JAI SW-2000M-CL-65 User manual

SW-2000M-CL-65
１
SW-2000M-CL-65
CMOS High Speed Monochrome
Line Scan Camera
Document Version: 1.1
Date: 28 August 2014
File: Manual_SW-2000M-CL-65_First_Release_1-1.docx
User's Manual

SW-2000M-CL-65
２
Notice
The material contained in this manual consists of information that is proprietary to JAI Oy,
Finland and may only be used by the purchasers of the product. JAI Oy, Finland makes no
warranty for the use of its product and assumes no responsibility for any errors which may
appear or for damages resulting from the use of the information contained herein. JAI Oy,
Finland reserves the right to make changes without notice.
Company and product names mentioned in this manual are trademarks or registered
trademarks of their respective owners.
Warranty
12 months from date of delivery, 4 months for repairs covering the work and parts at the
factory.
Certifications
CE compliance
As defined by the Electromagnetic compatibility requirements of Directive 2004/108/EC of the
European Parliament and of the Council, JAI Oy, Finland, declares that SW-2000M-CL-65
complies with the following provisions:
EN 61000-6-2 (2005), EMC immunity
EN 61000-6-4 (2007), EMC emissions
FCC
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-Consult the dealer or an experienced radio/TV technician for help.
-
Warning
Changes or modifications to this unit not expressly approved by the party
responsible for FCC compliance could void the user’s authority to operate the
equipment.

SW-2000M-CL-65
３
- Contents –
1General .......................................................................................................５
1.1 Camera nomenclature ...............................................................................５
2Main features ................................................................................................５
3Connectors and mounting..................................................................................６
3.1 Main unit ...............................................................................................６
3.2 Rear panel and indicators ...........................................................................７
4Input and output ............................................................................................８
4.1 M8 connector for power supply ....................................................................８
4.2 Camera Link connector ..............................................................................８
4.3 Camera Link output modes .........................................................................９
5Operation and functions .................................................................................. 10
5.1 Introduction .......................................................................................... 10
5.1.1 Image sensor...................................................................................... 10
5.1.2 Image processing................................................................................. 11
5.2 Operating Modes..................................................................................... 12
5.3 DSNU Corrector ...................................................................................... 12
5.4 Offset and gain stage ............................................................................... 12
5.5Test Pattern Generator............................................................................. 12
5.6 Flat Field Corrector, FFC........................................................................... 12
5.7 Region of interest, ROI ............................................................................. 13
5.8 Binning ................................................................................................ 13
5.9 Reversed readout direction ........................................................................ 13
5.10 Camera Link interface .............................................................................. 14
5.11 Ethernet interface................................................................................... 14
5.12 Firmware updates ................................................................................... 15
5.12.1 MCU firmware update ........................................................................ 15
5.12.2 FPGA firmware update....................................................................... 16
6Command line interface .................................................................................. 17
6.1 Connecting via Telnet .............................................................................. 17
6.2Connecting via Camera Link Serial Bus .......................................................... 17
6.3 Entering the commands ............................................................................ 17
6.4 Command Format.................................................................................... 18
7Description of commands ................................................................................. 19
7.1Group A: General settings.......................................................................... 21
7.1.1 MODE – select camera operating mode....................................................... 21
7.1.2 NET - network settings .......................................................................... 21
7.1.3 CL SERIAL – sets the baud rate................................................................. 23
7.1.4 Saving and restoring the capture settings ................................................... 24
7.2 Group B: Commands affecting exposure......................................................... 26
7.2.1 SENSOR – selects the sensor mode .......................................................... 26
7.2.2 LINE PERIOD and LINE RATE .................................................................... 26
7.2.3 LINE CTRL - Exposure Control .................................................................. 27
7.2.4 LINE IT - integration time....................................................................... 30
7.2.5 GAIN - signal gain ................................................................................ 30
7.2.6OFFSET - output offset .......................................................................... 30
7.2.7 FFC – flat field correction ...................................................................... 31
7.3 Group C: Commands affecting image output format .......................................... 32
7.3.1 CL MODE - Camera Link mode.................................................................. 32
7.3.2 CL RATE - Camera Link pixel rate ............................................................. 32
7.3.3 READOUT – pixel readout direction ........................................................... 32
7.3.4 ROI – region of interest ......................................................................... 33
7.3.5 BINNING – paring of pixels ...................................................................... 34
7.4 Group D: Utilities.................................................................................... 35

