JBL VLA-C SERIES User manual

VLA COMPACT
variable line array
VLA-C SERIES | USER’S GUIDE

2
JBL VLA-C SERIES | USER’S GUIDE
Note: While this guide refers to the VLA-C models without including a color designation, the color
suffix is part of the full model number of the product. When ordering a product, the color must be
specified via a suffix. Models with a –BK suffix (VLA-C125S-BK, VLA-C265-BK, and VLA-C2100-
BK) are black; models with a –GR suffix (VLA-C125S-GR, VLA-C265-GR, and VLA-C2100-GR)
are gray.
GENERAL INFORMATION
VLA-C SERIES | USER’S GUIDE
Document Number: 1000344625A
Version: A
Distribution Date: 09/24/2019

3
JBL VLA-C SERIES | USER’S GUIDE
TABLE OF CONTENTS
1 - Declaration of Conformity ..............................................................................................................................................4
2 - Safety ...............................................................................................................................................................................................5
2.1 - Safety Instructions ...................................................................................................................................................5
2.2 - General Hardware Information .....................................................................................................................5
2.3 - Attachment To Structures ..............................................................................................................................6
2.4 - Important Safety Warning .................................................................................................................................6
2.5 - Inspection and Maintenance ............................................................................................................................7
2.6 - Symbols ..............................................................................................................................................................................7
3 - Mechanical Information ....................................................................................................................................................8
4 - System Components ........................................................................................................................................................9
5 - Software ....................................................................................................................................................................................10
6 - Array Size Cabinet Suspension Limit Guidelines ......................................................................................13
7 - Bracket Plates (ie, Angle Brackets) ....................................................................................................................13
7.1 Which Bracket Plate to Use ..............................................................................................................................14
7.2 Assembly Drawing ....................................................................................................................................................15
7.3 Example of 6-Cabinet Array .............................................................................................................................16
7.4 Side-Panel External Trim Cover Panels ..................................................................................................17
8 - Amplification ...........................................................................................................................................................................18
9 - DSP Presets ......................................................................................................................................................................... 20
10 - Wiring ......................................................................................................................................................................................... 22
Wiring for VLA-C265 & VLA-C2100 Full-Range Loudspeakers ................................................ 22
Wiring for VLA-C125S Subwoofer ...................................................................................................................... 25
Wiring Three VLA-C-125S Cabinets in a Cardioid Subwoofer Configuration ................. 26
11 - Additional VLA-C Guides ............................................................................................................................................ 26
12 - Specifications .................................................................................................................................................................... 27
12.1 Impedance Curves ...............................................................................................................................................30
13 - Contact Information .....................................................................................................................................................31

4
JBL VLA-C SERIES | USER’S GUIDE
1 - DECLARATION OF CONFORMITY
BRAND: JBL Professional
FAMILY NAME: VLA Compact Loudspeakers and Accessories
MODEL NAMES:
• VLA-C265-BK
• VLA-C265-GR
• V L A- C210 0- BK
• V L A- C210 0- G R
• V L A- C125S -BK
• V L A- C125S - GR
We, HARMAN International, declare under our sole responsibility that the product, to which this declaration relates, is in
conformity with the following standards:
STANDARD DESCRIPTION TEST AGENCY
2006/42/EC MACHINE DIRECTIVE Applies to machinery and lays
down essential health and safety
requirements.
IS O12100
Tested at JBL Professional
2014/35/EC
LOW VOLTAGE DIRECTIVE
Applies to loudspeaker and lays
down essential health and safety
requirements.
EN60065
Tested at JBL Professional
ROHS Removal of Hazardous
Substances Directive
Directive on the restriction of the use
of certain hazardous substances in
electrical and electronic equipment.
Self-Declared by JBL Professional
IP-55 per IEC529, IEC 60529, EN60529 International Protection Marking Intertek
Frank Lacelle
Compliance Manager - Harman International

