JBL 1500 ARRAY BG User manual

Project Array™
1500 Array
Subwoofer
Service Manual
230 Volt
JBL Consumer Products
250 Crossways Park Dr.
Woodbury, New York 11797 Rev0 4/2006

- CONTENTS -
BASIC SPECIFICATIONS …………….……..…………..1
PACKING……..……......................................................2
DETAILED SPECIFICATIONS ……….……..…………..3
CONNECTIONS………………………...……..…...…..…5
OPERATION ……..………………….……...…….….…...6
BASIC TROUBLESHOOTING……………………………7
EXPLODED VIEW/PARTS LIST…….….….…………....8
TEST SET-UP AND PROCEDURE….………………….9
BLOCK DIAGRAM….…………………………………….10
ELECTRICAL PARTS LIST……………………………..11
P.C.B. DRAWINGS….……………...........................….16
IC/TRANSISTOR PINOUTS..……..….…….….….….….22
SCHEMATICS…………………….………………………23
1500 ARRAY SPECIFICATIONS
General
Output 1000W
Low-Frequency Transducer W1500H 15" Pulp-cone driver
Frequency Response (-3dB) 25Hz – 400Hz, variable
Crossover Frequencies 40Hz-140Hz HP
Port 4" Flared
Dimensions (H x W x D) 23" x 19-1/2" x 19" (584mm x 495mm x 483mm)
21" (533mm) Deep with grille
Weight 125 lb (57kg)
JBL continually strives to update and improve existing products, as well as create new ones. The
specifications and details in this and related JBL publications are therefore subject to change without
notice.
1
1500 Array Subwoofer

Ref# Part Number Description Qty
1 361041-002 1500 Array Owner’s Manual 1
2 331994-001 JBL Warranty Card 1
3 361408-001 1500 Array Outer Carton 1
4 354374-001 Packing Foam (Top) 1
5 354374-001 Packing Foam (Bottom) 1
6 340805-006 (Plate) Feet 4
2
1500 Array Subwoofer

1500 Array Powered Sub/ Plate Amp
LINE VOLTAGE Yes/No Hi/Lo Line Nom. Unit Notes
US 120VAC/60Hz YES 108-132 120 Vrms Normal Operation
EU 230VAC/50-60Hz YES 207-264 230 Vrms Normal operation, MOMS required
Asia 100VAC/50Hz YES 90-110 100 Vrms Normal operation, MOMS required
Parameter Specification Unit QA Test Limits Conditions Notes
Amp Section
Type (Class AB, D, other) D n/a n/a Bridge type amplifier, None of the speaker terminals
must be connected to system GND at any time.
Load Impedance (speaker) 8 Ohms n/a Nominal
Rated Output Power 650 Watts 593 1 input driven Test frequency 100 Hz
THD @ Rated Power 0.5 % 122K filter
THD @ 1 Watt 0.1 % 0.2 22K filter
Dynamic Power 700 Watts 690
Power is the average measurement
of the first four consecutive peaks of
the burst signal 3/20 Cycles @ 50 Hz, burst test into 8 Ohms, input driven with 800mV RMS
DC Offset 20 mV-DC 100 @ Speaker Outputs
Damping factor >20 DF 15 Measured at amplifier board
Measured at the speaker cable. 500 Watts,
measured at speaker output terminals located at the
amp board.
Input Sensitivity
Input Frequency 100 Hz 100 Nominal Freq.
Line level input 11.69 mVrms ±2dB To 1 Watt Single input driven, Ap Zo=600 Ohms, LFE mode, Volume ctrl. at max.
Signal to Noise
SNR-A-Weighted 100 dBA 95 Relative to rated power (650 Watts) A-Weighting filter
SNR-unweighted 95 dBr 90 Relative to rated power (650 Watts) 22K filter
SNR rel. 1W-unweighted 70 dBr 65 Relative to 1W Output 22K filter
Residual Noise Floor 0.5 mVrms 1Volume @max, LFE Mode, using
RMS reading DMM/VOM (or A/P)
Residual Noise Floor 0.5 mVrms(max) 1
Volume @max, LFE Mode, w/ A/P
Swept Bandpass Measurement
(Line freq.+ harmonics)
Input Impedance Line Input 10K ohms n/a Nominal
Filters
LP 4th order variable 40-140 Hz ± 10
Subsonic filter (HPF) 3rd Ord
e
Fixed Hz ± 10
LFE Mode Fixed Hz ± 10 LP Mode switch at LFE
Features
Line Level output YES functional RCA Line buffered line level output
Volume pot Taper (lin/log) LOG -- functional A Taper
Variable crossover 40-140 Hz YES functional 4th Order LP Filter, 2nd order fix and 2nd order
variable.
LP Selector switch LFE-
Normal YES functional Pass through from the speaker input section
Phase switch YES -- functional Disables LP filter, intended for LFE
Auto- On-Off selector YES functional Switch located at the back panel
Input Configuration
Single Line input YES -- functional Single RCA jack (BLK Color)
Line output configuration
Single Line level output YES Functional Gain=0dB respect to line level input,
Zo=600 Ohms Single RCA jack (BLK Color)
Signal Sensing (ATO)
Auto-Turn-On (yes/no) YES functional Auto - on selection switch in Auto
ATO Input test frequency 50 Hz functional "
ATO Level, Line Input 2.5 mV functional "
ATO Turn-on time 2 seconds functional Amp connected and AC on, then
input signal applied
Auto Mute/ Turn-OFF Time 15 minutes 17 (T) Time before muting, after input
signal is removed Auto turn of time (T) must be 10 > T < 17 Minutes
Power on Delay time
ATO mode 4 sec. 5After applying the minimum ATO voltage (2mVRMS)
ON mode 2 sec. 2After turning the stand-by knob to ON position
3
1500 Array Subwoofer

