Jedia JME-2A User manual

WWW.JEDIA.COM
4-MODULE EXTENSION
JME-4A
2-MODULE EXTENSION
JME-2A

AUTION AVIS
FEATURES
SAFETY INSTRUCTIONS
RONT PANEL CONTROLS
EAR PANEL CONTROLS
C
F
R
1
1
1
2
3
4~5
C
7
8
6
YSTEM CONNECTIONS(시스템 연결 방법)
S
PECIFICATIONS
S
LOCK DIAGRAM
B
ONNECTION OF THE ANTENNA AND GROUND CABLE

SAFETY INSTRUCTIONS
FEATURES
Read all safety instruction before operating the JMA-2A,4A.
1. Install equipment as follow conditions.
2-MODUAL EXTENSION (JME-2A)
The apparatus shall not be exposed to dripping or splashing and
no object filled with liquids, such as vases, shall be place on the
apparatus.
Install at the place, not bending curved.
Do not install this apparatus in a confined space such as a book
case or similar unit.
Locate this apparatus away from heat source, such as radiators
or other device that produce heat.
Do not drop objects or spill liquids into the inside of the apparatus.
2. Keep in mind the following when connecting the apparatus.
Connect the apparatus after reading of O/P manuals.
Connect each connection of amplifier perfectly, if not, it maybe
Caused hum, damage, electric shock in case of mis-connecting.
To prevent electric shock, do not open top cover.
Connect the power cord with safety after check of AC power.
This apparatus should be serviced by qualified service person.
안전사항
특징
제품을 운용하기전에 모든 안전사항을 읽어 보십시오.
1. 이런 장소에 설치하여 주십시오.
2-MODUAL EXTENSION (JME-2A)
진동이나 경사가 심하지 않고 바닥이 평평한 장소.
통풍이 잘되고 물기나 습기가 많지 않은 장소.
직사광선을 받지 않는 장소 또는 난방기구(발열체)에서 멀리 떨어진
장소.
인화성 물질(화학약품)이없는 장소.
2. 설치시 이런점을 주의하십시오.
사용설명서 시스템 연결방법을 완전히 읽으신 후에 연결해 주십시오.
각종 연결선을 완전하게 연결해 주십시오.
(주전원 코드를 뽑은 상태에서 연결.)
불완전한 연결은 잡음, 제품의 손상 또는 안전사고의 원인이 됩니다.
전기적 충격 또는 감전사고의 위험이 있으므로 뚜껑을 열지 말아주십
시오.
주교류 전원 플러그를 연결하기 전에 사용전압을 확인하신 후안전
하게 연결하십시오.
제품을 수리시는 규정된 부품과 자격이 있는 사람이 수리를 하여야 함.
1
다목적 모듈팩을 2개까지 사용할 수있습니다.
(JTP-10, JCP-10, JCR-10, JDM-10A, JCDP-10A, JCDR-10A)
4-MODUAL EXTENSION (JME-4A)
다목적 모듈팩을 4개까지 사용할 수있습니다.
(JTP-10, JCP-10, JCR-10, JDM-10A, JCDP-10A, JCDR-10A)
단, JCDP-10A 또는 JCDR-10A는2개까지만 사용할 수있습니다.
바란스 출력
각팩모듈의 바란스 XLR 출력 및2개또는 4개의 팩출력을 하나로 통
합한 바란스 XLR 출력으로 설계되어 운용에 편리하다.
비상용 밧데리 사용기능
AC전원 정전시 비상용 밧데리를 사용할 수있습니다.
Multiple expansion ports allow the use of up two additional.
JEDIA PACK-Series modules.
(JTP-10, JCP-10, JCR-10, JDM-10A, JCDP-10A, JCDR-10A)
BALANCED OUTPUT
Output connectors for 2-module or 4-module ex-cabinet have been
designed into each balanced XLR connector and it is convenient to
use two module packs with combined balanced XLR connector.
USE OF EMERGENCY BATTERY
You can operate this models by using emergency battery for
unexpected AC power failure. (Built in 24DC TERM)
4-MODUAL EXTENSION (JME-4A)
Multiple expansion ports allow the use of up two additional.
JEDIA PACK-Series modules.
(JTP-10, JCP-10, JCR-10, JDM-10A, JCDP-10A, JCDR-10A)
But, JCDP-10A or JCDR-10A can be added to two. (maximum)

