Jacuzzi ERA User manual

INSTALLATION AND OPERATION INSTRUCTIONS
Jacuzzi Luxury Bath
13925 City Center Drive, Suite 200
Chino Hills, CA 91709
1-800-288-4002
www.jacuzzi.com
MK22000 05/2014
ERATM FREESTANDING
TUB FAUCET WITH
HAND SHOWER

English
ERATM Freestanding Tub Faucet with Hand Shower
Page 2 Installation and Operation
English
Product Information
Contents
NOTE Save these instructions for future use. Use the form below to record your model and serial number for
future reference.
Date Purchased
Purchased From
Installed By
Serial Number
Model
Installer: Leave the manual for the homeowner.
Homeowner: Read this manual and keep for future reference.
Contents. .............................................................................................................................................................................................. 2
Specification
............................................................................................................................................................................. 3
Component Parts List
............................................................................................................................................................... 3
Dimensions
......................................................................................................................................................................... 4
Installation Instructions
Safety Instructions
............................................................................................................................................................................ 5
..................................................................................................................... 6
Care And Cleaning Instructions............................................................................................................................................................ 6
Warranty
............................................................................................................................................................................... 7
Dealer/Installer
Information
Dealer/Installer
Information

Page 6 Installation and Operation
Page 3 Specification and Component Parts List
Features:
Cast brass wall-mount or freestanding tub and shower faucet
Ceramic disc cartridges
Porcelain cross handles
60” Brass shower hose
Tub spout 6 GPM @ 60 PSI
Hand shower 2.2 GPM @ 60 PSI
Standards and certifications:
ASME A112.18.1 Compliant
IAPMO cUPC listed
CSA B125.1 compliant and listed
Specifications
Component Parts List
10
06 14
07 12
13
16
08 09
11
15
01
03 05
04
02
YTQ EMANTRAP#
1 1
1 2
1 3
1 4
1 5
6
1
7
1
1
8
2
9
2
10
11
1
12
1
13
2
2
41
15
16
1
1
ERATM Freestanding Tub Faucet with Hand Shower
Hand shower with built-in backflow prevention device.
Rubber ring.
Shower hose.
Cradle.
Rubber ring.
Hex lock nut.
Bonnet.
Cartridge, hot and cold.
Cross handle.
Diverter handle.
Spout.
Diverter plunger.
Flange.
S-union.
Faucet body.
Diverter mechanism.

Dimensions Page 4
Dimensions
Arm for use with wall
mounting. Not needed for
freestanding supply lines.
5”
13”
2.4” CTC
4.0”
1/2” NPT
English
ERATM Freestanding Tub Faucet with Hand Shower
Arms adjust from

Page 6 Installation and Operation
Page 5 Installation Instructions
Installation instructions:
1. Attach the S-Union to the tub with flat metal washer and 1/2” lock nut. Make sure the escutcheon is tight against the
S-Union arm ( hand tight only).
2. Attach faucet to S-Unions (3/4” fiber washers must be installed) and adjust faucet so that it sits level. Now tighten hex
nuts on back of faucet to secure the S-Unions. Then tighten the 1/2” lock nuts on the back of the S-Unions to secure
faucet on vertical surface.
3. Next connect the water supply lines. Ensure hot goes into the hot side and cold goes into the cold side. If using 1/2”
OD decorative supply lines, connect the hex nuts at the top of the supply lines to the back of the S-Unions. If installing inside
the wall use, copper fittings.
4. Install the hand shower cradle onto the top of the faucet body. Place the rubber washer in the hex nut at the base of the
cradle and tighten until sealed and secure.
5. To install the shower hose, place the 1/2” rubber washers in the cone nuts at both ends of the shower hose. Install one
end to the side port on the cradle stand and one end on the bottom of the hand shower. Hand tighten.
6. Once installed, remove aerator and hand shower to flush faucet and water lines. This will remove any debris that may be
trapped. Then reattach aerator and hand shower.
Installation Instructions - Wall-mounted faucet
Component Parts List
Installation instructions:
1. Discard the S-Union from the faucet.
2. Next connect the water supply lines to the back of the faucet. Ensure hot goes into the hot side and cold goes into the
cold side. Tighten hex nuts onto supply lines, being careful not to damage the finish.
4. Install the hand shower cradle onto the top of the faucet body. Place the rubber washer in the hex nut at the base of the
cradle and tighten until sealed and secure.
5. To install the shower hose, place the 1/2” rubber washers in the cone nuts at both ends of the shower hose. Install one
end to the side port on the cradle stand and one end on the bottom of the hand shower. Hand tighten.
6. Once installed, remove aerator and hand shower to flush faucet and water lines. This will remove any debris that may be
trapped. Then reattach aerator and hand shower.
Installation Instructions - Freestanding supply lines
ERATM Freestanding Tub Faucet with Hand Shower

