INSTALLATION INSTRUCTIONS
CommerCial-Style GaS CooktopS
30" (76.2 Cm), 36" (91.4 Cm), and 48" (121.9 Cm)
For residential use only
INSTRUCTIONS D’INSTALLATION
tableS de CuiSSon àGaz de type CommerCial
30" (76,2 Cm), 36" (91,4 Cm) et 48" (121,9 Cm)
Pour utilisation résidentielle uniquement
Table of Contents/Table des matières
W10899358A
IMPORTANT:
Installer:
Leave installation instructions with the homeowner.
Homeo
wner: Keep installation instructions for future reference.
IMPOR
TANT :
Installateur
:Remettre les instructions d'installation au propriétaire.
Pr
opriétaire : Conserver les instructions d'installation pour référence ultérieure
.
www.jennair.com (U.S.A.) www.jennair.ca (Canada)
COOKTOP SAFETY........................................................................2
INSTALLATION REQUIREMENTS.................................................3
Tools and Parts.............................................................................3
Location Requirements................................................................4
Electrical Requirements ...............................................................7
Gas Supply Requirements...........................................................7
INSTALLATION INSTRUCTIONS...................................................8
Install Cooktop .............................................................................8
Install Optional Backguard...........................................................8
Make Gas Connection .................................................................9
Install Griddle .............................................................................10
Complete Installation .................................................................10
GAS CONVERSIONS....................................................................12
LP Gas Conversion ....................................................................12
Natural Gas Conversion.............................................................14
STRIP CIRCUITS ..........................................................................15
WIRING DIAGRAMS.....................................................................16
SÉCURITÉ DE LA TABLE DE CUISSON.....................................18
EXIGENCES D’INSTALLATION ...................................................19
Outillage et pièces......................................................................19
Exigences d’emplacement.........................................................20
Spécifications électriques..........................................................23
Spécifications de l’alimentation en gaz .....................................23
INSTRUCTIONS D’INSTALLATION.............................................24
Installation de la table de cuisson..............................................24
Installation du dosseret facultatif...............................................25
Raccordement au gaz................................................................25
Installation de la plaque à frire ...................................................26
Achever l’installation ..................................................................26
CONVERSIONS POUR CHANGEMENT DE GAZ ......................29
Conversion pour l’alimentation au propane ..............................29
Conversion pour l’alimentation au gaz naturel ..........................32
SCHÉMA DES CIRCUITS ............................................................33
SCHÉMAS DE CÂBLAGE ............................................................34

2
COOKTOP SAFETY
WARNING: If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or death.
–Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance.
–WHAT TO DO IF YOU SMELL GAS:
•Do not try to light any appliance.
•Do not touch any electrical switch.
•Do not use any phone in your building.
•Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
•If you cannot reach your gas supplier, call the fire department.
–Installation and service must be performed by a qualified installer, service agency or
the gas supplier.
WARNING: Gas leaks cannot always be detected by smell.
Gas suppliers recommend that you use a gas detector approved by UL or CSA.
For more information, contact your gas supplier.
If a gas leak is detected, follow the “What to do if you smell gas” instructions.

3
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed here.
Tools Needed
Adjustable wrench Tape measure Marker or pencil
Pipe wrench Flat-blade screwdriver 15/16" combination wrench
Wrench or channel lock pliers Pipe-joint compound
resistant to LP gas Noncorrosive leak-detection solution
For LP/Natural Gas Conversions
Adjustable wrench 3/8" drive ratchet 1/2" deep-well socket
7 mm nut driver Masking tape
IMPORTANT: Do not install a ventilation system that blows air downward toward this gas cooking appliance. This type of
ventilation system may cause ignition and combustion problems with this gas cooking appliance resulting in personal injury or
unintended operation.
In the State of Massachusetts, the following installation instructions apply:
■ Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gasfitter qualified or licensed by
the State of Massachusetts.
■ If using a ball valve, it shall be a T-handle type.
■ A flexible gas connector, when used, must not exceed 3 feet.

