Jabra GN9350e User manual

How to connect my Jabra GN9350e with Aastra Open Phone
6771, 6773, 6775, 71, 73, 75, Aastra 6739i, Aastra 7434 and
7444
Jabra GN9350e MS
Prerequisite:
Jabra GN9350 + Jabra LINK 14201-10
In combination with one of the following phones:
Open Phone [phone] including IP (previous name: Open
Phone 71/73/75 including IP)
Aastra 6739i
Aastra 7434 / 7444 IP
Connection:
1. Plug the 1-sided end of the DHSG cable marked “blue” into the socket
of your phone marked with the “headset” symbol.
2. Plug the RJ10 plug into the socket marked with a complete “phone”
symbol and the RJ45 plug into the base socket of the Jabra GN9350
marked with "AUX".
Software setup:
In the LCD Display, set the Jabra GN9350 to "DHSG" and press the OK
button.
24/04/2021 11:12
https://www.jabra.com/supportpages/jabra-gn9350e/9326-607-505/faq/86794ddb-8f56-
4925-b1b3-1959b174a745
Page 1 of 3

Base setup:
Set the phone setup switch (A-G) to "A".
Microphone level setup:
We recommend setting the microphone volume in the LCD display to 7
out of 12.
Phone setup:
Open Phone 71 Menu > User> Settings > Audio > Headset ON
Open Phone 73 / 75 including IP: Menu > Overall Menu> Phone Settings >
Headset ON
Headset answer/end:
As soon as the dial tone signal can be heard in the headset, you can answer
the call by pressing the ”answer/end” button on the headset; by pressing
again the call is ended.
