jcb JCB-IT30 User manual

EN
JCB-IT30 & JCB-IT50
LED RECHARGEABLE
INDUSTRIAL TASK
LIGHTS
LED WORKLIGHTS
INSTRUCTION MANUAL

2JCB-IT30, JCB-IT50
Instruction Manual
INTRODUCTION
The LED Rechargeable Industrial Task Lights are available in 30W & 50W versions offering
up to 4000lm light output. The range is available with either an 11.1V or 14.8V battery,
delivering runtime of up to eight hours from a 4-6 hour charge time. The product is
supplied with a sturdy mounting bracket and has a 100% or 50% mode for brightness.
JCB-IT30 JCB-IT50

3
JCB-IT30, JCB-IT50
Instruction Manual
SPECIFICATION
JCB-IT30 JCB-IT50
Power Output 30W 50W
Lumen Output 2200lm 4000lm
Beam Angle 60º
IP Rating IP65
Charge Time 4-5 hours / battery 5-6 hours / battery
Run Time 2-2.5 Hours High
7-8 Hours Low
2-2.5 Hours High
7-8 Hours Low
Input Voltage 100-240V, 50Hz
Material Aluminium
LED 30W COB 50W COB
CRI 70Ra
Power Factor 0.9
Colour Temp 6500K
IK Rating IK09
Life Expectancy 20,000 Hours
Working Temp. -10ºC - 40ºC
Battery 1 x 11.1V 4000mAh 1 x 14.8V 5200mAh
PCB Protection Charging / Discharging Protection
Dimensions W250 x H158 x D95mm W302 x H197 x D100mm
Charger 12.6V, 1A, AC/DC 16.8V, 1A, AC/DC
Weight 1.5Kg 2.5Kg
Features • Carry handle
• Mounting bracket
• Sturdy base

4JCB-IT30, JCB-IT50
Instruction Manual
JCB-IT30
AVERAGE ILLUMINATION
PLANAR INTENSITY DISTRIBUTION CURVE
Bare Lamp Photometric Data Page 1 Of
Goniophotometer Test Report
Measured Para U: 0.0V I: 0.0mA P: 0.00W PF: 0.000
Lamp Name:
Shape Size:
Sur(m^2):
Lamp Type:
Lamp Spec:
Manufactory:
Weight(kg):
Lamp ID:
Protect Angle(Deg):
ataD cirtemotohPataD ecruoS thgiL
Model
Nominal P(w)
Rated Flux(lm)
Illuminant QTY
Peak Value(cd)
Dw Flux Rate(%) Down(C180-C360)
Efficiency(lm/w)
UP(C0-C180)
UP(C180-C360)
0.0
0.0
Planar Intensity Distribution Curve
0
2093.0
5.340.001
0.0
0.0
0.0
Position 180.0,7.0
Up Flux Rate(%) 0.0
C0 Plane beam angle(50%):66.9(DEG) C90 Plane beam angle(50%):67.2(DEG)
C0 Pla n e b e a m angle(50%)
C90 Pl a n e b e a m angle(50%) 
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
2,100
1,680
1,260
840
420
0
C Angle Range:0 - 180(Deg)
09 :)geD(lavretni C1 :)geD(lavretni amaG
Temperature(Deg): 27
Tester:
Test System: ZWL Goniophotometer System V3.0
Humidity(%): 50
Date: 2019-7-25
Gama Angle Range:-90 - 90(Deg)
:krameR70.01 :)m(ecnatsiD
4

5
JCB-IT30, JCB-IT50
Instruction Manual
JCB-IT50
PLANAR INTENSITY DISTRIBUTION CURVE
AVERAGE ILLUMINATION
Bare Lamp Photometric Data Page 1 Of
Goniophotometer Test Report
Measured Para U: 0.0V I: 0.0mA P: 0.00W PF: 0.000
Lamp Name:
Shape Size:
Sur(m^2):
Lamp Type:
Lamp Spec:
Manufactory:
Weight(kg):
Lamp ID:
Protect Angle(Deg):
ataD cirtemotohPataD ecruoS thgiL
Model
Nominal P(w)
Rated Flux(lm)
Illuminant QTY
Peak Value(cd)
Dw Flux Rate(%)Down(C180-C360)
Efficiency(lm/w)
UP(C0-C180)
UP(C180-C360)
0.0
0.0
Planar Intensity Distribution Curve
0
3457.1
9.140.001
0.0
0.0
0.0
Position180.0,7.0
Up Flux Rate(%)0.0
C0 Plane beam angle(50%):66.9(DEG) C90 Plane beam angle(50%):70.3(DEG)
C0 Plane beam ang l e ( 5 0 % )
C 9 0 P la n e beam angle(50%) 
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
3,460
2,768
2,076
1,384
692
0
C Angle Range:0 - 180(Deg)
54 :)geD(lavretni C1 :)geD(lavretni amaG
Temperature(Deg): 27
Tester:
Test System: ZWL Goniophotometer System V3.0
Humidity(%): 50
Date: 2019-7-25
Gama Angle Range:-90 - 90(Deg)
:krameR070.01 :)m(ecnatsiD
4