Parameter Specification Unit QA Test Limits Conditions Notes
Transients/Pops
ATO Transient 5 mV-peak n/a @ Speaker Output
Turn-on Transient 50 mV-peak 1V-pk-pk @ Speaker Output AC Line cycled from OFF to ON
Turn-off Transient 50 mV-peak 1V-pk-pk @ Speaker Output AC Line cycled from ON to OFF
Efficiency
Efficiency 73 % 70 500W of output power into rated
impedance Nominal Line voltage
Stand-by Input Power 2 3@ nominal line voltage, Amp in
OFF state, RED LED activated Maximum allowable input power LED in RED, Class D inactive
Stand-by Input Power 10 Watts 8@ nom. line voltage, Amp in On
state, Green LED activated
Maximum allowable input power under nominal
Input voltage and frequency, in stand-by mode
(HOT or COLD operation, LED GREEN). Class D
active but no stimulus signal applied.
Power Cons. @ 500W 678 Watts 714 @ nom. line voltage 500 Watts into rated impedance 8 Ohms
Protection
Thermal Protection YES functional @1/8 max unclipped Power
Temperature
rise
in
accessible
metal
parts
should
not exceed 35K rise for domestic version or 30K
rise for European versions (refer to requirements
sheet). Unit is protected for over-temperature
conditions
DC Offset Protection YES -DC present at Speaker Out leads Relay opens during a DC output condition
Line Fuse Rating
Japan 100V & USA- Versions 6.3 Amps Type-T or Slo Blo-250 V UL, PSE Approved
Europe 220-240V 3.15 Amps Type-T, Low breaking capacity-250
V
SEMKO Approved
4
1500 Array Subwoofer

SPEAKER CONNECTIONS
S
Su ub bw wo oo of fe er rC Co on nt tr ro ol ls sa an nd dC Co on nn ne ec ct ti io on ns s( (1 15 50 00 0A Ar rr ra ay yO On nl ly y) )
0
1
2
34
567
8
The 1500 Array includes
a line output. This output
allows you to “daisy chain”
one 1500 Array to multiple
1500 Array subwoofers.
Simply connect the first
subwoofer as described
above and then run a
subwoofer cable from the
line output(s) to the line
input on the next sub.
¡Line-Level Input
™Line-Level Output
£Power Indicator
¢Subwoofer Level (Volume) Control
∞Crossover Adjustment
§Phase Switch
¶LP/LFE Selector
•On/Off Auto Switch
ªPower Switch
Connection:
If you have a Dolby®Digital or DTS®
receiver/processor with a low-frequency-
effects (LFE) output, set LFE/LP switch to
LFE. If you prefer to use the crossover
built into the 1500 Array, set the LFE/LP
Switch ¶to LP.
SUBWOOFER OR
LFE OUTPUT
SUBWOOFER OR
LFE OUTPUT
Project Array OM 1/10/06 12:21 PM Page 8
5
1500 Array Subwoofer

