Jet JCDC-1.5 User manual

JCDC-1.5
1.5 HP Mobile Cyclone Dust
Collector
Original:
GB
Operating Instructions
JPW Tool) AG
Tämperlistrasse 5
8117 Fällanden
Switzerland
Phone +41 44 80 47 48
Fax +41 44 80 47 58
www.jettools.com
M-717515M 201 -04

2
CE-Conformity Declaration
CE-Konformitätserklärung
Déclaration de Conformité CE
Product / Produkt / Produit:
Dust Collector / Staubfänger / Collecteur de poussière
JCDC-1.
( 717515M )
Brand / Marke / Marque:
JET
Manufacturer / Hersteller / Fabricant:
JPW (Tool) AG Tämperlistrasse 5 CH-8117 Fällanden
Schweiz / Suisse / Switzerland
We hereby declare that this product complies with the regulations
Wir erklären hiermit dass dieses Produkt der folgenden Richtlinie entspricht
Par la présente nous déclarons que ce produit correspond aux directives suivantes
2006/42/EC
Machinery Directive / Maschinenrichtlinie / Directive Machines
2014/30/EU
electromagnetic compatibility / elektromagnetische Verträglichkeit / compatibilité électromagnétique
designed in consideration of the standards
und entspechend folgender zusätzlicher Normen entwickelt wurde
et été développé dans le respect des normes complémentaires suivantes
EN ISO 12100 : 2010
EN 60204-1 : 2006+AC:2010
EN 014-1:2006+A2:2011
EN 014-2:201
Responsible for the Documentation / Dokumentations-Verantwortung / Résponsabilité de Documentation:
Hansjörg Meier
Head Product-Mgmt. / Leiter Produkt-Mgmt. / Resp. Gestion des Produits
JPW (Tool) AG
2016-11-30 Alain Schmid General Manager
JPW (Tool) AG Tämperlistrasse 5 CH-8117 Fällanden
Schweiz / Suisse / Switzerland

3
GB - ENGLISH
Operating Instructions
Dear Customer,
Many thanks for the confidence you have shown in us with the purchase of your new JET-product. This manual
has been prepared for the owner and operators of a JET JCDC-1.5 cyclone dust collector to promote safety
during installation, operation and maintenance procedures. Please read and understand the information
contained in these operating instructions and the accompanying documents. To obtain maximum life and
efficiency from your dust collector, and to use it safely, read this manual thoroughly and follow instructions
carefully.
Warranty
The Seller guarantees that the supplied product is free from material defects and manufacturing faults. This
warranty does not cover any defects which are caused, either directly or indirectly, by incorrect use,
carelessness, accidental damage, repair, inadequate maintenance or cleaning and normal wear and tear.
Guarantee and/or warranty claims must be made within twelve months from the date of purchase (date of
invoice). Any further claims shall be excluded.
This warranty includes all guarantee obligations of the Seller and replaces all previous declarations and
agreements concerning warranties.
The warranty period is valid for eight hours of daily use. If this is exceeded, the warranty period shall be
reduced in proportion to the excess use, but to no less than three months.
Returning rejected goods requires the prior express consent of the Seller and is at the Buyer’s risk and
expense.
Further warranty details can be found in the General Terms and Conditions (GTC). The GTC can be viewed at
www.jettools.com or can be sent by post upon request.
The Seller reserves the right to make changes to the product and accessories at any time.
About this manual
This manual is provided by JET, covering the safe operation and maintenance procedures for a JET Model
JCDC-1.5 Cyclone Dust Collector. This manual contains instructions on installation, safety precautions, general
operating procedures and maintenance instructions. Your machine has been designed and constructed to
provide consistent, long-term operation if used in accordance with the instructions as set forth in this document.
This manual is not intended to be an exhaustive guide to dust removal strategies, installation of shop duct
work, or the use of optional dust collection accessories. Additional knowledge may be obtained from
experienced users or trade articles. Whatever accepted methods are used, always make personal safety a
priority.
If there are questions or comments about this product, please contact your local supplier or JET. JET can also
be reached at our web site: www.jettools.com.
Retain this manual for future reference. If the machine transfers ownership, the manual should accompany it.

