jcb JCB-SL-TUFFDUAL Instruction Manual

JCB-SL-TUFFDUAL
2500 LUMEN HYBRID WORKLIGHT
Tripod mountable stand
Brightness indicator
Power switch
Rotary dimmer
Battery indicator
Powerbank output
LED floodlight
Handle
Oil & chemical
resistant body

Rechargeable battery and mains powered site light
Chemical and oil resistant nylon casing
Stepless brightness control 250 - 2500 lumens
Fully adjustable tripod mountable stand
Battery status indicator showing percentage available
IP65 water and dustproof
IK07 drop tested
Mains 240V rechargeable with 5m lead 13amp BS plug which can also be used
for direct power
Optional 110V lead available
PRODUCT DESCRIPTION
SPECIFICATION
Charging: Mains/charging cable with 240V BS plug as standard
110V option available
Battery: 7.4V 5200mAh Li-ion
Charge Time: Up to 3h
Runtime: Up to 10 hrs
Brightness: 250 - 2500 lumen via stepless rotary dimmer
Colour Temperature: 6000K
Use original charging cable only
Recharge when battery status reads 25%
Fully charged when all segments of battery status light up
Do not leave the battery fully discharged
Recharge the work light at least once every 30 days
BATTERY TREATMENT / CHARGING
Press and hold the power switch for 2 seconds to turn the light on
The brightness and battery status light will illuminate
Rotate the rotary brightness control to change brightness levels
The digital display will show brightness as a percentage
Press and hold the power switch for 2 seconds to switch off the light
OPERATION

SAFETY NOTICE
Prior to use carry out the necessary risk assessment considering the people who
could be at risk, the level of risk and the precautions required to control the risk.
GENERAL
Ensure the worklight is correctly charged before initial use
DO NOT cover or block the lens during use
DO NOT shine the product directly into the eyes of people or animals
DO NOT allow children to use the worklight
DO NOT handle or move the worklight while it is being charged
DO NOT use the worklight if you suspect it is damaged
DO NOT place the product in or near naked flames
DO NOT open the equipment or touch any of the internal parts
DO NOT open the battery pack
DO ensure the worklight is unplugged and allow to cool before attempting
cleaning and maintenance
BATTERY
WARNING! To reduce the risk of fire or burns:
DO NOT attempt to open, disassemble, modify or service the battery
DO NOT expose to temperatures below 10ºC or above 40ºC
DO NOT crush, puncture, short external contacts or dispose of in fire or water
DO NOT dispose of with regular waste - dispose of the old batteries in
accordance with local authority battery regulations
DO NOT cover the battery while charging
Ensure the charger is switched off and disconnected from the worklight before
attempting to open the lamp unit
If the electrolyte in the cells comes into contact with the skin, wash thoroughly
with soap and water
If the electrolyte in the cells comes into contact with the eyes, rinse thoroughly
with cold water and seek immediate medical attention
The worklight should be turned off during charging to prolong battery life

SAFETY NOTICE
ELECTRICAL
WARNING! It is the user’s responsibility to read, understand and comply with
the following electrical instructions:
Ensure the risk of electrical shock is minimised by the installation of appropriate
safety devices
Inspect the charger cable and connection for wear and damage to ensure the
items are safe before connecting to the mains power supply
DO NOT use if worn or damaged
Check cables are always protected against short circuit and overload
DO NOT place the connector into any area of the worklight except the correct
outlet socket
DO NOT use the cable to charge or power any other electrical items
DO NOT wet the cable or use in wet or damp conditions (indoor use only)
MAINTENANCE & STORAGE
Keep the worklight clean from dirt and grease using a damp cloth
DO NOT submerge in water
DO NOT clean the worklight with solvents
DO check the product for damage before each use
If the product is not used for a long time , the battery will go into over discharge
protection. To re-activate the battery, charge three or four times for 30 seconds
until the indicator light comes on. Then fully charge the battery as normal.

GUARANTEE
This product is guaranteed against manufacturing defects for a period of 3 years
from the date of purchase.
Repair or replacement of products will be undertaken providing that:
• The product has been subject to fair wear and tear only
• The product has not been subject to accidental or cosmetic damage
• The product has not been misused and has been used only in accordance
with the instruction manual provided
• The product has not been subject to insufficient servicing and maintenance
• The product has not been subject to any abnormal environmental conditions
or inappropriate operating conditions
• Repairs have not been attempted by an unauthorised person and no
modifications have been made to the product
The guarantee excludes the following (where relevant):
• Components normally subject to wear and tear
• Batteries and chargers
Your statutory rights are not affected.
We reserve the right to alter specifications without prior notice
WE WILL NOT BE LIABLE FOR ANY INJURIES OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT

GENERAL WARNINGS & DISPOSAL
This product has been marked with a symbol relating to removing electric and
electronic waste. The product should not be discarded with household waste
but must be returned to a collection system which conforms to the European
Directive 2012/19/EU. It will then be recycled or dismantled in order to
reduce the impact on the environment. Electric and electronic equipment can
be hazardous for the environment and for human health since they contain
hazardous substances.
www.jcbworklights.com | [email protected]
JCB Lighting is used under licence by Property Perspective Ltd
