1.0 Introduction
The JANDS FP12 is a high quality, rugged, 12 channel, 2.4kVA per channel (10A/240V)
dimmer rack specifically designed for demanding touring and theatre applications.
The FP12 can be powered from three-phase or single-phase mains supplies. The FP12
features opto-controlled Triacs and medium risetime chokes protected by
thermal/magnetic circuit breakers. The FP12 uses microprocessor-based digital control
for accurate dimming and in-built test functions. Digital control is via standard DMX-512
protocol.
The FP12 features toroidal output chokes. These chokes provide excellent high
frequency noise suppression and, together with the temperature-controlled fan, low
acoustic noise.
Control signal to the dimmer is via a standard DMX-512 socket at the front panel, while
the dimmed outlets and three phase power entry are located on the rear panel.
Features
•12 x 2.4KW dimming channels
•DMX-512 digital control protocol
•DMX terminating switch
•Suitable for both touring and permanent installations
•Soft turn on characteristic
•Low acoustic/electrical noise
•Toroidal output chokes
•Circuit breaker protection of output devices
•Three mains phase indicator LEDs
•Built in test facilities
•Dimmer curve set for linear relationship between the control input and output power
•Compensates for fluctuations in the mains supply voltage, and filters superimposed
mains control tones, ensuring a constant light output and increased lamp life
•Rack mounted (3 rack units)
•Microprocessor control
•Temperature-controlled cooling fan
•Temperature monitor and thermal cut-out
•Dimmer will hold last DMX value should control data be interrupted
•50/60Hz operation
•CE and C-Tick approved

Equipment Description 2-1
Revision 0.1 – 3 June 1999 FP12 DIMMER USER MANUAL
2.0 Equipment Description
2.1 Front panel layout
Refer to Fig 2.1 (below) for a description of the front panel controls.
1. Channel output sockets (rear panel): The twelve output sockets are each rated at
10 amps.
2. Channel circuit breakers: If a breaker trips during use ensure the fault has been
cleared before resetting.
3. Bank select switches: These switches select the DMX start bank and the Test
functions.
4. DMX IN LED: A red LED indicates the presence of DMX signals. If there is no
DMX signal, the LED will flash at a rate of approximately 2 seconds on - 2 seconds
off.
5. STATUS LED: A red LED flashes in the presence of a fault. In normal operation
this LED should be off.
6. PHASE LEDs: Three blue LEDs (one for each phase) indicate that the three phase
mains supply is available.
➀ ➁ ➂
➃ ➄
➅
Figure 2.1FP12 front panel layout

Getting Started 3-1
Revision 0.1 – 3 June 1999 FP12 DIMMER USER MANUAL
3.0 Getting Started
The FP12 would normally be rack mounted before any wiring is terminated. Refer to
section 6.0 Installation for installation details.
3.1 Connecting power
The FP12 dimmer is supplied with a flexible cable fitted with a multipin power plug for
the connection of incoming mains power. The FP12 is ideally powered from a three
phase star (four wire plus earth) supply. If the dimmer power cable is damaged it must be
replaced with another cable available from JANDS or its service agents.
The upstream supply must be protected by fuses or circuit breakers at not more than the
rated maximum.
The power plug should be connected to an appropriately rated socket outlet. The plug’s
retaining lock ring (if present) must be screwed home.
WARNING
DAMAGE TO THE PLUG MAY OCCUR IF THE RETAINING LOCK RING IS
NOT PROPERLY SECURED.
Ensure adequate mains plug access once the dimmer is installed.
3.2 Setting the mains frequency
The FP12 can be configured to run from either 50Hz or 60Hz mains power. As supplied
from the factory the dimmer is configured for 50Hz.
The dimmer operating frequency may be changed as follows:
•Disconnect the mains supply to the dimmer
•Remove the lid
•Change the three jumpers on the main circuit card as shown in Figure 3.4
•Replace the lid and reconnect power
Figure 3.4: 60Hz jumper locations
60
50
50
60
50
60