4
1.0 Important Safety Instruction
When using an electrical appliance, basic
precautions should always be followed, including
the following:
READ ALL INSTRUCTIONS BEFORE USING
THIS DUST COLLECTOR.
WARNING – To reduce the risk of fire,
electric shock, or injury:
1. Read and understand entire owner’s manual
before attempting assembly or operation of
this dust collector.
2. Read and understand the warnings posted on
the machine and in this manual.
3. Replace warning labels if they become
obscured or removed.
4. This dust collector is designed and intended
for use by properly trained and experienced
personnel only. If you are not familiar with the
proper and safe operation of a dust collector,
do not use until proper training and knowledge
have been obtained.
5. Do not use this dust collector for other than its
intended use. If used for other purposes, JET
disclaims any real or implied warranty and
holds itself harmless from any injury that may
result from that use.
. Always wear approved safety glasses/face
shield while using this dust collector. Everyday
eyeglasses only have impact resistant lenses;
they are not safety glasses.
7. Keep hair, loose clothing, fingers, and all parts
of body away from openings and moving parts.
8. Wear hearing protection (plugs or muffs)
during extended periods of operation.
9. Some dust created by power sanding, sawing,
grinding, drilling and other construction
activities contains chemicals known to cause
cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead based paint.
• Crystalline silica from bricks, cement and
other masonry products.
• Arsenic and chromium from chemically
treated lumber.
Your risk of exposure varies, depending on
how often you do this type of work. To reduce
your exposure to these chemicals, work in a
well-ventilated area and work with approved
safety equipment, such as face or dust masks
that are specifically designed to filter out
microscopic particles.
10. Do not operate this machine while tired or
under the influence of drugs, alcohol or any
medication.
11. Make certain the switch is in the OFF position
before connecting the machine to the power
supply. Turn off all controls before unplugging.
12. Make certain the machine is properly
grounded. Connect to a properly grounded
outlet only. See Grounding instructions.
13. Make all machine adjustments or maintenance
with the machine unplugged from the power
source.
14. Remove adjusting keys and wrenches. Form a
habit of checking to see that keys and
adjusting wrenches are removed from the
machine before turning it on.
15. Keep safety guards in place at all times when
the machine is in use. If removed for
maintenance purposes, use extreme caution
and replace the guards immediately after
maintenance is complete.
1 . Check damaged parts. Before further use of
the machine, a guard or other part that is
damaged should be carefully checked to
determine that it will operate properly and
perform its intended function. Check for
alignment of moving parts, binding of moving
parts, breakage of parts, mounting and any
other conditions that may affect its operation.
A guard or other part that is damaged should
be properly repaired or replaced.
17. Provide for adequate space surrounding work
area and non-glare, overhead lighting.
18. Keep the floor around the machine clean and
free of scrap material, oil and grease.
19. Keep visitors a safe distance from the work
area. Keep children away.
20. Make your workshop child proof with padlocks,
master switches or by removing starter keys.
21. Give your work undivided attention. Looking
around, carrying on a conversation and “horse-
play” are careless acts that can result in
serious injury.
22. The dust collector is intended for indoor use.
To reduce the risk of electric shock, do not use
outdoors or on wet surfaces.
23. Do not use this dust collector for anything
except wood dust. Materials such as liquids,
metal shavings, metal dust, screws, glass,

