 for
minimum dimensions.
• Make sure that the flue pipe rises all the way up to the
chimney.
• With a rear outlet, use a flue pipe bend with a sweep hatch
to allow sweeping.
• Please note that it is extremely important for connections to
have a degree of flexibility. This is to prevent any movement
in the installation leading to the formation of cracks.
• For recommended chimney draught, see «2.0 Technical
Data». For flue pipe dimension see “2.0 Technical Data”.
NB: The chimney’s diameter must be at least just as big
as the flue pipe.
NB! The minimum recommended chimney length is 3.5 m
from the flue pipe insert. If the draught is too strong, a flue
pipe damper can be installed and used to reduce the draught.
Operation under different weather
conditions
The effect of the wind on the chimney may have a significant
impact on how the stove reacts under different gust loads. It
may be necessary to adjust the air supply to achieve good
combustion.
ENGLISH

19
ENGLISH
4.5 Fitting a flue pipe with a top outlet
The product is supplied from the factory with the smoke outlet
fitted for the top outlet.
Fig. 19
A
B
1. Thread the flue pipe (A) through the top plate and place it
in the top smoke outlet.
2. Seal well with a gasket (B).
4.6 Fitting a flue pipe with a rear outlet
The product is supplied from the factory with the smoke outlet
fitted for the top outlet. If you want a rear outlet, proceed as
follows:
Fig. 20
A
1. Remove the baffle by lifting at the rear edge, and remove
the two screws. Then twist it out of the burn chamber.
Fig. 21
A
1. Place the product in a correct position. See fig. 1
2. Remove the exhaust deflector (A).

20
Fig. 22
A
B
3. Unscrew the screws (A) and remove the smoke outlet (B)
from the top outlet.
Fig. 23
AB
B
1. Unscrew the screws (B) and remove the cover (A) of the
rear outlet from the inside of the burn chamber.
Fig. 24
AC C
DDB
2. Fasten the smoke outlet (A) to the rear outlet using the two
screws (C) from the inside of the burn chamber.
3. Fasten the cover (B) to the top outlet with the two screws
(D) from the inside of the burn chamber.
4. Reinstall the exhaust deflector.
5. Place the baffle.
Fig. 25
B
A
6. Place the gasket (B) on the edge of the flue pipe (A).
ENGLISH
