For Portable Gas Camp Fire:
Model # JFP-LP
Version: Jan14
OWNER’S MANUAL for Patio Fire
Important Notice
Please read ALL safety notices on PP.3 & PP.4
before assembling or operating this Patio
Fire.

2
TABLE OF CONTENTS:
Specifications: 3
Safety Warnings: 2
Warranty Registration: 4
Certification Info: 5
Package Contents Checklist: 5
Assembly & Preparation: 5-6
Lighting & Shutoff Instructions: 6
Natural Gas Conversion Instructions: 8
Care & Maintenance: 9
Storage 10-11
Parts List: 11
Warranty: 12
SPECIFICATIONS:
Input: 46,500 BTU/h (13.6 KW/h)
Manifold Pressure: 11 inch W.C. (2.74 KPa)
Maximum Gas Supply Pressure: 13 inch W.C. (3.50 KPa)
LP Orifice Size: # 47.
NG Orifice Size (for Conversion Purposes): # 35
Recommended propane cylinder size: 20 lbs.
Run Time using a 20 lb Cylinder of Propane: 8-10 hours
Minimum distances to combustibles –sides 16” (406mm)
Minimum distance to combustibles –above 84’ (2134mm)

3
!SAFETY WARNINGS!
IMPORTANT: Please read and understand all warnings and precautions before using your Patio Fire.
WARNING: Improper installation, adjustment alteration, service or maintenance can cause
injury or property damage. Read the installation, operating and maintenance instructions
thoroughly before installing or servicing this equipment.
1 The installation of this Patio Fire must conform to local codes or, in the absence of local codes, with the
B149.1 Natural Gas and Propane Installation Code in Canada, or the National Fuel Gas Code, ANSI
Z223.1 in the USA
2 This Patio Fire must be installed according to manufacturer instructions. Carefully read all the instruction
in this manual first. Consult the building authority having jurisdiction to determine the need for a permit
prior to commencing the installation.
3 Installation, service and repair should be done by a qualified installer, service agency or gas supplier.
4 This Patio Fire is set up from the factory for use with Propane Gas (LP) only.
5 This appliance should be inspected before the first use and, at least annually by a qualified service
person. More frequent cleaning may be required as necessary. It is imperative the controls, burners and
circulating air passageways of the appliance be kept clean.
6 Failure to follow manufacturer’s instructions may void your fire insurance and/or warranty.
7 Do not use this Patio Fire until it is COMPLETELY assembled, all parts are securely installed, and leak
testing has been completed.
8 Do not use this outdoor Patio Fire appliance for any purposes other than intended.
9 To prevent injury, do not allow anyone who is unfamiliar with this appliance to operate this appliance.
!WARNING!
Do not store or use gasoline or
other Flammable liquids in the
vicinity of this or any other
appliance.
An LP cylinder not connected for
use shall not be stored in the
vicinity of this or any other
appliance.
!
!DANGER!
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If the odor continues, keep away
from appliance and immediately call
your gas supplier or your fire
department.
!
!WARNING!
For Outdoor Use Only.
!
!DANGER!
This appliance can produce carbon
monoxide which has no odor.
Using it in an enclosed space can kill
you. Never use this appliance in an
enclosed space such as a camper,
tent, car or home
!

4
10 Children and adults should be alerted to the hazards of high surface temperatures and should stay a
safe distance away to avoid injury or ignition of clothing. Young children should be carefully supervised
when they are in the area of this appliance.
11 Clothing or other flammable materials should not be hung from the appliance, or placed near the
appliance.
12 Position the gas hose out of the pathways to avoid a tripping hazard.
13 Do not burn solid fuels in this appliance. Do not use gasoline, alcohol or other volatiles for lighting.
14 Do not use this Patio Fire if any part has been under water. Immediately call a qualified service
technician to inspect the appliance and to replace any part of the control or gas control systems that
have been under water.
15 Always place the Patio Fire on a hard level surface away from combustible materials. Do not attempt to
move this Patio Fire while lit.
16 To avoid burns, do not touch any metal surfaces on this Patio Fire until it has completely cooled.
17 It is essential to keep the gas valve, burner, and base tray free of obstructions and debris. Inspect the
Patio Fire before each use.
18 Propane (LP) gas supply cylinders must be constructed and marked in accordance with the
specifications for propane gas cylinders of the US Department of transport (DOT) CFR 49 or the
National Standards of Canada, CAN/CSA B339, Cylinders, Spheres and Tubes for the Transportation of
Dangerous Goods.
19 For appliances designed to use a CGA 791 Propane Gas Connection: Place dust cap on cylinder valve
outlet whenever the cylinder is not in use. Only install the type of dust cap on the propane cylinder valve
outlet, this provided with the cylinder valve. Other types of caps may result in leakage of propane gas.
20 Never fill any LP Gas Cylinder more than 80 percent full. Dented and rusted propane cylinders may be
hazardous and must be checked by a propane gas supplier, before use.
21 WARNING: if the information in #18 and #19 are not followed exactly, a fire causing death or serious
injury may occur.
22 To prevent propane from entering the regulator valve & causing a potential hazard, please ensure that
the propane cylinder is at a lower level than the regulator when in use.
23 Please note that propane (LP) is explosive under pressure, heavier than air, and settles and pools in low
areas, which can create an explosion hazard.
24 The fuel line for this appliance must be disconnected from the gas supply piping system during any
pressure testing of that system, at test pressures in excess of 0.5 psi (3.5 kPa).
25 This gas appliance must be isolated from the gas supply piping system by closing its individual manual
shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or
less than 0.5 psi (3.5 kPa).
26 Inspect fuel supply hose for damage before each use. If excessive wear, abrasion, or cracks are present,
the hose MUST be replaced with a genuine Jackson Grills replacement part, prior to using this outdoor
appliance (Contact your nearest dealer for assistance).
27 The Fuel Supply Hose must not touch any hot surfaces, as damage and gas leaks may occur.
28 It is recommended that the LP gas cylinder be fastened to a mounting surface using a bracket or
concrete anchor (not supplied) depending on the specific surface.

5
Special Message to Our Customers:
All of us at Jackson thank you, for choosing a Jackson Patio Fire! This appliance was designed, engineered, and
built with quality components and we are confident that it will provide you with years of excellent operation.
Please take the time to read the entire manual and familiarize yourself with all of the features of the Jackson
Patio Fire. This manual also contains important safety information and operation instructions. Please write your
Patio Fire’s serial number in the space below.
To obtain replacement parts for your Jackson Patio Fire, contact your local dealer. If you have any question,
contact us anytime via phone or email as shown below: (Please have your model and serial number at hand)
Patio Fire Model: JFP-LP Portable Patio Fire
*Serial Number: _________________
*Write your serial number here for future reference.
OWNER REGISTRATION: Please take the time to fill out and return a Warranty Registration Card, or on-line at
www.jacksongrills.com or simply fill in the form below and mail or fax to:
Jackson Patio Fires Customer Support (Tel): 1 [phone] or
#106-2480 Mt. Lehman Rd. Customer Support (E-mail): [e-mail]
Abbotsford, BC. Fax: [phone]
Canada V4X 2N3 Parts Ordering: Contact your Dealer
Please complete and return within 10 days. Thank you.
Title: Mr. Mrs. Ms. Miss (Circle One)
First Name:
Initial:
Last Name:
Street:
Apt. #:
City:
State/Prov.:
Zip/Postal:
Phone:
Email:
Date Purchased:
Dealer:
Model:
Serial #:
Comments:
Thank you for taking the time to fill out this Ownership and Registration Card
Dear Patio Fire Owner; please keep this manual for future reference.