Power On
Plug your subwoofer’s AC cord
into a wall outlet. Do not use
the outlets on the back of the
receiver.
Initially set the Subwoofer
Level (Volume) Control ¢to
the “min” position.
Turn on your sub by pressing
the Power Switch ªon the
rear panel.
Auto On/Standby
With the Power Switch ª
in the “on” position, the Power
Indicator LED £will remain
backlit in red or green to
indicate the On/Standby
mode of the subwoofer.
RED = STANDBY (No signal
detected, Amp Off)
GREEN = ON (Signal detected,
Amp On)
The subwoofer will auto-
matically enter the Standby
mode after approximately 10
minutes when no signal is
detected from your system.
The subwoofer will then power
ON instantly when a signal is
detected. During periods of
normal use, the Power Switch
ªcan be left on. You may turn
off the Power Switch ªfor
extended periods of non-
operation, e.g., when you are
away on vacation.
If the Auto Switch •is in the
“on” position, the subwoofer
will remain on.
Adjust Level
Turn on your entire audio
system and start a CD or movie
soundtrack at a moderate
level. Turn up the Subwoofer
Level (Volume) Control ¢
about halfway. If no sound
emanates from the subwoofer,
check the AC-line cord and
input cables. Are the con-
nectors on the cables making
proper contact? Is the AC
plug connected to a “live”
receptacle? Has the Power
Switch ªbeen pressed to
the “on” position? Once you
have confirmed that the sub-
woofer is active, proceed by
playing a CD or movie. Use a
selection that has ample bass
information.
Set the overall volume control
of the preamplifier or stereo
to a comfortable level. Adjust
the Subwoofer Level (Volume)
Control ¢until you obtain a
pleasing blend of bass. Bass
response should not over-
power the room but rather
should be adjusted so there is
a harmonious blend across the
entire musical range. Many
users have a tendency to set
the subwoofer volume too
loud, adhering to the belief
that a subwoofer is there to
produce lots of bass. This is
not entirely true. A subwoofer
is there to enhance bass,
extending the response of
the entire system so the bass
can be felt as well as heard.
However, overall balance
must be maintained or the
music will not sound natural.
An experienced listener will
set the volume of the sub-
woofer so its impact on bass
response is always there but
never obtrusive.
Crossover Adjustments
NOTE: This control will have
no effect if the LP/LFE Selector
Switch ¶is set to “LFE.” If
you have a Dolby Digital or
DTS processor/receiver, the
Crossover Frequency is set
by the processor/receiver.
Consult your owner’s manual
to learn how to view or change
this setting.
The Crossover Adjustment
Control ∞determines the
highest frequency at which the
subwoofer reproduces sounds.
If your main speakers can
comfortably reproduce some
low-frequency sounds, set this
control to a lower frequency
setting, between 50Hz and
100Hz. This will concentrate
the subwoofer’s efforts on
the ultradeep bass sounds
required by today’s films and
music. If you are using smaller
bookshelf speakers that do
not extend to the lower bass
frequencies, set the Crossover
Adjustment Control to a higher
setting, between 120Hz and
150Hz.
Phase Control
The Phase Switch §deter-
mines whether the subwoofer
speaker’s pistonlike action
moves in and out with the main
speakers (0˚) or opposite the
main speakers (180˚). Proper
phase adjustment depends
on several variables, such as
subwoofer placement and
listener position. Adjust the
Phase Switch to maximize
bass output at the listening
position.
1500 ARRAY OPERATION
Project Array OM 1/10/06 12:21 PM Page 9
6
1500 Array Subwoofer

BASIC TROUBLESHOOTING
If there is low (or no) bass output
•Make sure the connections to the left and right “Speaker
Inputs” have the correct polarity (+ and –).
•Make sure the subwoofer is plugged into an active electrical
outlet.
•Make sure the Power Switch is on.
•In Dolby Digital or DTS modes, make sure your
receiver/processor is configured so that the subwoofer
and LFE output are enabled.
•Adjust the Subwoofer Level Control
7
1500 Array Subwoofer