5
plastic or rock can cause sparks and/or
damage when coming into contact with any
part of the dust collector.
24. Do not use to pick up anything that is burning
or smoking, such as cigarettes, matches or hot
ashes.
25. Do not use to pick up flammable or
combustible liquids such as gasoline, or use in
areas where they may be present.
2 . Do not pull or carry by cord, use cord as a
handle, close a door on cord, or pull cord
around sharp edges or corners. Do not run
dust collector over cord. Keep cord away from
heated surfaces.
27. Do not use this dust collector with a damaged
cord or plug. If the unit is not working as it
should, has been dropped, damaged, left
outdoors, or dropped into water, return it to a
service center.
28. Do not unplug by pulling on cord. To unplug,
grasp the plug, not the cord.
29. Do not use without dust bag and/or filters in
place.
30. Do not handle plug or machine with wet hands
31. Do not put any objects into the openings. Do
not use with any opening blocked; keep free of
dust, lint, hair, and anything that may reduce
air flow.
32. Do not operate without hose connected to the
inlet. Place cap on unused inlet port.
Hazardous moving parts inside. Unplug before
removing or connecting inlet or inlet guard.
33. Use recommended accessories; improper
accessories may be hazardous.
34. Maintain tools with care. Follow instructions for
lubricating and changing accessories.
35. Turn off machine and disconnect from power
before cleaning. Use a brush or compressed
air to remove chips or debris; do not use bare
hands.
3 . Do not leave the machine when it is plugged
in. Unplug from outlet when not in use and
before servicing.
37. Do not stand on the machine. Serious injury
could occur if the machine tips over.
38. This dust collector is intended for household
use.
Familiarize yourself with the following safety notices used in this manual:
This means that if precautions are not heeded, it may result in minor injury and/or possible
machine damage.
This means that if precautions are not heeded, it may result in serious, or possibly even fatal,
injury.
SAVE THESE INSTRUCTIONS

2.0 Direction / Safety Label
Figure 1 Shows the general saftey rules to operate this machine
Figure 2 Product Brand Logo Figure 3 Machine ID label : Shows the
machine’s specifications and series number
Figure 4 Warns user of hazardous voltage, and
should be open up by trained personnel only.
Figure 5 Warns user of heated hot surface
hazard
Figure 6 Indicate the main electrical power
supply wire’s location, and the label itself.
Figure 7 Motor & Fan Rotation Direction
Figure 8 Notice the operator do not put the foot
on the base.
Figure 9 Grounding Notice

7
3.0 Specifications
Model number ......................................................................................................................................... JCDC-1.5
Stock number ........................................................................................................................................... 717515M
Motor and electricals:
Motor type ........................................................................ .totally enclosed fan cooled, induction, capacitor start
Horsepower ............................................................................................................................. 1-1/2 HP (1.1kW)
Phase .......................................................................................................................................................... single
Voltage ......................................................................................................................................................... 230V
Cycle ............................................................................................................................................................ 50Hz
Listed FLA (full load amps) ............................................................................................................................. 8 A
Start capacitor .......................................................................................................................... 300MFD 125VAC
Run capacitor ..................................................................................................................................... 30µF 250V
On/off switch ................................................................................................................... KJD-12 Magnet Switch
Motor speed ........................................................................................................................................ 2850 RPM
Power cord ....................................................................................................................... VDE H05VV-F 1.0mm
2
Power plug ..................................................................................................... VDE CE Plug, 1 A/250A installed
Recommended circuit and fuse/breaker size
1
.............................................................................................. 1 A
Sound emission (at 9.84 ft./3m)
2
................................................................................................................ 75 dB
Performance:
Inlet diameter ................................................................................................................................ in. (152 mm)
Inlet adaptors, number of ................................................................................................................................... 2
Inlet adaptors, diameter of ............................................................................................................. 4in. (100 mm)
Filter efficiency ........................................................................................................................... 99% at 2 micron
Air Flow with filters installed .................................................................. ......................... 899 CFM (1,527 m³/hr)
Air Velocity ............................................................................................ ........................... 4,5 7 FPM (23.2 m/s)
Static pressure loss (WC) ..................................................................... ..................... 2.3 in-H
2
O ( 0 mm-H
2
O)
Maximum static pressure loss (WC) ..................................................... ................... 5.43 in-H
2
O (138 mm-H
2
O)
Impeller:
Impeller diameter ........................................................................................................................ 13 in. (330 mm)
Impeller type .......................................................................................................................................... radial fin
Impeller material .......................................................................................................................................... steel
Canister filter:
Filter type ........................................................................................................ cartridge and spunbond polyester
Canister filter diameter ........................................................................................................ 14-9/1 in. (370 mm)
Canister filter length .............................................................................................................. 15-3/4 in. (400 mm)
Filter surface area .................................................................................................................... 21.53 sq. ft. (2m
2
)
Filter efficiency ............................................................................................................. 99% of 2 micron particles
Cleaning system ............................................................................................................ manual scraper rotation
Collection drum:
Capacity .................................................................................................................................................... 20 gal.
Diameter ............................................................................................................................. 1 -9/1 in. (420 mm)
Height ............................................................................................................................... 19-11/1 in. (500 mm)
Material ........................................................................................................................................................ steel
1
Subject to local/national electrical codes. Recommendation based upon dedicated circuit.
2
The specified values are emission levels and are not necessarily to be seen as safe operating levels. As wor place
conditions vary, this information is intended to allow the user to ma e a better estimation of the hazards and ris s
involved only.

