Jet SuperSaw JWSS-10CS Service manual

Operating Instructions and Parts Manual
SuperSaw
Model: JWSS-10CS
WMH TOOL GROUP
2420 Vantage Drive
Elgin, Illinois 60124 Part No. M-708781
Ph.: 800-274-6848 Revision B 07/06
www.wmhtoolgroup.com Copyright © WMH Tool Group
This manual is bookmarked

2
Warranty and Service
WMH Tool Group, Inc., warrants every product it sells. If one of our tools needs service or repair, one of our Authorized
Service Centers located throughout the United States can give you quick service. In most cases, any of these WMH Tool
Group Authorized Service Centers can authorize warranty repair, assist you in obtaining parts, or perform routine
maintenance and major repair on your JET® tools. For the name of an Authorized Service Center in your area call 1-800-
274-6848.
MORE INFORMATION
WMH Tool Group is consistently adding new products to the line. For complete, up-to-date product information, check with
your local WMH Tool Group distributor, or visit jettools.com.
WARRANTY
JET products carry a limited warranty which varies in duration based upon the product. (MW = Metalworking, WW =
Woodworking)
WHAT IS COVERED?
This warranty covers any defects in workmanship or materials subject to the exceptions stated below. Cutting tools,
abrasives and other consumables are excluded from warranty coverage.
WHO IS COVERED?
This warranty covers only the initial purchaser of the product.
WHAT IS THE PERIOD OF COVERAGE?
The general JET warranty lasts for the time period specified in the product literature of each product.
WHAT IS NOT COVERED?
Five Year Warranties do not cover woodworking (WW) products used for commercial, industrial or educational purposes.
Woodworking products with Five Year Warranties that are used for commercial, industrial or education purposes revert to a
One Year Warranty. This warranty does not cover defects due directly or indirectly to misuse, abuse, negligence or
accidents, normal wear-and-tear, improper repair or alterations, or lack of maintenance.
HOW TO GET SERVICE
The product or part must be returned for examination, postage prepaid, to a location designated by us. For the name of the
location nearest you, please call 1-800-274-6848.
You must provide proof of initial purchase date and an explanation of the complaint must accompany the merchandise. If our
inspection discloses a defect, we will repair or replace the product, or refund the purchase price, at our option.
We will return the repaired product or replacement at our expense unless it is determined by us that there is no defect, or
that the defect resulted from causes not within the scope of our warranty in which case we will, at your direction, dispose of
or return the product. In the event you choose to have the product returned, you will be responsible for the shipping and
handling costs of the return.
HOW STATE LAW APPLIES
This warranty gives you specific legal rights; you may also have other rights which vary from state to state.
LIMITATIONS ON THIS WARRANTY
WMH TOOL GROUP LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD OF THE LIMITED WARRANTY FOR EACH
PRODUCT. EXCEPT AS STATED HEREIN, ANY IMPLIED WARRANTIES OR MERCHANTABILITY AND FITNESS ARE
EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG THE IMPLIED WARRANTY LASTS, SO
THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
WMH TOOL GROUP SHALL IN NO EVENT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY, OR FOR
INCIDENTAL, CONTINGENT, SPECIAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF OUR
PRODUCTS. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
WMH Tool Group sells through distributors only. The specifications in WMH catalogs are given as general information and
are not binding. Members of WMH Tool Group reserve the right to effect at any time, without prior notice, those alterations to
parts, fittings, and accessory equipment which they may deem necessary for any reason whatsoever. JET® branded
products are not sold in Canada by WMH Tool Group.

3
Table of Contents
Warranty and Service.................................................................................................................................... 2
Table of Contents.......................................................................................................................................... 3
Ordering Replacement Parts..................................................................................................................... 4
Warnings ....................................................................................................................................................... 5
Kickback Prevention...................................................................................................................................... 7
Protection Tips from Kickback....................................................................................................................... 7
Specifications ................................................................................................................................................ 7
Contents of the Shipping Containers ............................................................................................................ 8
Accessory Package Box............................................................................................................................ 8
Sliding Table Box (optional accessory) ..................................................................................................... 8
Left Wing Extension Box (optional accessory).......................................................................................... 9
XACTA Fence II Homeshop 30/52 ............................................................................................................ 9
Assembly..................................................................................................................................................... 10
Unpacking and Clean-Up ........................................................................................................................ 10
Installation Requirements........................................................................................................................ 10
Right Extension Wing Assembly ............................................................................................................. 10
Handwheel Assembly.............................................................................................................................. 10
Mounting Rails......................................................................................................................................... 11
Mounting Left Extension Wing with Miter Slot......................................................................................... 11
Miter Gauge for Left Extension Wing ...................................................................................................... 12
Mounting Sliding Table............................................................................................................................ 12
Sliding Table Miter Gauge....................................................................................................................... 14
Mounting the Switch Assembly ............................................................................................................... 15
On-Off Switch Padlock ............................................................................................................................ 15
Wooden Extension Table............................................................................................................................ 15
Installation ............................................................................................................................................... 15
Guide Tube.............................................................................................................................................. 16
XACTA Fence.......................................................................................................................................... 17
Fence Adjustments.................................................................................................................................. 17
Level with the Saw Table Adjustment.................................................................................................. 17
Parallel to the Miter Slot Adjustment.................................................................................................... 18
Clamping Pressure Adjustment ........................................................................................................... 18
90°to the Table Adjustment ................................................................................................................ 18
Initial Cursor Pre-adjustment ............................................................................................................... 18
Installing the Blade .................................................................................................................................. 19
Guide Tube Scale Application ................................................................................................................. 19
Blade Guard Assembly............................................................................................................................ 20
Table Insert Adjustment........................................................................................................................... 20
Aligning Blade Guard and Splitter ........................................................................................................... 20
Hooks for Miter Gauge and Fence .......................................................................................................... 21
Blade Raising and Tilting Mechanism ..................................................................................................... 21
Electrical Connections................................................................................................................................. 21
Grounding Instructions ............................................................................................................................ 22
115 Volt Operation................................................................................................................................... 22
230 Volt Operation................................................................................................................................... 22
Adjustments ................................................................................................................................................ 23
Blade Alignment ...................................................................................................................................... 23
XACTA Fence Cursor Adjustment........................................................................................................... 23
Adjusting 45°and 90°Positive Stops ...................................................................................................... 24
Wear Adjustment in Raising Mechanism................................................................................................. 25
Wear Adjustment in Tilting Mechanism ................................................................................................... 25
Changing Poly V-Belt .............................................................................................................................. 26
Changing the Transfer Belt ..................................................................................................................... 26
Maintenance................................................................................................................................................ 27
General Maintenance .............................................................................................................................. 27
Blades and Accessories .......................................................................................................................... 27