5
JBL VLA-C SERIES | USER’S GUIDE
2 - SAFETY
2.1 - SAFETY INSTRUCTIONS
1. Read these instructions
2. Keep these instructions
3. Heed all warnings
4. Follow all instructions
5. Do not expose the product to sea spray or caustic environmental factors. VLA-C
loudspeakers are not outfitted for use on the deck of cruise ships
6. Clean only with a dry cloth
7. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus that produce heat
8. Only use attachments / accessories specified by the manufacturer
9. Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way
10. Contact JBL Professional for advanced servicing issues
11. CAUTION - DO NOT PERFORM ANY SERVICING UNLESS YOU ARE QUALIFIED TO DO SO
12. Prolonged exposure to excessive SPL can cause hearing damage: the loudspeaker is
easily capable of generating sound pressure levels (SPL) sufficient to cause permanent
hearing damage to performers, production crew and audience members. Caution should
be taken to avoid prolonged exposure to SPL in excess of 90 dB
13. Read the System Rigging Manual before installation and use of the product
2.2 - GENERAL HARDWARE INFORMATION
Any hardware used in an overhead suspension application must be load rated for the intended
use. Generally, this type of hardware is available from rigging supply houses, industrial supply
catalogs and specialized rigging distributors. Local hardware stores do not usually stock these
products. Hardware that is intended for overhead suspension will comply with ASME B30.20
and will be manufactured under product traceability controls. Compliant hardware will be
referenced with a working load limit (WLL) and a traceability code.

6
JBL VLA-C SERIES | USER’S GUIDE
2.3 - ATTACHMENT TO STRUCTURES
A licensed Professional Engineer must approve the placement and method of attachment to the
structure prior to the installation of any overhead object. The installation of the hardware and
method of attachment must be carried out in the manner specified by the Professional Engineer.
Improper installation may result in damage, injury or death.
CAUTION: Installation must be done by
qualified persons using safe rigging standards.
The installer is responsible for proper selection and use of mounting
hardware to properly and safely suspend the speakers.
2.4 - IMPORTANT SAFETY WARNING
The information in this section has been assembled from recognized engineering data and is
intended for informational purposes only. None of the information in this section should be used
without first obtaining competent advice with respect to applicability to a given circumstance.
None of the information presented herein is intended as a representation or warranty on the
part of JBL. Anyone making use of this information assumes all liability arising from such use.
All information presented herein is based upon materials and practices common to North
America and may not directly apply to other countries because of differing material dimensions,
specifications and/or local regulations. Users in other countries should consult with appropriate
engineering and regulatory authorities for specific guidelines.
Correct use of all included hardware is required for secure system suspension. Careful
calculations should always be performed to ensure that all components are used within their
working load limits before the array is suspended. Never exceed the maximum recommended
load ratings.

7
JBL VLA-C SERIES | USER’S GUIDE
2.5 - INSPECTION AND MAINTENANCE
Suspension systems are comprised of mechanical devices and, as such, they require regular
inspection and routine maintenance to ensure proper functionality. Before suspending any
speaker system, always inspect all components (enclosure, suspension frames or brackets,
eyebolts, etc.) for cracks, deformations, corrosion or missing/loose/damaged parts that
could reduce strength and safety of the array. Do not suspend the speaker until the proper
corrective action has been taken.
Installed systems should be inspected at least annually. The inspection shall include a visual survey
of all corners and load-bearing surfaces for signs of cracking, water damage, delamination or any
other condition that may decrease the strength of the loudspeaker enclosure.
Accessory suspension hardware provided with or for VLA-C systems must be inspected for
fatigue at least annually or as required by local ordinance. The inspection shall include a visual
survey of the material for signs of corrosion, bending or any other condition that may decrease
the strength of the fastener. Additionally, any eyebolts shall be checked for possible spin-out of
the enclosure.
For all other hardware and fittings, refer to the hardware manufacturer’s inspection and
maintenance guidelines for process .
JBL is not responsible for the application of its products for any purpose or the misuse of this
information for any purpose. Fur thermore, JBL is not responsible for the abuse of its products
caused by avoiding compliance with inspection and maintenance procedures or any other abuse.
Prior to suspending the system, an expert, trained and experienced in suspending speaker
systems, should inspect all parts and components.
2.6 - SYMBOLS
The following set of symbols are used in this document:
CAUTION: This symbol gives notice of a potential risk of harm to the individual or the
equipment. Instruction marked with this symbol must be strictly followed.
TIP: This symbol gives notice of helpful, relevant information about the topic.
INSTRUCTIONS: This symbol gives notice of instructions that must be followed for
proper installation and use of the product.
TOOLS REQUIRED: This symbol gives notice of tools that must be used for proper
installation and use of the product.