Getting Started 3-2
Revision 0.1 – 3 June 1999 FP12 DIMMER USER MANUAL
3.3 Powering up
Turn on the power and check that the three PHASE indicator LEDs are on before
connecting any loads. If any of the PHASE LEDs are dim or off, power down and
remedy the fault before trying again. Refer to section 5.3 Phase fault indication.
If all is well, power down and connect loads.
3.4 Connecting loads
The standard output connectors are twelve Clipsal 415P 10 amp sockets (export models
may differ from these configurations). Ensure any plugs are pushed firmly into their
sockets.
The FP12 will drive most incandescent loads as well as pinspots, fans, and dimmable
fluorescent tubes. The load should be within the specified limits.
3.5 Connecting DMX-512 input
The input signal to the dimmer should conform to the USITT DMX-512 1990
specification. The DMX input connects to the frontpanel socket labelled “DMX IN”. The
DMX signal may be daisy-chained to the next dimmer via the connector labelled
“LOOP”.
The red DMX IN LED indicates the presence of DMX signals.
The DMX receiver input is protected against extreme over-voltages across any input pins
and from any input to chassis. The “terminating” resistor is not protected against over-
voltages.
3.6 DMX Termination
In any DMX-512 system the signal should be terminated at the last dimmer or receiver in
the chain, and the FP12 can provide this function. To terminate the DMX signal, set the
frontpanel slide switch from “Loop” to the “Term” position. Note that in this position no
signal is present at the “Loop” connector.
3.7 Power-up sequence
When powering up lighting systems, the following sequence should be used:
1. First the control desk;
2. Then any softpatches and/or DMX receivers;
3. Finally the dimmers, preferably one at a time starting from the first dimmer rack in the
DMX loop.
This procedure minimises the risk of lamps and fixtures responding to any false DMX
data produced by control desks or ancillary equipment at turn-on (producing the lighting
equivalent of an audio “thump”) and prevents damage to lamps, dimmers, and other
controlled devices.
Use the reverse procedure when powering down.
Disconnect mains power when not in use.

Dimmer Operation 4-1
Revision 0.1 – 3 June 1999 FP12 DIMMER USER MANUAL
4.0 Dimmer Operation
This section assumes the dimmer has been correctly connected to three phase power and
a source of DMX-512 control signal.
4.1 Operating modes
The FP12 has two operating modes:
1. DMX mode: the dimmer is controlled from an external DMX-512 control
console,
2. Test mode: the dimmer is controlled by the internal microprocessor.
4.1.1 DMX mode
In this mode, the DMX Bank Select switches are used to select which bank of 12
channels from the 43 possible DMX-512 banks will control the FP12.
See Table 4.1 (below) for a list of banks and their corresponding Channels.
Decide which bank of channels is required, and rotate the selector switches to the
desired setting. For example, if DMX Channels 25 to 36 are desired (ie. bank 3), set
selectors to “03”. FP12 Channel #1 is now DMX Channel #25. A FP12 with this
setting ignores DMX Channels 1 to 24 and 37 to 512, and only decodes Channels 25 to
36 as it’s dimmer information.
Setting the Selectors to “00” puts the dimmer in a standby state, with all channels off.
Bank Channels Bank Channels Bank Channels Bank Channels
00 Outputs Off 11 121 - 132 22 253 - 264 33 385 – 396
01 1 - 12 12 133 - 144 23 265 - 276 34 397 – 408
02 13 - 24 13 145 - 156 24 277 - 288 35 409 – 420
03 25 - 36 14 157 - 168 25 289 - 300 36 421 – 432
04 37 - 48 15 169 - 180 26 301 - 312 37 433 – 444
05 49 - 60 16 181 - 192 27 313 - 324 38 445 – 456
06 61 - 72 17 193 - 204 28 325 - 336 39 457 – 468
07 73 - 84 18 205 - 216 29 337 - 348 40 469 – 480
08 85 - 96 19 217 - 228 30 349 - 360 41 481 – 492
09 97 - 108 20 229 - 240 31 361 - 372 42 493 – 504
10 109 – 120 21 241 - 252 32 373 - 384 43 505 – 512
Table 4.1 DMX bank / Channel allocation
4.1.2 Test mode
In this mode, the FP12’s internal controller is used to drive the dimmer channels. It is
accessed by setting the Selector switches to banks between “44” and “99”. No DMX
control is necessary, but a control signal may be left connected if desired.