1500 ARRAY MECHANICAL PARTS LIST
Item # Description Part Number Qty
1 CABINET ASSEMBLY-1500 ARRAY Not for Sale 1
2 15" WOOFER-W1500H 353721-001 1
3 AMPLIFIER ASSEMBLY, 230V-1500 ARRAY 361406-003 1
4 POWER TRANSFORMER-1500 ARRAY BG 361407-001 1
5 PORT TUBE -1500 ARRAY 360806-001 1
6 CARBOARD TUBE,4 1/4x4x1/8x6-4338 47909-68 1
7 FOOT,NUT,INSERT,BLK 340805-004 4
8 FOOT,SPIKE,BLK 340805-005 4
9 GRILLE,FRONT, 1500 ARRAY 354507-001 1
10 WOOFER SCREW,10-32 X 1,FIL,PH,BLK ZINC,LCS 804-01110-16 8
11 AMPLIFIER SCREW,8 X 1,PAN,PH,PB,BLK ZINC,LCS 883-41110-16 10
12 GASKET,DRVR,15" 338073-001 1
13 LOGO-JBL 360813-001 1
1500 ARRAY SUB EXPLODED VIEW
X RAY VIEW FOR
ILLUSTRATIVE PURPOSES ONLY
DAMPING MATERIAL NOT SHOWN
8
1500 Array Subwoofer

1500 Array TEST PROCEDURE
Equipment needed:
•Function/signal generator/sweep generator
•Multimeter
•RCA cable
General Unit Function (UUT = Unit Under Test)
Switch/Controls:
GAIN control full Counterclockwise (Min)
CROSSOVER (Hz) Full Clockwise (140)
PHASE switch - either position
LFE/LP – LP position
1) From the signal generator, connect one line level (RCA) cable to the Line In jack on the UUT.
2) Turn on generator; adjust to 200mV, 50 Hz.
3) Plug AC power cord in UUT, turn power switch ON.
4) LED should be ON (faceplate). Turn up LEVEL control to full Clockwise (Max).
5) LED should be Green; Bass response should be heard and felt vigorously from woofer and port tube.
6) Turn LEVEL control full Counterclockwise (Min). Turn power switch OFF.
Sweep Function
1) Follow steps 1-5 above, using a sweep generator as a signal source – adjust the generator to 75mV, 50 Hz.
2) Sweep generator from 20Hz to 300Hz. Listen for any rattles, clicks, buzzes or any other noises. If any unusual
noises are heard, test woofer according to the instructions below.
Driver Function
1) Remove woofer from the enclosure.
2) Check DC resistance of woofer; it should be 5.9 Ω±10%,
3) Connect a pair of speaker cables to woofer terminals. Cables should be connected to an integrated amplifier
fed by a signal generator. Turn on generator and adjust so that speaker level output is 6.0V.
4) Sweep generator from 20Hz to 1kHz. Listen to driver for any rubbing, buzzing, or other unusual noises.
9
1500 Array Subwoofer