SW-2000M-CL-65
４
7.4.1 HELP or ‘?’ – list of commands ................................................................. 35
7.4.2 STATUS - camera information and settings .................................................. 35
7.4.3 VER - camera information ...................................................................... 35
7.4.4 TEST - test patterns ............................................................................. 35
7.4.5 REBOOT – restart the camera .................................................................. 37
7.4.6 FIRMWARE UPDATE – initiate the MCU update............................................... 37
8Summary of commands.................................................................................... 38
9Software tools for camera communications ........................................................... 41
9.1 JAI SweepConf ....................................................................................... 41
9.2 JAI Sweep Ethernet Tool ........................................................................... 42
9.3 Internal web server ................................................................................. 44
10 External dimensions ....................................................................................... 45
11 Specifications ............................................................................................... 46
11.1 Operating range...................................................................................... 46
11.2 Common properties ................................................................................. 47
11.3 Performance per selected sensor mode ......................................................... 47
11.4 Spectral sensitivity .................................................................................. 48
12 Change History.............................................................................................. 49

SW-2000M-CL-65
５
1General
The JAI Sweep Series SW-2000M-CL-65 is a CMOS line scan camera based on a custom-made
2048 pixel imager with large square pixels of 20 µm for high responsivity. It operates at a rate
of up to 80,000 scans per second.
The camera outputs digital data in 8-, 10-, or 12-bit formats, one, two, or three pixel values at
a time via one Camera Link connector. The camera is configured by software through the serial
communication port of the Camera Link interface or via a 10/100 Mbps Ethernet port using an
industry standard RJ-45 connector.
The default lens mount is F-mount. Additional options will be added.
The latest version of this operation manual can be downloaded from www.jai.com.
For camera revision history, please contact your local JAI distributor.
1.1 Camera nomenclature
The standard camera composition consists of:
SW-2000M-CL-65 camera body with F-mount x 1
Lens mount/sensor protection cap x 1
In the model number of the camera,SW stands for “Sweep” Series, 2000 represents the
resolution “2000 pixels”, Mstands for “monochrome”, CL stands for “Camera Link®” interface,
and 65 stands for “65 kHz” maximum scan rate.
2Main features
•CMOS line scan camera
•Resolution: 2048 x 1
•Pixel size: 20 µm, square
•Selectable Quantum Well size: 60k or 360k electrons
•Selectable clock rate for sensor and data output
•Maximum scan rate: 65,000 lines per second
•Camera Link Base Configuration data interface
oOne connector
o8, 10, or 12 bits per pixel
oSingle, dual, and triple data formats
•DSNU correction as factory default
•Flat field correction (FFC)
•Test pattern generator for set-up and troubleshooting
•Default lens mount: F-mount
•DC input voltage range from +12 V to +24 V
•Ethernet port for
oControl and monitoring
oFirmware updates
oDownload of files from camera (internal web server)
•Short ASCII commands for set-up via Camera Link or Ethernet using the Telnet protocol
oWindows user interface

SW-2000M-CL-65
６
3Connectors and mounting
3.1 Main unit
Fig. 1.Location of external features
1 Camera Link Base Configuration connector (1)
2LED indicator
3 M8 connector for supply voltage (+12 to +24 V DC)
4Ethernet connector
5Lens mount: Nikon F-Mount
6Mounting holes: all 12 pcs. are M5 with depth of 8 mm
*Note 1: Please do not excessively tighten the Camera Link connector screws by using tools.
This may damage the receptacle on the camera side. It is sufficient to tighten by hand.
1
2
4
3
5
6
6
6
6
6
6
66
1

SW-2000M-CL-65
７
3.2 Rear panel and indicators
Fig.2.Rear panel
Status indicator
A multi-colour LED with the following functions:
Green (steady)
Normal operation
Green (flashing slowly)
Busy, performing a time consuming operation like FFC calibration.
Green (flashing rapidly)
Performing firmware update or waiting for a firmware update to start.
Orange (steady)
Initializing
 Orange (flashing rapidly)
Firmware update in progress.
Do not disconnect the Ethernet cable.
Do not switch off the power.
Red
Internal error
Ethernet Link LED
Green (steady)
Connected to an active network device. This indicates the existence of a physical
link only. It does not indicate a valid TCP/IP network configuration.
Ethernet Status LED
Yellow (flashing)
Activity indicator. Blinks shortly during data transfer.
1
2
3

SW-2000M-CL-65
８
4Input and output
4.1 M8 connector for power supply
Camera side connector is an industry standard 3-pin M8 male connector. Use any compatible
3-pin M8 female connector on the cable side.
Fig. 3. Power supply connector (viewed looking into the camera)
4.2 Camera Link connector
Fig. 4. Camera Link connector (viewed looking into the camera)
The connector and respective signalling comply with Base Configuration of AIA Camera Link
standard v2.0. Please use only compliant cabling.
Pin No
In/Out
Name
Note
1,14
Shield
GND
2(-),15(+)
O
TxOUT0
Data out
3(-),16(+)
O
TxOUT1
4(-),17(+)
O
TxOUT2
5(-),18(+)
O
TxClk
Clock for CL
6(-),19(+)
O
TxOUT3
Data out
7(+),20(-)
I
SerTC (RxD)
LVDS Serial Control
8(-),21(+)
O
SerTFG (TxD)
9(-),22(+)
I
CC1 (Trigger)
Trigger, line rate
10(+),23(-)
I
CC2 (reserved)
integration control
11,24
N.C.
12,25
N.C.
13,26
Shield
GND
Pin No.
Signal
Remarks
1
DC in
+12 V to +24 V
3
GND
Ground (power supply negative)
4
CHGND
Chassis ground