Dimmer Operation 4-2
Revision 0.1 – 3 June 1999 FP12 DIMMER USER MANUAL
This mode is split into two sections with individual Channel testing from banks “44” to
“59” and group channel testing from banks “60” to “99”. The first section is not level
controllable and each channel is driven to full.
Refer to Table 4.2.
Selector Channel Output
Switches Under Test Level
44 Channel 1 Full
45 Channel 2 Full
46 Channel 3 Full
47 Channel 4 Full
48 Channel 5 Full
49 Channel 6 Full
50 Channel 7 Full
51 Channel 8 Full
52 Channel 9 Full
53 Channel 10 Full
54 Channel 11 Full
55 Channel 12 Full
56 - 59 12 Step Chase Full
Table 4.2 TEST MODE – Individual Channel Selection
The second section is level controllable, the level being set by the right hand Selector
switch. The left-hand Selector switch changes the grouping. Refer to Table 4.3.
Selector Switches Channel Channel Left
Right Grouping Level
6 0-9 Channels 1-4 ON (Phase A) 0-9
7 0-9 Channels 5-8 ON (Phase B) 0-9
8 0-9 Channels 9-12 ON (Phase C) 0-9
9 0-9 Channels 1-12 ON 0-9
Table 4.3 TEST MODE – Group Selection

Dimmer Operation 4-3
Revision 0.1 – 3 June 1999 FP12 DIMMER USER MANUAL
4.2 Status LED
The Status LED is used to indicate fault conditions. In normal operation this LED should
not illuminate. When active this LED will either be flashing or on continuously.
1. When the LED is flashing an over-temperature or over-voltage condition is present,
and the dimmer outputs will be off until the over-voltage or over-temperature
condition is removed.
2. When the status LED is on continuously, one or more of the following error
conditions have occurred:
•Over-voltage
•Over-temperature
•Serial data errors
•Software failure
The dimmer outputs are active while the Status LED is on continuously.
If the Status LED is on it may be cleared by changing the setting of the bank select
switches or by switching the dimmer off momentarily.

Fault Diagnosis 5-1
Revision 0.1 – 3 June 1999 FP12 DIMMER USER MANUAL
5.0 Fault Diagnosis
NOTE
Contact your authorised JANDS Distributor for repairs or servicing.
In Australia refer all repairs to an authorised JANDS service agent or return the
faulty unit in suitable packaging to:
JANDS ELECTRONICS Service Dept,
40 Kent Rd
Mascot NSW 2020
Australia
5.1 Output protection
Each of the twelve output circuits is protected by a 10 amp fast-acting thermal/magnetic
circuit breaker. These breakers are designed to pass the rated current, but will disconnect
the output circuit for any overload condition (the larger the overload, the quicker the
disconnection).
NOTE: 3-pin GPO outlet sockets are rated at 10 amps. Dimmer channels should
not be loaded beyond the socket capacity.
The breakers protect the dimmer’s output devices from short-circuit loads and faulty
wiring looms, and save on expensive dimmer repairs. A tripped circuit breaker indicates a
load fault that requires immediate attention.
If a short-circuit lamp or output cable is plugged into the dimmer, the breaker will trip to
disconnect the fault from the dimmer. In nearly all circumstances, this is quick enough to
prevent damage to the output devices.
In some circumstances however, a triac failure may be experienced, although these
devices are usually quite reliable and robust. If a triac does fail, it will either turn a
channel on to full (triac short-circuit), or turn it off (triac open-circuit). If a triac fault
should occur, that channel may be isolated by tripping that channel’s circuit breaker.
These breakers have been specified for electrical protection, reliability and safety. They
will allow repeated turn-on surges to cold lamps without failure, while still protecting the
triacs. The breakers will interrupt large short-circuit fault currents without damage.
5.2 DMX faults
The FP12 dimmer features an “Output Hold” facility that “remembers” the last received
DMX message. In the event of a cable being unplugged or severed, the FP12 dimmer
rack will continue to output the “Held” DMX levels until a new DMX message is
provided.
The DMX IN LED will “flash” slowly if the DMX signal is removed.
Note that control consoles, when powered down, may transmit spurious DMX data
which can unintentionally cause dimmer channels to turn on. Disconnect mains power
when not in use.
The DMX receiver input is protected against extreme over-voltages across any input pins
and from any input to chassis. The “terminating” resistor is not protected against over-
voltages.

