ASSEMBLY INSTRUCTIONS
Quadro Loop
Desk
Size: 1000mm
Page 1 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set (provided)
2 persons required for installation
ASSEMBLY INSTRUCTIONS
Quadro Loop
Desk
Size: 1000mm
Table top x1
Legs Quadro x2
Legs Quadro Loop x2
Beam x1
Plastic bracket x4
A
B
C
D
E
Allen key x2J
M8x20MM CSK x1
M8x20MM Socket head x1
M6x20MM Socket head x2
M6x30MM Socket head x2
F
G
H
I
COMPONENTS
SCREWS
Page 2 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
D
E
F G H I
A
B
C
G
ASSEMBLY INSTRUCTIONS
Quadro Loop
Desk
Size: 1000mm
Using Allen Key provided, attach 2 plastic brackets per leg (E)
(as per picture above) using M6x20MM (H) Socket head screw.
Connect Loop Legs (C) to Bottom of Quadro Legs (B) by using
4 bolts per leg.
Using Allen Key provided, attach M8x20MM Socket head (G)-
screw socket half way into leg for both legs (B)
STEP 02
Page 3 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
H
STEP 01
ASSEMBLY INSTRUCTIONS
Quadro Loop
Desk
Size: 1000mm
STEP 03
Adjust extendable beam (D) to desired
length using markers and secure beam
at that length using screws provided
Page 4 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
50
1200
1300
1400
1500
1600
1700
1800
1900
2000
50
ASSEMBLY INSTRUCTIONS
Quadro Loop
Desk
Size: 1000mm
STEP 04
TOP VIEW
Attach beam (D) to legs (B) using nut insert in legs
See point attached
Frame looks like this. Using Allen Key, attach beam (D) with Socket (F)
STEP 05
Page 5 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
F
F
ASSEMBLY INSTRUCTIONS
Quadro Loop
Desk
Size: 1000mm
STEP 06
Page 6 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Place desktop ontop of frame. Nut inserts in top will align with plastic
joiner brackets using M6x30MM (I) sockets attached top to frame.
nut insert nut insert
TABLE TOP
BOTTOM VIEW
I