8
Collection bags:
Bag material ..................................................................................................................................... polyethylene
Drum collection bag size (Dia. x L) ........................................................................ 2 x 27-9/1 ( 0 x 700 mm)
Canister collection bag size (Dia. x L) ...................................................... 19-11/1 x 23-5/8 in. (500 x 00 mm)
Main materials:
Frame ................................................................................................................................................ steel tubing
Body .................................................................................................................................................. 18 ga. steel
Paint finish ....................................................................................................................................... powder coat
Dimensions:
Footprint/base dimensions (L x W) ......................................................................... 47 x 22 in. (1195 x 559 mm)
Overall dimensions, assembled (L x W x H) ................................ 22 x 47 x 7-9/1 in. (559 x 1195 x 1715mm)
Overall dimensions, shipping carton (L x W x H) ............ 42-5/1 x 23-1/4 x 30-5/1 in. (1075 x 590 x 770 mm)
Weights:
Net weight ..................................................................................................................................... 132 lb. ( 0 kg)
Shipping weight, approximate .................................................................................................... 144 lb. ( 5.5 kg)
The specifications in this manual were current at time of publication, but because of our policy of continuous
improvement, JET reserves the right to change specifications at any time and without prior notice, without incurring
obligations.


10
4.3 Tools required for assembly
Hex keys, 4mm and 5mm (provided)
Open-end wrench, 10/12mm (provided)
Cross-point (Phillips) screwdriver
4.4 Assembly
1. Install four casters (L) to base (C). See Figure
3.
2. Install left and right stands (D
1
,D
2
) to base (C)
with flange head screws (HP8).
3. Install stand support (R) to base (C) with
flange head screws (HP4).
Figure 3
4. Install four casters (L) into the threaded nuts
beneath drum (F). See Figure 4.
Figure 4
5. Lift main housing (A) using hoist with straps
through lifting rings atop main housing. If hoist
is not available, at least 2 persons must lift
housing.
Main housing is heavy.
Two-person lift, or use hoist.
. Position main housing (A) between left and
right stands (D
1
,D
2
), and secure with six flange
head screws (HP2). See Figure 5.
Figure 5
7. Install funnel (B) beneath main housing.
Secure with funnel clamp (G). See Figure .
Tighten screw on funnel clamp securely.
Figure 6