Fault Diagnosis 5-2
Revision 0.1 – 3 June 1999 FP12 DIMMER USER MANUAL
5.3 Phase fault indication
The three blue PHASE LEDs will show when all three power input phases are present.
WARNING
IF ONE OR MORE PHASE LEDS IS OFF, IMMEDIATELY DISCONNECT
POWER TO THE DIMMER AND CHECK THE MAINS SUPPLIES AND
WIRING BEFORE RE-CONNECTING POWER TO THE DIMMER.
Although the dimmer will survive most power supply faults, indications of unusual or
potentially dangerous power conditions should never be ignored.
5.4 Thermal protection
The FP12 dimmers feature temperature-controlled fan cooling. As the internal
temperature of the dimmer increases, the fan speed also increases.
The internal heatsink temperature is constantly monitored by the dimmer. If the heatsink
temperature rises above the specified maximum, the dimmer will automatically shut
down the output drive. The fan will continue to cool the heatsink during the shut down
period.
The electronic shutdown is backed up by a buried cutout, which shuts down power to all
electronics other than the cooling fan should the temperature continue to rise.
Even though the FP12 is a fan-cooled dimmer, it is very important that adequate
ventilation is provided when in use, particularly around the sides of the chassis. If air
circulation to the air vents is blocked and/or the ambient air temperature is too high, the
dimmer will shut down and the status LED will flash until the temperature is reduced.
Refer to section 6.1 Dimmer Ventilation regarding FP12 ventilation requirements.
5.5 Over-voltage
The FP12 incorporates an over-voltage cutout that constantly monitors the incoming
mains voltage. If the mains voltage rises above the specified maximum the dimmer will
shut down and the status LED will flash until the over-voltage condition is removed.

Fault Diagnosis 5-3
Revision 0.1 – 3 June 1999 FP12 DIMMER USER MANUAL
5.6 Fault finding guide
FAULT SYMPTOM POSSIBLE CAUSE REMEDY
Breaker trips when desk channel
flashed to full or near full
Large incandescent load
Excessive load
Use console preheat facility
Reduce channel loading
Breaker trips after prolonged
operation
Excessive load
Lamp or wiring fault
Reduce channel loading
Check lamps and wiring
Breaker trips immediately when
channel is driven
Output short
Triac short
Check lamps and wiring
Factory service
One channel flickers when dimmed
Same load flickers on another
Channel
DMX source problem
Faulty dimmer channel
Insufficient or very inductive load
Softpatch another console fader
Service console
Factory service
Connect >100W incandescent
lamp in parallel
Radio interference Faulty EMC filtering Factory service
All Channels flicker when dimmed Incorrect DMX protocol / wiring
Unterminated DMX line
Mains control tones exceed limits
Replace DMX source / wiring
Set Terminate switch on last
DMX receiver to TERM
Contact factory
Signal LED flickers Faulty DMX wiring/connections
Faulty console
Faulty dimmer rack
Repair
Repair
Factory service
Status LED flashing Over-voltage
Over-temperature
Check mains connection/supply
Improve dimmer cooling
Status LED on continuously Recent over-voltage
Recent over-temperature
DMX control errors
Software failure
Check mains connection/supply
Improve dimmer cooling
Check DMX wiring, console
Factory service
No signal at DMX Loop output Terminate switch set to TERM Set Terminate switch to LOOP