Safety and Cleaning Instructions Page 6
Important Safety Instructions
READ AND FOLLOW ALL INSTRUCTIONS. SAVE THESE INSTRUCTIONS.
Use this unit only for its intended use as described in this manual. Do not use attachments not recommended by the
manufacturer.
This is a professional grade product. A working knowledge of plumbing installation according to codes are required
for proper installation and user satisfaction. We recommend that a licensed plumber perform the installation of all
Jacuzzi Luxury Bath products. Our warranty does not cover improper installation related problems.
CAUTION After the installation, double check all connections for any water leaks.
The Company has obtained applicable code (standards) listings generally available on a national basis for products of
the product. Proper installation of the units is the responsibility of the installer. Jacuzzi Luxury Bath is not responsible
SAVE THESE INSTRUCTIONS.
CAUTION Use this unit only for its intended use as described in this manual.
Care and Cleaning Instructions
Cleaning your faucet with only soap and warm water is recommended. The use of any abrasive cleaners or
chemicals will void the finish warranty of your product. Although the finishes are scratch resistant on the surface,
excessive rubbing and use of abrasives can, over time, cause undesirable effects. We also recommend waxing
your faucet to protect the finish and ensure long lasting color and durability. Therefore, after cleaning the faucet
with soap and warm water, dry the faucet and apply a coat of standard car wax (Note: make sure you are not
using rubbing compound) and remove with a dry cloth. This will ensure that your product looks and functions
beautifully for many years to come.
English
ERATM Freestanding Tub Faucet with Hand Shower

NINETY DAY (PARTS ONLY) LIMITED WARRANTY ON OPTIONS AND ACCESSORIES
O
ur limited warranty on options and accessories is for ninety (90) days for parts only (LABOR IS
N
OT COVERED). Our warranty covers options and accessories manufactured by other
c
ompanies (e.g., drains fill spout kits, trim kits, skirts, video monitors, plasma television screens,
C
D and MP3 players and other music and video devices and optional heaters) against defects in
m
aterial or workmanship. Warranty coverage begins on the date the option or accessory was
o
riginally purchased by the User. These items may be covered by the actual manufacturer's
w
arranty which may have a longer duration than this limited warranty. Please confirm with the
m
anufacturer the duration of the appropriate warranty for Options and Accessories.
WARRANTY LIMITATIONS
O
ur limited warranty does not cover defects, damage, or failure caused by the common carrier,
i
nstaller, User, or other persons, pets, or rodents, or resulting from, without limitation, any of the
f
ollowing: careless handling (lifting unit by plumbing, abrading finish, etc.) including its own
n
egligence; modification of any type whatsoever made to the bath for any reason (including but
n
ot limited to modification to meet local codes and any deletion or addition to Bath); improper
i
nstallation (including installation not in accordance with instructions and specifications provided
w
ith the unit); connections supplied by the installer of the equipment; improper voltage supply or
u
nauthorized electrical modification; misuse; incorrect operation, or lack of proper routine
m
aintenance; operation of the unit without specified minimum amount of water or at inappropriate
w
ater temperature; use of abrasive or improper cleaners; or acts of God, such as lightning,
f
loods, earthquakes, etc.
I
N ADDITION, THE COMPANY WILL NOT BE RESPONSIBLE FOR INCIDENTAL OR
C
ONSEQUENTIAL DAMAGES OR LOSSES ARISING FROM ANY CAUSE (E.G., WATER
D
AMAGE TO CARPET, CEILING, TILES, MARBLE, LOSS OF USE, ETC.) INCLUDING ITS
O
WN NEGLIGENCE; DAMAGES TO, RESPECTING, OR RESULTING FROM: PLATED PARTS
W
HEN POOL AND/OR SPA CHEMICALS ARE USED IN THE UNIT OR HARD WATER
C
ONDITIONS; OPTIONAL BATH EQUIPMENT NOT MANUFACTURED BY THE COMPANY
B
UT SUPPLIED BY DEALER, INSTALLER OR THE COMPANY; THE UNIT'S PRIOR USAGE
A
S AN OPERATIONAL DISPLAY; OR DEFECTS THAT SHOULD HAVE BEEN DISCOVERED
B
EFORE INSTALLATION.
T
his limited warranty does not include: labor, transportation, or other costs incurred in the
r
emoval and/or reinstallation of the original unit and/or installation of a replacement unit; any
c
osts relating to obtaining access for repair; or loss of use damage, including loss of sales, profit
o
r business advantage of any kind under any circumstances. Warranty coverage is provided in
t
he United States of America and Canada only.
EXCLUSION OF IMPLIED WARRANTIES
I
MPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
P
URPOSE ARE DISCLAIMED ALTOGETHER OR TO THE FULLEST EXTENT ALLOWED BY
L
AW. NOTICE: This warranty gives you specific legal rights, and you may also have other rights
w
hich vary from state to state. There are no warranties applicable to Jacuzzi Luxury Bath
p
roducts except as expressly stated herein or as implied by applicable state and federal laws.
T
he Company will not be responsible for any statements or representations made in any form tha
t
g
o beyond, are broader than or are inconsistent with any authorized literature or specifications
f
urnished by the Company. Some states do not allow limitations on how long an implied warranty
l
asts, or the exclusion or limitation of incidental or consequential damages, so the above
limitations and exclusions may not apply to you.
Warranty Page 7
Important Safety Instructions