8
JBL VLA-C SERIES | USER’S GUIDE
3 - MECHANICAL INFORMATION
VLA Compact suspension system and accessories are also in compliance with the ANSI E1.8
- 2012 Section 5.3.4 standard for a minimum safety factor of 5:1. Minimum safety factor
requirements are often set by local regulations and the VLA-C Calculator should be used to
verify the safety factor for each array configuration.
TIPS:
•While the VLA-C265 and VLA-C2100 have similar dimensions and weights, they
are not identical. Therefore, there may be small gaps between boxes in an array.
•Because of their similar sizes, VLA-C2100 & VLA-C265 are sometimes used
interchangeably throughout this document.

9
JBL VLA-C SERIES | USER’S GUIDE
4 - SYSTEM COMPONENTS
VLA-C265 V L A- C210 0 V L A - C12 5S
VLA-C265
Bracket Plate
V L A- C 210 0
Bracket Plate
V L A - C12 5S
Bracket Plate
See later sections for additional information.
CAUTION: Always use components and accessories specified and approved by
JBL Professional.

10
JBL VLA-C SERIES | USER’S GUIDE
5 - SOFTWARE
EASE GLL FILES
EASE GLL files are available for VLA-C Series loudspeakers at the JBL Professional website www.
jblpro.com on the VLA Compact Series webpage and on each of the individual model webpages.
Example of small stadium with two flanking scoreboard arrays of 8 x VLA-C265 each (ave. 500 Hz – 4 kHz).
CLF FILES
CLF Common Loudspeaker Format files are available for VLA-C Series loudspeakers at the JBL
Professional website.

11
JBL VLA-C SERIES | USER’S GUIDE
VLA-C CALCULATOR
The free VLA-C Calculator is simulation software for designing and predicting JBL VLA-C
Series systems.
Acoustical Mapping
The Acoustical Mapping tab allows for 2D sectional-view modeling of VLA-C arrays on up to
four seating planes. Included are both patterns of the VLA-C full-range boxes (VLA-C265 and
VLA-C2100) and the subwoofer (VLA-C125S). Mixed arrays may be modeled.

12
JBL VLA-C SERIES | USER’S GUIDE
Array Configuration
The Array Configuration tab describes the array and provides information about weight factors
and center of gravity (CG), along with mechanical validation of the array. The array weight
design factor is selectable between 5:1, 7:1, and 10:1. Frame options are selectable. If the array
configuration falls outside the load limits of either the speaker cabinets, the speaker interconnect
system, or the suspension system, this will be indicated via an error indication. Array statistics like
total weight, attach point span, and array height and depth are also calculated.
There are two types of warning messages, which show in red lettering at the top of the Suspension
Detail and Mapping graphics: One is “Invalid CG Location” which is when the center of gravity (CG)
is outside of the two suspension points. This indicates that the array aiming angle is not physically
achievable. A second warning is “Array exceeds load limit conditions” (may also include additional
information about which load limit factor is exceeded). This indicates that one or more of the
components of the array exceeds the selected Design Factor