6JCB-IT30, JCB-IT50
Instruction Manual
SAFETY NOTICE
GENERAL
Ensure the worklight is correctly charged before initial use
DO NOT cover or block the lens during use
DO NOT shine the product directly into the eyes of people or animals
DO NOT allow children to use the worklight
DO NOT handle or move the worklight while it is being charged
DO NOT use the worklight if you suspect the battery or casing is damaged
DO NOT place the product in or near naked flames
DO NOT open the equipment or touch any of the internal parts
DO NOT open the battery pack
Ensure the worklight is unplugged and allow to cool before attempting cleaning & maintenance
BATTERY
WARNING! To reduce the risk of fire or burns:
DO NOT attempt to open, disassemble, modify or service the battery
DO NOT expose to temperatures below 10ºC or above 40ºC
DO NOT crush, puncture, short external contacts or dispose of in fire or water
DO NOT dispose of with regular waste - dispose of the old batteries in accordance with
local authority battery regulations
DO NOT cover the battery while charging
Ensure the charger is switched off and disconnected from the worklight before attempting
to open the lamp unit
If the electrolyte in the cells comes into contact with the skin, wash thoroughly with soap
and water
If the electrolyte in the cells comes into contact with the eyes, rinse thoroughly with cold
water and seek immediate medical attention
The worklight should be turned off during charging to prolong battery life
Only use the mains charger supplied
Prior to use carry out the necessary risk assessment considering the people who could be
at risk, the level of risk and the precautions required to control the risk.

7
JCB-IT30, JCB-IT50
Instruction Manual
SAFETY NOTICE
ELECTRICAL
WARNING! It is the user’s responsibility to read, understand and comply with the
following electrical instructions:
Ensure the risk of electrical shock is minimised by the installation of appropriate safety
devices
Inspect the charger plug, cable and connection for wear and damage to ensure the items
are safe before connecting to the mains power supply
DO NOT use if worn or damaged
Check cables are always protected against short circuit and overload
IMPORTANT! Check that the voltage marked on the charger plug is the same as the
power supply to be used
Uncoil the cable between charger and the worklight
DO NOT use any other type of charger with this product
DO NOT place the connector into any area of the worklight except the correct inlet
socket
DO NOT try to take the charger plug apart
DO NOT use the charger plug to charger or power any other electrical items
DO NOT wet the charger or use in wet or damp conditions (indoor use only)

8JCB-IT30, JCB-IT50
Instruction Manual
OPERATION
CHARGING WARNING! Ensure that you read and fully understand the safety
instruction before use
Charge the battery before use
IMPORTANT! Ensure the worklight is turned OFF while charging. Failure to do so will
damage the charger plug/vehicle plug
Connect the charging plug into the charging socket located on the rear of worklight
Connect the 230V charger to a power supply
Disconnect the charger from the worklight when it is fully charged and replace the dust cap
DO NOT shine the product directly into the eyes of people or animals
MAINTENANCE & STORAGE
When not in use store the product in a safe, clean, dry environment out of the reach of
children
Keep the worklight clean from dirt and grease using a damp cloth
DO NOT submerge in water
DO NOT clean the worklight with solvents
Check the product for damage before each use

9
JCB-IT30, JCB-IT50
Instruction Manual
GUARANTEE
This product is guaranteed against manufacturing defects for a period of 3 years from the
date of purchase.
Repair or replacement of products will be undertaken providing that:
• The product has been subject to fair wear and tear only
• The product has not been subject to accidental or cosmetic damage
• The product has not been misused and has been used only in accordance with the
instruction manual provided
• The product has not been subject to insufficient servicing and maintenance
• The product has not been subject to any abnormal environmental conditions or
inappropriate operating conditions
• Repairs have not been attempted by an unauthorised person and no modifications
have been made to the product
The guarantee excludes the following (where relevant):
• Components normally subject to wear and tear
• Batteries and chargers
Your statutory rights are not affected.
We reserve the right to alter specifications without prior notice.
WE WILL NOT BE LIABLE FOR ANY INJURIES OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT

10 JCB-IT30, JCB-IT50
