Jason.L Elements Workstation 2 Person Run User manual

ASSEMBLY INSTRUCTIONS
Elements Workstation
2 Person Run
Size: 1600mm
Tools Required: Power screwdriver.
2 persons required for installation
Special Note: No pre-drilled holes or nut inserts are
provided. Wood screws will be required to be drilled
directly into underside of desk top.
Page 1 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au

A
B
C
D
E
F
G
H
I
J
K
Phillip Head M6*15 Wood Screw (silver) x8
Phillip Flat Head M6*20 Screw (gold) x12
L
M
COMPONENTS
SCREWS
Page 2 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Elements Workstation
2 Person Run
Size: 1600mm
A
B
D
JJ
F
F
G
G
E
E
H
H
I
C
K
Desk top x2 (1600mm x 800mm)
Top plate x3
Leg core insert x2
Leg core return x3
Leg sleeve x6
Sleeve cover x6
Fold Scren x6
Base Foot x6
Core cover x3
Sleeve Cap x6
Extandable Beam x2

Page 3 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Elements Workstation
2 Person Run
Size: 1600mm
Unwrap all leg components.
Remove sleeve cap (J) and sleeve
cover (F) from all leg sleeves.
Insert base foot (H) into leg sleeve (E)
by rotating base foot (H) clockwise.
Insert sleeve cap (J) onto leg core (D)
for all legs.
Insert leg sleeve (E) onto leg core (D)
for all legs. TIP: Keep height adjustment
holes pointing outwards.
Place leg core insert (C) onto leg core
(D) for all legs.
Place core cover (I) onto leg core (D)
for all legs.
Place sleeve cover (F) over leg sleeve
(E) for all legs.
D
J
J
F
F
G
GE
E
H
H
I
C
01

Page 4 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Elements Workstation
2 Person Run
Size: 1600mm
Connect extendable Beam (K) to Leg Core (D)
02
D
K
Tighten Top Plate (B) to middle leg core (D) by tightening Screw (M).
04
D
BM
Tighten Top Plates (B) to outer legs core (D) by tightening Screw (M).
03
D
B
M

Page 5 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Elements Workstation
2 Person Run
Size: 1600mm
Attach outsider legs + beam to Desk Tops by tightening Scews (L).
05
L
L
Attach middle leg to Desk Tops by tightening Scews (L).
06
