jbc CL8499 User manual

CLM
Manual Tip Cleaner
INSTRUCTION MANUAL

OK
OK
CLU
CLS
CLM
ANTISPLASH MEMBRANE
ON OFF
SWITCH
OFFON
SWITCH
OK
OK
CLU
CLS
CLM
ANTISPLASH MEMBRANE
ON OFF
SWITCH
OFFON
SWITCH
Select the option to suit your needs and improve the thermal transfer of the tip.
Features
Packing list
Brass Wool
Ref. CL6210
Splashguard
Ref. 0017576
Non-Slip Base
Sponge
Ref. S0354
ESD Safe Tip Wiper
Ref. CL0240
Very effective cleaning
method. It leaves a small
layer of solder on the tip to
prevent oxidation between
cleaning and rewetting.
It prevents splashing of
solder particles when
using the brass wool. No need to hold the
base while cleaning tips.
The least harmful
cleaning method. Keep
the sponge damp with
distilled water when
working to avoid tip wear.
A temperature resistant
receptacle lets the
operator remove
excess solder by gentle
tapping or wiping.
Tapping: Wiping:
Tap to remove excess
solder.
Use the slots to remove
remaining particles.
Sponge ............................1 unit
Ref. S0354
Brass Wool .....................1 unit
Ref. CL6210
Manual Tip Cleaner ..... 1 unit
Ref. CL8499
Manual ............................ 1 unit
Ref. 0028694
The following items are included:
Antisplash
Membrane
R ef . 0 017574
Prevents splashing
and keeps the
work area clean.
This manual corresponds to the following reference:
CL8499
If the tip is very dirty, JBC recommends first cleaning it with the wiper to remove excess solder and then with the
brass wool.
2

OK
OK
CLU
CLS
CLM
ANTISPLASH MEMBRANE
ON OFF
SWITCH
OFFON
SWITCH
OK
OK
CLU
CLS
CLM
ANTISPLASH MEMBRANE
ON OFF
SWITCH
OFFON
SWITCH
OK
OK
CLU
CLS
CLM
ANTISPLASH MEMBRANE
ON OFF
SWITCH
OFFON
SWITCH
OK
OK
CLU
CLS
CLM
ANTISPLASH MEMBRANE
ON OFF
SWITCH
OFFON
SWITCH
OK
OK
CLU
CLS
CLM
ANTISPLASH MEMBRANE
ON OFF
SWITCH
OFFON
SWITCH
OK
OK
CLU
CLS
CLM
ANTISPLASH MEMBRANE
ON OFF
SWITCH
OFFON
SWITCH
OK
OK
CLU
CLS
CLM
ANTISPLASH MEMBRANE
ON OFF
SWITCH
OFFON
SWITCH
OK
OK
CLU
CLS
CLM
ANTISPLASH MEMBRANE
ON OFF
SWITCH
OFFON
SWITCH
Membrane
Fixing
Clamp
Wool/Brush Replacement
Wiper Replacement
Membrane Replacement
First pull the wiper out.
Depending on the component used, replace the brass wool (1) or
brush (2) for a new one.
Open the splashguard and take
it off.
Loosen the screw and remove
the screw, the washer.
Screw
and
Washer
12
Then take out the fixing clamp. Finally the membrane. Replace
the membrane for a new one.
Once the new membrane is positioned, place all the components back again and tighten the screw.
Then inset the new one.
3
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm

This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
Specifications
CLM
Manual Tip Cleaner
Ref. CL8499
- Total Net Weight: 877 g / 1.93 lb
- Package Dimensions / Weight: 130 x 100 x 98 mm / 936 g
(Lx W x H) 5.12 x 3.92 x 3.86 in / 2.06 lb
Complies with CE standards.
ESD Safe.
0028694-0222