1. BLANK PANEL1. BLANK PANEL
2
Remove panels to insert pack modules.
(JTP-10, JCP-10, JCR-10, JDM-10A, JCDP-10A, JCDR-10A)
But, JCDP-10A or JCDR-10A can be added to two. (maximum)
JME-4A EXTENSION
2. POWER
Push power switch to supply power to the pack module.
팩모듈을 장착시 이판넬을 제거 하십시오.
(JTP-10, JCP-10, JCR-10, JDM-10A, JCDP-10A, JCDR-10A)
단, JCDP-10A 또는 JCDR-10A는2개까지만 사용할 수있습니다
2. POWER
전원 스위치를 누르면 팩모듈에 전원이 공급됩니다.
1
2
4-MODULE EXTENSION
JME-4A
PACK 1
PACK 3
PACK 2
PACK 4
CD module(JCDP-10A, JCDR-10A) can be only equipped to
upper two-holes. (PACK 1, PACK 2)
JME-4A 확장시 CD PLAYER 팩모듈(JCDP-10A,JCDR-10A)
은윗부분 2개(PACK1, PACK2)의홀에만 장착이 가능합니다.
FRONT PANEL CONTROLS (전면기능)
2-MODULE EXTENSION JME-2A
1
2
PACK 1 PACK 2

3
1. AC POWER
교류 전원 공급 소켓(INLET) 입니다.
3. 24VDC TERMINAL
이단자는 배터리 24V를공급받기 위한 직류 전원 단자로서 연결시 극성이
바뀌지 않도록 주의하십시오.
4. OUTPUTS
출력은 각팩모듈별로 독립된 팩1, 2, 3, 4 바란스 XLR 출력과 하나로 통합한
바란스 XLR 출력으로 구성되어 있습니다.
신호 극성은 2번: + , 3번: -, 1번: GND입니다.
5. TERMINALS PANEL
튜너의 안테나 터미날 및JDM-10A, JCDP-10A의리모트 콘트롤 잭면을 부착
하는 판넬 구멍입니다.
2. FUSE HOLDER
교류 전원 공급용 소켓에는 교류전원 퓨즈가 들어 있으며 퓨즈가 용단될 경우
아래와 같은 동일 타입 용량 퓨즈로 갈아끼우십시오. 계속 퓨즈가 용단될 경우
퓨즈 교체를 중단하고 전문가에게 수리를 요청하십시오.
1. AC POWER
This is for AC power with inlet socket.
2. FUSE HOLDER
Built in AC fuse in the AC socket.
When fuse is blown-out, use some time, some spec as below spec.
If fuse blown-out repeatedly, stop replacing fuse and refer servicing
to qualified person.
REAR PANEL CONTROLS (후면기능)
120VAC : T1AH 250V(55T)
220VAC~240VAC :T500mAL 250V(50T)
24VDC : 2AH 250(55T)
FM : You can connect 75ohm coaxial cable or 300ohm feeder
cable according to antennas.
GND : An earthing terminal for AM receiving, it is possible to
protect the unit in a flash of lighting and to clear the noise.
AM : Connect it to the AM terminal in case of using outdoor or
lead antenna.
FM : 안테나의 종류에 따라 75 동축 케이블 또는 300 휘다선
을연결하십시오.
GND : AM 방송 수신을 위한 접지 단자 입니다.
천둥, 번개로부터 제품을 보호하기 위해 접지를 사용하십시오.
AM : 리드 안테나 또는 옥외 안테나 사용시 AM 단자에 연결하십
시오.
120VAC : T1AH 250V(55T)
220VAC~240VAC :T500mAL 250V(50T)
24VDC : 2AH 250(55T)
BUIT IN DC FUSE
This is for connection of DC 24V power supply.
Please confirm the polarities before connection.
3. 24VDC TERMINAL
Output connector have been designed into each balanced XLR
connector PACK1, 2, 3, 4 and combined balanced XLR, signal
polarities are No.2 : +, No.3 : -, No.1 : GND.
4. OUTPUTS
This is a hole of remote control for JDM-10A, JCDP-10A and ANT
terminal for tuner.
5. TERMINAL PANELS
USE ONLY WITH A 250V FUSE
1 5
24
DC POWER
24V MAX 1.9A
300
AM GND
FM 75
300
AM GND
FM 75
PACK 1PACK 2
PACK 1PACK 2SUMMING
12
3
SERIAL NO.:
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK DON'T EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
2-MODULE EXTENSION
MADE IN KOREA
MODEL NO.: JME-2A
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
12
3
CAUTION: TO REDUCE THE RISK OF
FIRE REPLACE ONLY WITH SAME TYPE FUSE.
MAX 55W
230V / 50Hz
FUSE RATING
T500mAL 250V
240V / 50Hz
BALANCED OUTPUTS 0dBm
USE ONLY WITH A 250V FUSE
15
24
3
300
AM GND
FM 75
PACK 4
SUMMING PACK 4
DC POWER
24V MAX 1.9A
CAUTION: TO REDUCE THE RISK OF
FIRE REPLACE ONLY WITH SAME TYPE FUSE.
12
3
BALANCED OUTPUTS 0dBm
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK DON'T EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
4-MODULE EXTENSION
MADE IN KOREA
MODEL NO.: JME-4A
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
SERIAL NO.:
MAX 55W
230V / 50Hz
FUSE RATING
T500mAL 250V
240V / 50Hz
12
3
300
AM GND
FM 75
PACK 3
300
AM GND
FM 75
PACK 2
300
AM GND
FM 75
PACK 1
PACK 3 PACK 2 PACK 1
3