4
Parts Supplied
Check that all parts are included.
■Gas pressure regulator
■Burner grates
■Burner bases and burner caps
■Griddle drip tray (on griddle models)
■Foam tape
■LP orifice package (W10393255)
■Conversion label (W10393342)
NOTE: The cooktop is manufactured for use with Natural gas.
To convert to LP gas, see the “Gas Conversions” section.
Optional Backguards
48" (121.9 cm) models and grill models must be installed with
a backsplash if installing at zero clearance to a combustible
backwall. See the “Cabinet Dimensions” section in the “Location
Requirements” section for installation requirements.
■36" (91.4 cm) Retractable Backguard
Order Part Number 8284756
■48" (121.9 cm) Retractable Backguard
Order Part Number 8284755
■9" (22.9 cm) Backguard for 36" (91.4 cm) Cooktops
Order Part Number W10115776
■9" (22.9 cm) Backguard for 48" (121.9 cm) Cooktops
Order Part Number W10115777
■331/2" (85.0 cm) Retractable Backguard with Wire Shelf
for 36" (91.4 cm) Cooktops
Order Part Number W10285448
■331/2" (85.0 cm) Retractable Backguard with Wire Shelf
for 48" (121.9 cm) Cooktops
Order Part Number W10285449
To order, see the “Assistance or Service” section of the Use
and Care Guide.
Check local codes and consult gas supplier. Check existing gas
supply and electrical supply. See the “Electrical Requirements”
and “Gas Supply Requirements” sections.
High Altitude Conversion
To convert the cooktop for elevations above 6,560 ft (1999.5 m),
order a High Altitude Conversion Kit.
■Part Number W10394296 - LP high altitude
■Part Number W10394295 - Natural gas high altitude
To order, see the “Assistance or Service” section of the Use and
Care Guide.
Location Requirements
IMPORTANT: Observe all governing codes and ordinances.
Do not obstruct flow of combustion and ventilation air.
■It is the installer’s responsibility to comply with installation
clearances specified on the model/serial/rating plate. The
model/serial/rating plate is located on the underside of the
cooktop burner base.
■It is recommended that a 600 CFM or larger vent hood
be installed above the cooktop.
■It is not recommended that a microwave hood combination
be mounted above the cooktop.
■The cooktop should be installed in a location away from
strong draft areas, such as windows, doors, and strong
heating vents or fans.
■All openings in the wall or floor where cooktop is to be
installed must be sealed.
■Cabinet opening dimensions that are shown must be used.
Given dimensions are minimum clearances.
■Grounded electrical supply is required. See the “Electrical
Requirements” section.
■Proper gas supply connection must be available. See the
“Gas Supply Requirements” section.
■The cooktop is designed to hang from the countertop
by its side or rear flanges.
■The gas and electric supply should be located as shown in
the “Gas and Electric Connection Locations” section so that
they are accessible without requiring removal of the cooktop.
■Provide cutout in left rear corner of cutout enclosure as
shown to provide clearance for gas inlet, power supply cord,
and to allow the rating label to be visible.
IMPORTANT: To avoid damage to your cabinets, check with
your builder or cabinet supplier to make sure that the materials
used will not discolor, delaminate, or sustain other damage.
Mobile Home - Additional Installation Requirements
The installation of this cooktop must conform to the
Manufactured Home Construction and Safety Standard,
Title 24 CFR, Part 3280 (formerly the Federal Standard for
Mobile Home Construction and Safety, Title 24, HUD Part
280). When such standard is not applicable, use the Standard
for Manufactured Home Installations, ANSI A225.1/NFPA 501A
or local codes.
In Canada, the installation of this cooktop must conform with
the current standards CAN/CSA-A240-latest edition or with
local codes.

