Jacuzzi Ristorre Ovale EC31 User manual

Gentle glass curves envelope powerful body sprays to create the
Ristorre™ Ovale™ shower.
FEATURES:
 
 
 
 
 
 

 
 
Ristorre™Ovale™| SHOWER TOWER
Ristorre™Ovale™

EC31

465⁄8" L x 101⁄4" W
x 3" D

Technical Specifications
DIMENSIONS
46-5/8” L x 10-1/4” W x 3” D
(1184 mm) L x (260 mm) W x (76 mm) D
PRODUCT WEIGHT
22 lb. (10 kg)
This is a wall mounting shower tower bathroom fixture.
© 2008 Jacuzzi Whirlpool Bath • 14880 Monte Vista Avenue • Chino, CA 91710 • www.jacuzzi.com
INSTALLATION NOTES
Refer to installation instructions included with fixture before
beginning installation. Please conrm product availability and
specications before commencing with any installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT
TO CHANGE WITHOUT NOTICE.
#EC31000 04/08
Ristorre™Ovale™
SHOWER TOWER
EC31 Ovale™ Shower Tower (Optional Spout Included)
Product Shown:
Ristorre™ Ovale™ Shower Tower, Model: EC31
Minimum Working Water Pressure 21.76 psi (1.5 bar)
Maximum Working Water Pressure 72.52 psi (5.0 bar)
Recommended Working Water Pressure 43.51 psi (3.0 bar)
Maximum Working Water Temp. 140-158° F (60 – 70° C)
Minimum Working Water Temp. 41-68° F (5-20° C)
Recommended Working Temp. 100° F (38° C)
Under water pressure at
21.76 psi (1.5 bar)
Flow Rate of Hand Shower 1.61 US gal/min (6.1 L/min)
Flow Rate of Wall Mount 1.69 US gal/min (6.4 L/min)
Flow Rate of Body Jet 1.66 US gal/min (6.3 L/min)
Flow Rate of Bath Spout 1.69 US gal/min (6.4 L/min)
14-1/2"
MAX
10-1/4"
46-5/8"
3"
43"
OPTIONAL TEMPERATURE -CHECK
SPOUT INCLUDED
FLOW RATE = (1.66 US gal/min)