1500 ARRAY BLOCK DIAGRAM
10
1500 Array Subwoofer

Part number Description
361406-003 Power amplifier module
015-1616600-100ZRI Input and preamp PCB
015-1616600-100ZRP Power PCB
015-1616600-100ZRF Fuse PCB
005-005756-003ZR GR Outer Carton K=K 570x555x475mm
005-011813-001ZR GR Inner carton K=K 180x130x440mm
005-031116-000ZS GS EPE 110x160mm t=10mm
005-055554-000ZR GR Carbon K=K 550x535mm
008-001002-090ZR GR Label (T3.15A) 100x22mm
008-061215-000ZR GR GASKET C4305 12x15 t=5mm CR
008-061602-022ZR GR GASKET CR4305 Gasket
008-063702-002ZR GR GASKET CR4305 Gasket
008-065757-002ZR GR GASKET CR4305 Gasket
020-220496-100ZS GS Resistor 2K2 1/2W J
021-100402-021ZS GS Resistor 1K 2W J
021-432598-100ZS GS Resistor 43K2 1/8W F
021-475498-100ZR GRResistor 4K75 1/8W F
022-005105-020ZS GS Resistor PN:SQM 0R05 5W J 25x13
024-000097-120ZS GS SMD Resistor PN:1206J000 0R 1/4W J 1206
024-000098-120ZS GS SMD Resistor 0R 1/8W J 0805
024-100298-120ZS GS SMD Resistor 10R 1/8W J 0805
024-100497-100ZS GS Resistor PN:1206F102 1K 1/4W F 1206
024-100498-120ZS GS SMD Resistor 1K 1/8W J 0805
024-100498-120ZS GS Resistor PN:1206F103 10K 1/4W F 1206
024-100598-101ZS GS SMD Resistor 10K 1/8W J 0805
024-100598-120ZS GS SMD Resistor 10K 1/8W J 0805
024-100598-120ZS GS SMD Resistor 10K 1/4W J 1206
024-100598-121ZS GS SMD Resistor 100K 1/8W J 0805
024-100698-120ZS GS SMD Resistor 11K 1/8W J 0805
024-110598-120ZS GS SMD Resistor 13K 1/8W J 0805
024-130598-120ZS GS SMD Resistor 13K 1/8W J 0805
024-150498-121ZS GS SMD Resistor 1K5 1/4W J 1206
024-150598-100ZS GS SMD Resistor 15K 1/8W F 0805
024-200597-100ZS GS Resistor PN:1206F203 20K 1/4W F 1206
024-200598-120ZS GS SMD Resistor 20K 1/8W J 0805
024-220298-121ZS GS Resistor 22R 1/4W J 1206
024-220397-120ZS GS Resistor 220R 1/4W J 1206
024-220398-120ZS GS SMD Resistor 220R 1/8W J 0805
024-220498-120ZS GS SMD Resistor 2K2 1/4W J 1206
024-220498-121ZS GS SMD Resistor 2K2 1/8W J 0805
024-220598-120ZS GS SMD Resistor 22K 1/8W J 0805
024-220798-120ZS GS SMD Resistor 2M2 1/8W J 0805
024-237598-120ZS GS SMD Resistor 23K7 1/8W F 0805
024-270498-120ZS GS SMD Resistor 2K7 1/8W J 0805
024-270498-121ZS GS SMD Resistor 2K7 1/4W J 1206
024-330397-120ZR GR SMD Resistor 330R 1/4W J 1206
024-330498-121ZS GS Resistor 3K3 1/4W J 1206
JBL ARRAY 1500 SUB 230V ELECTRICAL PARTS LIS
T