4
Troubleshooting .......................................................................................................................................... 28
Parts ............................................................................................................................................................ 29
XACTA Fence II Homeshop 30/52 Fence Assembly .............................................................................. 29
Cabinet Assembly.................................................................................................................................... 30
Guard Assembly ...................................................................................................................................... 31
Table Assembly ....................................................................................................................................... 32
Sliding Table Assembly ........................................................................................................................... 35
Rail Assembly.......................................................................................................................................... 38
Motor & Trunnion Parts List..................................................................................................................... 40
Wiring Diagrams.......................................................................................................................................... 43
Ordering Replacement Parts
To order parts or reach our service department, call 1-800-274-6848 between 7:30am and 5:30pm (CST),
Monday through Friday. Having the Model Number and Serial Number of your machine available when
you call will allow us to serve you quickly and accurately.

5
Warnings
1. Read and understand the entire owners manual before attempting assembly or operation.
2. Read and understand the warnings posted on the machine and in this manual. Failure to comply with
all of these warnings may cause serious injury.
3. Replace the warning labels if they become obscured or removed.
4. This Table Saw is designed and intended for use by properly trained and experienced personnel only.
If you are not familiar with the proper and safe operation of a Table Saw, do not use until proper
training and knowledge has been obtained.
5. Do not use this Table Saw for other than its intended use. If used for other purposes, WMH Tool
Group disclaims any real or implied warranty and holds itself harmless from any injury that may result
from that use.
6. Always wear approved safety glasses/face shields while using this Table Saw. Everyday eyeglasses
only have impact resistant lenses; they are not safety glasses.
7. Before operating this Table Saw, remove tie, rings, watches and other jewelry, and roll sleeves up
past the elbows. Remove all loose clothing and confine long hair. Non-slip footwear or anti-skid floor
strips are recommended. Do not wear gloves.
8. Always use the blade guard on all ''through-sawing'' operations. A through-sawing operation is one in
which the blade cuts completely through the workpiece.
9. Kickback occurs when the workpiece is thrown towards the operator at a high rate of speed. If you do
not have a clear understanding of kickback and how it occurs, DO NOT operate this table saw!
10. Wear ear protectors (plugs or muffs) during extended periods of operation.
11. Some dust created by power sanding, sawing, grinding, drilling and other construction activities
contain chemicals known to cause cancer, birth defects or other reproductive harm. Some examples
of these chemicals are:
•Lead from lead based paint.
•Crystalline silica from bricks, cement and other masonry products.
•Arsenic and chromium from chemically treated lumber.
12. Your risk of exposure varies, depending on how often you do this type of work. To reduce your
exposure to these chemicals, work in a well-ventilated area and work with approved safety
equipment, such as face or dust masks that are specifically designed to filter out microscopic
particles.
13. Do not operate this machine while tired or under the influence of drugs, alcohol or any medication.
14. Make certain the switch is in the OFF position before connecting the machine to the power supply.
15. Make certain the machine is properly grounded.
16. Make all machine adjustments or maintenance with the machine unplugged from the power source.
17. Remove adjusting keys and wrenches. Form a habit of checking to see that keys and adjusting
wrenches are removed from the machine before turning it on.
18. Keep safety guards in place at all times when the machine is in use. If removed for maintenance
purposes, use extreme caution and replace the guards immediately.
19. Make sure the Table Saw is firmly secured to the floor or bench before use.
20. Check damaged parts. Before further use of the machine, a guard or other part that is damaged
should be carefully checked to determine that it will operate properly and perform its intended
function. Check for alignment of moving parts, binding of moving parts, breakage of parts, mounting
and any other conditions that may affect its operation. A guard or other part that is damaged should
be properly repaired or replaced.