13
JBL VLA-C SERIES | USER’S GUIDE
6 - ARRAY SIZE CABINET SUSPENSION LIMIT GUIDELINES
Refer to the free VLA-C Calculator software for the array size cabinet suspension limits for your
particular configuration.
7 - BRACKET PLATES (ie, Angle Brackets)
Each loudspeaker model ships with a corresponding pair of bracket plates which can be seen here:
V L A - C12 5S VLA-C265 V L A- C 210 0
Orientation: Note that the FRONT arrow must always point toward the front of the loudspeaker
cabinets. This places one dot-outlined section on the top, which connects via two bolt points to
the top loudspeaker cabinet, and it places the other dot-outlined section on the bottom, which
connects via two bolt points to the lower loudspeaker cabinet.
Attach the Appropriate Plate -- See charts below for which plate and which holes to use, based on
the cabinet models and the desired inter-cabinet splay angle.
Bolt Installation – Select the bolt holes in the bracket plate that correspond to the two cabinet models
that are being connected by that plate and the desired inter-box angle setting. Use the supplied
stainless steel M10 x 35 mm bolts and lock washers to secure the angle plates to the cabinet. Remove
the neoprene washer from the locations used to attach rigging components. Insert two of the M10
bolts (with lock washers) through the holes in the top section of the bracket and thread them into the
two bottom threaded insert points in the top cabinet. Insert two of the M10 bolts (with lock washers)
through the corresponding holes in the bottom section of the bracket plate and thread them into the
two top threaded insert points in the bottom cabinet. (See diagrams)
INSTRUCTIONS: Bolt Torque Settings -- Use non-permanent thread locker such as
Loctite brand Blue 242 on the threads of all fasteners. Torque bolts to 29.5 ft•lbf (±3
ft•lbf); 40 N•m (±4 N•m)
NOTE: The composite enclosure will make noises as bolts are tightened – this is normal.
Once all the plates and bolts have been checked, install the side covers using the supplied 8x32
Philips screws. Torque screws to 2.0 ft·lbf (±0.2 ft·lbf); 2.6 N·m (±0.3 N·m).

14
JBL VLA-C SERIES | USER’S GUIDE
7.1 WHICH BRACKET PLATE TO USE
•When attaching a VLA-C265 to a VLA-C265, use the included VLA-C265 bracket. The possible
splay angles are: 1.5°, 2.4°, 3.8°, 6.0°, and 9.5°.
•When attaching a VLA-C2100 to a VLA-C2100, use the included VLA-C2100 bracket. The
possible splay angles are: 2.4°, 3.8°, 6.0°, 9.5°, and 15.0°.
•When attaching a VLA-C265 and VLA-C2100 together (with either model at the top or bottom),
you may be using a VLA-C265 or VLA-C2100 plate. Which one to use depends on the desired
splay angle.
ARRAY RIGGING COMBINATIONS
VLA-C265 to VLA-C265 VLA-C265 to VLA-C2100 VLA-C2100 to VLA-C2100
VLA-C265 Bracket Plates (x2) 1.5°, 2.4°, 3.8°, 6.0°, and 9.5° 4.7°, 7.5°, 11.9° NO
VLA-C2100 Bracket Plates (x2) NO 1.9°, 3.0° 2.4°, 3.8°, 6.0°, 9.5°, 15°
(Note: The opposite plate to cabinet combination is not allowed – in other words, a VLA-C265 plate cannot be
used to join two VLA-C2100s.)
•When attaching a VLA-C125S subwoofer to another VLA-C125S subwoofer or to either a
VLA-C265 or VLA-C2100 full-range model, use the included VLA-C125S bracket.
•For attaching to another VLA-C125S, the only angle possible is 0°.
•For attaching to VLA-C265, the possible splay angles are: 0° and 5.0°.
•For attaching to VLA-C2100, the possible splay angle are: 0° and 7.5°.
ARRAY RIGGING COMBINATIONS
VLA-C125S to VLA-C125S VLA-C125S to VLA-C265 VLA-C125S to VLA-C2100
VLA-C125S Bracket Plates (x2) 0° 0°, 5.0° 0 ° , 7. 5 °
Here is the same information as the tables above but from the point-of-view of the angles:
VLA-C Splay Angle Settings from POV of Angles – Which Brackets to Use
ANGLE
1.5° 1.9° 2.4° 3.0° 3.8° 4.7° 6.0° 7. 5° 9.5° 11.9° 15.0°
COMBINATION
VLA-C2100 to VLA-C2100 V L A- C 2100
Bracket
Plate
V L A- C 2100
Bracket
Plate
V L A- C 2100
Bracket
Plate
V L A- C 2100
Bracket
Plate
V L A- C 2100
Bracket
Plate
VLA-C265 to VLA-C265 VLA-C265
Bracket
Plate
VLA-C265
Bracket
Plate
VLA-C265
Bracket
Plate
VLA-C265
Bracket
Plate
VLA-C265
Bracket
Plate
VLA-C265 to VLA-C2100
[either model can be on top or bottom]
V L A- C 2100
Bracket
Plate
V L A- C 2100
Bracket
Plate
VLA-C265
Bracket
Plate
VLA-C265
Bracket
Plate
VLA-C265
Bracket
Plate