JBL ARRAY 1500 SUB 230V ELECTRICAL PARTS LIS
T
024-330598-121ZS GS SMD Resistor 33K 1/4W J 1206
024-332498-100ZS GS SMD Resistor 3K32 1/8W F 0805
024-332598-101ZS GS SMD Resistor 33K2 1/8W F 0805
024-365697-100ZR GR SMD Resistor 365K 1/4W F 1206
024-390498-120ZS GS SMD Resistor 3K9 1/8W J 0805
024-390598-120ZS GS SMD Resistor 39K 1/8W J 0805
024-392498-100ZR GR Resistor 3K92 1/8W F 0805
024-402597-100ZS GS SMD Resistor 40K2 1/4W F 1206
024-432598-100ZR GR SMD Resistor 43K2 1/8W F 0805
024-470398-120ZS GS SMD Resistor 470R 1/8W J 0805
024-470398-121ZS GS Resistor 470R 1/4W J 1206
024-470498-120ZS GS SMD Resistor 4K7 1/8W J 0805
024-470598-120ZS GS SMD Resistor 47K 1/8W J 0805
024-470598-121ZS GS SMD Resistor 47K 1/4W J 1206
024-470698-120ZS GS SMD Resistor 470K 1/8W J 0805
024-470698-121ZS GS SMD Resistor 470K 1/4W J 1206
024-470797-100ZS GS SMD Resistor 4M7 1/4W F 1206
024-536597-100ZR GR SMD Resistor 53K6 1/4W F 1206
024-560298-120ZS GS SMD Resistor 56R 1/8W J 0805
024-560498-120ZS GS SMD Resistor 5K6 1/8W J 0805
024-560598-120ZS GS SMD Resistor 56K 1/8W J 0805
024-560598-121ZS GS SMD Resistor 56K 1/4W J 1206
024-620398-121ZS GS SMD Resistor 620R 1/4W J 1206
024-680498-120ZS GS SMD Resistor 6K8 1/8W J 0805
024-680498-121ZS GS SMD Resistor 6K8 1/4W J 1206
024-680598-121ZS GS SMD Resistor 68K 1/4W J 1206
024-820598-121ZS GS SMD Resistor 82K 1/4W J 1206
024-910498-120ZS GS SMD Resistor 9K1 1/8W J 0805
025-006000-000ZR GR Resistor P/N:CL-60
025-010300-000ZR GR Resistor PN:NTSE103KZ072 K L:50mm
025-210100-000ZS GS Resistor PN:PTMS2101RP516Y
026-500495-005ZS GS VR 5K PN:RD163111R22B-5K15A
026-500595-267ZS GS VR 50KBx4 PN:RD1631411001D-50KBx4
028-100301-020ZR GR FUSIBLE RES 100R 1W J
030-180394-300ZR GR Capacitor 180pF/500V K Y5P P:5
031-100144-103ZS GS Capacitor 0u001/50V K 0805 X7R
031-100244-100ZS GS Capacitor 0u01/50V K 1206 X7R
031-100244-101ZS GS Capacitor 100pF/50V J 0805 NPO
031-100343-100ZS GS Capacitor 0u1/50V K 0805 X7R
031-100344-100ZS GS Capacitor 0u1/50V K 1206 X7R
031-100344-102AZS GS Capacitor 0u1/50V K 1206 X7R
031-100344-104AZS GS SMD Capacitor 100pF/50V K NPO 1206
031-100364-100ZS GS Capacitor 0u1/100V K 1206 X7R
031-100384-100RZS GS Capacitor 0u1/250V K 1206 X7R
031-180344-100ZS GS SMD Capacitor 0u18/50V K 0805 X7R
031-220344-106AZS GS SMD Capacitor 220pF/50V K X7R 1206
031-220344-300ZS GS Capacitor 220pF/50V K 0805
031-220364-100ZS GS Capacitor 0u22/100V K 1206 X7R
031-270244-100ZR GR Capacitor 0u027/50V K 0805 X7R

JBL ARRAY 1500 SUB 230V ELECTRICAL PARTS LIS
T
031-270444-101 SMD Capacitor 2700pF/50V K 1206 X7R
031-470144-101AZS GS SMD Capacitor 0u0047/50V K 0805 X7R
031-470244-102ZS GS Capacitor 0u047/50V K 0805 X7R
031-470344-100ZS GS Capacitor 470pF/50V K 0805 X7R
031-560243-100ZS GS Capacitor 56pF/50V J 0805
031-560343-102ZS GS Capacitor 560pF/50V J 0805
031-680144-100ZS GS Capacitor 0u0068/50V K 0805 X7R
032-100484-200ZS GS Capacitor 1uF/250V K
033-330494-270ZS GS Capacitor 3u3/63V K10 (R) 8x13
033-330515-300ZS GS Capacitor 33uF/16V M (R)0511
033-680464-270ZS GS Capacitor 6u8/100V K10 (R)1020
034-100515-304ZS GS Capacitor 10uF/16V M (R)0511
034-100614-300ZS GS Capacitor 100uF/16V M (R)0611
034-100615-301ZS GS Capacitor 100uF/16V M (R)0611
034-100625-300ZS GS Capacitor 100uF/25V M (R)6.3x11
034-100715-300ZS GS Capacitor 1000uF/16V M (R)1017
034-220516-301ZS GS Capacitor 22uF/16V M (R)0511
034-220525-300ZR GR Capacitor 22uF/25V M (R)5x11
034-220615-300ZS GS Capacitor 220uF/16V M (R)0611
034-220625-300ZS GS Capacitor 220uF/25V M (R)0812
034-330615-301ZS GS Capacitor 330uF/16V M (R)0812
034-330625-300ZS GS Capacitor 330uF/25V M (R)1013
034-470415-300ZS GS Capacitor 4u7/50V M (R)0511
034-470515-200ZR GR Capacitor 47uF/16V M (R)0511
034-680794-200ZR GR Capacitor (LP) 85 6800uF/80V M (R)3050
034-820794-200ZR GR Capacitor (LP) 85 8200uF/80V M (R)3545
035-100343-300ZS GS PE Capacitor 0uF1/50V J
035-100464-300ZR GR Capacitor 1u/100V K
035-220243-100ZR GR Capacitor 0u022/63V J
035-330293-300ZR GR Capacitor PN:ESK063S33JT 0u033/63V J
035-470353-302ZR GR Capacitor 0u47/63V J P/N:R82DC347DQJ
035-680253-300ZR GR Capacitor FE-M PN:ESK063S68JT 0u068/63V J
039-220384-100ZR GR X2 Safety capacitor 0u22/250V PN:HQX0.22K275VX2
042-010115-000ZR GR X'fmr PN:YT-13167
043-110300-000ZR GR COIL PN:YT-13141 110uHx2±10%
043-155300-000ZR GR COIL PN:YT-13192 155uH±10%
043-300101-000ZR GR INDUCTOR PN:YT-10033 30uH
043-324300-000ZR GR INDUCTOR 324uH YT-10778
043-560200-000ZR GR INDUCTOR 56uH YT-10779
044-100100-000ZS GS SMD FERRITE BEAD PN:321611 600R/100MHz
044-100103-000ZS GS SMD FERRITE BEAD PN:321611 800R/100MHz
050-013000-100 DIODE TVZ:DIP PN:P6KE130A
050-505200-001ZS GS LED PN:LT-2402-21
051-000600-100ZR GR Transistor PN:MPSW06RLRA TO-92
051-003100-000ZS GS Transistor NPN PN:TIP 31C TO-220
051-005600-100ZR GR Transistor PNP PN:MPSW56RLRAR TO-92
051-011100-100ZR GR JFET N-Channel PN:J111 TO-92
051-222200-100ZR GR Transistor NPN (ON SEM) PN:MPS2222ARLRAR TO-92
051-290700-100ZR GR Transistor PNP (ON) PN:MPS2907A RLRAR TO-92

