Jason.L Litewall Boardroom Table User manual

ASSEMBLY INSTRUCTIONS
Litewall
Boardroom Table
Size: 3600mm
Page 1 of 4
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set.
2 persons required for installation

Legs x2
Beams 994mm x4
Beams 794mm x2
Connector Frame x2
Connector Frame T Legs x4
Feets x8
1
2
3
4
5
6
M8x25mm Dome Head x12
M6x40mm Hex Head x26
M6x35mm Hex Head x8
7
8
9
COMPONENTS
SCREWS
ASSEMBLY INSTRUCTIONS
Litewall
Boardroom Table
Size: 3600mm
Page 2 of 4
Need help!
Call us on
1300 527 665
www.jasonl.com.au
1
7
6
9
2
2
5
4
8
3

ASSEMBLY INSTRUCTIONS
Litewall
Boardroom Table
Size: 3600mm
01 02
04
Screw the feet to each leg and T leg. Assemble connector frames. Attach the 2 T legs to the double connector frame
using M6x35mm hex scews x4.
Add both connector frames together appropriate beams.
03
Attach 2x beams to legs using M8x25mm dome head screw. Attach connector
frame from diagram 2 to 4 beams using M8x25mm dome head screws.
Page 3 of 4
Need help!
Call us on
1300 527 665
www.jasonl.com.au

Attach tops to frame by tightening M6x40mm through beams & into tops.
ASSEMBLY INSTRUCTIONS
Litewall
Boardroom Table
Size: 3600mm
Page 4 of 4
Need help!
Call us on
1300 527 665
www.jasonl.com.au
05