15
JBL VLA-C SERIES | USER’S GUIDE
7.2 ASSEMBLY DRAWING
V L A- C 210 0
Bracket Plate
M10 stainless steel
lock washers
M10 x 35 m m
Stainless Steel Bolts
1.5mm pitch
6 mm hex drive
(See torque spec, above.)
V L A- C 210 0
V L A- C 210 0

16
JBL VLA-C SERIES | USER’S GUIDE
7.3 EXAMPLE OF 6-CABINET ARRAY
VLA-C125S
C125S, C265
OR C2100
LOWER
SPEAKER
UPPER SPEAKER
C125S ONLY
UPPER SPEAKER :
LOWER SPEAKER :
ANGLE:
C125S
C125S C265 C 2100
0
º
5
º
7.5
º
UPPER SPEAKER :
LOWER SPEAKER :
ANGLE:
C125S
C125S C265 C 2100
0
º
5
º
7.5
º
UPPER SPEAKER :
LOWER SPEAKER :
ANGLE:
C125S
C2100
0
º
UPPER SPEAKER :
LOWER SPEAKER :
ANGLE:
C125S
C265
0
º
UPPER SPEAKER :
LOWER SPEAKER :
ANGLE:
C125S
C2100
0
º
UPPER SPEAKER :
LOWER SPEAKER :
ANGLE:
C125S
C265
0
º
FRONT
VLA-C125S
C125S, C265
OR C2100
LOWER
SPEAKER
UPPER SPEAKER
C125S ONLY
UPPER SPEAKER :
LOWER SPEAKER :
ANGLE:
C125S
C125S C265 C 2100
0
º
5
º
7.5
º
UPPER SPEAKER :
LOWER SPEAKER :
ANGLE:
C125S
C125S C265 C 2100
0
º
5
º
7.5
º
UPPER SPEAKER :
LOWER SPEAKER :
ANGLE:
C125S
C2100
0
º
UPPER SPEAKER :
LOWER SPEAKER :
ANGLE:
C125S
C265
0
º
UPPER SPEAKER :
LOWER SPEAKER :
ANGLE:
C125S
C2100
0
º
UPPER SPEAKER :
LOWER SPEAKER :
ANGLE:
C125S
C265
0
º
FRONT
1.5
º
1.5
º
2.4
º
2.4
º
9.5
º
1.5
º
2.4
º
9.5
º
6.0
º
3.8
º
3.8
º
3.8
º
4.7
º
11.9
º
6.0
º
4.7
º
7.5
º
9.5
º
6.0
º
4.7
º
11.9
º
11.9
º
1.5
º
2.4
º
9.5
º
3.8
º
6.0
º
4.7
º
7.5
º
7.5
º
VLA-C 265
UNBOXED ANG LES:
C265-C265 ONLY
BOXED ANGLES :
C265-C2100 ONLY
FRONT
11.9
º
7.5
º
1.5
º
1.5
º
2.4
º
2.4
º
9.5
º
1.5
º
2.4
º
9.5
º
6.0
º
3.8
º
3.8
º
3.8
º
4.7
º
11.9
º
6.0
º
4.7
º
7.5
º
9.5
º
6.0
º
4.7
º
11.9
º
11.9
º
1.5
º
2.4
º
9.5
º
3.8
º
6.0
º
4.7
º
7.5
º
7.5
º
VLA-C 265
UNBOXED ANG LES:
C265-C265 ONLY
BOXED ANGLES :
C265-C2100 ONLY
FRONT
11.9
º
7.5
º
2.4
º
2.4
º
2.4
º
2.4
º
9.5
º
9.5
º
9.5
º
15.0
º
15.0
º
15.0
º
15.0
º
3.8
º
3.8
º
3.8
º
3.8
º
6.0
º
6.0
º
6.0
º
6.0
º
1.9
º
1.9
º
1.9
º
1.9
º
3.0
º
3.0
º
3.0
º
3.0
º
FRONT
VLA-C 2100
UNBOXED ANG LES:
C2100-C2100 ONLY
BOXED ANGLES :
C2100-C265 ONLY
9.5
º
V L A - C12 5S
0° INTER-CABINET SPLAY ANGLE
• VLA-C125S UPPER SPEAKER to VLA-C125S LOWER SPEAKER uses
VLA-C125S bracket plate.
• Orient “FRONT” arrow toward fronts of speaker cabinets.
• On top half of bracket plate, use the 2 holes marked for when