5
Product Dimensions
Side View of Cooktop
Gas and Electric Connection Locations
AB
C
D
E
A. 271/8” (68.9 cm)
B. 30" (76.2 cm) cooktop: 297/8" (75.9 cm)
36" (91.4 cm) cooktop: 353/4" (90.8 cm)
48" (121.9 cm) cooktop: 477/8" (121.6 cm)
C. Island trim or optional backguard
D. 36" (91.4 cm) long 3 prong grounding-type
power supply cord
E. Model/serial/rating plate (located on the
underside of the cooktop burner base)
A
C
F
G
D
E
B
A. 273/4" (70.5 cm)
B. 11/4" (3.2 cm)
C. 77/16" (18.8 cm)
D. Gas inlet is located 17/8" (4.8 cm) from the back
of the cooktop burner base and 47/8" (12.4 cm) in
from left-hand side of the cooktop burner base.
E. 22" (55.9 cm)
F. 3 5/16" (8.4 cm)
G. 9/16" (1.4 cm)
A
BC
D
A. Grounded 3 prong outlet should be located on
left-hand side of the cutout 16" (40.6 cm) max.
from enclosure sidewall
B. 10" (25.4 cm) min. clearance from countertop to
top of the outlet
C. 14" (35.6 cm) countertop to the gas supply line
D. Gas supply line should be located in this area on
rear or side walls or the supply line can come up
through the floor.
NOTE: Solid side and bottom of cutout enclosure
not shown.

6
Cabinet Requirements
Size Model A*
Cooktop
Cutout to
Back Wall
B**
Cooktop to
Cabinet
C
Optional Backguard
and Upper Cabinet
Opening
D
Cabinet and
Countertop
E
Countertop Only
30" (76.2 cm) JGCP430 13/4" (4.4 cm)* 30" (76.2 cm) 30" (76.2 cm) 291/4" (74.3 cm) 30" (76.2 cm) or
297/8" (75.9 cm) for
zero clearance
36" (91.4 cm) JGCP436
JGCP536 13/4" (4.4 cm)* 42" (106.7 cm) 36" (91.4 cm) 351/4" (89.5 cm) 36" (91.4 cm) or 353/4" (90.8 cm) for
zero clearance
48" (121.9 cm) JGCP548 13/4" (4.4 cm)* 42" (106.7 cm) 48" (121.9 cm) 471/4" (120.0 cm) 48" (121.9 cm) or
477/8" (121.6 cm) for
zero clearance
* NOTE: If backwall is constructed of a combustible material and a backguard is not installed, a minimum clearance of
dimension A + 3" (7.6 cm) is required for 36" (91.4 cm) and 48" (121.9 cm) cooktops.
** NOTES: Dimension “B” can be reduced by 6" (15.2 cm) when bottom of wood or metal cabinet is covered by not less than
0.25" (6.4 mm) flame retardant millboard covered with not less than No. 28 MSG sheet metal, 0.015" (0.4 mm) stainless steel,
0.024" (0.6 mm) aluminum, or 0.020" (0.5 mm) copper.
If installing a range hood above the cooktop, follow the range hood instructions for dimensional clearances above the
cooktop surface.
B min.**
C
A*
D
E
F
I
J
KM
G
N
O
H
C
EL
P
L
D
A. See chart.
B. See chart.
C. See chart.
D. See chart.
E. See chart.
F. 18" (45.7 cm) min. clearance upper cabinet
to countertop
G. 3/4" (1.9 cm) back of cabinet cutout to gas
opening cutout
H. 67/8" (16.1 cm) gas opening cutout depth
I. 121/2" (31.7 cm) gas opening cutout width
J. 221/4" (56.5 cm) cabinet cutout depth
K. 2" (5.1 cm) cabinet side to gas cutout
L. 6" (15.2 cm) min. distance on both sides of the
cooktop to the side wall or other combustible
material above cooking surface
M. 24" (61.0 cm) cabinet depth
N. 71/4" (18.4 cm) cabinet depth to countertop
O. Notch to be equal on both sides
P. 13" (33.0 cm) upper cabinet depth

7
Electrical Requirements
IMPORTANT: The cooktop must be electrically grounded in
accordance with local codes and ordinances, or in the absence
of local codes, with the National Electrical Code, ANSI/NFPA 70
or Canadian Electrical Code, CSA C22.1.
