Jason.L Quadro A leg Counter table Radius Corners User manual

ASSEMBLY INSTRUCTIONS
Quadro A leg
Counter table
Radius Corners
Sizes: 3200x1100 mm
Page 1 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set (provided)
2 persons required for installation

ASSEMBLY INSTRUCTIONS
Quadro A leg
Counter table
Radius Corners
Sizes: 3200x1100 mm
Table top x2
Leg Quadro A x3
Upper Beam x2
Lower Beam x2
Plastic bracket x8
Feet x6
A
B
C
D
E
F
Allen key x2K
M8x20MM CSK x12
M8x20MM Socket head x8
M6x20MM Socket head x6
M6x30MM Socket head x8
OR M6x30mm wood screws x8
G
H
I
J
COMPONENTS
SCREWS
Page 2 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
D
C
E
F
G H I J
B
A

H
ASSEMBLY INSTRUCTIONS
Quadro A leg
Counter table
Radius Corners
Sizes: 3200x1100 mm
Using Allen Key provided, attach 2 plastic brackets per exterior
leg (D), and 4 plastic brackets for the shared leg (as per picture
above) using M6x20MM (I) Socket head screw.
Screw the feets (F) to the bottom of each leg (B)
Using Allen Key provided, attach M8x20MM Socket head (H)-
screw socket half way into leg for all legs (B)
STEP 02
Page 3 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
TOP VIEW
I
STEP 01
F
B

ASSEMBLY INSTRUCTIONS
Quadro A leg
Counter table
Radius Corners
Sizes: 3200x1100 mm
Page 4 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
C
STEP 03
Adjust extendable beam (C) to desired
length using markers and secure beam
at that length using screws provided
50
1200
1300
1400
1500
1600
1700
1800
1900
2000
50

D
ASSEMBLY INSTRUCTIONS
Quadro A leg
Counter table
Radius Corners
Sizes: 3200x1100 mm
STEP 04
Adjust extendable beams (D) to desired length.
Remove plastic inserts
Loosen 2 bolts on beam using allen key
Extent lower beam to the same distance as upper beam
Insert plastic inserts back into the beam
Page 5 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
2
2
2
4
1
1
1
3
3

ASSEMBLY INSTRUCTIONS
Quadro A leg
Counter table
Radius Corners
Sizes: 3200x1100 mm
STEP 05
TOP VIEW
Frame looks like this. Using Allen Key, attach Upper Beam (C)
with Sockets (G).
STEP 06
Page 6 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
G
C
G
Attach Upper Beams (C) to legs (B) using nut insert in legs.
See point attached

G
G
Frame looks like this. Using Allen Key. Tighen Sockets (G) on the Lower Beams
(D) using Allen Key (J). Insert plastic spacers to improve regidity. Attach two
Sockets (G) to the side of each lower side beam (as shown in the picture).
STEP 07
D
ASSEMBLY INSTRUCTIONS
Quadro A leg
Counter table
Radius Corners
Sizes: 3200x1100 mm
Page 7 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
G

ASSEMBLY INSTRUCTIONS
Quadro A leg
Counter table
Radius Corners
Sizes: 3200x1100 mm
STEP 08
Page 8 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
J
TABLE TOP
BOTTOM VIEW
Place desktop on top of frame. Please drill wood screws using
M6x30MM (J) into the underneath of the tops.
Wood screws drill location Wood screws drill location
