Jason.L Horizon Quadro A 6P workstation 1200x800 mm User manual

ASSEMBLY INSTRUCTIONS
Horizon Quadro A
6P workstation
Sizes: 1200x800, 1400x800, 1600x800, 1800x800 mm
Page 1 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set (provided)
2 persons required for installation

B
ASSEMBLY INSTRUCTIONS
Horizon Quadro A
6P workstation
Sizes: 1200x800, 1400x800, 1600x800, 1800x800 mm
Table top x6
Leg Quadro A x2
Connector frame x2
Beam x8
Plastic bracket x24
A
B
C
D
E
Allen key x2J
M8x20MM CSK x12
M8x20MM Socket head x12
M6x20MM Socket head x24
M6x30MM Socket head x24
F
G
H
I
COMPONENTS
SCREWS
Page 2 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
D
E
F G H I
A
C

ASSEMBLY INSTRUCTIONS
Horizon Quadro A
6P workstation
Sizes: 1200x800, 1400x800, 1600x800, 1800x800 mm
Using Allen Key provided, attach 2 plastic brackets per leg (E)
(as per picture above) using M6x20MM (H) Socket head screw.
Do the same with Connector frame (C).
Using Allen Key provided, attach M8x20MM Socket head (G)-
screw socket half way into leg for all legs (B) and into
Connector frame (C).Page 3 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
G
H
STEP 01 STEP 02

ASSEMBLY INSTRUCTIONS
Horizon Quadro A
6P workstation
Sizes: 1200x800, 1400x800, 1600x800, 1800x800 mm
STEP 03
Adjust extendable beam (D) to desired
length using markers and secure beam
at that length using screws provided
Page 4 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
50
1200
1300
1400
1500
1600
1700
1800
1900
2000
50

ASSEMBLY INSTRUCTIONS
Horizon Quadro A
6P workstation
Sizes: 1200x800, 1400x800, 1600x800, 1800x800 mm
Attach beam (D) to legs (B) and Connector frame (C)
using nut insert in legs. See point attached
Frame looks like this. Using Allen Key, attach beam (D) with Socket (F)
STEP 05
Page 5 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
STEP 04
TOP VIEW
F
F
F
F
F
F

ASSEMBLY INSTRUCTIONS
Horizon Quadro A
6P workstation
Sizes: 1200x800, 1400x800, 1600x800, 1800x800 mm
Page 6 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
I
STEP 06
Place desktops ontop of frame - with cutout at the back of the
desk. Nut inserts in top will align with plastic joiner brackets
using M6x30MM (I) sockets attached tops to frame.
TABLE TOP
BOTTOM VIEW

ASSEMBLY INSTRUCTIONS
Horizon Quadro A
6P workstation
Sizes: 1200x800, 1400x800, 1600x800, 1800x800 mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Page 7 of 8
TABLE TOPS
BOTTOM VIEW
The following nut inserts should be used for this specific desk / workstation
nut insertnut insert nut insertnut insert
nut insertnut insert nut insertnut insert
nut insertnut insert
nut insertnut insert

ASSEMBLY INSTRUCTIONS
Horizon Quadro A
6P workstation
Sizes: 1200x800, 1400x800, 1600x800, 1800x800 mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
STEP 07
Page 8 of 8
Under the desktops, use l-shaped panel brackets to secure
the screens to the desktops. Place two brackets in each
screen (4 L-Shaped bracket in total).
Using an Allen key remove top 2 caps from all screens uprights.
Bring two partition towards one another and slide the 2 way
connector rod - down between the two screen uprights.