This cooktop is equipped with an electronic ignition system
that will not operate if plugged into an outlet that is not
properly polarized.
If codes permit and a separate ground wire is used, it is
recommended that a qualified electrical installer determine
that the ground path is adequate.
A copy of the above code standards can be obtained from:
National Fire Protection Association
1 Batterymarch Park
Quincy, MA 02169-7471
CSA International
8501 East Pleasant Valley Road
Cleveland, Ohio 44131-5575
■A 120-volt, 60 Hz, AC-only, 15-amp, fused electrical circuit
is required. A time-delay fuse or circuit breaker is also
recommended. It is recommended that a separate circuit
serving only this cooktop be provided.
■Electronic ignition systems operate within wide voltage limits,
but proper grounding and polarity are necessary. Check that
the outlet provides 120-volt power and is correctly grounded.
■The wiring diagrams are provided with this cooktop. The
wiring diagrams are located inside the control console and
in the “Wiring Diagrams” section.
Gas Supply Requirements
Observe all governing codes and ordinances.
IMPORTANT: This installation must conform with all local codes
and ordinances. In the absence of local codes, installation must
conform with American National Standard, National Fuel Gas
Code ANSI Z223.1 - latest edition or CAN/CGA B149 - latest
edition.
IMPORTANT: Leak testing of the cooktop must be conducted
according to the manufacturer’s instructions.
Type of Gas
Natural Gas:
■This cooktop is factory-set for use with Natural gas. To
convert to LP gas, see the Gas Conversion instructions
provided in the package containing literature. The model/
serial/rating plate located on the left underside of the
cooktop burner base has information on the types of gas
that can be used. If the types of gas listed do not include
the type of gas available, check with the local gas supplier.
LP Gas conversion:
Conversion must be done by a qualified service technician.
No attempt shall be made to convert the cooktop from the gas
specified on the model/serial/rating plate for use with a different
gas without consulting the serving gas supplier. To convert to LP
gas, use the LP gas conversion kit provided with the cooktop
and see the “Gas Conversions” section.
Gas Supply Line
■Provide a gas supply line of 3/4" (1.9 cm) rigid pipe to the
cooktop location. A smaller size pipe on longer runs may
result in insufficient gas supply. With LP gas, piping or tubing
size can be 1/2" (1.3 cm) minimum. Usually, LP gas suppliers
determine the size and materials used in the system.
NOTE: Pipe-joint compounds that resist the action of LP gas
must be used. Do not use TEFLON®† tape.
WARNING
Explosion Hazard
Use a new CSA International approved gas supply line.
Install a shut-off valve.
Securely tighten all gas connections.
If connected to LP, have a qualified person make sure
gas pressure does not exceed 14" (36 cm) water
column.
Examples of a qualified person include:
licensed heating personnel,
authorized gas company personnel, and
authorized service personnel.
Failure to do so can result in death, explosion, or fire.
†®TEFLON is a registered trademark of Chemours.

8
Flexible metal appliance connector:
■If local codes permit, a new CSA design-certified, 4 - 5 ft
(122 - 152.4 cm) long, 5/8" (1.6 cm) or 3/4" (1.9 cm) I.D.,
flexible metal appliance connector may be used for
connecting the cooktop to the gas supply line.
■A 1/2" (1.3 cm) male pipe thread is needed for connection
to the female pipe threads of the inlet to the appliance
pressure regulator.
■Do not kink or damage the flexible metal tubing when
moving the cooktop.
■Must include a shut-off valve:
The supply line must be equipped with a manual shut-off
valve. This valve should be located in the same room but
external to the cooktop enclosure or cabinet. It should be in
a location that allows ease of opening and closing. Do not
block access to shut-off valve. The valve is for turning on or
shutting off gas to the cooktop.