Installation 6-1
Revision 0.1 – 3 June 1999 FP12 DIMMER USER MANUAL
6.0 Installation
The FP12 dimmer is designed for use in 19 inch racks or a 19 inch bar frame, and
occupies 3 rack units (export models may differ). The dimmer is supplied with rear rack
mounting support brackets, which provide additional support for touring applications.
The three phase power cable entry is located at the rear right side of the rack when
viewed from the front. Ensure adequate access to the power plug when mounting
dimmers in racks.
6.1 Dimmer Ventilation
The FP12 dimmer is fan-cooled, with the air intake at the right and air exhaust at the left
when viewed from the front. All racks must have adequate ventilation for the side-to-side
airflow of the dimmers. Fully enclosed racks will cause overheating problems.
Racks must allow at least 100 square centimetres of air venting per dimmer at each side
of the rack, level with the dimmer’s intake and exhaust slots. Additional venting area will
serve to further reduce internal dimmer temperatures and will enhance the dimmer’s
operational reliability.
Dimmers may be stacked in racks without intervening rack spaces as long as the racks
are adequately vented.
Racks of dimmers must be placed such that one rack does not breathe the hot exhaust of
the rack to its right. Allow at least 0.5m (18") between racks unless duty cycles are light.

Maintenance 7-1
Revision 0.1 – 3 June 1999 FP12 DIMMER USER MANUAL
7.0 Maintenance
With care, the FP12 dimmer will require little or no maintenance.
Periodic electrical safety checks may be required by law in some applications.
WARNING
DO NOT ALLOW THE ENTRY OF LIQUIDS OF ANY SORT INTO THE
DIMMER CHASSIS.
EXTERNAL CLEANING:
If the front panel requires cleaning, wipe with a mild detergent on a damp soft cloth.
DO NOT spray liquids onto the front panel.
DO NOT use solvents for cleaning the front panel.
INTERNAL CLEANING:
The FP12 dimmer will require little internal maintenance other than periodic flushing of
dust build to prevent the fan and air-path becoming clogged with dirt or fluff.
•ISOLATE POWER to the dimmer (by disconnecting the power cable or
locking off the mains supply isolator).
•Remove the lid.
•Blow clean the fan and internals with compressed air from left to right.
•DO NOT "spin" the fan with compressed air - the blades may break off.
•When the fan and internals are clean, replace the lid and screws, and re-connect
the power cable.
ROUTINE MAINTENANCE:
Installed dimmers should be routinely flushed of dust at six- to twelve-month periods.
Touring dimmers may need a more rigorous maintenance routine, which should include:
•Inspection of chassis for evidence of impact damage and physical abuse
•Inspection of outlets for wear and damage
•Inspection of power cable for wear and damage
•Electrical checking of ground integrity from power cable to chassis
•Electrical checking of ground integrity from power cable to outlet grounds
•Flushing of dust buildup
•Testing the operation of all frontpanel switches and breakers

Technical Data and Specifications 8-1
Revision 0.1 – 3 June 1999 FP12 DIMMER USER MANUAL
8.0 Technical Data and Specifications
PARAMETER FP12
No. of Channels: 12
Input Power Requirements:
3 phase Star only 415 VAC Phase-Phase @ 40A/phase
protected at 50A/phase
Full size neutral required
Maximum Power / Channel 2.4 kW
Minimum Power/Channel 25W
Maximum Dissipation <24 W/channel (<300 W total)
Maximum Ambient Temp 40ºC
Control Signal DMX-512 (1990) Protocol
DMX Input 5 pin AXR male / female
Test Function Level Individual Channels @ 100%
Group Channels @ 10% steps
LED Indicators DMX IN, STATUS,
Phases A, B, and C
Output Protection 12 x 10 Amp thermal/magnetic circuit breakers
Over-temperature cutout Electronic: 83oC rising, 78oC falling
Mechanical: 90oC
Over-voltage cutout Average 290VAC
Ingress protection IP20
Size (mm) 482 (w) x 133 (h) x 250 (d)
Weight 16 kg net
Rack mounting requirements 3 x 19” rack spaces / standard spacing for mounting holes
Ventilation required at sides of rack
No blank spaces required between units
Power inlet at rear right (looking from front of unit)
Rear access required for patching outputs

