Jason.L Switch System 3 Person Run User manual

Note: Please ignore any pre-drilled holes or nut inserts that maybe present in your top(s). They will not match your particular
table/desk base and woods screws will be required to be screwed directly into the underside of the top.
Note: It is important to fully tighten all bolts and screws before attaching the top(s) so that the frame is suciently rigid.
Failure to do this may aect stability once the tops are attached.
Tools Required: Power screwdriver.
INSTALLATION GUIDE
Switch System
3 Person Run
Size: 1200x700 mm
Page 1 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au

Page 2 of 5
INSTALLATION GUIDE
Switch System
3 Person Run
Size: 1200x700 mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
9
4
1
2
3
4
5
6
11 12
7
6
5
8
10
13
Table Top x3 (1200x700mm)
Leg x8
Leg Bracket x8
Beam Bracket x16
Switch Beam x2 (1100mm)
Switch Beam x4 (915mm)
Switch Beam x4 (325mm)
L-Bracket x12
1
2
3
4
5
6
7
8
Hex Nut x8
L-Bracket screws x12
Hex Head screws x8
M8x40mm Bolt x16
M8x20mm Bolt x20
9
10
11
12
13
COMPONENTS
SCREWS

Page 3 of 5
INSTALLATION GUIDE
Switch System
3 Person Run
Size: 1200x700 mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Join Leg Brackets to each Leg using screws to secure them, as follow.
Securely connect each Beam to each Beam Bracket. Screw to secure. Insert Hex Nut on each Beam Bracket.
01
03 04
Join 1 L-Bracket through each Beam.
02

Page 4 of 5
INSTALLATION GUIDE
Switch System
3 Person Run
Size: 1200x700 mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
For the 4 central legs, attach as presented, using T Beam Bracket.
06
Position as presented, and proceed to screw to ensure each corner of the frame.
05
If this bolt does not drop into the joint
use the Allen key to screw it all the way
in so that it creates its own thread.
This will ensure a nice, tight joint.

Page 5 of 5
INSTALLATION GUIDE
Switch System
3 Person Run
Size: 1200x700 mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Directly screw into table tops, using L-Bracket
screws through each L-Bracket.
07
Note: It is important to fully tighten all bolts and
screws before attaching the top(s) so that the frame is
suciently rigid. Failure to do this may aect stability
once the tops are attached.