11
8. Install side cover (M) on left and right stands.
See Figure 7.
Figure 7
9. Assemble handle (N) to canister filter (E) using
set screw and nut. See Figure 8.
Figure 8
10. Place gasket (W) between canister filter and
main housing. Install canister filter onto main
housing, and tighten with flange head screws
(HP8) and nuts (HP9). See Figure 9.
Figure 9
11. Apply foam tape (T) around inlet port near
edge. See Figure 10. The foam tape should
completely encircle the port.
12. Install inlet adaptor (I) on main housing and
secure with pan head screw (HP1).
13. Apply foam tape (V) just above lower lip of
canister filter. The foam tape should
completely encircle the canister filter.
14. Install collection bag (O) to bottom of canister
filter and secure with steel bag clamp (W).
Figure 10
15. Apply foam tape (U) around funnel just above
its bottom edge. See Figure 11. The foam tape
should completely encircle the funnel.
1 . Apply foam tape (U) around outside lip of drum
opening. The foam should completely encircle
the lip.
Figure 11
17. Install hose (J) onto cone and drum lid and
secure with two hose clamps (K), at top and
bottom. See Figure 12.

12
Figure 12
The bag frame maintains the shape of the bag in
the negative-pressure environment of the cyclone
drum. Assemble bag frame as follows:
18. Screw the short and long frame supports into
the hoops in alternating manner, as shown in
Figure 13. Secure with twelve pan head
screws and hex nuts (HP10,HP11). (Note: The
bends on long supports point inward as
shown.)
Figure 13
19. Place drum collection bag (P) into drum with its
top edge wrapped around top edge of drum.
Place bag frame (R) inside bag and press all
the way down. See Figure 14.
20. Pull down both quick levers (Q, Figure 12)
then assemble drum lid (H, Figure 12) to quick
levers. Tighten long nut (Q
1
, Figure 12) onto
each quick lever.
21. Raise drum lid using quick levers, and position
drum beneath lid. Lower quick levers to secure
lid upon drum.
Figure 14
5.0 Electrical connections
All electrical connections must
be done by a qualified electrician in compliance
with all local codes and ordinances. Failure to
comply may result in serious injury.
Mains connection and any extension cords used
must comply with applicable regulations.
The mains voltage must comply with the
information on the machine license plate. The dust
collector comes with a plug designed for use on a
circuit with a grounded outlet.
Keep in mind that a circuit being used by other
machines, tools, lights, heaters, etc. at the same
time will add to the electrical load. A dedicated
circuit to the dust collector will offer best results
since dust collectors are generally used while other
tools are running.
5.1 Grounding Instructions
This appliance must be grounded. If it should
malfunction or breakdown, grounding provides a
path of least resistance for electric current to
reduce the risk of electric shock. This appliance is
equipped with a cord having an equipment-
grounding conductor and grounding plug. The plug
must be inserted into an appropriate outlet that is
properly installed and grounded in accordance with
all local codes and ordinances.

13
Improper connection of the
equipment-grounding conductor can result in a
risk of electric shock. Check with a qualified
electrician or service person if you are in doubt
as to whether the outlet is properly grounded.
Do not modify the plug provided with the
appliance – if it will not fit the outlet, have a
proper outlet installed by a qualified electrician.
The conductor with insulation having an outer
surface that is green with or without yellow stripes
is the equipment-grounding conductor. If repair or
replacement of the electric cord or plug is
necessary, do not connect the equipment-
grounding conductor to a live terminal.
Repair or replace damaged or worn cord
immediately.
Make sure that the appliance is connected to an
outlet having the same configuration as the plug.
No adapter should be used with this appliance. If
the appliance must be reconnected for use on a
different type of electric circuit, the reconnection
should be made by qualified service personnel;
and after reconnection, the appliance should
comply with all local codes and ordinances.
6.0 Operations
6.1 Switches
Main power switch (Figure 15)
You can start the machine with the green ON
button. The red OFF button stops the machine.
Figure 15
6.2 Dust hose connection
Use proper type hose to connect dust collector to
machine(s) being operated. Dryer vent hose is not
acceptable for this purpose. Secure hose at both
ends with proper clamps.
If an inlet port is not being used, it should
remain capped. An open port will diminish the
machine’s efficiency, and may create a safety
hazard.
Contact your nearest JET distributor for a line of
Dust Collector hoses and accessories. You can
customize your installation and obtain maximum
performance with dust hoods, hoses, clamps,
fittings, and blast gates.
7.0 User-maintenance
Turn OFF dust collector and
remove plug from power source before
performing any adjustments or maintenance.
Failure to comply may result in serious injury.
7.1 Cleaning and bag inspection
Clean canister filter frequently to keep the
collector's performance at its optimum. To clean
filter, turn handle a couple of rotations so dust falls
into attached collection bag.
Empty or replace canister and drum collection bags
when full.
ATTENTION:
During the changing or cleaning of the filters it’s
necessary to use a mask (mask with filtration).
7.2 Motor inspection
Make frequent inspections of motor fan, and blow
out (with low pressure air hose) or vacuum any
accumulation of foreign material to maintain normal
motor ventilation.
7.3 Additional servicing
No lubrication is required for the dust collector.
Any other servicing should be performed by an
authorized service representative.