Technical Data and Specifications 8-2
Revision 0.1 – 3 June 1999 FP12 DIMMER USER MANUAL
8.1 DMX connector pin-outs
PIN
No CONNECTION (DMX IN) CONNECTION (LOOP)
1 SHIELD SHIELD
2 IN- OUT-
3 IN+ OUT+
4nc nc
5nc nc
The DMX shield connection is tied to chassis by a 47K resistor and a RF bypass
capacitor.
8.2 DMX bank allocations
BANK CHANNELS BANK CHANNELS
00 Off 22 253 – 264
01 1 – 12 23 265 – 276
02 13 – 24 24 277 – 288
03 25 – 36 25 289 – 300
04 37 – 48 26 301 – 312
05 49 – 60 27 313 – 324
06 61 – 72 28 325 – 336
07 73 – 84 29 337 – 348
08 85 – 96 30 349 – 360
09 97 – 108 31 361 – 372
10 109 – 120 32 373 – 384
11 121 – 132 33 385 – 396
12 133 – 144 34 397 – 408
13 145 – 156 35 409 – 420
14 157 – 168 36 421 – 432
15 169 – 180 37 433 – 444
16 181 – 192 38 445 – 456
17 193 – 204 39 457 – 468
18 205 – 216 40 469 – 480
19 217 – 228 41 481 – 492
20 229 – 240 42 493 – 504
21 241 – 252 43 505 – 512

Technical Data and Specifications 8-3
Revision 0.1 – 3 June 1999 FP12 DIMMER USER MANUAL
8.3 Mains wiring colour codes
FLEXIBLE TAILS INSTALLED WIRING
PHASE A BROWN RED
PHASE B WHITE WHITE
PHASE C BLACK BLUE
NEUTRAL BLUE BLACK
EARTH GREEN / YELLOW GREEN / YELLOW
8.4 Internal Mains Wiring
The FP12 dimmer has been designed to run from most commonly used power systems.
8.4.1 Normal Three Phase plus Neutral Operation
The FP12 is normally supplied with a three-phase power cable and plug attached, suiting
the vast majority of available mains supplies (ie. three phase and neutral).
The incoming mains supply must be protected at not more than the specified maximum.
Mains supplies are generally protected at lower currents (32 amps or 40 amps at most
Australian venues). It is the responsibility of the user to ensure that the dimmer is used in
a manner that does not exceed the available supply capacity.
The power cable is terminated within the dimmer at a six-way terminal block and an
earthing stud. The six-way terminal block has three poles for the three live mains phases
(labelled A1, A2, A3), and three poles for the mains neutral (N1, N2, N3). The three
neutral poles are bridged by a copper link, with the incoming mains neutral connected to
terminal N2.
8.4.2 Single Phase Operation
The dimmer may be configured for single phase operation where three phase mains
supply is unavailable.
The dimmer should be supplied with three same-phase actives and three neutrals. The
three active lines must each be protected at not more than the specified maximum. The
three neutral conductors must each be rated at the same current as the actives. The earth
conductor should be similarly rated.
The bridge between the three neutral terminal poles (N1, N2, N3) must be removed
before the three incoming neutral lines are connected.
Although it is possible to supply the dimmer with one large single phase feed, the
dimmer’s breakers may not be rated to clear faults if the supply is protected at currents
greater than the specified maximum.
The overvoltage detection will operate as normal.
8.4.3 Delta Supply Operation
The available venue mains supply in some countries (eg. the Philippines) is in the form of
three phases (220 volts between phases) with no neutral connection. The dimmer may be
configured for operation from 220V delta supplies.

Technical Data and Specifications 8-4
Revision 0.1 – 3 June 1999 FP12 DIMMER USER MANUAL
The bridge between the three neutral terminal poles (N1, N2, N3) must be removed
before the three incoming active lines are connected.
•The first incoming active is connected to terminals A1 and N3.
•The second incoming active is connected to terminals A2 and N1.
•The third incoming active is connected to terminals A3 and N2.
WARNING
This connection is ILLEGAL in Australia, Europe and the U.K.
This connection renders the output socket’s neutral pins LIVE.
Note that a dimmer wired in this fashion will be subjected to CONTINUOUS
OVERVOLTAGE if connected to the 415V wye or star three-phase supply of most
countries.
The three active lines must each be protected at not more than the specified maximum.
The earth conductor must be rated the same as the active lines.
W
WX X
MANUAL ENDS W
WX X
