Jason.L Switch System Small Round Meeting Table User manual

Page 1 of 4
INSTALLATION GUIDE
Switch System
Small Round Meeting Table
Size: 700mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Note: Please ignore any pre-drilled holes or nut inserts that maybe present in your top(s). They will not match your
particular table/desk base and woods screws will be required to be screwed directly into the underside of the top.
Note: It is important to fully tighten all bolts and screws before attaching the top(s) so that the frame
is suciently rigid. Failure to do this may aect stability once the tops are attached.
Tools Required: Power screwdriver.

Table Top (700mm D)
Leg x3
Leg Bracket x3
Beam Bracket x6
Switch Beam x3 (180mm)
L-Bracket x6
1
2
3
4
5
6
Hex Nut x3
L-Bracket screws x3
Hex Head screws x9
M8x25mm Dome Head x3
7
8
9
10
COMPONENTS
SCREWS
Page 2 of 4
INSTALLATION GUIDE
Switch System
Small Round Meeting Table
Size: 700mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
5
4
3
6810
1
7

Page 3 of 4
Join 1 L-Bracket through each Switch Beam
Join Leg Brackets to each Leg using screws to secure them, as follow.
Securely connect each Beam to each Beam Bracket. Screw to secure. Insert Hex Nut on each Beam Bracket.
01
03 04
02
INSTALLATION GUIDE
Switch System
Small Round Meeting Table
Size: 700mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au

Page 4 of 4
INSTALLATION GUIDE
Switch System
Small Round Meeting Table
Size: 700mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Position as presented, and proceed to screw to ensure each corner of the frame.
05
If this bolt does not drop into the joint
use the Allen key to screw it all the way
in so that it creates its own thread.
This will ensure a nice, tight joint. Directly screw into table tops, using L-Bracket
screws through each L-Bracket.
06
Note: It is important to fully tighten all bolts and screws before attaching
the top(s) so that the frame is suciently rigid. Failure to do this may
aect stability once the tops are attached.