14
8.0 Optional accessories
Part no. Description
717511
Canister collection bag for JCDC (package of 5)
71751 Drum collection bag for JCDC-1.5 (package of 5)
Table 2
9.0 Troubleshooting the JCDC-1.5
9.1 Electrical and motor problems
Symptom Possible Cause Correction*
Motor will not start.
No incoming current. Check connections at plug or circuit
panel.
Safety key missing from switch. Install safety key.
Low voltage. Check power line for proper voltage.
Open circuit in motor or loose
connection.
Inspect all connections to switch box and
motor for loose or open connections.
Faulty start switch. Inspect and replace switch if needed.
Faulty start capacitor. Replace capacitor.
Faulty motor. Inspect and replace motor if needed.
Motor will not start:
fuse blows or circuit
breaker trips.
Too many machines on shared
circuit.
Connect dust collector to dedicated
circuit.
Short circuit in line cord or plug. Inspect cord or plug for damaged
insulation and shorted wires.
Short circuit in motor or loose
connections.
Inspect all connections on motor for loose
or shorted terminals or worn
insulation.
Incorrect fuse or circuit breaker in
power line.
Install correct fuse or circuit breaker at
power source.
Motor overheats.
Motor overloaded. Reduce load on motor.
Air circulation through motor is
restricted.
Clean motor fan with compressed air to
restore normal air circulation.
Motor stalls, resulting
in blown fuses or
tripped circuit.
Motor overloaded. Reduce load on motor.
Short circuit in motor or loose
connections.
Inspect connections on motor for loose or
shorted terminals or worn insulation.
Low voltage. Correct low voltage conditions.
Incorrect fuse or circuit breaker in
power line. Install correct fuse or circuit breaker.
Loud noise or
vibrations coming from
machine.
Loose fasteners. Inspect machine and tighten all fasteners.
Motor fan is hitting the cover. Tighten fan or shim cover. Replace fan
cover if damaged.
Impeller damaged. Replace impeller.
* WARNING: Some corrections may require a qualified electrician.

15
9.2 Performance problems
Symptom Possible Cause Correction
Poor performance;
lack of suction.
Hose improperly secured at dust
origination point. Inspect and remedy.
Inlet port is open. Cap unused inlet ports.
Collection bag is full. Empty bag (check sight window).
Collection drum not sealed properly. Inspect drum for leaks, make sure lid is
tight.
Canister filter is dirty. Clean filter.
Wood has excess moisture content. Use lumber with lower moisture content.
Obstruction in dust hose or inlet
port. Inspect and clear obstruction.
Dust hose too long. Move collector closer to dust source.
Excess dust or large
chips backing up into
canister filter.
Collection drum not sealed properly. Inspect drum for leaks, make sure lid is
tight.
Collection bag full. Empty bag (check sight window).
Other manuals for JCDC-1.5
2
Table of contents
Other Jet Dust Collector manuals