SW-2000M-CL-65
９
4.3 Camera Link output modes
All these modes are presented in the standard according to the names shown on the first line.
This table shows the use of these configurations to implement various data output modes.
Bit depths of 8, 10, and 12 are supported, where MSB is labeled as M11 and LSB as M0. Camera
operates internally with more than 12 bits. All blanks are electrically zeroes.
Dual and Triple modes send data from multiple pixels in parallel to enable higher scan rates
and/or longer cable lengths. Camera Link is nominally limited to 10 meters and 85 MHz. Data
from two or three consecutive pixels is sent out at once, where the index n-1 refers to the
previous pixel and n-2 respectively to the pixel before that. If the pixels are numbered from 1
to 2048, then the transmission in 8-bit Triple mode starts with a 24-bit package, where port A
shows the 8-bit value for pixel #3, Port B equals pixel #2 and Port C contains data from the first
pixel. Respectively, the Dual modes effectively send the data out as odd and even numbered
pixels, two in parallel.
CL v2.0
specification
8-bit x 1
10-bit x 1
12-bit x 1
8-bit x 2
10-bit x 2
12-bit x 2
8-bit x 3
Mode
Base 8
Base 10
Base 12
Base 8 x2
Base 10 x2
Base 12 x2
Base 8 x3
Port
Bit
8 bit
10 bit
12 bit
8 bit Dual
10 bit Dual
12 bit Dual
8 bit Triple
A
0
M4
M2
M0
M4
M2
M0
M4
1
M5
M3
M1
M5
M3
M1
M5
2
M6
M4
M2
M6
M4
M2
M6
3
M7
M5
M3
M7
M5
M3
M7
4
M8
M6
M4
M8
M6
M4
M8
5
M9
M7
M5
M9
M7
M5
M9
6
M10
M8
M6
M10
M8
M6
M10
7
M11
M9
M7
M11
M9
M7
M11
B
0
M10
M8
M4(n-1)
M10
M8
M4(n-1)
1
M11
M9
M5(n-1)
M11
M9
M5(n-1)
2
M10
M6(n-1)
M10
M6(n-1)
3
M11
M7(n-1)
M11
M7(n-1)
4
M8(n-1)
M10(n-1)
M8(n-1)
M8(n-1)
5
M9(n-1)
M11(n-1)
M9(n-1)
M9(n-1)
6
M10(n-1)
M10(n-1)
M10(n-1)
7
M11(n-1)
M11(n-1)
M11(n-1)
C
0
M2(n-1)
M0(n-1)
M4(n-2)
1
M3(n-1)
M1(n-1)
M5(n-2)
2
M4(n-1)
M2(n-1)
M6(n-2)
3
M5(n-1)
M3(n-1)
M7(n-2)
4
M6(n-1)
M4(n-1)
M8(n-2)
5
M7(n-1)
M5(n-1)
M9(n-2)
6
M8(n-1)
M6(n-1)
M10(n-2)
7
M9(n-1)
M7(n-1)
M11(n-2)

SW-2000M-CL-65
１０
5Operation and functions
5.1 Introduction
5.1.1 Image sensor
The SW-2000M-CL-65 is built around a high performance CMOS line scan image sensor, which
converts the light collected by each pixel into electrical charge. The amount of charge
generated in each of the individual pixels is basically directly proportional to the amount of
light they receive.
The sensor has two options to store the charge of each pixel. These are called Quantum Wells.
The smaller well can hold about 60,000 electrons (60 ke-), while the larger has capacity for 360
ke-. The larger well should be used whenever feasible as it provides the best image quality due
to higher dynamic range and better signal-to-noise ratio (SNR).
SNR is limited by the shot noise of the light itself and thus it is beneficial to collect as many
photons (light) as possible. The smaller well can be used to provide about six times higher
response to light, but with the cost of lower SNR and dynamic range.
Correlated Double Sampling (CDS) is used for sampling the charge voltage and the reset level
to find the difference, which is then digitized into more than 12 bits and sent out of the sensor
for processing.
Fig.5. Sensor block diagram
e
-
P I X E L
S M A LL
L A R G E
VOLTAGE VO L T A G E
CDS A / D
12½ B I T S
QUANTUM W E LL
C O MM A N D : S E N S O R