JBL ARRAY 1500 SUB 230V ELECTRICAL PARTS LIS
T
051-359400-000ZR GR MOSFET N-CHANNEL PN:2SK3594-01SC
051-540101-000ZR GR Transistor PNP PN:2N5401
051-555100-000ZR GR Transistor NPN PN:2N5551 TO-92
052-150400-000ZR GR Bridge Regulator PN:GBJ1504
053-010200-000 IC:DIP PN:TOP102YAI (TOP SWITCH)
053-211100-000ZR GR IC:DIP,DRIVER PN:IR2111 8PIN
054-000100-100ZS GS SMD DIODE: PN:ES1D 200V 1A
054-005501-100ZR GR SMD ZENER DIODE PN:BZV55C3V6
054-007200-100LZS GS SMD IC PN:M072M-TE1-#ZZZB
054-008406-000ZR GR SMD ZENZER DIODE:(PHILIPS) PN:BZX84C10-7-F SOT-23
054-008407-000ZR GR SMD ZENZER DIODE:(PHILIPS) PN:BZX84C15-7-F SOT-23
054-008408-000ZR GR SMD ZENZER DIODE:(PHILIPS) PN:BZX84C5V6-7-F SOT-23
054-008409-000ZR GR SMD ZENZER DIODE:(PHILIPS) PN:BZX84C3V0-7-F SOT-23
054-011400-100ZR GR Transistor PN:DTC114TKA SMT3
054-033904-100ZR GR Transistor PN:MMBT3904LT1G SOT23
054-033906-100ZR GR Transistor (ON) PN:MMBT3906LT1G SOT23
054-290701-100ZR GR Transistor (ON) PN:MMBT2907ALT1 SOT-23
054-390402-100ZR GR Transistor (SC00044) PN:MMBT3904TR
054-414803-100ZS GS SMD DIODE: PN:LL4148 MINI-MELF
054-523701-100ZR GR SMD ZENZER DIODE: (GMT) PN:GMBZ5237B 8V2 SOT23
054-540100-100ZR GR Transistor PNP (ON SEN) PN:MMBT5401 LT1 SOT-23
054-555100-100ZR GR Transistor (NPN) PN:MMBT5551 LT1R
061-001052-000ZS GS Knob PN:49001-W D=15.1 H=14.5
061-100016-000ZR GR Partition Post PN:BCMS-8 L=8mm (UL)
061-700044-000ZR GR Mycar 13x18mm TO-220
061-700090-900ZR GR Ceramic washer 16x21mm t=2mm white
063-010010-000ZR GR Bucket P/N:TRK-2
063-060606-000ZR GR X'fmr PLATE SPCC 56.9x57.2 t=2.0mm
063-401604-000ZR GR Plate SPCC 402x156.8 t=2.3mm
065-040102-090ZR GR UL PVC Sleeve 300V 1mm blk
066-120300-900ZR GR CABLE TIE CV-120S
070-030530-312ZR GR Screw FMS:M3x12mm
070-040510-216ZR GR Screw M3x16mm
070-040530-410ZR GR Screw PMS:M4x10mm
070-040565-508ZR GR Screw #6-32x5/16" (8mm)
070-040866-504ZR GR Screw #6-32x1/4"
070-440510-112ZR GR Screw PN:PTP PTS-4 3x12mm
070-840515-708AZR GR Screw PN:PTP PTS-4:3x8mm
071-060211-200ZR GR Washer M3 (Ni)
071-100606-060ZR GR Washer PN:WS3-2 OD=6 ID=3.t=2mm
071-140061-900ZR GR Washer 6# BLK
072-010360-000ZR GR RCA JACK PN:B217CK
072-040007-000ZS GS Terminal SWA101 PN:JS-1001-07 7P
072-040008-110ZS GS Terminal PN:JS-1001-08 8P P:2.5
072-040039-000ZR GR Terminal (t=0.8m/m) T205MA
072-040064-000ZR GR Terminal (t=0.8m/m) T250MA
072-040229-000ZR GR HEADER Right Angle PN:211-107-000-400 7PIN
072-040230-000ZR GR HEADER Right Angle PN:211-111-000-400 11PIN
073-014103-500ZR GR Bracket 6.64"x3.5"x3.2" SPCC