Gas Pressure Regulator
The gas pressure regulator supplied with this cooktop must
be used. The inlet pressure to the regulator should be as
follows for proper operation:
Natural Gas:
Minimum pressure: 6" (15.2 cm) WCP
Maximum pressure: 14" (35.5 cm) WCP
LP Gas:
Minimum pressure: 11" (27.9 cm) WCP
Maximum pressure: 14" (35.5 cm) WCP
Contact local gas supplier if you are not sure about the inlet
pressure.
Burner Input Rating - Altitude
Input ratings shown on the model/serial rating plate are for
elevations up to 2,000 ft (609.6 m).
For elevations above 2,000 ft (609.6 m), ratings need to be
reduced at a rate of 4% for each 1,000 ft (304.8 m) above
sea level (not applicable for Canada).
Gas Supply Pressure Testing
Gas supply pressure for testing regulator must be at least
1" water column pressure above the manifold pressure shown
on the model/serial/rating plate.
Line pressure testing above 1/2psi gauge (14" WCP)
The cooktop and its individual shut-off valve must be
disconnected from the gas supply piping system during any
pressure testing of that system at test pressures in excess of
1/2psi (3.5 kPa).
Line pressure testing at 1/2psi gauge (14" WCP) or lower
The cooktop must be isolated from the gas supply piping
system by closing its individual manual shut-off valve during
any pressure testing of the gas supply piping system at test
pressures equal to or less than 1/2psi (3.5 kPa).
INSTALLATION INSTRUCTIONS
Install Cooktop
Write down the model and serial numbers before installing the
cooktop. Both numbers are located on the left front underside of
the burner base.
Unpack the parts supplied with your cooktop. The parts shipped
with the cooktop depend on your model ordered. See the “Tools
and Parts” section for a complete list of parts supplied with your
cooktop.
The pressure regulator and flexible stainless steel gas supply
line connector can be assembled to the cooktop now or after
the cooktop is installed in the cutout. See the “Make Gas
Connection” section.
1. Decide on the final location for the cooktop.
2. Using two or more people, place the cooktop upside down
on a covered surface.
3. Remove foam strip from literature packing. Remove backing
from foam strip. Apply foam strip adhesive-side down along
the left and right sides of the cooktop trim.
NOTE: The foam strip helps the cooktop sit flat on uneven
counters and avoids damage to the countertop surface.
4. Using 2 or more people, turn cooktop right side up.
Install Optional Backguard
36" (91.4 cm) and 48" (121.9 cm) models may require a
backguard. See “Cabinet Dimensions” in the “Location
Requirements” section for installation requirements. See
the “Tools and Parts” section for information on ordering.
Remove island trim and attach backguard using 6 screws;
insert 3 from the front and 3 from the back (9" [22.9 cm]
backguard shown).
A
B
C
A. Gas supply line
B. Shut-off valve “open” position
C. To cooktop
WARNING
Excessive Weight Hazard
Use two or more people to move and install cooktop.
Failure to do so can result in back or other injury.
A
B
C
A. Cooktop base
B. Foam strip
C. Cooktop

9
Make Gas Connection
To Assemble Pressure Regulator:
1. Using 2 or more people, stand the cooktop on its side
or back.
2. Connect the flexible stainless steel connector to the pressure
regulator using a 1/2" male pipe thread adapter.
A combination of pipe fittings must be used to connect the
cooktop to the existing gas line. The following shows a
typical connection. Your connection may be different,
according to the supply line type, size, and location.
3. Install the pressure regulator with the arrow pointing up
toward the bottom of the cooktop burner base and in a
position where you can reach the regulator cap.
IMPORTANT: All connections must be wrench-tightened.
Do not make connections to the gas regulator too tight.
Making the connections too tight may crack the regulator
and cause a gas leak. Do not allow the regulator to turn on
the pipe when tightening fittings.
Use only pipe-joint compound made for use with Natural
and LP gas. Do not use TEFLON®tape.
You will need to determine the fittings required depending
on your installation.
4. Place cooktop into the countertop cutout.
NOTE: Check that the front edge of the cooktop is parallel
to the front edge of the countertop. If repositioning
is needed, lift entire cooktop up from cutout to avoid
scratching the countertop.