4
FM RECEIVING ANTENNA
The electric wave of FM broadcasting is weaker in valleys, around
buildings and in iron-reinforced buildings because of its one nature.
CONNECTION OF THE ANTENNA GROUND CABLE
FM 수신용 안테나
FM 방송의 전파는 그성질상 산골짜기나 빌딩 주변, 철근 건물속 등에서는
약해집니다. 주변의 상황이나 전파의 세기등을 고려해서 안테나를 설치해
주십시오.
FM 전용 안테나의 설치
안테나 휘다선(FREE CABLE)를300 단자에 접속하고 방송을 들으면서 수
신상태가 가장 좋게 되도록 설치장소, 방향을 결정해서 단단히 고정합니다.
실내 안테나
방송국이 가깝거나 목재 건물등으로 FM방송이 비교적 잘들리는 장소에서는
"T"자형 실내 안테나를 사용하여도 좋은 음질의 방송을 수신할 수있습니다.
옥외 안테나와 같이 300 단자에 안테나를 접속하고 수신 상태가 가장 좋은
곳에 안테나를 고정시키면 됩니다.
동축 케이블을 사용한 안테나 설치
교통량이 많은 도심지나 시가지, 공장지대, 고압 송전선의 부근에서는 FM전
용안테나를 사용해도 잡음을 느끼는 경우가 있습니다. 이러한 지역에서는
전용 안테나의 접속을 75 동축 케이블로 설치해 주십시오.
* FM전용 안테나 75 동축 케이블에 대해서는 부근의 제디아 대리점과 상담
해주십시오.
INDOOR ANTENNA
In the regions where FM broadcasting are heard comparatively well
due to a good signal strenght, you can receive broadcasting of good
quality by using T-type antenna at the best place for reception after
connecting it with a terminal of 300ohms.(Fig.1-1)
INSTALLATION OF AN ANTENNA USING
THE COAXIAL CABLE
You may have noise at the crowded downtown, in downtown and
factory sites as well as around power cables, even in the case of
using an antenna exclusively for FM. In these regions, install it through
connection with a coaxial cable of 75ohms.
INSTALLATION OF AN ANTENNA EXCLUSIVELY FOR FM
Connect the feeder of the antenna to the terminal of 300ohms.(Fig.1-1)
Listening to the broadcasting, fix it after deciding the location and
direction so that the reception may be optimiz.
GNDAM
FM 75
300
FM DIPOLE ANTENNA
FM ANTENNA
ANTENNA
DIRECTION OF
BROADCASTING STATION
EARTH

5
AM LEAD ANTENNA
Connect6~8M cable to the AM terminal and route cable to give the
best reception.
Keep away from power cables and fluorescent lights.(Fig.1~2)
CONNECTION OF THE ANTENNA GROUND CABLE
AM 수신용 안테나
ONE EARTHING(ERTH GND)
Broadcasting may be heard well without earth connection.
But connect the earth to the earth terminal.
(GND for safety and prevention of noise)(fig.1~2)
AM OUTDOOR ANTENNA
Install the vinyl-coated cable outdoor if indoor reception is poor.(Fig.1~2)
AM 리드 안테나
단선의 비닐 피복선을 6~8m정도로 해서 한쪽을 AM 단자에, 다른쪽을 벽등
의높은 장소에 걸쳐 고정합니다.
AM 옥외 안테나
리드 안테나를 실내에 설치해도 잘들리지 않을 경우는 옥외에 비닐 피복선을
장치합니다.
접지에 대해서(EARTH GND)
접지를 하지 않아도 방송은 잘들립니다만, 뇌우시 안전성과 잡음 제거를 위
해될수있는대로 접지선을 GND 단자에 접속해 주십시오.
GNDAM
FM 75
300
ANTENNA
ANTENNA
EARTH
AM OUTDOOR
WALL SURFACE
INDOOR ANTENNA
OR