INSTRUCCIONES PARA LA INSTALACIÓ N Y EL FUNCIONAMIENTO
Jacuzzi Luxury Bath
13925 City Center Drive, Suite 200
Chino Hills, CA 91709
1-800-288-4002
www.jacuzzi.com
MK22000 05/2014
GRIFO DE BAÑERA
NO EMPOTRADO
CON DUCHADOR
DE MANO ERATM

English
Grifo de Bañ era No Empotrado con Duchador de Mano ERATM
Pá gina 2 Instalació n y funcionamiento
Spanish
Informació n del producto
Í ndice
NOTA Conserve estas instrucciones para uso futuro. Utilice el formulario a continuació n para registrar su
modelo y nú mero de serie para referencia futura.
Fecha de compra
Comprado a
Instalado por
Nú mero de serie
Modelo
Instalador:Deje el manual para el propietario.
Propietario: Lea este manual y consé rvelo para referencia futura.
Í ndice ............................................. ................................................................................................................................................. 2
Especificaciones
........................................................................................................................................................................ 3
Lista de piezas de los componentes
............................................................................................................................................ 3
Dimensiones
......................................................................................................................................................................... 4
Instrucciones de instalació n
Instrucciones de seguridad
..................................................................................................................................................................... 5
............................................................................................................. 6
Instrucciones para el cuidado y la limpieza.......................................................................................................................................... 6
Garantí a
............................................................................................................................................................................... 7
Informació n del
distribuidor/instalador
Informació n del
distribuidor/instalador

Page 6 Installation and Operation
Pá gina 3 Especificaciones y lista de piezas de los componentes
Caracterí sticas:
Grifo de bañ era no empotrado de lató n fundido con duchador para montar en la pared.
Cartuchos de discos de cerá mica
Manijas de porcelana en forma de cruz
Manguera de lató n de 60” (1,5 m) para duchador
Pico de la bañ era: 6 GPM (23 LPM) a 60 PSI
Duchador de mano: 2,2 GPM (8 LPM) a 60 PSI
Normas y certificaciones:
Cumple con la norma ASME A112.18.1.
Figura en la lista de IAPMO cUPC.
Figura en la lista y cumple con la norma CSA B125.1.
Especificaciones
Lista de piezas de los componentes
10
06 14
07 12
13
16
08 09
11
15
01
03 05
04
02
CANT. NOMBRE DE LA PIEZ A#
1 1
1 2
1 3
1 4
1 5
6
1
7
1
1
8
2
9
2
10
11
1
12
1
13
2
2
41
15
16
1
1
Grifo de Bañ era No Empotrado con Duchador de Mano ERATM
Duchador de mano con dispositivo de prevenció n
de flujo de retorno incorporado.
Argolla de goma.
Manguera para duchador.
Soporte.
Argolla de goma.
Contratuerca hexagonal.
Sombrero.
Cartucho para agua caliente y frí a.
Manija en forma de cruz.
Manija de desviació n.
Pico.
É mbolo del desviador.
Brida.
Unió n en forma de “ S”.
Cuerpo del grifo.
Mecanismo de desviació n.
Spanish