Typical flexible connection
1. Apply pipe-joint compound made for use with LP gas to the
smaller thread ends of the flexible connector adapters (see
B and F in the following illustration).
2. Attach one adapter to the gas pressure regulator and
the other adapter to the gas shut-off valve. Tighten both
adapters.
3. Use a 15/16" combination wrench and channel lock pliers to
attach the flexible connector to the adapters. Check that
connector is not kinked.
Complete Connection
1. Open the manual shut-off valve in the gas supply line. The
valve is open when the handle is parallel to the gas pipe.
2. Test all connections by brushing on an approved
noncorrosive leak-detection solution. If bubbles appear,
a leak is indicated. Correct any leak found.
3. Remove cooktop burner caps, burner bases, and grates
from parts package. Place burner bases on cooktop. Place
burner caps on burner bases. Place grates over burners and
caps.
WARNING
Explosion Hazard
Use a new CSA International approved gas supply line.
Install a shut-off valve.
Securely tighten all gas connections.
If connected to LP, have a qualified person make sure
gas pressure does not exceed 14" (36 cm) water
column.
Examples of a qualified person include:
licensed heating personnel,
authorized gas company personnel, and
authorized service personnel.
Failure to do so can result in death, explosion, or fire.
A
B
D
C
A. Gas pressure regulator
B. Regulator - Must be installed with arrow pointing up
to cooktop bottom
C. Adapter - Must have 1/2" male pipe thread
D. CSA Approved flexible stainless steel gas supply line
A
B
C
D
EFG
H
A. Gas pressure regulator
B. Use pipe-joint compound.
C. Adapter - must have 1/2"
male pipe thread
D. Flexible connector
E. Adapter
F. Use pipe-joint compound.
G. 1/2" or 3/4" gas pipe
H. Manual gas shut-off valve
A
B
A. Closed valve
B. Open valve

10
4. Plug into a grounded 3 prong outlet.
5. Check the operation of the surface burners. See “Check
Operation of Cooktop Burners” in the “Complete Installation”
section.
6. If your model has a griddle, see the “Install Griddle” section.
Install Griddle
(on griddle models)
The griddle is factory installed.
1. Place drip tray in the well at the front of the griddle. Slide tray
toward the back until it stops.
2. Clean griddle before using. Refer to the Use and Care Guide.
Complete Installation
Install Burner Bases and Burner Caps
Install the burner base, making sure the igniter electrode is
properly aligned with the base. Place burner caps on top
of burner bases. If burner caps are not properly positioned,
surface burners will not light.
Ultra Power™ Dual-Flame Burner
Professional Burner
Simmer/Melt Burner
Electronic Ignition System
Initial lighting and gas flame adjustments
Cooktop burners use electronic igniters in place of standing
pilots. When the cooktop control knob is turned to any position,
the system creates a spark to light the burner. This sparking
continues until the flame is lit or the knob is turned to OFF.
Check Operation of Cooktop Burners
Push in and turn each control knob to the Lite position.
The surface burners and grill flames should light within
4 seconds. The first time a burner is lit, it may take longer
than 4 seconds to light because of air in the gas line.
After verifying the proper burner operation, turn the control
knobs to OFF.
If burners do not light properly:
■Turn cooktop control knob to the Off position.
■Check that the cooktop is plugged in and the circuit breaker
has not tripped or the fuse has not blown.
■Check that the gas shut-off valves are set to the
open position.
■Check that burner caps are properly positioned on
burner bases.
Repeat start-up. If a burner does not light at this point, contact
your dealer or authorized service company for assistance.
If you need Assistance or Service:
Please reference the “Assistance or Service” section of the Use
and Care Guide or contact the dealer from whom you purchased
your cooktop.
A
B
A. Griddle drip tray
B. Griddle
A
B
A. Incorrect
B. Correct
A
B
A. Incorrect
B. Correct
A
B
A. Incorrect
B. Correct