JBL ARRAY 1500 SUB 230V ELECTRICAL PARTS LIS
T
073-032141-600ZR GR Heatsink 82.8x120.7x19.1mm
073-050001-000ZS GS FUSE CLIP P/N:CT-FH1206
073-111003-000ZR GR Shorting bar 54.9x13.6x1mm
073-111004-000ZR GR Shorting bar 29.5x12.4x0.8m/m
074-020005-000ZR GR Jack P/N 3516-T3C02
074-020018-000ZR GR ROCKER SW (POWER) PN:RF1003-BB4-0
074-030002-000ZR GR TOGGLE SW PN:L101-T2B4QE
074-030018-000ZR GR TOGGLE SW PN:L103-T2-B4
080-060351-009ZS GS Tinned plated copper wire φ0.6x63m/m TAPING
082-021479-000ZR GR Wire set #14 UL1015 L=31"
082-061630-000ZR GR Wire set #16 UL1015 L=300mm 6P PN:1102038-555
082-072620-001ZR GR Wire set #26 UL1007 L=200mm
082-082620-002ZR GR Wire set #26 UL1007 L=200mm
181-911422-002ZR GR Wire set #14AWG UL1015 red 200mm
181-911466-001ZR GR Wire set #14AWG UL1015 blue 200mm
181-911800-338ZR GR Wire set #18AWG UL1007 blk L=110mm
181-921400-003ZR GR wire set #14AWG UL1015 blk 200mm
181-981811-000ZR GR Wire set #18AWG UL1617
181-981866-000ZR GR Wire set #18AWG UL1617 blue
*015-110404-100ZR GR Double-sided PCB FR-4
*015-170803-100ZR GR Double-sided PCB FR-4
*031-100144-106ZS GS Capacitor 0u01/50V K 0805 X7R
*061-700119-000ZR GR Isolation sheet 114.3x84mm t=0.254mm FR700
*061-701003-000ZR GR Isolation sheet 170x85mm t=0.432mm FR700
086-020036-000ZR GR European Power Cable H05VV-F 2x1 L=3660mm
091-000424-000ZR GR FUSE PN:VBS UTE3.15A 250VAC-P

16
1500 Array Subwoofer

17
1500 Array Subwoofer

18
1500 Array Subwoofer

19
1500 Array Subwoofer