connecting C125S (ie, VLA-C125S) UPPER SPEAKER and C125S (ie,
VLA-C125S) LOWER SPEAKER and for 0°ANGLE. Screw the bolts
into the two spaced holes in the lower part of the UPPER SPEAKER.
• On bottom half of bracket plate, use the 2 holes marked for C125S
(ie, VLA-C125S) UPPER SPEAKER and C125S (ie, VLA-C125S)
LOWER SPEAKER and for 0°ANGLE. Screw the bolts into the two
spaced holes in the upper part of the LOWER SPEAKER.
0° INTER-CABINET SPLAY ANGLE
• VLA-C125S UPPER SPEAKER to VLA-C265 LOWER SPEAKER uses
VLA-C125S bracket plate.
• Orient “FRONT” arrow toward fronts of speaker cabinets.
• On top half of bracket plate, use the 2 holes marked for when
connecting C125S (ie, VLA-C125S) UPPER SPEAKER and C265 (ie,
VLA-C265) LOWER SPEAKER and for 0°ANGLE.
• On bottom half of bracket plate, use the 2 holes marked for C125S
UPPER SPEAKER to C265 LOWR SPEAKER and for 0° ANGLE.
6° INTER-CABINET SPLAY ANGLE
• VLA-C265 UPPER SPEAKER to VLA-C265 LOWER SPEAKER uses
VLA-C265 bracket plate.
• Orient “FRONT” arrow toward fronts of speaker cabinets.
• On top half of bracket plate, use the 2 holes marked for 6°
(unboxed).
• On bottom half of bracket plate, use the 2 holes marked for 6°
(unboxed).
11. 9 ° INTER-CABINET SPLAY ANGLE
• VLA-C265 UPPER SPEAKER to VLA-C2100 LOWER SPEAKER
uses VLA-C265 bracket plate for this 11.9° inter-cabinet splay
angle. (The VLA-C2100 bracket plate would instead be used for
this VLA-C265 to VLA-C2100 junction in situations where a much
smaller (1.9° or 3.0°) inter-cabinet splay angle is desired.)
• Orient “FRONT” arrow toward fronts of speaker cabinets.
• On top half of bracket plate, use the 2 holes marked for 11.9°
(boxed).
• On bottom half of bracket plate, use the 2 holes marked for 11.9°
(boxed).
15° INTER-CABINET SPLAY ANGLE
• VLA-C2100 UPPER SPEAKER to VLA-C2100 LOWER SPEAKER uses
VLA-C2100 bracket plate.
• Orient “FRONT” arrow toward fronts of speaker cabinets.
• On top half of bracket plate, use the 2 holes marked for 15° (boxed).
• On bottom half of bracket plate, use the 2 holes marked for 15°
(boxed).
V L A - C12 5S
VLA-C265
VLA-C265
V L A- C 210 0
V L A- C 210 0

17
JBL VLA-C SERIES | USER’S GUIDE
7.4 SIDE-PANEL EXTERNAL TRIM COVER PANELS
8-32 x 1/2” trusshead,
Phillips-drive,
stainless steel bolts
(See torque spec, above.)

