JBL M-Patch2 User manual

PASSIVE VOLUME CONTROL
MONITOR SWITCH

* Note: Please take into consideration your particular setup and cable
arrangement when deciding on mounting your M-Patch with the highest degree
of angle in relation to your desktop surface. You will need to ensure that you
have enough space to connect your cables!
* Note: The M-Patch 2 accepts mic or line level input signals. Do not connect
your power amplier outputs to the M-Patch 2 inputs!
PASSIVE VOLUME CONTROL
MONITOR SWI TCH

* Note: You can connect up to three different devices to the three physical
connector sets simultaneously. The input selector on the front panel allows
selection of the desired inputs!
* Note: It is possible to activate or deactivate each desired output pair using
the output selector switches on the front panel. It is possible to have both
1&2 outputs active at the same time. This is very useful when simultaneously
connecting the outputs to a recording device and a monitoring system.

* Note: All passive attenuation functions operate fully without the connection of
the power supply. This enables portable use of the M-Patch 2 without restriction.
* Note: If you have more than one pair of monitor speakers you could create a
perfect switching facility for toggling between near-eld and lager format active
room monitors.

* Note: Use of the headphone amplier requires connection of the included
external power supply.

JBL PRO FESS I ON AL
NORTHRIDGE, CA. USA AHARMANI NTERNATI ONAL COM PANY
Soundcard, C D player, MP3 Player
OUTPUTS
DAW or Mixer
OUTPUTS
Active speakers 1
INPUTS
Active speakers 2
INPUTS

Input Connectors 1 2 x Combination XLR / 1/4-inch (6.5mm)
Maximum Input Level > + 26dB
Input Connectors 2 1 x stereo RCA pair (L&R)
Input Connectors 3 1 x stereo 1/8 inch (3.5mm) jack
Output Connectors 1 2 x XLR output pairs (1- / L&R, 2-/L&R)
Output Connectors 1 x 1/4” TRS stereo output
Output Level >+ 26dB
Impedance 0- 5K ohms
Headphone Output 1 x 1/4 in (6.5mm) TRS stereo output
Headphone Output Level 320mWinto 32 Ω
Frequency Response 20Hz - 20Hz +/- 0.5dB
Signal-To-Noise better than -120dB
Channel Cross Tal k bet ter t han - 80dB
Dist ort ion < 0.0004%
Included Power Supply DC12- 16V, 200 ma
Dimensions (Wx D x H) 8.7 in x 4.7 in x 3.4 in
(220 mm x 120 mm x 86 mm)
Weight 2.2 lbs (1.0 kg)
