Jason.L Quadro Loop desk User manual

ASSEMBLY INSTRUCTIONS
Quadro Loop desk
Size: 1000W x 600D mm
Page 1 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set (provided)
2 persons required for installation

ASSEMBLY INSTRUCTIONS
Quadro Loop desk
Size: 1000W x 600D mm
Table top x1
Legs Quadro x2
Legs Quadro Loop x2
Beam x1
Plastic bracket x4
A
B
C
D
E
Allen key x2J
M8x20MM CSK x1
M8x20MM Socket head x1
M6x20MM Socket head x2
M6x30MM Socket head x2
F
G
H
I
COMPONENTS
SCREWS
Page 2 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
D
E
F G H I
A
B
C

ASSEMBLY INSTRUCTIONS
Quadro Loop desk
Size: 1000W x 600D mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
F
G
STEP 01 STEP 02 STEP 03
Using Allen Key provided, attach 2 plastic brackets
per leg (E) (as per picture above) using M6x20MM
(H) Socket head screw. Connect Loop Legs (C) to
Bottom of Quadro Legs (B) by using 4 bolts per leg.
Using Allen Key provided, attach
M8x20MM Socket head (G)- screw
socket half way into leg for both legs (B)
Use fixed beam (D) 1000mm and secure beam
using screws provided to suit 1000mm desk
Page 3 of 5

ASSEMBLY INSTRUCTIONS
Quadro Loop desk
Size: 1000W x 600D mm
STEP 04
TOP VIEW
Attach beam (D) to legs (B) using nut insert in legs
See point attached
Frame looks like this. Using Allen Key, attach beam (D) with Socket (F)
STEP 05
Page 4 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
F
F

ASSEMBLY INSTRUCTIONS
Quadro Loop desk
Size: 1000W x 600D mm
STEP 06
Page 5 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Place desktop ontop of frame. Nut inserts in top will align with plastic
joiner brackets using M6x30MM (I) sockets attached top to frame.
nut insert nut insert
TABLE TOP
BOTTOM VIEW
I