18
JBL VLA-C SERIES | USER’S GUIDE
8 - AMPLIFICATION
The VLA-C full-range models may be driven passively or actively, and the full-range models can be
driven individually or in pairs. Below is the listing of the current amplifier models that contain the
proper FIR presets for the VLA-C loudspeaker models. The Harman amplifier model line-up may
change over time. These speakers should not be driven from amps that only provide IIR filters.
(See DSP Preset section, below.)
VLA-C265 OR VLA-C2100 FULL-RANGE SPEAKERS
Driving a single cabinet per amp channel:
CABINET 1 IMPEDANCE POWER HANDLING (W) AMPLIFIER(S) POWER INTO IMPEDANCE
LF (Low Frequency) 8800 1 channel of either:
DCi1250N or DCi1250DA 1250W into 8Ω
HF (High Frequency) 16 150 1 channel of either:
DCi600N or DCi600DA * 300W into 16Ω
Passive Full-Range 8 800 1 channel of either:
DCi1250N or DCi1250DA 1250W into 8Ω
VLA-C265 OR VLA-C2100 FULL-RANGE SPEAKERS
Driving two cabinets in parallel per amp channel:
CABINET 1 AND
CABINET 2 IN PARALLEL IMPEDANCE POWER HANDLING (W) AMPLIFIER(S) POWER INTO IMPEDANCE
LF (Low Frequency) 41600 1 channel of DCi2400N 2400W into 4Ω
HF (High Frequency) 8300 1 channel of either:
DCi600N or DCi600DA* 600W into 8Ω
Passive Full-Range 4 1600 1 channel of DCi2400N 2400W into 4Ω
VLA-C125S SUBWOOFER
Driving a single cabinet:
CABINET 1 IMPEDANCE POWER HANDLING (W) AMPLIFIER(S) POWER INTO IMPEDANCE
LF (Low Frequency) 41600 1 channel of: DCi2400N 2400W into 4Ω
* Because of the high transient signal capability of these HF drivers, using an even larger amp than listed may
allow through some additional output on momentary transients.
NOTE: DCI-N model amplifiers contain networking capability. DCI-DA models include
Dante input for applications that require Dante or AES67 networked audio.
DRIVING CABINETS INDIVIDUALLY
The user may wish to drive the cabinets individually if they need the ability to gain shade the
array to the resolution as indicated by the EASE (or other modeling system) model or the VLA-
Compact Line Array Calculator. Driving cabinets individually may also be useful in order to utilize
the smaller amplifier sizes, if desired.

19
JBL VLA-C SERIES | USER’S GUIDE
PASSIVE VERSUS ACTIVE SETTING ON LOUDSPEAKERS
Note that the VLA-C models ship in passive mode. For diagrams showing how to wire the
speaker systems in either full-range passive mode or bi-amp mode, see the WIRING section of
this guide.
USING AMPLIFIERS WITH EXTERNAL DANTE
If a different size amplifier is needed such that a Dante model is not offered, a BSS BLU-DA or any
of the BSS Dante BLU units can be added into the system.

20
JBL VLA-C SERIES | USER’S GUIDE
9 - DSP PRESETS
FIR filters and limiters for the VLA-C products have been developed specifically for the Crown DCI-N
and DCI-DA amplifiers. The list of available presets are shown below and can be found on the VLA-C
home page at www.jblpro.com.
To load a preset:
1. Download the ‘VLA-C’ Speaker tuning file.
2. Move the downloaded file to: C:\ProgramData\Harman Professional\Audio Architect (this is the
default location that Audio Architect looks at for speaker tuning files)
3. In Audio Architect, Double click the Amplifier Panel.
4. On the Device panel, click File>Open>Speaker Tuning...
5. Click yes when prompted with the following message.
6. The preset will populate the limiter, crossover, and EQ settings.
Important: Note that since it is an FIR filter you will not see filters above 300Hz as they don’t
manifest themselves the same way an IIR filter would in that setting. However, they will be
engaged. In addition, you will have plenty of filters and delays to make suitable on-site adjustments.
