JCHADWICK 5500L User manual

5500L
Lab Stand Kit
Including optional X-Y Stage
USER MANUAL
www.jchadwickco.com
[e-mail]
Toll Free [phone]
Fax [phone]
1005 S. Mountain Ave.
Monrovia CA 91016
Scan QR Code (with
smartphone camera)
to view a short training
video on our website.
JCC DOC# B5 March-2020

LAB STAND STORAGE
1. Adjust Focus Knobs so that the tops of the moving parts align with
the staonary parts of Focus Block to prevent damage.
2. Remove Focus Block from pole assembly.
3. Remove Safety Ring from pole assembly and return to Carrying Case.
4. Uninstall (unthread) the Upper Pole from the Lower Pole on the Base
Plate and return to Carrying Case.
5. Invert the Focus Block, install and clamp rmly to the Lower Pole on
the Base Plate and return to Carrying Case.
5500L Lab Stand Kit
Base Plate
w/ Pole Boom
Pole Top
Safety Ring
Focus Block
Correct Storage in Carrying Case

LAB STAND SETUP
for use Model 8400 Opcal Micrometer




















5500L Lab Stand
Correct Setup with
Opcal Micrometer
and Flashlight

X-Y STAGE INSTRUCTIONS
1. The X-Y Stage aaches to the Lab Stand with (4) ¼-20 x ½” Socket
Head Cap Screws on the underside of the Base Plate.
2. To remove the X-Y Stage: Loosen the Socket Head Cap Screws with
an Allen Wrench (not included) and remove the X-Y Stage from the
Base Plate.
3. To reaach the X-Y Stage: Orient the X-Y stage on Base Plate as
shown in lower image and secure using an Allen Wrench and (4)
Socket Head Cap Screws.
4. Install (2) Lead Screws into the threaded holes on the (2) Lead
Screw Translators. Turn both Lead Screws evenly unl the X-Y Stage is
approximately centered on the Base Plate, as shown in lower image.
5. During measurement, turn Lead Screws for ne adjustment of
target’s X-Y posion under Opcal Micrometer.
Note: Lead Screws are removed for storage in Carrying Case.
X-Y Stage with Lead Screws
Correct installaon on Model 5500 Lab Stand.

WARRANTY INFORMATION
John Chadwick Corporaon DBA J Chadwick Co warrants the 5500L
Lab Stand Kit, herein referred to as the product, against defects in
material or workmanship as follows;
LABOR
For a period of two (2) years from the purchase date, if the product is
determined to be defecve, J Chadwick Co will repair the product
at no charge to the buyer. If the product is determined by J Chadwick
Co to be defecve beyond repair, a replacement will be provided.
PARTS
For a period of two (2) years from the date of purchase, if the
product or its components are determined defecve, J Chadwick Co
will supply, at no charge to buyer, new or rebuilt parts.
DISCLAIMER
(1) This warranty does not cover cosmec damage or damage due to
acts of God, accident, misuse, abuse, or negligence to any part of the
product.
(2) This warranty does not cover damage due to improper operaon
or maintenance. Warranty is null and void if repair or modicaon
is aempted by anyone other than J Chadwick Co or its authorized
representaves.
Repair or replacement as provided under this warranty is the
exclusive remedy of the consumer. J Chadwick Co shall not be liable
for any incidental or consequenal damages for breach of any ex-
press or implied warranty on the product.
To obtain warranty service, buyer must contact J Chadwick Co prior to
return to obtain an authorizaon to return the product for service.
Buyer is responsible for providing proof of sale, which may be
required for warranty service. The product should be returned to J
Chadwick Co, in either its original packaging or packaging aording an
equal degree of protecon, with a copy of the bill of sale.
