Jason.L Elements 4 Person Workstation User manual

ASSEMBLY INSTRUCTIONS
Elements 4 Person
Workstation
Size: 1800mm
Tools Required: Power screwdriver.
2 persons required for installation
Special Note: No pre-drilled holes or nut inserts are
provided. Wood screws will be required to be drilled
directly into underside of desk top.
Page 1 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au

K
L
A
B
D
JJ
F
F
G
G
E
E
H
H
I
C
Phillip Head M6*15 Wood Screw (silver) x16
Phillip Flat Head M6*20 Screw (gold) x24
H6x30 x16
O
P
Q
SCREWS
Page 2 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Elements 4 Person
Workstation
Size: 1800mm
A
B
C
D
E
F
G
COMPONENTS
Desk top x4
(1800mm x 800mm)
Top plate x6
Leg core insert x4
Leg core return x6
Leg sleeve x12
Sleeve cover x12
Fold Scren x12
H
I
J
K
L
M
N
Base Foot x12
Core cover x6
Sleeve Cap x12
Extandable Beam x4
Screen x2 (1800mm)
Rod Brackets for screens x2
2 way screen connector x1

Page 3 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Elements 4 Person
Workstation
Size: 1800mm
Unwrap all leg components.
Remove sleeve cap (J) and sleeve
cover (F) from all leg sleeves.
Insert base foot (H) into leg sleeve (E)
by rotating base foot (H) clockwise.
Insert sleeve cap (J) onto leg core (D)
for all legs.
Insert leg sleeve (E) onto leg core (D)
for all legs. TIP: Keep height adjustment
holes pointing outwards.
Place leg core insert (C) onto leg core
(D) for all legs.
Place core cover (I) onto leg core (D)
for all legs.
Place sleeve cover (F) over leg sleeve
(E) for all legs.
D
J
J
F
F
G
GE
E
H
H
I
C
01

Page 4 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Elements 4 Person
Workstation
Size: 1800mm
Connect extendable Beams (K) to Legs Core (D)
02
D
K
Tighten Top Plates (B) to middle legs core (D) by tightening Screw (P).
04
D
BP
Tighten Top Plates (B) to outer legs core (D) by tightening Screw (P).
03
D
B
P

Page 5 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Elements 4 Person
Workstation
Size: 1800mm
Attach outsider legs + beam to Desk Tops by tightening Scews (O).
05
O
O
Attach middle leg to Desk Tops by tightening Scews (O).
06

Page 6 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Elements 4 Person
Workstation
Size: 1800mm
Place 10mm Rod Brackets (M) into designated screen holes.
Drill desk tops (A) with H6x30 screws (Q) to assemble the screens.
07
Place screens (L) in the gap, aligned with desk tops (A).
08
M
M
Q
Q
Using an Allen key remove top 2 caps
from all screens (L) uprights. Bring two
partition towards one another and slide
the 2 way connector rod (N) - down
between the two screen uprights.
09
